ORDER NO. ITD0509049AE
Wide Plasma Display
TH-42PWD8WK / TH-42PWD8WS / TH-37PWD8WK / TH-
37PWD8WS
GP8D Chassis
Please file and use this manual together with the service manual for
Model No.TH-42PWD8BK, ORDER NO. ITD0506035CE.
2005 Matsushita Electric Industrial Co., Ltd. All rights reserved.
Unauthorized copying and distribution is a violation of law.
1. Difference point
1.1. TH-42PWD8WK/WS
1

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TH-42PWD8WK

Summary of Contents for Panasonic TH-42PWD8WK

  • Page 1 ORDER NO. ITD0509049AE Wide Plasma Display TH-42PWD8WK / TH-42PWD8WS / TH-37PWD8WK / TH- 37PWD8WS GP8D Chassis Please file and use this manual together with the service manual for Model No.TH-42PWD8BK, ORDER NO. ITD0506035CE. 2005 Matsushita Electric Industrial Co., Ltd. All rights reserved.
  • Page 2 Ref. No. Parts No. Parts Name & Description Remarks TH-42PWD8BK TH-42PWD8WK/ EUR7636070R EUR7636090R REMOTE CONTROLER - - - - - K2CK3DH00017 AC CORD Obique flat blade - - - - - K2CN3DH00006 AC CORD Round pin - - - - -...
  • Page 3 Ref. No. Parts No. Parts Name & Description Remarks TH-37PWD8BK TH-37PWD8WK/ EUR7636070R EUR7636090R REMOTE CONTROLER - - - - - K2CK3DH00017 AC CORD Obique flat blade - - - - - K2CN3DH00006 AC CORD Round pin - - - - - K2CT3DH00018 AC CORD Rectangular blade TBXA46601...
  • Page 4 ORDER NO. ITD0506035CE D10 Canada: B07 Progressive Wide Plasma Display TH-37PWD8BK TH-37PWD8BS TH-37PWD8EK TH-37PWD8ES TH-37PWD8GK TH-37PWD8GS TH-37PWD8UK TH-42PWD8BK TH-42PWD8BS TH-42PWD8EK TH-42PWD8ES TH-42PWD8GK TH-42PWD8GS TH-42PWD8UK GP8D Chassis...

  • Page 5: Specifications

    SPECIFICATIONS Specifications Power Source (UK, GK/S) 120 V AC, 50/60 Hz (GK/GS/UK) Power Source (EK/S, BK/ 220-240 V AC, 50/60 Hz (EK/ES/BK/BS) Power Consumption (UK, GK/S) Maximum 225 W (37PWD8GK/GS/UK) 275 W (42PWD8GK/GS/UK) Stand-by condition Save OFF 1.0 W, Save ON 0.7 W (GK/GS /UK) Power off condition 0.05 W (GK/GS/UK)
  • Page 6 Operating condition Temperatuer 32 °F - 104 °F (0 °C - 40 °C) Humidity 20 % - 80 % Applicable signals Color System NTSC, PAL, PAL60, SECAM, Modified NTSC Scanning format 525 (480) / 60i 60p, 625 (575) / 50i 50p, 750 (720) / 60p 50p, 1125 (1080) / 60i 50i 24p 25p 30p 24sF ..

  • Page 7: Applicable Signals

    Dimensions ( W × H × D ) 36.2” (920 mm) × 21.7” (550 mm) × 3.5” 40.2” (1,020 mm) × 24” (610 mm) × 3.5” (89 mm) (89 mm) (exclusive of protruding portion) (37 (exclusive of protruding portion) (42 inch) inch) Mass (Weight) (UK)

  • Page 9: Safety Precautions

    2. Safety Precautions 2.1. General Guidelines 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.

  • Page 10: Leakage Current Hot Check

    2.1.2. Leakage Current Hot Check (See Figure 1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check. 2. Connect a 1.5k , 10 watts resistor, in parallel with a 0.15 F capacitors, between each exposed metallic part on the set and a good earth ground such as a water pipe, as shown in Figure...

  • Page 11: About Lead Free Solder (Pbf)

    4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD protected)" can generate electrical charge sufficient to damage ES devices. 5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices. 6.
  • Page 12 PCBs manufactured using lead free solder will have the PbF within a leaf Symbol stamped on the back of PCB. Caution Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher. Please use a high temperature soldering iron and set it to 700 ±...

  • Page 13: Pcb Structure Sheet Of Gp8D Chassis

    5. PCB Structure sheet of GP8D chassis Board Name Function Remarks Digital Signal Processor Slot Interface (Audio/Video/ Sync input Switch), SYNC processor, Audio processor, Speaker out amplifier, DC-DC converter Sustain Out Scan out Sustain connection (Upper) Sustain connection (Lower) Data Drive (Lower Right) Data Drive (Lower Left) Speaker terminal Power switch...

  • Page 14: Service Hint

    1. Recommend PCB's for initial service for GP8D chassis. 2. For TH-37/42PWD8UK/BK/BS/EK/ES 3. For TH-37/42PWD8UK 6. Service Hint...
  • Page 15 Note: Extension cable kit for Slot Board is supplied as service fixtures and tools. (Part No. TZSC0704) J13 Slot is not equiped for 37” model. 7. P.C.Board and Plasma panel replacement Prior to the replacement of Plasma panel, place the unit on the pedestal stand and remove the front frame.

  • Page 16: Removal Of The Slot Block

    7.2. Removal of the Slot block Caution: To remove P.C.B., wait 1 minute after power was off for discharge from electrolysis capacitors. 1. Remove the couplers (J1, J2, J3, J4, J5, J6, J7, J8, J10, J15). 2. Release the cable from the clampers at left side of the slot block. 3.

  • Page 17: Removal Of The J-Board

    7.3. Removal of the J-Board 1. Unscrew the screws (×8 ), release J14 from the HX-Board and remove the J- Board.

  • Page 18: Removal Of The Hx-Board

    7.4. Removal of the HX-Board 1. Unscrew the screws (×6 ) and remove the slot case.
  • Page 19 2. Unscrew the screws (×4 ). 3. Unscrew the screws (×1 ) and remove the HX-Board.

  • Page 20: Removal Of The P-Board

    7.5. Removal of the P-Board 1. Remove the couplers (P2, P5, P7, P9, P10, P11, P12, P23 and P25). 2. Unscrew the screws (×5 ) and remove the P-Board.

  • Page 21: Removal Of The D-Board

    7.6. Removal of the D-Board 1. Disconnect the couplers (D1, D3, D5, D20, D25) and the flexible cables (D31, D32). 2. Unscrew the screws (×5 ) and remove the D-Board.

  • Page 22: Removal Of The Ac-Inlet

    7.7. Removal of the AC-Inlet 1. Remove the coupler (P9) on the P-Board and release the cables from the clamper. 2. Unscrew the screws (×2 ) and remove the AC inlet.

  • Page 23: Removal Of The H3-Board

    7.8. Removal of the H3-Board 1. Unscrew the screws (×2 ), and remove the H3-Board with the Bracket (right & left).
  • Page 24 2. Remove the couplers (H37). 3. Unscrew the screws (×6 ), and remove the H3-Board (right & left).

  • Page 25: Removal Of The S1-Board

    7.9. Removal of the S1-Board 1. Release the cable from the clamper. 2. Unscrew the screws (×2 ) and remove the S1-Board with the bracket. 3. Remove a coupler (S34), unscrew a screw (×1 ) and remove the S1-Board.

  • Page 26: Removal Of The Su-Board

    7.10. Removal of the SU-Board 1. Unscrew the screws (×2 ). 2. Slide the SU-Board to the left and disconnect from the couplers (SC41) on the SC- Board. 3. Remove the coupler (SU45).
  • Page 27 4. Remove the flexible cables (SU1, SU2, SU3) connected to the SU-Board from the plasma panel, and remove the SU-Board.

  • Page 28: Removal Of The Sd-Board

    7.11. Removal of the SD-Board...
  • Page 29 1. Unscrew the screws (×2 ). 2. Slide the SD-Board to the left and disconnect from the couplers (SC42) on the SC- Board. 3. Remove the coupler (SD46).
  • Page 30 4. Remove the flexible cables (SD1, SD2, SD3) connected to the SD-Board from the plasma panel, and remove the SD-Board.

  • Page 32: Removal Of The Sc-Board

    7.12. Removal of the SC-Board 1. Remove the couplers (SC2, SC20, SC23, SC45, SC46). 2. Unscrew the screws (×6 ) and remove the SC-Board.

  • Page 33: Removal Of The Ss-Board

    7.13. Removal of the SS-Board 1. Remove the couplers (SS11, SS12, SS23, SS34). 2. Remove the flexible cables (SS41, SS42, SS43, SS44). 3. Unscrew the screws (×6 ), and remove the SS-Board.

  • Page 34: Removal Of The C1-Board

    7.14. Removal of the C1-Board 1. Unscrew the flexible cable holder fastening screws (×6 ). 2. Remove the flexible cables (CB1, CB2, CB3). 3. Remove a flexible cable (C11), a coupler (C12) and release the speaker cables...

  • Page 35: Removal Of The C2-Board

    from a clamper (×1) on the C1-Board. 4. Unscrew the screws (×3 ), and remove the C1-Board. 7.15. Removal of the C2-Board 1. Unscrew the flexible cable holder fastening screws (×8 ). 2. Remove the flexible cables (CB4, CB5, CB6, CB7). 3.

  • Page 36: Removal Of The Front Frame (Glass)

    7.16. Removal of the Front frame (glass) 1. Remove the screws (×2 ) fixing the front frame and the plasma panel.
  • Page 37 2. Confirm the S1-Board has been removed and the cable to the V1-Board and V2- Board released. 3. For leaving the front frame from the plasma panel, pull the bottom of the front frame to forward, lift up, and remove.

  • Page 39: Removal Of The V1-Board And The V2-Board

    7.17. Removal of the V1-Board and the V2-Board 1. Lay down the front frame on the flat surface of the table (covered by a soft cloth not to damage the surface.) 2. Remove the couplers (V2 on the V1-Board and V15 on the V2-Board). 3.

  • Page 40: Replacement Of The Plasma Panel

    7.19. Replacement of the plasma panel 1. Place the new plasma panel (finished) on the flat surface of the table (covered by a soft cloth), with the plasma panel surface facing downward. 2. Fit the stand brackets (left, right.) fasten 4 screws each on the new plasma panel. 3.

  • Page 42: Wiring For 42 Inch Model

    8.2. Wiring for 42 inch model...

  • Page 44: Adjustment Procedure

    9. Adjustment Procedure 9.1. Driver Set-up 9.1.1. Item / Preparation 1. Input a white signal of the RGB signal generator. 2. Set the picture controls: - Picture menu: Standard Color temperature: Middle Picture: 25 Aspect: Full Caution 1. First perform Vsus adjustment. 2.

  • Page 45: Initialization Pulse Adjust

    Name Test Voltage Volume Remarks Point Vsus TPVSUS Vsus ± 1V R628 (P) (SS) TPVE Ve ± 2V VR6074 (SS) (SS) Vset TPVSET 232V ± 7V Fixed (SC) TPVAD -90V ± 1V VR6477 (SC) (SC) Vscn TPVSCN Vad+120V Fixed (SC) ±...

  • Page 46: Printed Circuit Board) Exchange

    1. Input the White signal to plasma video input. 2. Set the picture controls as follows. - Picture menu: Standard - Color temperature : Middle - Picture : 25 3. Connect Oscilloscope to TPSC1 (T1) and check for 15±10 Sec. 4.

  • Page 47: Quick Adjustment After P.c.b. Exchange

    1. To remove P.C.B. , wait 1 minute after power was off for discharge from electrolysis capacitors. 9.3.2. Quick adjustment after P.C.B. exchange P.C.B. Name Test Point Voltage Volume Remarks P Board Vsus TPVSUS (SS) Vsus ± 2V R628 (P) TPVDA (SS) 67V ±...

  • Page 48: Test Point Location

    9.5. Test Point Location...

  • Page 49: Service Mode

    10. Service mode 10.1. CAT (computer Aided Test) mode...

  • Page 50: Iic Mode

    To exit the CAT mode, access the ID mode and switch off the main power. 10.1.1. IIC mode Select the IIC mode by Up/Down button on the remote control at the front page of CAT mode then press the Action button on the remote control.
  • Page 51 Subject and item are mentioned on page 24. To exit the IIC mode, press the R button on the remote control.
  • Page 53 10.1.2. CD mode Select the CD mode by Up/Down button on the remote control at the front page of CAT mode then press the Mute button on the remote control more than 5 sec. Micom software version (IC9703), this version can be upgrade by 1.

  • Page 54: Iic Mode Structure (Following Items Value Is Sample Data.)

