Display panel

IMPORTANT:
any old parts. Return all old parts to HP for warranty processing.
CAUTION:
the correct cable may result in panel failure.
To remove the display panel:
1. Prepare the computer for disassembly (see
2. Remove the rear port cover (see
3. Remove the stand (see
4. Remove the access panel (see
5. Remove the optical drive (see
6. Remove the system board shield (see
7. Remove the top trim (see
8. Remove the right trim (see
9. Remove the bottom panel and trim (see
10. Non-touch models: To separate the bezel from the main frame, remove the two Torx screws that secure
the bezel to the frame.
56 Chapter 4 Removal and Replacement Procedures
Install the new display panel together with all other parts in the replacement kit. Do not reuse
it is very important to use the exact cable that shipped with the replacement panel. Failure to use
Attaching and removing a stand on page
Access panel on page
Replacing the optical drive on page
Top trim on page
Right trim on page
Preparing to disassemble the computer on page
Rear port cover on page 23).
24).
System board (EMI) shield on page
48).
51).
Feet, bottom panel and trim on page
20).
30).
32).
53).
19).
