PRODUCT NO.
BASE MODEL NO.
FAC065L7A2
FAC065L7A
MARKET
North America
WIRING DIAGRAM - # 309341601
OWNER'S GUIDE - # 309000825
ENERGY GUIDE - # 309367484
ELECTROLUX HOME PRODUCTS, INC
P.O.BOX 212378, AUGUSTA, GA 30917
FACTORY PARTS CATALOG
ROOM AIR CONDITIONER
VOLTS
BTU-COOLING
115
6100 BTU
Publication No.
5995371639
020508
©2002 Electrolux Home Products, Inc.
-EN/SERVICE /BLT
All rights reserved
345
ROOM AIR CONDITIONER
Model No.
FAC065L7A
Advertisement
Table of Contents
Related Manuals for Frigidaire FAC065L7A2
Summary of Contents for Frigidaire FAC065L7A2
-
Page 1: Room Air Conditioner
PRODUCT NO. BASE MODEL NO. FAC065L7A2 FAC065L7A MARKET North America WIRING DIAGRAM - # 309341601 OWNER’S GUIDE - # 309000825 ENERGY GUIDE - # 309367484 ELECTROLUX HOME PRODUCTS, INC P.O.BOX 212378, AUGUSTA, GA 30917 FACTORY PARTS CATALOG ROOM AIR CONDITIONER... -
Page 2: Cabinet Front And Wrapper
Publication No. FAC065L7A2 5995371639 CABINET FRONT AND WRAPPER 05/02... - Page 3 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC065L7A2 CABINET FRONT AND WRAPPER PART NO DESCRIPTION 309643602 Cabinet 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs 309640204 Louver Assy,Includes 8 & 9 309639302 Louver,horizontal 309647201 Louver,vertical ,with link 309343501 Filter-air,7.12 x 17.31 ,no frame...
- Page 4 Publication No. FAC065L7A2 5995371639 CONTROLS 05/02...
- Page 5 POS. NO 13 # 17 # 72 # # = Fast-moving Parts * = Non-Illustrated Parts FAC065L7A2 CONTROLS PART NO DESCRIPTION 309643801 Control Box 309643702 Bulkhead 309111201 Grommet,wire protector 5304413782 Holder,thermistor ,w/seal 5304426449 Capacitor,250 V ,35+5 mfd 5303285199 Screw,Ph truss hd ,8-18 x 0.38 ,grounding 309351901 Strap,capacitor mtg.
-
Page 6: Air Handling Parts
Publication No. FAC065L7A2 5995371639 AIR HANDLING PARTS 05/02... - Page 7 POS. NO 11 # # = Fast-moving Parts * = Non-Illustrated Parts FAC065L7A2 AIR HANDLING PARTS PART NO DESCRIPTION 309646202 Fan Blade,with clamp 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs 3202975 Screw,10-16AB x 0.72 ,square drive 309643901 Housing,fan shroud 5303303759...
-
Page 8: Compressor Parts
Publication No. FAC065L7A2 5995371639 COMPRESSOR PARTS 05/02... - Page 9 POS. NO 10 # 11 # 12 # 13 # 16 # 17 # 05/02 COMPRESSOR PARTS PART NO DESCRIPTION 309616921 Compressor 5303303691 Screw,truss head ,8-18AB x 0.375 ,w/nibs 5303283877 Grommet,compressor mtg ,(3) 5308006948 Nut,compressor mtg ,(3) 3201668 Gasket,terminal cover 5304405245 Cover,compr terminal 5303317553...
- Page 10 Publication No. FAC065L7A2 5995371639 WINDOW MOUNTING PARTS 05/02...
- Page 11 POS. NO # = Fast-moving Parts * = Non-Illustrated Parts FAC065L7A2 WINDOW MOUNTING PARTS PART NO DESCRIPTION 5304407729 Seal,window stuffer 5303211056 Bracket,sash lock 309644901 Frame Extension Kit,accordian ,LH & RH ,includes 4 & 14 5304413847 Extension-frame,LH ,w/o accordian 08016226 Seal,top rail/cab...
-
Page 12: Wiring Diagram
Publication No. FAC065L7A2 5995371639 WIRING DIAGRAM 05/02...