    To exit the CD mode, press the R button on the remote control. 10.1.3. SD mode Select the SD mode by Up/Down button on the remote control at the front page of CAT mode then press the Action button on the remote control. To exit the SD mode, press the R button on the remote control.
  • Page 55 11. Alignment...

  • Page 56: Pc/Rgb Panel White Balance

    11.1. PC/RGB panel white balance 11.2. HD/ 525ip /625ip panel white balance 12. Trouble shooting guide 12.1. Self Check 12.1.1. Display Indication 1. Self-check is used to automatically check the bus line controlled circuit of the Plasma display. 2. To get into the Self-check mode, press the volume down button on the customer controls at the front of the set, at the same time pressing the OFF-TIMER button on the remote control, and the screen will show :- If the CCU ports have been checked and found to be incorrect...

  • Page 57: Power Led Blinking Timing Chart

    12.1.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinkes of the Power LED on the front panel of the unit.
  • Page 58 12.2. No Power [First check point] There are following 3 states of No Power indication by power LED. 1. No lit 2. Green is lit then turns red blinking a few seconds later. 3. Only red is lit. 1. No lit...

  • Page 59: Local Screen Failure

    12.3. No Picture 12.4. Local screen failure Plasma display may have local area failure on the screen. Fig - 1 is the possible defect P.C.B. for each local area.

  • Page 60: Option Setting

    Fig - 1 13. Option Setting Hidden Option Menu for GP8D series GP8D chassis series have special function and operation setting facility called Option Menu. This Option Menu is useful for special function required customers. This should be set at the installation stage. The end user could not set or change these because of hidden On screen menu.

  • Page 61: Circuit Board Layout

    Option menus default setting Contents Off-timer function Enable Off-timer operation Enable/Disable. On Screen display Enable/Disable to display input mode indication after power on and no signal indication. Initial INPUT Sets the initial input mode when the power is turned on . Allow input mode selection while power is on.
  • Page 62 14.1. P-Board 14.2. HA-Board 14.3. HB-Board 14.4. HX-Board (37 inch) 14.5. HX-Board (42 inch) 14.6. J-Board (37 inch)
  • Page 63 14.7. J-Board (42 inch) 14.8. D-Board 14.9. C1-Board (37 inch) 14.10. C1-Board (42 inch) 14.11. C2-Board (37 inch) 14.12. C2-Board (42 inch) 14.13. SC-Board...
  • Page 64 14.14. SU-Board (37 inch) 14.15. SU-Board (42 inch) 14.16. SD-Board (37 inch) 14.17. SD-Board (42 inch) 14.18. SS-Board 14.19. H3, S1, V1 and V2-Board...

  • Page 65: Block And Schematic Diagrams

    15. Block and Schematic Diagrams 15.1. Schematic Diagram Notes...
  • Page 69 15.2. Main Block Diagram 15.3. P-Board Block Diagram 15.4. P-Board (1 of 6) Schematic Diagram 15.5. P-Board (2 of 6) Schematic Diagram 15.6. P-Board (3 of 6) Schematic Diagram 15.7. P-Board (4 of 6) Schematic Diagram 15.8. P-Board (5 of 6) Schematic Diagram 15.9.
  • Page 70 15.10. HA-Board Block and Schematic Diagram 15.11. HB-Board Block Diagram 15.12. HB-Board (1 of 2) Schematic Diagram 15.13. HB-Board (2 of 2) Schematic Diagram 15.14. HX-Board Block Diagram 15.15. HX-Board Schematic Diagram 15.16. S1, V1 and V2-Board Block Diagram and Schematic Diagram...
  • Page 71 15.17. J-Board (1 of 2) and H3-Board Block Diagram 15.18. J-Board (2 of 2) Block Diagram 15.19. J-Board (1 of 4) Schematic Diagram (37 inch) 15.20. J-Board (2 of 4) Schematic Diagram (37 inch) 15.21. J-Board (3 of 4) Schematic Diagram (37 inch) 15.22.
  • Page 72 15.25. J-Board (3 of 4) Schematic Diagram (42 inch) 15.26. J-Board (4 of 4) Schematic Diagram (42 inch) 15.27. D-Board Block Diagram 15.28. D-Board (1 of 12) Schematic Diagram 15.29. D-Board (2 of 12) Schematic Diagram 15.30. D-Board (3 of 12) Schematic Diagram 15.31.
  • Page 73 15.32. D-Board (5 of 12) Schematic Diagram 15.33. D-Board (6 of 12) Schematic Diagram 15.34. D-Board (7 of 12) Schematic Diagram 15.35. D-Board (8 of 12) Schematic Diagram 15.36. D-Board (9 of 12) Schematic Diagram 15.37. D-Board (10 of 12) Schematic Diagram 15.38.
  • Page 74 15.40. C1 and C2-Board Block Diagram 15.41. C1-Board (1 of 2) Schematic Diagram (37 inch) 15.42. C1-Board (2 of 2) Schematic Diagram (37 inch) 15.43. C1-Board (1 of 2) Schematic Diagram (42 inch) 15.44. C1-Board (2 of 2) Schematic Diagram (42 inch) 15.45.
  • Page 75 15.47. C2-Board (1 of 2) Schematic Diagram (42 inch) 15.48. C2-Board (2 of 2) Schematic Diagram (42 inch) 15.49. SC-Board Block Diagram 15.50. SC-Board (1 of 2) Schematic Diagram 15.51. SC-Board (2 of 2) Schematic Diagram 15.52. SU-Board Block Diagram 15.53.

  • Page 76: Parts Location

    15.55. SD-Board Block Diagram 15.56. SD-Board Schematic Diagram (37 inch) 15.57. SD-Board Schematic Diagram (42 inch) 15.58. SS-Board Block Diagram 15.59. SS-Board Schematic Diagram 16. Parts Location 16.1. Parts Location (1) 16.2. Parts Location (2)

  • Page 77: Packing Exploded Views

    17. Packing Exploded Views 17.1. Packing Exploded Views (1) 17.2. Packing Exploded Views (2) 17.3. Packing Exploded Views (3) 18. Mechanical Replacement Parts List Note: All parts except parts mentioned [PAVCCZ] in the Remarks column are supplied by AVC-SPC. Parts mentioned [PAVCCZ] are supplied by PAVCCZ.
  • Page 78 K2CN3DH00006 AC CORD TH-37/42PWD8EK/ES K2CT3DH00018 AC CORD TH-37/42PWD8BK/BS MD37S08A1J PLASMA DISPLAY PANEL TH-37PWD8 SERIES MD42S08A1J PLASMA DISPLAY PANEL TH-42PWD8 SERIES TBMA162 PANASONIC BADGE TBXA46601 POWER BUTTON TBXA46701 5KEY BUTTON TESD031 SPRING THEA068N SCREW THEL0239 SCREW (SLOT5~METAL4~COVER3) TH-37PWD8 SERIES THEL0239 SCREW (SLOT5~METAL4~COVER3)
  • Page 79 Ref. No. Part No. Part Name & Description Remarks TMM17434-2 CLAMPER TMM17499 CLAMPER TMM25401 CLAMPER TMM6463-1 CLAMPER TMM6496-1 CLAMPER TMM7464-2 CLAMPER TH-37/42PWD8BK/BS/EK/ES TMM7464-2 CLAMPER TH-37/42PWD8GK/GS/UK TMM7468-1 CLAMPER TH-42PWD8 SERIES TMME047 CLAMPER TH-37/42PWD8BK/BS/EK/ES TMME047 CLAMPER TH-37/42PWD8GK/GS/UK TMME061 CLAMPER TMME185 CLAMPER TMME187 CLAMPER TMME199 CLAMPER...
  • Page 80 Ref. No. Part No. Part Name & Description Remarks TPD0E9007 TOP PAD TH-37PWD8BK/BS/EK/ES PAVCCZ TPD0E9008 TOP PAD TH-42PWD8BK/BS/EK/ES PAVCCZ TPDF0737 ACCESSORIES BOX TH-37/42PWD8GK/GS/UK TPDF1197 ACCESSORIES BOX TH-37/42PWD8BK/BS/EK/ES PAVCCZ TPDF0905 TOP PAD(UPPER) TH-42PWD8GK/GS/UK TPE0E4010 PROTECT COVER TH-37/42PWD8BK/BS/EK/ES PAVCCZ TPEH007-3 PROTECT COVER TH-37PWD8GK/GS/UK TPEH170 PROTECT COVER...

  • Page 81: Replacement Parts List Notes

    Ref. No. Part No. Part Name & Description Remarks TTUA1231 REAR COVER TH-42PWD8ES PAVCCZ TTUA1232 REAR COVER TH-42PWD8BK PAVCCZ TTUA1233 REAR COVER TH-42PWD8BS PAVCCZ TTUA1234 REAR COVER TH-37PWD8EK PAVCCZ TTUA1235 REAR COVER TH-37PWD8ES PAVCCZ TTUA1236 REAR COVER TH-37PWD8BK PAVCCZ TTUA1237 REAR COVER TH-37PWD8BS PAVCCZ TXFKE010YLS...

  • Page 82: Electrical Replacement Parts List (37Inch)

