PRODUCT NO.
FFC09M5CW4
MARKET
North America
WIRING DIAGRAM - # 216372500
OWNER'S GUIDE - # 216768600
SERVICE DATA SHEET - # 216372500
ELECTROLUX HOME PRODUCTS N. AMERICA
P.O BOX 212378, AUGUSTA , GA 30917
BASE MODEL NO.
SERIES
FFC09M5CW
134A
Publication No.
5995349734
-EN/SERVICE /KSC
FACTORY PARTS CATALOG
COLOR
white
010213
365
©2001 White Consolidated Industries, Inc.
All rights reserved
FREEZER
VOLTS
115
FREEZER
Model number
FFC09M5CW
Advertisement
Related Manuals for Frigidaire FFC09M5CW
Summary of Contents for Frigidaire FFC09M5CW
- Page 1 PRODUCT NO. BASE MODEL NO. FFC09M5CW4 FFC09M5CW MARKET North America WIRING DIAGRAM - # 216372500 OWNER’S GUIDE - # 216768600 SERVICE DATA SHEET - # 216372500 ELECTROLUX HOME PRODUCTS N. AMERICA P.O BOX 212378, AUGUSTA , GA 30917 FACTORY PARTS CATALOG...
- Page 2 Publication No. FFC09M5CW 5995349734 DOOR 02/01...
- Page 3 POS. NO 44 # 53 # # = Fast-moving Parts * = Non-Illustrated Parts FFC09M5CW DOOR PART NO DESCRIPTION 216481001 Gasket-door,white 5303925107 Lock Assy 216702900 Key,lock 216067400 Panel-inner door/lid,white 216141101 Plug button,white 216117919 Panel-outer lid,white 216208100 Bezel-nameplate 216683000 Insert-bezel 216140200...
- Page 4 Publication No. FFC09M5CW 5995349734 CABINET 02/01...
- Page 5 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFC09M5CW CABINET PART NO DESCRIPTION 216117700 Catch-lock 216502600 Plug-drain,interior ,interior 216073900 Plug-drain,exterior 216117500 Breaker-hinge side,white 216117600 Breaker-lock side 216105600 Breaker-ends,white 216707200 Knob-control 216714500 Control-temperature 216337700 Screw,hex washer head ,10-24 x 0.500...
- Page 6 Publication No. FFC09M5CW 5995349734 SYSTEM 02/01...
- Page 7 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FFC09M5CW SYSTEM PART NO DESCRIPTION 5300120781 Condenser 216634500 Drier-filter 216552700 Harness,electrical 216056400 Clip-spring mtg 5308002681 Grommet,compressor 216510900 Compressor,R134a ,w/electricals 216511200 Starter 216100113 Overload Protector 216347800 Cover terminal,cover-comp term 216707700 Screw,8-18 X ½...
