PRODUCT NO.
BASE MODEL NO.
FAC088L7A1
FAC088L7A
MARKET
USA
WIRING DIAGRAM - # 309107703
OWNER'S GUIDE - # 309000823
ENERGY GUIDE - # 309367423
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
VOLTS
BTU-COOLING
115
8000 BTU
Publication No.
5995367728
020307
©2002 Electrolux Home Products, Inc.
-EN/SERVICE /BLT
All rights reserved
345
ROOM AIR CONDITIONER
Model No.
FAC088L7A1
Advertisement
Table of Contents
Related Manuals for Frigidaire FAC088L7A1
Summary of Contents for Frigidaire FAC088L7A1
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAC088L7A1 FAC088L7A MARKET WIRING DIAGRAM - # 309107703 OWNER’S GUIDE - # 309000823 ENERGY GUIDE - # 309367423 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER VOLTS BTU-COOLING... -
Page 2: Cabinet Front And Wrapper
Publication No. FAC088L7A1 5995367728 CABINET FRONT AND WRAPPER 03/02... - Page 3 Filter-air,7.12 x 17.31 ,no frame 309640104 Front-cabinet,4 way ,complete assy 3015312 Screw,8-18AB x 0.500 309342904 Dial Plate 309306810 Knob-control,rotary 5303001775 Spacer,dial plate 309328603 Door,fresh air vent 309638201 Handle,vent door 309330201 Detent-vent 309646301 Panel,cabinet front 309646401 Frame,cabinet front 309367423 Energy Guide,FAC088L7A1 Publication No. 5995367728 03/02...
- Page 4 Publication No. FAC088L7A1 5995367728 CONTROLS 03/02...
- Page 5 POS. NO 13 # 17 # # = Fast-moving Parts * = Non-Illustrated Parts FAC088L7A1 CONTROLS PART NO DESCRIPTION 309643802 Box-control 5303323284 Switch,selector ,7 posn,3 speed 5304402838 Control,temperature 309643702 Bulkhead 309111201 Grommet,wire protector 309101202 Clip,retainer ,temp sensor ,(2) 5304426336 Capacitor,250 V ,35+10 mfd 3015312 Screw,8-18AB x 0.500...
-
Page 6: Air Handling Parts
Publication No. FAC088L7A1 5995367728 AIR HANDLING PARTS 03/02... - Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAC088L7A1 AIR HANDLING PARTS PART NO DESCRIPTION 309624502 Fan Blade,with clamp 3202975 Screw,10-16AB x 0.72 ,square drive 309643901 Housing,fan shroud 5303303759 Seal,bottom 5304421913 Seal,top 08007481 Nut,Keps ,motor mtg ,(4)
-
Page 8: Compressor Parts
Publication No. FAC088L7A1 5995367728 COMPRESSOR PARTS 03/02... - Page 9 POS. NO 10 # 11 # 12 # 13 # 16 # 17 # 03/02 COMPRESSOR PARTS PART NO DESCRIPTION 309616919 Compressor 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 3201668 Gasket,terminal cover 5304405245 Cover,compr terminal 5303317553 Overload Protector 3201670 Nut,terminal cover 5303317601 Start Assist Kit,compressor...
- Page 10 Publication No. FAC088L7A1 5995367728 WINDOW MOUNTING PARTS 03/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC088L7A1 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 309644901 Frame Extension Kit,accordian ,LH & RH ,includes 4 & 14 5304414120 Frame,cab extension ,LH 08016226 Seal,top rail/cab...
-
Page 12: Wiring Diagram
Publication No. FAC088L7A1 5995367728 WIRING DIAGRAM 03/02...