    19.2. Electrical Replacement Parts List (37inch) Note: All parts except parts mentioned [PAVCCZ] in the Remarks column are supplied by AVC-SPC. Parts mentioned [PAVCCZ] are supplied by PAVCCZ.
  • Page 83 Ref. No. Part No. Part Name & Description Remarks F401.402 K5D802BNA005 TIME LAG FUSE HIGH K1MN55BA0076 55P CONNECTOR K1KA04BA0107 4P CONNECTOR K1MN55BA0076 55P CONNECTOR K1KA04BA0107 4P CONNECTOR K1KA12AA0153 12P CONNECTOR C801,02 EEVHB1C471 E 470UF, 16V C804 ECJ2XB1H222K C 2200PF, K, 50V C805 ECJ1VB1C105K C 0.01UF, K, 16V...
  • Page 84 Ref. No. Part No. Part Name & Description Remarks C1530 ECJ3XB0J106M C 10UF, M,6.3V C2350,51 TCUY1C225KBM C 2.2UF, 16V C2352,53 EEEHB1H100P C 10PF, J, 50V C2354,55 EEEHB1V470P E 47UF, 35V C2356,57 ECJ2XB1H102K C 1000PF, K, 50V C2358,59 EEEHB1H2R2R C 2.2PF, J, 50V C2360,61 ECJ2XC1H102J C 1000PF, J, 50V...
  • Page 85 Ref. No. Part No. Part Name & Description Remarks C3009 ECJ1XB1C104K C 0.1UF, Z, 16V C3009 EEEHB1C470P C 47PF, J, 16V (HB) C3010 ECJ1XB1C104K C 0.1UF, Z, 16V C3011 ECJ1XB1C104K C 0.1UF, Z, 16V C3011 ECJ1XB1C104K C 0.1UF, Z, 16V (HB) C3011 EEEHB1C470P...
  • Page 86 Ref. No. Part No. Part Name & Description Remarks C3109,10 ECJ1XB1C104K C 0.1UF, Z, 16V (HB) C3110 TCUY1C225KBM C 2.2UF, 16V C3111 ECJ1XB1C104K C 0.1UF, Z, 16V (HB) C3111 ECJ1XF1C104Z C 0.1UF, Z, 16V C3112 ECJ1XB1C104K C 0.1UF, Z, 16V (HB) C3112 ECJ1XF1C104Z...
  • Page 87 Ref. No. Part No. Part Name & Description Remarks C3179 EEEHB0G221P C 220PF, J, 4V C3180-83 ECJ1XB1C104K C 0.1UF, Z, 16V C3185 ECJ1XC1H060D C 6PF, D, 50V C3186 ECJ1XC1H470J C 47PF, J, 50V C3188 ECJ1VF1A105Z C 1UF, Z, 10V C3200 ECJ2VF1C105Z C 1UF, Z, 16V C3201...
  • Page 88 Ref. No. Part No. Part Name & Description Remarks C6011 F1L2J392A022 C 3900UF, K,6.3V C6012 F1L2J562A022 C 5600UF, K,6.3V C6016 F1L2J392A022 C 3900UF, K,6.3V C6017 F1L2J562A022 C 5600UF, K,6.3V C6021-30 ECQE2105RKB P 1UF, 250V C6031,32 F1L1E4750004 C 4.7UF, 25V C6034,35 F1L1E4750004 C 4.7UF, 25V C6037...
  • Page 89 Ref. No. Part No. Part Name & Description Remarks C6524 F1K2J471A014 C 470UF, K,6.3V C6526 ECA2EHG220 E 22UF, 250V C6529,30 F1K2J471A014 C 470UF, K,6.3V C6531,32 F1L1E4750004 C 4.7UF, 25V C6533,34 F1K2J471A014 C 470UF, K,6.3V C6541 F1L1E4750004 C 4.7UF, 25V C6543,44 F1K2J102A014 C 1000PF, C6546...
  • Page 90 Ref. No. Part No. Part Name & Description Remarks C7104-06 TCUY1C105ZFN C 1UF, 16V C7108-10 TCUY1C105ZFN C 1UF, 16V C7135 ECJ1XB1C104K C 0.1UF, Z, 16V C7137 ECJ1XB1C104K C 0.1UF, Z, 16V C7140 ECJ1XB1C104K C 0.1UF, Z, 16V C7153 ECJ1XC1H101J C 100PF, J, 50V C7161 ECJ3XB2A474K C 0.47UF, 6.3V...
  • Page 91 Ref. No. Part No. Part Name & Description Remarks C8071 EEEHB1C470P C 47PF, J, 16V C8072,73 ECJ3YF1A106Z C 10UF, Z, 10V C8080-83 ECJ1XF1C104Z C 0.1UF, Z, 16V C8084 TCUY1C105ZFN C 1UF, 16V C8100 EEEHB1C470P C 47PF, J, 16V C8101 ECJ1VF1H103Z C 0.010UF, Z, 50V C8102,03 EEEHB1C470P...
  • Page 92 Ref. No. Part No. Part Name & Description Remarks C9304 ECJ1VF1H103Z C 0.010UF, Z, 50V C9305 ECJ2FF1C475Z C 0.047UF, Z, 16V C9306 ECJ1XF1C104Z C 0.1UF, Z, 16V C9502 F1J0J106A013 C 0.010UF, K, 16V C9503,04 ECJ1XB1C104K C 0.1UF, Z, 16V C9505 ECJ1XC1H150J C 15PF, J, 50V C9506...
  • Page 93 Ref. No. Part No. Part Name & Description Remarks C9676 ECJ1VC1H080D C 8PF, C, 50V C9682,83 ECJ1XB1C104K C 0.1UF, Z, 16V C9691 ECJ1XB1C104K C 0.1UF, Z, 16V C9692 F1J0J106A013 C 0.010UF, K, 16V C9693 ECJ1XB1C104K C 0.1UF, Z, 16V C9694 F1J0J106A013 C 0.010UF, K, 16V C9696...
  • Page 94 Ref. No. Part No. Part Name & Description Remarks C9988 F1J0J106A013 C 0.010UF, K, 16V C9989 ECJ1XF1C104Z C 0.1UF, Z, 16V C9991 ECJ1XF1C104Z C 0.1UF, Z, 16V C9992 EEEHB1C470P C 47PF, J, 16V C9993 ECJ1XF1C104Z C 0.1UF, Z, 16V C9994 F1J0J106A013 C 0.010UF, K, 16V CB1-B7...
  • Page 95 Ref. No. Part No. Part Name & Description Remarks D6063 MA8051L ZENER DIODE D6064 MA111 DIODE D6065 LNJ301MPUJA D6066,67 MA8330M ZENER DIODE D6451 B0JCME000037 DIODE D6452,53 MA111 DIODE D6455 MA111 DIODE D6456 B0ECHP000003 DIODE D6459 MA111 DIODE D6460,61 B0HCKS000002 DIODE D6462 B0JCME000037 DIODE...
  • Page 96 Ref. No. Part No. Part Name & Description Remarks D6546-48 MA8330M ZENER DIODE D6549,50 MA111 DIODE D6551 B0JCME000037 DIODE D6552,53 MA111 DIODE D6554 B0HCKS000002 DIODE D6570 B0HCMM000014 DIODE D6572 B0ECHP000003 DIODE D6582 MA8051L ZENER DIODE D6583 LNJ301MPUJA D6584 MA111 DIODE D6585,86 MA8330M ZENER DIODE...
  • Page 97 Ref. No. Part No. Part Name & Description Remarks FL3006-10 F1J1E1040022 LC FILTER FL7106 J0HABH000013 LC FILTER FL7201 J0HABH000013 LC FILTER FL9001 J0MAB0000175 LC FILTER FL9601-03 F1J1E1040022 LC FILTER FL9701-03 F1J1E1040022 LC FILTER FL9705-09 F1J1E1040022 LC FILTER K1KA08AA0150 8P CONNECTOR K1KA80B00037 80P CONNECTOR (HA)
  • Page 98 Ref. No. Part No. Part Name & Description Remarks IC6011 AN1431M LINEAR IC IC6451 AN1431M LINEAR IC IC6452,53 C0CBALC00010 IC6454,55 C0CBADC00075 IC6456 AN1431M LINEAR IC IC6471,72 AN1431M LINEAR IC IC6491 AN1431M LINEAR IC IC6501,02 C0JBAZ000994 IC6511 C0ZBZ0001033 IC6512 C0CBADC00075 IC6521 C0ZBZ0001033 IC6541,42 C0ZBZ0001033...
  • Page 99 Ref. No. Part No. Part Name & Description Remarks IC9703 TVRN632 TH-37PWD8BK/BS/EK/ES PAVCCZ IC9704 C0EBE0000447 IC9711 C0JBAE000354 IC9713 C0JBAS000215 IC9714 C0JBAZ000856 IC9715 C0JBAE000354 IC9951 C0DBAMH00013 IC9952 C0DBAMH00014 IC9953 C0DBEJG00001 IC9954 C0DBEGE00002 IC9955 C0CBCAC00282 K1KA20AA0335 20P CONNECTOR K1KA06BA0047 6P CONNECTOR K1KA40AA0009 40P CONNECTOR K1KA11BA0051 11P CONNECTOR...
  • Page 100 Ref. No. Part No. Part Name & Description Remarks L3002 G1C100K00020 INDUCTION COIL L3002 J0HABB000004 LC FILTER (HA) L3002 J0HABB000004 LC FILTER (HB) L3003 G1C100K00020 INDUCTION COIL L3003 J0HABB000004 LC FILTER (HA) L3003 J0HABB000004 LC FILTER (HB) L3004 J0HABB000003 LC FILTER L3005 ERJ3GEY0R00 M 0 OHM, 1/16W...
  • Page 101 Ref. No. Part No. Part Name & Description Remarks L6647 J0JJC0000021 CHIP INDUCTOR L8001 G1C100K00020 INDUCTION COIL L8003 G1C100K00020 INDUCTION COIL L8005 G1C100K00020 INDUCTION COIL L8101-08 J0JHC0000078 CHIP INDUCTOR L8181 G1C100K00020 INDUCTION COIL L8501,02 G0A2R5H00003 CHOKE COIL L9204-06 J0JHC0000096 CHIP INDUCTOR L9501 G1C150KA0038 INDUCTION COIL...
  • Page 102 Ref. No. Part No. Part Name & Description Remarks Q6012 2SB1073001TV TRANSISTOR Q6013 2SD2185 TRANSISTOR Q6014 2SB1073001TV TRANSISTOR Q6021 2SK3996000VP Q6024 2SK3996000VP Q6025 2SK620 Q6041,42 2SK373100L TRANSISTOR Q6045 2SK326800L Q6046 2SK373100L TRANSISTOR Q6051 2SD1263A TRANSISTOR Q6052 2SC1473A TRANSISTOR Q6056 2SD601A TRANSISTOR Q6451 2SD1263A...
  • Page 103 Ref. No. Part No. Part Name & Description Remarks Q8010 2SD601A TRANSISTOR Q8011 2SB709A TRANSISTOR Q8012 2SD601A TRANSISTOR Q8013 2SB709A TRANSISTOR Q8019 2SD601A TRANSISTOR Q8181-84 2SK2731T146 TRANSISTOR Q8200-02 2SD601A TRANSISTOR Q9201,02 2SD601A TRANSISTOR Q9301-03 2SD601A TRANSISTOR Q9701 2SK2731T146 TRANSISTOR Q9702-07 2SD601A TRANSISTOR Q9708...
  • Page 104 Ref. No. Part No. Part Name & Description Remarks R2367 ERJ6GEYJ332 M 3.3KOHM,J,1/10W R2368,69 ERJ6GEYJ103 M 10KOHM,J,1/10W R2370 ERJ6GEYJ222 M 2.2KOHM,J,1/10W R2371,72 ERJ6GEYJ102 M 1KOHM,J,1/10W R2373 ERJ6GEYJ103 M 10KOHM,J,1/10W R2374 ERX1FJSR56D M0.56 OHM, J, 1W R2376 ERJ6GEYJ332 M 3.3KOHM,J,1/10W R2377 ERJ6GEYJ103 M 10KOHM,J,1/10W R2383...
  • Page 105 Ref. No. Part No. Part Name & Description Remarks R3008 ERJ3GEYJ103 M 10KOHM,J,1/16W R3008 ERJ3GEYJ103 M 10KOHM,J,1/16W (HB) R3009,10 D0GB101JA002 M 100 OHM,J,1/16W R3011 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R3012 D0GB333JA002 M 33KOHM,J,1/16W R3013 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R3014 D0GB333JA002 M 33KOHM,J,1/16W R3015 ERJ3GEYJ103 M 10KOHM,J,1/16W (HA)
  • Page 106 Ref. No. Part No. Part Name & Description Remarks R3034 ERJ3GEYJ331 M 330 OHM,J,1/16W R3035 ERJ3GEYJ102 M 1KOHM,J,1/16W (HB) R3035 ERJ3GEYJ331 M 330 OHM,J,1/16W R3036 ERJ3GEYJ103 M 10KOHM,J,1/16W (HB) R3036 ERJ3GEYJ331 M 330 OHM,J,1/16W R3036 ERJ6ENF1800 M 180 OHM, 1/10W (HB) R3037 ERJ3EKF2200...
  • Page 107 Ref. No. Part No. Part Name & Description Remarks R3058 TAJAAH0101JV M 100 OHM,J,1/16W (HB) R3059,60 ERJ3GEYJ102 M 1KOHM,J,1/16W R3060 ERJ3GEYJ102 M 1KOHM,J,1/16W (HB) R3061 ERJ3GEYJ561 M 560 OHM,J,1/16W (HB) R3061 J0JCC0000100 CHIP INDUCTOR R3062 ERJ3GEYJ561 M 560 OHM,J,1/16W (HB) R3062 ERJ6GEYJ101 M 100 OHM,J,1/10W...
  • Page 108 Ref. No. Part No. Part Name & Description Remarks R3133 ERJ6ENF10R0 M 10 OHM, 1/10W R3134 ERJ6GEYJ104 M 100KOHM,J,1/10W R3135 ERJ6ENF10R0 M 10 OHM, 1/10W R3136-39 ERJ3GEY0R00 M 0 OHM, 1/16W R3140 ERJ3GEYJ220 M 22 OHM,J,1/16W (HB) R3140 ERJ3GEYJ473 M 47KOHM,J,1/16W R3141 ERJ3GEY0R00 M 0 OHM, 1/16W...
  • Page 109 Ref. No. Part No. Part Name & Description Remarks R3212-15 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R3216-19 ERJ6GEYJ3R3 M 3.3KOHM,J,1/10W R3230,31 ERJ6GEYJ102 M 1KOHM,J,1/10W R3251 TAJAAH0101JV M 100 OHM,J,1/16W R3252 ERJ3GEYJ103 M 10KOHM,J,1/16W R3253 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R3254,55 ERJ3GEYJ220 M 22 OHM,J,1/16W R3300,01 ERJ3EKF1501 M 1.5KOHM, 1/16W R3302...
  • Page 110 Ref. No. Part No. Part Name & Description Remarks R6041,42 ERJ14YJ5R6U M 6.2OHM, 1/4W R6049,50 ERJ14YJ5R6U M 6.2OHM, 1/4W R6055 ERJ6GEYJ101 M 100 OHM,J,1/10W R6056 ERJ6GEYJ104 M 100KOHM,J,1/10W R6057 ERG1FJS470D M 47 OHM, J, 1W R6059,60 TAJAAH0101JV M 100 OHM,J,1/16W R6061 ERJ6ENF1001 M 1KOHM, 1/10W...
  • Page 111 Ref. No. Part No. Part Name & Description Remarks R6463 ERJ6GEYJ102 M 1KOHM,J,1/10W R6464 ERJ6GEYJ222 M 2.2KOHM,J,1/10W R6465 ERX3FJS8R2D M 8.2 OHM, J, 3W R6466 ERJ6GEYJ102 M 1KOHM,J,1/10W R6467 ERJ6GEYJ122 M 1.2KOHM,J,1/10W R6468 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R6469 ERJ6ENF1602 M 16KOHM, 1/10W R6471 ERJ6ENF4701 M 4.7KOHM, 1/10W...
  • Page 112 Ref. No. Part No. Part Name & Description Remarks R6538 ERJ6GEYJ102 M 1KOHM,J,1/10W R6539 TAJAAH0101JV M 100 OHM,J,1/16W R6540 ERJ6GEYJ104 M 100KOHM,J,1/10W R6541 ERJ6GEYJ470 M 47 OHM,J,1/10W R6542 ERJ6GEYJ100 M 10 OHM,J,1/10W R6544-46 ERJ6GEYJ100 M 10 OHM,J,1/10W R6548 ERJ6GEYJ100 M 10 OHM,J,1/10W R6550 ERJ6GEYJ223 M 22KOHM,J,1/10W...
  • Page 113 Ref. No. Part No. Part Name & Description Remarks R6624 ERJ6GEYJ100 M 10 OHM,J,1/10W R6625 ERJ6GEYJ103 M 10KOHM,J,1/10W R6626 ERJ6GEYJ100 M 10 OHM,J,1/10W R6627,28 TAJAAH0101JV M 100 OHM,J,1/16W R6629 ERJ6ENF2202 M 2.2KOHM, 1/10W R6630 ERJ14YJ204 M 200KOHM, J,1/4W R6635-38 ERJ14YJ150U M 15 OHM, J,1/4W R6641,42 ERJ14YJ5R6U...
  • Page 114 Ref. No. Part No. Part Name & Description Remarks R7132-35 ERJ3GEY0R00 M 0 OHM, 1/16W R7136-41 ERJ14YJ220 M 22 OHM, J,1/4W R7142-46 EXB38V470J RESISTOR ARRAY R7161 ERJ6GEY0R00 M 0 OHM, 1/10W R7162,63 TAJAAH0470JV M 47 OHM,J,1/16W R7166,67 TAJAAH0470JV M 47 OHM,J,1/16W R7170,71 TAJAAH0470JV M 47 OHM,J,1/16W...
  • Page 115 Ref. No. Part No. Part Name & Description Remarks R8036 ERJ6ENF1500 M 150 OHM, 1/10W R8037 ERJ6ENF4701 M 4.7KOHM, 1/10W R8039 ERJ6ENF4701 M 4.7KOHM, 1/10W R8041 ERJ3GEYJ183 M 18KOHM,J,1/16W R8045,46 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R8047 ERJ3GEYJ271 M 270 OHM,J,1/16W R8048 ERJ3GEYJ222 M 2.2KOHM,J,1/16W R8050,51 ERJ3GEYJ222...
  • Page 116 Ref. No. Part No. Part Name & Description Remarks R9023 ERJ6GEY0R00 M 0 OHM, 1/10W R9028-30 ERJ3GEY0R00 M 0 OHM, 1/16W R9032 ERJ3GEY0R00 M 0 OHM, 1/16W R9034 ERJ3GEY0R00 M 0 OHM, 1/16W R9035-38 TAJAAH0101JV M 100 OHM,J,1/16W R9039-42 ERJ3GEY0R00 M 0 OHM, 1/16W R9043,44 ERJ3GEYJ122...
  • Page 117 Ref. No. Part No. Part Name & Description Remarks R9260,61 ERJ3GEY0R00 M 0 OHM, 1/16W R9265 ERJ3GEY0R00 M 0 OHM, 1/16W R9271-73 EXB2HV470JV RESISTOR ARRAY R9274,75 ERJ3GEY0R00 M 0 OHM, 1/16W R9276 ERJ3GEYJ220 M 22 OHM,J,1/16W R9277-79 EXB2HV470JV RESISTOR ARRAY R9280,81 ERJ3GEY0R00 M 0 OHM, 1/16W...
  • Page 118 Ref. No. Part No. Part Name & Description Remarks R9585 ERJ3GEYJ220 M 22 OHM,J,1/16W R9586 ERJ3GEY0R00 M 0 OHM, 1/16W R9591 ERJ3GEY0R00 M 0 OHM, 1/16W R9593,94 ERJ3GEY0R00 M 0 OHM, 1/16W R9595 ERJ3GEYJ220 M 22 OHM,J,1/16W R9596 ERJ3GEY0R00 M 0 OHM, 1/16W R9601 ERJ3GEYJ100 M 10 OHM,J,1/16W...
  • Page 119 Ref. No. Part No. Part Name & Description Remarks R9734,35 ERJ3GEYJ272 M 2.7KOHM,J,1/16W R9736,37 ERJ3GEYJ562 M 5.6KOHM,J,1/16W R9738 ERJ3GEYJ330 M 33 OHM,J,1/16W R9739 ERJ3GEYJ103 M 10KOHM,J,1/16W R9740 TAJAAH0101JV M 100 OHM,J,1/16W R9741 ERJ3GEYJ103 M 10KOHM,J,1/16W R9742 ERJ3GEYJ102 M 1KOHM,J,1/16W R9743 ERJ3GEYJ103 M 10KOHM,J,1/16W R9744...
  • Page 120 Ref. No. Part No. Part Name & Description Remarks R9808 ERJ3GEYJ103 M 10KOHM,J,1/16W R9810 ERJ3GEY0R00 M 0 OHM, 1/16W R9811 ERJ3GEYJ103 M 10KOHM,J,1/16W R9812 ERJ3GEYJ473 M 47KOHM,J,1/16W R9813 ERJ3GEYJ103 M 10KOHM,J,1/16W R9814 ERJ3GEYJ102 M 1KOHM,J,1/16W R9815 ERJ3GEYJ473 M 47KOHM,J,1/16W R9816 ERJ3GEYJ103 M 10KOHM,J,1/16W R9817...
  • Page 121 Ref. No. Part No. Part Name & Description Remarks R9894 ERJ3GEYJ103 M 10KOHM,J,1/16W R9895-97 ERJ3GEY0R00 M 0 OHM, 1/16W R9951 ERJ6GEY0R00 M 0 OHM, 1/10W R9953 ERJ6GEY0R00 M 0 OHM, 1/10W R9954 ERJ6ENF2322 M23.2KOHM, 1/10W R9955 ERJ6ENF1002 M 10KOHM, 1/10W R9956 ERJ3GEYJ473 M 47KOHM,J,1/16W...
  • Page 123 Ref. No. Part No. Part Name & Description Remarks TNPA3640 CIRCUIT BOARD V1 TNPA3641 CIRCUIT BOARD V2 TNPA3642 CIRCUIT BOARD S1 K1KA03AA0193 3P CONNECTOR K1KA06AA0192 6P CONNECTOR SC20 K1KA20AA0008 20P CONNECTOR SC23 K1KA03AA0193 3P CONNECTOR SC30 K1KA03AA0193 3P CONNECTOR SC41,42 K1ML80BA0001 80P CONNECTOR SC45,46...
  • Page 124 Ref. No. Part No. Part Name & Description Remarks ZA6002 K4CD01000013 TERMINAL ZA6004 K4CD01000013 TERMINAL ZA6601-03 K4CD01000013 TERMINAL ZA7101 K4CD01000013 TERMINAL ZA7103 K4CD01000013 TERMINAL ZA7201 K4CD01000013 TERMINAL ZA7203 K4CD01000013 TERMINAL C402 ECJ2XC1H101J C 100PF, J, 50V C403 ECKCNA222MEB C 2200PF, M C404 F0CAF105A021 C 1UF, 250V...
  • Page 126 Ref. No. Part No. Part Name & Description Remarks C482 ECJ2XB1H104K C 0.1UF, K, 50V C490 ECJ2XC1H331J C 330PF, J, 50V C491 ECJ2XB1E104K C 0.1UF, K, 25V C492 ECJ2XC1H271J C 270PF, J, 50V C493 ECA1EM101 E 100UF, 25V C494,95 ECJ2XC1H101J C 100PF, J, 50V C496 F1J1C1050011...
  • Page 127 Ref. No. Part No. Part Name & Description Remarks C610 F1J1C1050011 C 1UF, Z, 50V C611 F2B2D1720001 E 1700UF,@ 200V C612 ECJ2XB1H103K C 0.01UF, K, 50V C615 F2B2D1720001 E 1700UF,@ 200V C616 F1A3A102A040 C 1000PF, J, 1KV C619 ECJ2XB1H104K C 0.1UF, K, 50V C620 ECJ2XB1H103K C 0.01UF, K, 50V...
  • Page 128 Ref. No. Part No. Part Name & Description Remarks D443 MA4240MTA ZENER DIODE D444 B0HAMM000122 DIODE D445 MA165 DIODE D459 MA188 DIODE D461 MA4082M ZENER DIODE D462 MA142WKTX ZENER DIODE D463-67 ERA15-10 DIODE D501 B0HANR000016 DIODE D503,04 MA165 DIODE D505 B0JAME000081 DIODE D506...
  • Page 129 Ref. No. Part No. Part Name & Description Remarks IC403,04 CNC1S171R IC406 C0DAZZZ00021 IC407 C0DBAZZ00111 IC408,09 CNC1S171R IC411 C0BBAA000038 IC412 CNC1S171R IC501 C2ABDD000064 IC502 C0EBH0000190 IC503,04 C0DAEMB00004 IC505 CNC1S171R IC506 C0ZBZ0000878 IC507 C0CBABE00023 IC509 C0DABZZ00010 IC512 C0DAEMB00004 IC520 C9ZB00000496 L402 EXCELSA24 BEAD CHOKE L403...
  • Page 130 Ref. No. Part No. Part Name & Description Remarks Q414 B1ABCF000134 TRANSISTOR Q415 2SB1218ARL TRANSISTOR Q417 B1CHND000004 TRANSISTOR Q418 2SD1819A TRANSISTOR Q420-22 2SD1819A TRANSISTOR Q423,24 B1CBGD000001 TRANSISTOR Q430 B1CEJQ000002 TRANSISTOR Q431 B1DEGS000001 TRANSISTOR Q432 B1CEJQ000002 TRANSISTOR Q433 B1CBGD000001 TRANSISTOR Q434 B1CEJQ000002 TRANSISTOR Q435...
  • Page 131 Ref. No. Part No. Part Name & Description Remarks R401 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R402 ERJ6EKF6803 M 680KOHM, 1/10W R403 ERJ6ENF4702 M 47KOHM, 1/10W R404 ERJ6GEYJ104 M 100KOHM,J,1/10W R405 ERJ6EKF6803 M 680KOHM, 1/10W R407 ERJ6GEYJ103 M 10KOHM,J,1/10W R408 ERJ6GEYJ104 M 100KOHM,J,1/10W R410,11 D1F5100E0002 F 3.3 OHM, 5W...
  • Page 132 Ref. No. Part No. Part Name & Description Remarks R456,57 ERJ6GEYJ333 M 33KOHM,J,1/10W R458 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R461 ERJ6GEYJ102 M 1KOHM,J,1/10W R462 ERJ6ENF4303 M 430KOHM, 1/10W R463 ERJ6GEYJ333 M 33KOHM,J,1/10W R464 ERJ6ENF3302 M 33KOHM, 1/10W R465 ERJ6ENF5603 M 560KOHM, 1/10W R466,67 ERJ6GEYJ102 M 1KOHM,J,1/10W...
  • Page 133 Ref. No. Part No. Part Name & Description Remarks R528 ERJ6GEYJ4R7 M 4.7 OHM,J,1/10W R530 ERJ6RBD3302 M 33KOHM,F,1/10W R531 ERJ8GEYJ472 M 4.7KOHM, J,1/8W R532 ERJ6GEYJ101 M 100 OHM,J,1/10W R533 ERJ8GEYJ223 M 22KOHM, J,1/8W R534 ERJ8GEYJ224 M 220KOHM, J,1/8W R535,36 ERJ6GEYJ102 M 1KOHM,J,1/10W R537 ERJ6ENF3602...
  • Page 134 Ref. No. Part No. Part Name & Description Remarks R586,87 ERJ6GEYJ473 M 47KOHM,J,1/10W R588 ERJ8ENF3900 M 390 OHM, 1/8W R589,90 ERJ8GEYJ123 M 12KOHM, J,1/8W R591 ERJ6GEYJ105 M 1MOHM,J,1/10W R592 ERJ6ENF3001 M 3KOHM, 1/10W R593 ERJ6ENF5601 M 5.6KOHM, 1/10W R594 ERJ6GEYJ103 M 10KOHM,J,1/10W R595 ERJ8GEYJ222...
  • Page 135 Ref. No. Part No. Part Name & Description Remarks R650 ERJ6GEYJ103 M 10KOHM,J,1/10W R651 ERJ6GEYJ473 M 47KOHM,J,1/10W R652 ERJ6ENF9101 M 9.1KOHM, 1/10W R653 ERJ6GEYJ103 M 10KOHM,J,1/10W R654 ERJ8GEYJ101 M 100 OHM, J,1/8W R655 ERJ8RQJR39 M0.39 OHM, 1/8W R656 ERJ6ENF4702 M 47KOHM, 1/10W R657 ERJ6GEYJ102 M 1KOHM,J,1/10W...
  • Page 136 Ref. No. Part No. Part Name & Description Remarks R713 ERJ8GEYJ472 M 4.7KOHM, J,1/8W R901 ERJ6ENF2702 M 27KOHM, 1/10W R903-06 ERJ8ENF1203 M 12KOHM, 1/8W R907 ERJ6ENF2702 M 27KOHM, 1/10W R908 ERJ6GEYJ335 M 3.3MOHM,J,1/10W R909-11 ERJ6GEYJ106 M 10MOHM,J,1/10W R912 ERJ6GEYJ103 M 10KOHM,J,1/10W R913,14 ERJ6GEYJ102 M 1KOHM,J,1/10W...

  • Page 137: Electrical Replacement Parts List (42Inch)

    Ref. No. Part No. Part Name & Description Remarks ZN404 D4EAB681A011 VARISTOR 19.3. Electrical Replacement Parts List (42inch) Note: All parts except parts mentioned [PAVCCZ] in the Remarks column are supplied by AVC-SPC. Parts mentioned [PAVCCZ] are supplied by PAVCCZ. Ref.
  • Page 138 Ref. No. Part No. Part Name & Description Remarks C831 EEEHB1C470P C 47PF, J, 16V C832 ECJ1XB1C104K C 0.1UF, Z, 16V C833 ECJ1VB1H103K C 0.001UF, K, 50V C834 EEEHB1C470P C 47PF, J, 16V C835 F1J0J1060004 C 0.010UF, K, 16V C836 TCUY1C225KBM C 2.2UF, 16V C837...
  • Page 139 Ref. No. Part No. Part Name & Description Remarks C2411-13 ECJ3XB1C106M C 1.0UF, K, 16V C3001 ECJ1VF1H103Z C 0.010UF, Z, 50V C3002 ECJ2XB1E104K C 0.1UF, K, 25V (HB) C3002 ECJ3XF1C475Z C 4.7UF, Z, 16V C3003 ECJ2VF1C105Z C 1UF, Z, 16V C3003 EEEHP1A100R E 10UF, 10V...
  • Page 140 Ref. No. Part No. Part Name & Description Remarks C3024 ECJ3XB0J106M C 10UF, M,6.3V (HB) C3024-31 TCUY1C225KBM C 2.2UF, 16V C3033 ECJ2VF1C105Z C 1UF, Z, 16V C3040,41 ECJ1XF1C104Z C 0.1UF, Z, 16V C3051-54 ECJ1XC1H561J C 560PF, J, 50V C3055,56 ECJ2VF1C105Z C 1UF, Z, 16V C3101 TCUY1C225KBM...
  • Page 141 Ref. No. Part No. Part Name & Description Remarks C3145 EEEHB1C470P C 47PF, J, 16V C3146 ECJ1XB1C104K C 0.1UF, Z, 16V (HB) C3146 TCUY1C225KBM C 2.2UF, 16V C3147 ECJ3XB0J106M C 10UF, M,6.3V C3148 ECJ1XB0J105K C 1UF, K, 16V C3149 ECJ1XB1C104K C 0.1UF, Z, 16V C3150 ECJ1VB1C103K...
  • Page 142 Ref. No. Part No. Part Name & Description Remarks C3309 ECJ1VF1A105Z C 1UF, Z, 10V C3311 ECJ1XB1C104K C 0.1UF, Z, 16V C3313 ECJ1VF1A105Z C 1UF, Z, 10V C3316,17 ECJ1VF1A105Z C 1UF, Z, 10V C3318-21 ECJ1XB1C104K C 0.1UF, Z, 16V C3322,23 EEEHB0G221P C 220PF, J, 4V C3324...
  • Page 143 Ref. No. Part No. Part Name & Description Remarks C6469 EEUFC1E221 E 220UF, 25V C6470 ECA1HM221 E 220UF, 50V C6471 TCUY1C105ZFN C 1UF, 16V C6472 ECJ2VB1H333K C 0.033UF, K, 50V C6473 TCUY1C105ZFN C 1UF, 16V C6474 ECJ2XB1H103K C 0.01UF, K, 50V C6475 EEUFC1E221 E 220UF, 25V...
  • Page 144 Ref. No. Part No. Part Name & Description Remarks C6617 F1L2J562A022 C 5600UF, K,6.3V C6621-30 ECQE2105RKB P 1UF, 250V C6631,32 F1L1E4750004 C 4.7UF, 25V C6634,35 F1L1E4750004 C 4.7UF, 25V C6637 F1L1E4750004 C 4.7UF, 25V C6639 F1L1E4750004 C 4.7UF, 25V C6647 TCUY1C105ZFN C 1UF, 16V C6650...
  • Page 145 Ref. No. Part No. Part Name & Description Remarks C8009 ECJ3XB0J106M C 10UF, M,6.3V C8013 ECJ1XF1C104Z C 0.1UF, Z, 16V C8015 ECJ3YF1A106Z C 10UF, Z, 10V C8016 ECJ3YB1A475K C 0.047UF, K, 10V C8019 ECJ1VB1H103K C 0.001UF, K, 50V C8021 ECJ3VB1C474K C 0.47UF, K, 16V C8023 ECJ1VB1H103K...
  • Page 146 Ref. No. Part No. Part Name & Description Remarks C9019 F1J0J106A013 C 0.010UF, K, 16V C9020 ECJ1XF1C104Z C 0.1UF, Z, 16V C9022 ECJ1XF1C104Z C 0.1UF, Z, 16V C9031 ECJ1XF1C104Z C 0.1UF, Z, 16V C9101-05 ECJ1XF1C104Z C 0.1UF, Z, 16V C9107,08 ECJ1XF1C104Z C 0.1UF, Z, 16V C9151-54...
  • Page 147 Ref. No. Part No. Part Name & Description Remarks C9637 ECJ1XB1C104K C 0.1UF, Z, 16V C9639 ECJ1XB1C104K C 0.1UF, Z, 16V C9641 ECJ1XB1C104K C 0.1UF, Z, 16V C9643 ECJ1XB1C104K C 0.1UF, Z, 16V C9645 ECJ1XB1C104K C 0.1UF, Z, 16V C9647 ECJ1XB1C104K C 0.1UF, Z, 16V C9649...
  • Page 148 Ref. No. Part No. Part Name & Description Remarks C9951 ECJ2FF1C475Z C 0.047UF, Z, 16V C9952 F2H1E221A007 E 2.2UF, 25V C9955 EEEHB0G221P C 220PF, J, 4V C9957 ECJ1XF1C104Z C 0.1UF, Z, 16V C9959 ECJ2FF1C475Z C 0.047UF, Z, 16V C9961 ECJ2XB1H472K C 4700PF, K, 50V C9963 ECJ1XB1C104K...
  • Page 149 Ref. No. Part No. Part Name & Description Remarks D3507-10 MA8160H ZENER DIODE D6001,02 B0HBSN000008 DIODE D6015 B0ECHP000003 DIODE D6020 B0HBSN000008 DIODE D6021 B0ECHP000003 DIODE D6022 B0HBSN000008 DIODE D6023 B0ECHP000003 DIODE D6024 B0HBSN000008 DIODE D6029 B0HBSN000008 DIODE D6035 MA8033L ZENER DIODE D6036 MA111 DIODE...
  • Page 150 Ref. No. Part No. Part Name & Description Remarks D6503 MA8056H ZENER DIODE D6509 MA111 DIODE D6511 B0HCMM000014 DIODE D6512-14 MA111 DIODE D6515 MA8240M ZENER DIODE D6516 MA111 DIODE D6519 MA111 DIODE D6520 B0JCKG000002 DIODE D6521 B0ECHP000003 DIODE D6522 MA111 DIODE D6523 B0ECHP000003...
  • Page 151 Ref. No. Part No. Part Name & Description Remarks D8003 MA111 DIODE D8010,11 MA153 DIODE D8180 MA111 DIODE D8181 MA8056-M DIODE D8183 MA8033L ZENER DIODE D8184,85 MA8056-M DIODE D8200 MA3150M ZENER DIODE D8201 MA111 DIODE D8203 MA3100M ZENER DIODE D8204 MA111 DIODE D9301,02...
  • Page 152 Ref. No. Part No. Part Name & Description Remarks IC3004 CXA1875AM LINEAR IC IC3005 C1AB00002311 IC3007,08 C0JBAS000215 IC3101 C0DBEZG00018 IC3101 C1AB00002238 IC3102 C0DBZLB00003 IC3103 C1AB00002158 IC3104 PST9128NR IC (LOGIC) IC3105 C0JBAZ002269 IC3150 C0JBAA000419 IC3201 C3HBKZ000002 IC3251 C0ZBZ0000967 IC3301 MM1065ZMR LINEAR IC IC3302 C0DBEZG00018 IC3303...
  • Page 153 Ref. No. Part No. Part Name & Description Remarks IC8014 C0ZBZ0000911 IC8016 C0JBAZ001934 IC8100 C0CBAKG00008 IC8181 C1DB00001208 IC9001 C0FBAD000102 IC9002 C0CBCBC00190 IC9031 C0JBAZ002198 IC9101 C0ZBZ0000764 IC9102 C0JBAZ002198 IC9103 C0JBAE000354 IC9151-54 C0JBAZ000856 IC9201 C1ZBZ0002917 IC9202 C0EBD0000038 IC9203 TVRN628 IC9303 TVRN627 IC9500 C1ZBZ0002769 IC9601 MN84513-A...
  • Page 154 Ref. No. Part No. Part Name & Description Remarks JK3002 K2HA204B0097 JACK (HA) JK3004 K2HA204B0097 JACK JK3509 K1FB109BA018 CONNECTOR JK3511 K1FB115BA020 CONNECTOR JK3513 K2HC103B0105 JACK JK8500 K4BC02B00013 TERMINAL JS801-16 ERJ6GEY0R00 M 0 OHM, 1/10W JS3001-08 ERJ3GEY0R00 M 0 OHM, 1/16W JS3011-16 ERJ3GEY0R00 M 0 OHM, 1/16W...
  • Page 155 Ref. No. Part No. Part Name & Description Remarks L6019 G0ZZ00002183 PEAKING COIL L6022 J0JJC0000021 CHIP INDUCTOR L6024-27 G0ZZ00002183 PEAKING COIL L6034-37 G0ZZ00002183 PEAKING COIL L6042,43 J0JJC0000021 CHIP INDUCTOR L6047 J0JJC0000021 CHIP INDUCTOR L6050 G0ZZ00002183 PEAKING COIL L6451 J0JJC0000021 CHIP INDUCTOR L6453 J0JJC0000021 CHIP INDUCTOR...
  • Page 156 Ref. No. Part No. Part Name & Description Remarks Q6471 B1BBCJ000004 TRANSISTOR Q6472 2SB0709A TRANSISTOR Q6474 2SD814A TRANSISTOR Q6476,77 2SD601A TRANSISTOR Q6491 2SD1263A TRANSISTOR Q6492 2SC1473A TRANSISTOR Q6501-05 2SK620 Q6511,12 B1DFGL000008 TRANSISTOR Q6520 2SD601A TRANSISTOR Q6521 B1DFES000002 TRANSISTOR Q6522-28 2SK400000L Q6530 2SB1073001TV TRANSISTOR...
  • Page 157 Ref. No. Part No. Part Name & Description Remarks Q3101 2SD601A TRANSISTOR Q3102 2SD1030 TRANSISTOR (HB) Q3102,03 2SD601A TRANSISTOR Q3104 2SD1030 TRANSISTOR Q3531,32 2SD601A TRANSISTOR Q6001-03 B1JADN000001 TRANSISTOR Q6006-08 B1JADN000001 TRANSISTOR Q6011 2SD2185 TRANSISTOR Q6012 2SB1073001TV TRANSISTOR Q6013 2SD2185 TRANSISTOR Q6014 2SB1073001TV TRANSISTOR...
  • Page 158 Ref. No. Part No. Part Name & Description Remarks R1500 ERJ6GEYJ102 M 1KOHM,J,1/10W R1510 ERJ3GEYF222 M 2.2KOHM, 1/16W R1511 ERJ3GEYF302 M 3.0KOHM, 1/16W R1512 ERJ3GEYF472 M 4.7KOHM, 1/16W R1513 ERJ3GEYF822 M 8.2KOHM,J,1/16W R1550 ERJ6GEYJ102 M 1KOHM,J,1/10W R1551 ERJ6GEYJ470 M 47 OHM,J,1/10W R1552 ERJ6GEYJ224 M 220KOHM,J,1/10W...
  • Page 159 Ref. No. Part No. Part Name & Description Remarks R3003 ERJ3GEYJ473 M 47KOHM,J,1/16W R3004 ERJ3GEYJ101 M 100 OHM,J,1/16W R3004 ERJ6ENF75R0 M 75 OHM, 1/10W (HB) R3004 ERJ6GEYJ184 M 180KOHM,J,1/10W (HA) R3005 ERJ3GEYJ332 M 3.3KOHM,J,1/16W R3005 ERJ6ENF75R0 M 75 OHM, 1/10W (HB) R3005 ERJ6GEYJ184...
  • Page 160 Ref. No. Part No. Part Name & Description Remarks R3023 ERJ3GEYJ101 M 100 OHM,J,1/16W R3023 ERJ3GEYJ102 M 1KOHM,J,1/16W (HA) R3023 ERJ3GEYJ472 M 4.7KOHM,J,1/16W (HB) R3024 ERJ3GEYJ101 M 100 OHM,J,1/16W R3024 TAJAAH0101JV M 100 OHM,J,1/16W (HB) R3025 ERJ3GEYJ101 M 100 OHM,J,1/16W R3025 TAJAAH0101JV M 100 OHM,J,1/16W...
  • Page 161 Ref. No. Part No. Part Name & Description Remarks R3046 TAJAAH0101JV M 100 OHM,J,1/16W (HB) R3047 ERJ3GEYJ102 M 1KOHM,J,1/16W (HB) R3047 ERJ3GEYJ103 M 10KOHM,J,1/16W R3048 ERJ3GEYJ334 M 330KOHM,J,1/16W R3048 TAJAAH0101JV M 100 OHM,J,1/16W (HB) R3049 ERJ3GEYJ102 M 1KOHM,J,1/16W (HB) R3049 ERJ3GEYJ334 M 330KOHM,J,1/16W R3050...
  • Page 162 Ref. No. Part No. Part Name & Description Remarks R3110 ERJ6ENF4701 M 4.7KOHM, 1/10W R3111 ERJ6ENF1501 M 1.5KOHM, 1/10W R3112,13 ERJ3EKF1501 M 1.5KOHM, 1/16W R3114 ERJ3GEY0R00 M 0 OHM, 1/16W R3115 ERJ3GEYJ102 M 1KOHM,J,1/16W R3116 ERJ3GEYJ103 M 10KOHM,J,1/16W R3116 ERJ6GEY0R00 M 0 OHM, 1/10W (HB) R3117...
  • Page 163 Ref. No. Part No. Part Name & Description Remarks R3159 ERJ6GEY0R00 M 0 OHM, 1/10W R3160 ERJ3EKF2701 M 2.7KOHM, 1/16W (HB) R3160 ERJ3GEYJ562 M 5.6KOHM,J,1/16W R3161 ERJ3EKF2701 M 2.7KOHM, 1/16W (HB) R3161 ERJ3GEYJ562 M 5.6KOHM,J,1/16W R3162 ERJ3EKF2701 M 2.7KOHM, 1/16W R3163 ERJ3GEYJ102 M 1KOHM,J,1/16W...
  • Page 164 Ref. No. Part No. Part Name & Description Remarks R3547,48 ERJ6GEYJ101 M 100 OHM,J,1/10W R3585,86 ERJ6GEYJ560 M 56 OHM,J,1/10W R3589 ERJ6GEYJ473 M 47KOHM,J,1/10W R3590 ERJ6GEYJ560 M 56 OHM,J,1/10W R3591-93 ERJ6GEY0R00 M 0 OHM, 1/10W R3653 ERJ6GEYJ153 M 15KOHM,J,1/10W R3654 ERJ6GEYJ333 M 33KOHM,J,1/10W R3655 ERJ6GEYJ153...
  • Page 165 Ref. No. Part No. Part Name & Description Remarks R6088 ERJ6GEYJ103 M 10KOHM,J,1/10W R6089 ERJ6GEYJ102 M 1KOHM,J,1/10W R6090 ERJ14YJ181U M 181 OHM, J,1/4W R6091 ERJ6GEYJ102 M 1KOHM,J,1/10W R6092 ERJ6GEYJ151 M 150 OHM,J,1/10W R6101 TAJAAH0470JV M 47 OHM,J,1/16W R6102 EXB38V470J RESISTOR ARRAY R6104 ERJ3GEYJ472 M 4.7KOHM,J,1/16W...
  • Page 166 Ref. No. Part No. Part Name & Description Remarks R6484 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R6485,86 ERJ6GEYJ103 M 10KOHM,J,1/10W R6487 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R6488 ERJ6GEYJ103 M 10KOHM,J,1/10W R6489 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R6491 ERJ14YJ104 M 100KOHM, J,1/4W R6492 ERJ6ENF2003 M 200KOHM, 1/10W R6493 ERJ6ENF2703 M 270KOHM, 1/10W R6495,96...
  • Page 167 Ref. No. Part No. Part Name & Description Remarks R6566 TAJAAH0101JV M 100 OHM,J,1/16W R6567,68 ERJ6GEYJ472 M 4.7KOHM,J,1/10W R6570 ERJ6GEYJ103 M 10KOHM,J,1/10W R6571-78 ERJ6GEYJ471 M 470 OHM,J,1/10W R6580 ERJ6GEYJ103 M 10KOHM,J,1/10W R6581 TAJAAH0101JV M 100 OHM,J,1/16W R6582,83 ERJ6ENF3902 M 39KOHM, 1/10W R6584 ERJ6ENF7501 M 7.5KOHM, 1/10W...
  • Page 168 Ref. No. Part No. Part Name & Description Remarks R6667,68 ERJ6GEYJ151 M 150 OHM,J,1/10W R6669 EXB38V472J RESISTOR ARRAY R6670 EXB38V470J RESISTOR ARRAY R6675 EXB38V472J RESISTOR ARRAY R6676 EXB38V470J RESISTOR ARRAY R6683 EXB38V470J RESISTOR ARRAY R6686 EXB38V472J RESISTOR ARRAY R6696 ERJ6GEYJ103 M 10KOHM,J,1/10W R6699 ERJ6GEYJ103...
  • Page 169 Ref. No. Part No. Part Name & Description Remarks R7204,05 ERJ8GEY0R00 M 0 OHM, 1/8W R7206,07 ERJ14YJ220 M 22 OHM, J,1/4W R7208,09 ERJ8GEY0R00 M 0 OHM, 1/8W R7210,11 ERJ14YJ220 M 22 OHM, J,1/4W R7212 ERJ6GEYJ103 M 10KOHM,J,1/10W R7213 ERJ6GEY0R00 M 0 OHM, 1/10W R7214,15 ERJ14YJ220 M 22 OHM, J,1/4W...
  • Page 170 Ref. No. Part No. Part Name & Description Remarks R8057 ERJ3GEYJ102 M 1KOHM,J,1/16W R8058,59 ERJ3GEYJ101 M 100 OHM,J,1/16W R8065 D0GB911JA002 M 910 OHM,J,1/16W R8067 D0GB911JA002 M 910 OHM,J,1/16W R8069 ERJ6GEYJ681 M 680 OHM,J,1/10W R8072 J0JCC0000100 CHIP INDUCTOR R8089 ERJ3GEYJ181 M 180 OHM,J,1/16W R8093 ERJ6GEYJ101 M 100 OHM,J,1/10W...
  • Page 171 Ref. No. Part No. Part Name & Description Remarks R9108 EXB38V103J RESISTOR ARRAY R9109 ERJ3GEYJ103 M 10KOHM,J,1/16W R9110,11 EXB38V103J RESISTOR ARRAY R9112 ERJ3GEY0R00 M 0 OHM, 1/16W R9113-15 ERJ3GEYJ103 M 10KOHM,J,1/16W R9116-26 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R9127 ERJ3GEY0R00 M 0 OHM, 1/16W R9129,30 ERJ3GEY0R00 M 0 OHM, 1/16W...
  • Page 172 Ref. No. Part No. Part Name & Description Remarks R9284 ERJ3GEY0R00 M 0 OHM, 1/16W R9286 ERJ3GEYJ223 M 22KOHM,J,1/16W R9287,88 ERJ3GEYJ103 M 10KOHM,J,1/16W R9289 TAJAAH0101JV M 100 OHM,J,1/16W R9290 ERJ3GEYJ561 M 560 OHM,J,1/16W R9293-95 ERJ3GEYJ472 M 4.7KOHM,J,1/16W R9296 ERJ3GEYJ331 M 330 OHM,J,1/16W R9297 ERJ3GEYJ472 M 4.7KOHM,J,1/16W...
  • Page 173 Ref. No. Part No. Part Name & Description Remarks R9605,06 ERJ3GEY0R00 M 0 OHM, 1/16W R9607 ERJ3GEYJ103 M 10KOHM,J,1/16W R9608 ERJ3GEY0R00 M 0 OHM, 1/16W R9609 ERJ3GEYJ103 M 10KOHM,J,1/16W R9610,11 ERJ3GEY0R00 M 0 OHM, 1/16W R9614-17 ERJ3GEY0R00 M 0 OHM, 1/16W R9620 ERJ3GEY0R00 M 0 OHM, 1/16W...
  • Page 174 Ref. No. Part No. Part Name & Description Remarks R9747 ERJ3GEYJ103 M 10KOHM,J,1/16W R9748-50 ERJ3GEY0R00 M 0 OHM, 1/16W R9751,52 ERJ3GEYJ103 M 10KOHM,J,1/16W R9753 TAJAAH0101JV M 100 OHM,J,1/16W R9754 ERJ3GEYJ103 M 10KOHM,J,1/16W R9755 TAJAAH0101JV M 100 OHM,J,1/16W R9756 ERJ3GEYJ102 M 1KOHM,J,1/16W R9757 ERJ3GEYJ103 M 10KOHM,J,1/16W...
  • Page 175 Ref. No. Part No. Part Name & Description Remarks R9818 ERJ3GEYJ473 M 47KOHM,J,1/16W R9819 ERJ3GEYJ103 M 10KOHM,J,1/16W R9820,21 ERJ3GEYJ562 M 5.6KOHM,J,1/16W R9822 ERJ3GEYJ331 M 330 OHM,J,1/16W R9823 ERJ3GEYJ102 M 1KOHM,J,1/16W R9824 ERJ3GEYJ332 M 3.3KOHM,J,1/16W R9825 ERJ3GEYJ682 M 6.8KOHM,J,1/16W R9826 ERJ3GEYJ103 M 10KOHM,J,1/16W R9828 ERJ3GEYJ104...
  • Page 176 Ref. No. Part No. Part Name & Description Remarks R9963 ERJ6GEY0R00 M 0 OHM, 1/10W R9964 ERJ6ENF5101 M 5.1KOHM, 1/10W R9965 ERJ6ENF1002 M 10KOHM, 1/10W R9966 ERJ3GEYJ183 M 18KOHM,J,1/16W R9967 ERJ3GEYJ683 M 68KOHM,J,1/16W R9971 ERJ6GEY0R00 M 0 OHM, 1/10W R9973 ERJ6ENF2002 M 20KOHM, 1/10W R9974...
  • Page 177 Ref. No. Part No. Part Name & Description Remarks SC23 K1KA03AA0193 3P CONNECTOR SC30 K1KA03AA0193 3P CONNECTOR SC41,42 K1ML80BA0001 80P CONNECTOR SC45,46 K1KA10A00431 10P CONNECTOR SD1-D3 K1MN80B00004 80P CONNECTOR SD46 K1KA10B00209 10P CONNECTOR SS11 K1KA07AA0192 7P CONNECTOR SS12 K1KA05AA0192 5P CONNECTOR SS23 K1KA12AA0194 12P CONNECTOR...
  • Page 178 Ref. No. Part No. Part Name & Description Remarks C405 ECJ2XB1H103K C 0.01UF, K, 50V C407 ECA2WHG220 E 22UF, 450V C409 F0CAF105A021 C 1UF, 250V C410 ECJ3YB1E105K C 1UF, K, 25V C411-14 ECJ2XB1H103K C 0.01UF, K, 50V C415,16 F1A3A102A040 C 1000PF, J, 1KV C417 ECJ2XB1H103K C 0.01UF, K, 50V...
  • Page 179 Ref. No. Part No. Part Name & Description Remarks C505 ECJ2XB1H102K C 1000PF, K, 50V C506-08 ECJ2XB1H103K C 0.01UF, K, 50V C509 ECA1EM101 E 100UF, 25V C510 ECJ2XB1H104K C 0.1UF, K, 50V C511 ECA1EM331 E 330UF, 25V C512-14 ECJ2XC1H471J C 470PF, J, 50V C515 ECA1CM222 E 2200UF, 16V...
  • Page 180 Ref. No. Part No. Part Name & Description Remarks C631 ECJ2XB1H103K C 0.01UF, K, 50V C633 ECJ2XB1H103K C 0.01UF, K, 50V C634 ECJ2XB1H102K C 1000PF, K, 50V C635 ECJ2XB1H103K C 0.01UF, K, 50V C636 F1J1C1050011 C 1UF, Z, 50V C637 ECJ2XB1H104K C 0.1UF, K, 50V C638,39...
  • Page 181 Ref. No. Part No. Part Name & Description Remarks D507,08 MA4150M ZENER DIODE D509,10 B0HANM000028 DIODE D511 B0HBSM000043 DIODE D514 MA4062M ZENER DIODE D521 B0HAMP000067 DIODE D528,29 MA153 DIODE D530 MA4100M ZENER DIODE D531,32 B0HAPR000012 DIODE D534 B0JBSG000026 DIODE D535 MA188 DIODE D536...
  • Page 182 Ref. No. Part No. Part Name & Description Remarks IC507 C0CBABE00023 IC509 C0DABZZ00010 IC512 C0DAEMB00004 IC520 C9ZB00000496 L402 EXCELSA24 BEAD CHOKE L403 EXCELSA35 BEAD CHOKE L404,05 G0B123K00003 INDUCTION COIL L501 EXCELSA35 BEAD CHOKE L502 TALL08N102JA INDUCTION COIL L506 EXCELDR25C BEAD CHOKE L509 J0JBC0000032 CHIP INDUCTOR...
  • Page 183 Ref. No. Part No. Part Name & Description Remarks Q436 B1CEJQ000002 TRANSISTOR Q438 B1CBGD000001 TRANSISTOR Q439 B1CHND000004 TRANSISTOR Q440,41 2SD1819A TRANSISTOR Q501,02 2SD1820A TRANSISTOR Q503 XN0440100L TRANSISTOR Q505 B1CEJQ000002 TRANSISTOR Q506 B1CHND000004 TRANSISTOR Q507 B1DAGQ000013 TRANSISTOR Q508 XN0450100L TRANSISTOR Q509 XN0440100L TRANSISTOR Q510...
  • Page 184 Ref. No. Part No. Part Name & Description Remarks R415 ERJ6GEYJ103 M 10KOHM,J,1/10W R416 ERJ6GEYJ332 M 3.3KOHM,J,1/10W R417 ERJ6ENF4303 M 430KOHM, 1/10W R418 ERJ6GEYJ473 M 47KOHM,J,1/10W R419 ERJ6GEYJ104 M 100KOHM,J,1/10W R420 ERJ6GEYJ474 M 470KOHM,J,1/10W R421 ERJ6GEYJ333 M 33KOHM,J,1/10W R422 ERJ8GEYJ181 M 180 OHM, J,1/8W R423 ERJ6GEYJ154...
  • Page 185 Ref. No. Part No. Part Name & Description Remarks R472,73 ERJ6ENF5603 M 560KOHM, 1/10W R474 ERG1SJ104P M 100KOHM, J, 1W R475 ERJ6EKF6803 M 680KOHM, 1/10W R476,77 ERJ14YJ181U M 181 OHM, J,1/4W R478 ERJ8GEYJ220 M 22 OHM, J,1/8W R479 ERG1SJ104P M 100KOHM, J, 1W R480 ERJ6ENF9102 M91.0KOHM, 1/10W...
  • Page 186 Ref. No. Part No. Part Name & Description Remarks R542 ERJ6GEYJ102 M 1KOHM,J,1/10W R543 ERJ6GEYJ222 M 2.2KOHM,J,1/10W R544 ERJ6GEYJ331 M 330 OHM,J,1/10W R545 ERJ6GEYJ103 M 10KOHM,J,1/10W R546,47 ERJ6GEYJ102 M 1KOHM,J,1/10W R548 ERJ8GEYJ102 M 1KOHM, J,1/8W R549 ERJ6GEYJ102 M 1KOHM,J,1/10W R550 ERJ6GEYJ105 M 1MOHM,J,1/10W R551...
  • Page 187 Ref. No. Part No. Part Name & Description Remarks R602 ERJ6ENF3301 M 3.3KOHM, 1/10W R603 ERJ6GEYJ332 M 3.3KOHM,J,1/10W R604 ERJ6GEYJ122 M 1.2KOHM,J,1/10W R606 ERJ6ENF1201 M 1.2KOHM, 1/10W R607 ERJ6GEYJ822 M 8.2KOHM,J,1/10W R608 ERJ8GEYJ332 M 3.3KOHM, J,1/8W R609 ERJ6GEYJ822 M 8.2KOHM,J,1/10W R610,11 ERJ6GEYJ103 M 10KOHM,J,1/10W...
  • Page 188 Ref. No. Part No. Part Name & Description Remarks R662 ERJ6ENF1303 M 130KOHM, 1/10W R663 ERJ3GEYJ2R2 M 2.2 OHM,J,1/16W R664 ERJ6ENF9101 M 9.1KOHM, 1/10W R665 EVMAASA00B23 CONTROL 2KOHMB R666 ERJ6GEYJ102 M 1KOHM,J,1/10W R667,68 ERJ8GEY0R00 M 0 OHM, 1/8W R669 ERJ6ENF1303 M 130KOHM, 1/10W R670 ERJ6GEYJ102...

  • Page 189: Schematic Diagram For Printing With A4

    Ref. No. Part No. Part Name & Description Remarks R920 ERJ6GEYJ104 M 100KOHM,J,1/10W R921 ERJ6RBD3092 M30.9KOHM,F,1/10W R922 ERJ6GEYJ101 M 100 OHM,J,1/10W R925 ERJ6GEYJ335 M 3.3MOHM,J,1/10W R926,27 ERG2DJW224E M 220KOHM, J, 2W R928-31 ERJ8ENF1203 M 12KOHM, 1/8W R932 ERJ6GEYJ105 M 1MOHM,J,1/10W RL402 TSEH8011 RELAY...
  • Page 190 2005 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.
  • Page 191 15 Block and Schematic Diagrams 15.1. Schematic Diagram Notes...

  • Page 193: Main Block Diagram

    15.2. Main Block Diagram DIGITAL SIGNAL PROCESSOR/FORMAT CONVERTER SCAN OUT SC23 PLASMA AI PROCESSOR (1.2V)3.3V DC/DC 1.5V CONVERTER VSUS STB3.3V DISCHARGE SC20 CONTROL CONTROL MAIN MPU SDRAM SDRAM SOS1 EEPROM SOS2 FORMAT PLASMA AI CONVERTER CONTROL SUB-FIELD PULSE PROCESSOR PROCESSOR SDRAM LVDS LVDS...
  • Page 194 POWER DC/DC CONVERTER SUPPLY STBY5V +12V VSUS VSUS ON/OFF SS11 SUSTAIN DRIVE PROCESS VOLTAGE SUSTAIN RECTIFIER VOLTAGE SDRAM RECTIFIER PLASMA AI PROCESS SUSTAIN VOLTAGE VOLTAGE SUB-FIELD CONTROL CONTROL PROCESSOR ADDRESS STANDBY STB14V VOLTAGE VOLTAGE POWER (VE) STB5V RECTIFIER FACTOR CONTROL SUSTAIN PULSE STANDBY...

  • Page 195: P-Board Block Diagram

    15.3. P-Board Block Diagram POWER SUPPLY D417 PR401 D419 395V D420 T401 Q404 Q406 L402 D415 PR402 C405 Q401 IC406 CURR DRIVE POWER CURR FACTOR COMP CONTROL IC52 BUFF Q420 Q422 Q407 COLD L403 Q418 Q421 AC CORD R443 PFC DET F402 L404 L405...
  • Page 196 COLD D539 Q527 SS12 T404 D531 395V Vda 75V Q412 D532 D542 D544 D545 Q408 +15V D534 STB12V D536 IC512 STB_PS ERROR DET PR402 Q413 (Vda) R665 Q409 DC15V T402 C405 D535 PR509 T407 DC12V SC23 D568 +15V +15V D521 SS11 D530 Vsus...

  • Page 197: P-Board (1 Of 6) Schematic Diagram

    15.4. P-Board (1 of 6) Schematic Diagram D504 MA165 D503 RL402 MA165 DG12D1-O(M)-2 0.25W TV-8 COLD RL403 DJ12D2-O(M)0.25W Z451 Z450 EYF52BCY EYF52BCY F401 L404 SC06-120J ZH67 ZH10 R410 10/5W AC CORD T8AH 250V ZH12 ZH104 ZH108 ZH110 ZH102 ZH106 LIVE CAUTION ZN402 L405...
  • Page 198 P-BOARD TNPA3570 (1/6) TV-8 COLD C461 330p C449 ZH73 ZH75 C443 1000p PR401 ZH54 ZH55 0216005.MXEP ZH30 ZH31 ZH32 ZH33 ZH34 ZH35 D417 RU30ALF014 ZH40 ZH42 R417 ZH37 D419 430K[F] ZH36 D415 RU30ALF014 AW04V0 ZH51 ZH43 ZH38 L402 ZH20 EXCELSA24V T401 Q406 Q404...

  • Page 199: P-Board (2 Of 6) Schematic Diagram

    15.5. P-Board (2 of 6) Schematic Diagram P-BOARD TNPA3570 (2/6) COLD C605 150u/160V ZH57 ZH58 T404 G4D4A0000109 ZH79 ZH99 ZH65 ZH86 C604 Q412 150u/160V ZH63 ZH56 D539 B1DAGQ000013 D8LD40 ZH94 D423 MA188 ZH81 C451 100P ZH66 ZH62 R476 R478 R680 ZH72 ZH74 Q408...
  • Page 200 67.0 SS-BOARD C605 Q527 150u/160V 15.0 (SS12) +15V B1DEHL000018 ZH84 ZH83 R631 R674 R676 12.0 STB_PS 12.0 C624 STB12V 1[KB] D543 C604 MAZ41500MF R662 150u/160V K1KA05A00139 130K[F] IC512 AVR DC75V R669 C625 130K[F] C0DAEMB00004 R632 R680 C581 C584 0.022[KB] 0.022[KB] D542 R664 C577...

  • Page 201: P-Board (3 Of 6) Schematic Diagram

    15.6. P-Board (3 of 6) Schematic Diagram P-BOARD (1/6) R926 220K ZH68 ZH69 R413 D404 10/5W S1WB(A)80-7101 D435 D467 R927 ERA15-10 ERA15-10 220K R481 R411 R474 10/5W 100K/1W R483 ZH13 ZH14 R479 100K/1W R455 R903 R928 120K[F] 120K[F] R909 R488 R904 R929 Q432...
  • Page 202 P-BOARD TNPA3570 (3/6) COLD Q518 B1DEHL000018 Q519 B1DEHF000002 C562 L501 EXCELSA35T D507 0.1[KB] MA4150-M R555 PR501 D508 K5H502Z00003 MA4150-M D566 D1NL20U-7070 R564 470K T410 R550 C529 G4D2A0000229 1[KB] R570 1000 Q560 ZH89 R635 B1CHHG000002 100K Q558 B1CHHG000002 R521 C512 C513 470P[JC] 470P[JC] IC503...

  • Page 203: P-Board (4 Of 6) Schematic Diagram

    15.7. P-Board (4 of 6) Schematic Diagram P-BOARD P-BOARD TNPA3570 (4/6) (2/6) C525 820/25V K1KA06A00220 14.0 F_STB_14V 14.0 F_STB_14V 14.0 F_STB_14V PA-BOARD (PA10) PR601 T 3.15A 250V ZH29 D501 RU30ALF014-102 ZH39 R526 220K C591 Q507 R527 ZH27 220K 0.015 B1DAGQ000013 C616 D587 1000P...
  • Page 204 P-BOARD (2/6) SS-BOARD (SS11) K1KA07A00096 PR601 185.1 Vsus 185.1 R620 R622 ZH47 ZH25 T 3.15A 250V Vsus 150K[F] R648 R589 D501 150K[F] ZH26 RU30ALF014-102 IC506 ZH46 R636 C0ZBZ0000878 R590 150K[F] ZH23 ZH24 SHUNT REGULATOR R626 R621 150K[F] K1KA06A00180 185.1 Q505 R526 VSUS 220K...

  • Page 205: P-Board (5 Of 6) Schematic Diagram

    15.8. P-Board (5 of 6) Schematic Diagram P-BOARD (3/6) IC411 COMPARATOR Q417 C0BBAA000040 B1CHND000004 IC402 C0BBAA000040 R404 C405 100K 0.01[KB] COMPARATOR R494 R416 560K[F] 3300 R408 R495 100K 560K[F] R496 560K[F] R453 1000 Q403 R497 B1CBGD000001 24K[F] 2SD181 C421 C418 0.01[KB] 1[KB] R418...
  • Page 206 IC402 C0BBAA000040 COMPARATOR R494 R487 560K[F] 6800 R495 R486 560K[F] 6800 COLD R496 560K[F] Q421 R497 C482 Q418 2SD1819ARL 24K[F] R693 0.1[KB] 2SD1819ARL C418 4700 1[KB] R450 1000 R480 C422 91K[F] R692 0.01[KB] 4700 C635 0.01[KB] IC401 IC404 CNC1S171RLL2 CNC1S171RLL2 PHOTO COUPLER PR503...

  • Page 207: P-Board (6 Of 6) Schematic Diagram

    15.9. P-Board (6 of 6) Schematic Diagram P-BOARD (4/6) P-BOARD TNPA3570 (6/6) D-BOARD (D25) K1KA20A00085 12.0 12.0 FAN_CONT STB5V F_STBY_ON FAN_SOS ECO_ON PS_SOS Panel_Main_ON ALL_OFF RUSH_ON KILL_SOS K1KA05A00177 15.4 +15V FAN_SOS FAN_CONT TH-37/42PWD8 SERIES P-Board (6 of 6) Schematic Diagram...
  • Page 208 OARD TH-37/42PWD8 SERIES P-Board (6 of 6) Schematic Diagram...

  • Page 209: Ha-Board Block And Schematic Diagram

    15.10. HA-Board Block and Schematic Diagram HA-BOAR HA BNC COMPONENT VIDEO J-BOARD SLOT JK3001 COMPONENT VIDEO IN PB/B PR/R JK3002 K2HA204B0097 SLOT+9V Q3001 AUDIO IN L AMP JK3002 AUDIO IN L R3004 COMPONENT R3022 180k AUDIO IN R AUDIO IN Q3002 R AMP R3023...
  • Page 210 HA-BOARD TXNHA10RBS L3001 J0HABB000004 LAN15V LAN15V JS3011 JS3014 COMPONENT TP032 L3002 VIDEO IN J0HABB000004 JS3012 JS3015 TP033 TP034 L3003 J0HABB000004 JK3001 -0.8 JS3013 JS3016 K1QBB3BB0002 AB_AUD_R PLUG_DET R3041 AUD_R TP035 L3006 AB_AUD_L AA_SCL2 R3042 L3004 C3012 AUD_L Q3001 C3011 J0HABB000003 R3016 TP036 AA_SDA2...

  • Page 211: Hb-Board Block Diagram

    15.11. HB-Board Block Diagram HB BNC COMPOSITE/S VIDEO IC3103 GC2M IC3003 Q3006 Q3101,3102 BUFFER BUFFER Q3002 JK3001 IC3003 Analog Front-End IC3003 S-VIDEO IN SWITCH JK3002 Q3007 Q3104 L.P .F. VIDEO IN/OUT Q3005 BUFFER BUFFER VIDEO Q3003 VIDEO Q3023 JK3004 AUDIO IN Q3051 L AMP L IN...
  • Page 212 IC3104 IC3201 RESET MEMORY FIFO IC3103 IC3251 GC2M LVDS TRANSMITTER J-BOARD SLOT MEMORY CONTROLLOR TX0+ TX0+ TX0- TX0- TX1+ TX1+ Color TX1- 2DScalar Output TX1- Analog Adaptive Decoder Front-End Comb Formatter TX2+ NTSC TX2+ Filter Panorama Mixer TX2- Contast SECAM TX2- NTSC Brightness...

  • Page 213: Hb-Board (1 Of 2) Schematic Diagram

    15.12. HB-Board (1 of 2) Schematic Diagram IC3101 C0DBEZG00004 HB-BOARD TXNHB10QXS (1/2) R3112 1.5k C3102 R3113 0.1u 1.5k IC3003 C3012 0.1u C0ABGB000001 IC3102 C3005 C0DBZLB00001 0.1u ERROR DET R3010 Q3001 C3001 L3001 2SD0601A0L J0HABB000003 D3001 0.1u MA2J72900L R3022 CROMA R3016 C3002 D3002 0.1u...
  • Page 214 IC3101 AVR 2.5V C0DBEZG00004 C3127 3.3V IC3104 R3145 C3159 220u AD2R5V C0EBE0000066 R3112 1.5k RESET R3159 C3105 C3102 R3113 C3103 R3144 R3185 0.1u 1.5k 220u R3143 C3142 C3144 C3132 C3133 C3179 0.1u 0.1u 0.1u 0.1u GC3R3V GC2R5V 220u C3122 C3128 C3129 R3120 R3122...

  • Page 215: Hb-Board (2 Of 2) Schematic Diagram

    15.13. HB-Board (2 of 2) Schematic Diagram HB-BOARD TXNHB10QXS (2/2) C3265 C3266 220u 0.1u 3.3V TS3100 AE_V_Y TS3101 TS3102 AL_S2_DET R3251 AM_HS IC3251 LVDS TRANSMITTER C0ZBZ0000684 AM_VS AE_R AE_L SCL2 SDA2 3.3V L3252 L3251 ELJPA2R2MF ELJPA2R2MF 3.3V C3261 C3264 220u 0.1u AD_TX AD_TX...
  • Page 216 SCL2 SDA2 3.3V AI_TX3+ AI_TX3- AJ_TXC+ AJ_TXC- AH_TX2+ AH_TX2- AK_TX1+ AK_TX1- AD_TX0+ AD_TX0- J-BOARD SLOT C3327 0.1u L3306 ELKE103FA C3328 0.1u L3307 ELKE103FA C3329 0.1u L3308 ELKE103FA C3330 0.1u FACTORY STB5V R3319 SCL2 SDA2 SDA2 SCL2 C3317 R3308 R3309 R3307 R3337 SCL2 SDA2...

  • Page 217: Hx-Board Block Diagram

    15.14. HX-Board Block Diagram PC TYPE INPUT TERMINAL IC3502 DDC EEPROM PC-R TO J14 PC-G PC-G PC-G PC-B PC-B PC-B PC-R PC-R PC-HD JK3511 PC-HD_HX PC-HD PC IN PC-VD PC-VD_HX PC-VD PC_AUDIO_IN_R STB5V STB+5V PC-AUDIO_IN_L PC-TXD PC-RXD JK3513 AUDIO IN JK3509 RS232C TH-37/42PWD8 SERIES...
  • Page 218 TH-37/42PWD8 SERIES HX-Board Block Diagram...

  • Page 219: Hx-Board Schematic Diagram

    15.15. HX-Board Schematic Diagram HX-BOARD TZTNP020YLS (FOR 37 INCH MODELS) L3555 ELJPA100KF C3550 C3551 C3404 C3405 R3653 C3561 Q3531 0.01u 2SD0601A0L 0.1u JK3513 R3776 K2HC103B0105 R3654 R3668 R3663 L3512 J0HAAB000012 AUDIO IN R3529 R3547 180k R3655 Q3532 L3513 R3777 2SD0601A0L J0HAAB000012 R3530 R3548...
  • Page 220 HX-BOARD TZTNP020YNS (FOR 42 INCH MODELS) L3555 ELJPA100KF R3653 C3550 C3405 C3551 C3404 Q3531 C3561 0.01u 2SD0601A0L JK3513 0.1u K2HC103B0105 R3776 R3668 R3654 R3663 FL3512 R3547 J0HAAB000012 R3529 AUDIO IN R3655 180k Q3532 C3562 R3548 2SD0601A0L R3530 R3777 180k R3656 R3672 R3664 FL3513...
  • Page 221 15.16. S1, V1 and V2-Board Block Diagram and Schematic Diagram TO J2 R1554 D1550 STB+3.3V RM001 LED G LED_G REMOTE RECIEVER LED R R1553 LED_R REMOTE_IN R1550 R1551 D1551 C1530 R1500 Q1540 R1552 D1554 REMOTE RECIEVER POWER LED R1511 R1512 R1513 R1510 TO J15...
  • Page 222 V1-BOARD TNPA3640 J-BOARD (J2) D1550 LNJ107W5PRW L1501 STB3.3V STB3.3V LED G L1502 R1554 LED R LED_G L1503 LED_R L1504 R1553 L1505 R1551 R1550 L1506 REMOCON C1530 D1551 MAZ80330LL 6.3V VOUT RM001 Q1540 PNA4701M05TV R1552 R1500 2SD0601ASL D1554 REMOTE RECIEVER 220k MAZ80330LL V2-BOARD TNPA3641 J-BOARD...

  • Page 223: J-Board (1 Of 2) And H3-Board Block Diagram

    15.17. J-Board (1 of 2) and H3-Board Block Diagram J SLOT INTERFACE/SYNC PROCESSOR/SOUND PROCESSOR TO P5 DIG+12V DIG+12V DR15V AUDIO+12V AUDIO+12V AUDIO+12V Q2370 Q2371 12V DET 12V DET Q2372 MUTE SW Q2334 Q2333 D2303 12V DET 12V DET IC8100 AVR 12V IC801 AVR 9V 1.8V...
  • Page 224 S_CLOCK3 S_DATA3 RESET AUDIO MUTE AUDIO L AUDIO R AMP_STB_SW IC2301 DIG12V 10W MONO BTL AMP R JK8500 +R OUT SP_R+ R OUT TONE -R OUT SP_R- L OUT IC2305 2303 EQUALIZER D CONTROL IC2302 AMP_STB_SW 10W MONO BTL AMP L JK8500 +L OUT SP_L+...

  • Page 225: J-Board (2 Of 2) Block Diagram

    15.18. J-Board (2 of 2) Block Diagram SLOT INTERFACE/SYNC PROCESSOR/SOUND PROCESSOR STB3.3V S_CLOCK3 IC3008 AA_SCL3 S_DATA3 IC3004 AA_SDA3 STB5V IIC ON/OFF IC3007 STB5V EX.I/O(SLOT DET IIC CONTROL) AB_SCL3 AB_SCL3 IIC ON/OFF AB_SDA3 AB_SDA3 AH_SLO AC_SCL3 AA_SCL3 RESET 3.3V OUTPUT PORT RESET AC_SDA3 AA_SDA3...
  • Page 226 TO HX1 STB5V IC3003 EX I/O(VIDEO/AUDIO SELECT) T IIC CONTROL) STB5V IC8014 AH_SLOT1_DET AC_SW0 UT PORT OUTPUT PORT(SW0) AC_SW1 RS232C AH_SLOT2_DET OUTPUT PORT(SW1) DRIVER UT PORT AE_SW0 AH_SLOT3_DET OUTPUT PORT(SW0) UT PORT AE_SW1 STB3.3V Q8010- OUTPUT PORT(SW1) AH_SOS_ALL 42inch CONT. Q8013 UT PORT SYNC_INH(M)
  • Page 227 15.19. J-Board (1 of 4) Schematic Diagram (37 inch) J-BOARD TNPA3631AB (1/4) IC801 C0DBAMH00013 DIG12V AVR 9V D_1.8V D_3.3V R801 C807 C802 L801 4.7u 470u G1C470MA0078 R802 R2397 R808 5.1k 9V/0.5A C809 C801 C806 2.2u 0.1u R805 470u C2402 84.5k 0.1u C805 C2403...
  • Page 228 D_1.8V IC2301 10W MONO C1BA00000383 BTL AMP R HP_IN HP_OUT R2351 HP-STB HP_D.C C2362 470u SW_GND C2354 AMP-STB SW_GND R2353 Q2300 SW_B B1BBCF000028 JK8500 SW_E K4BC02B00013 L2330 L8501 ON-TIME 220u G0A2R5H00003 SW_OUT SPEAKER +R OUT C2352 C2366 Vcc(SW) C2412 TERMINAL 2.2u PRE-GND R2357...

  • Page 229: J-Board (2 Of 4) Schematic Diagram (37 Inch)

    15.20. J-Board (2 of 4) Schematic Diagram (37 inch) 3.3V STB3.3V R3125 J-BOARD TNPA3631AB (2/4) IC3008 C0JBAS000215 IIC ON/OFF R3134 100k P-BOARD (P10) F_STB_14V F_STB_14V F_STB14V FL3001 F1J1E1040022 LAN15V C8100 C8101 0.01u FL3000 F1J1E1040022 STB3.3V STB5V_S R8185 2.7k R8183 Q8181 R8186 FL3002 B1CBHD000001...
  • Page 230 IC8001 C8035 C0JBAR000241 0.1u C8003 Q8002 SYNC SELECT 2SD0601A0L 0.1u C8001 R3163 L8001 G1C100K00020 R8072 R8047 R8001 IC8007 R8036 C8049 C8027 R8035 2.2u R8010 0.01u C0JBAR000419 R8003 R8004 R8011 SYNC SWITCH R8017 5.6k R8012 AE_SW0 AE_SW1 R8025 C8009 6.3V R8018 5.6k R8026 C8005...

  • Page 231: J-Board (3 Of 4) Schematic Diagram (37 Inch)

    15.21. J-Board (3 of 4) Schematic Diagram (37 inch) IC8003 C1AA00000706 SYNC SIGNAL PROCESSOR L8003 G1C100K00020 C8036 H.State Clamp Timing 100p R8041 V.State V.Pol. C8045 L8005 Green Sep Filter H.Pol. G1C100K00020 C8025 R8033 Green IN Clamp OUT C8029 100k 0.01u R8056 C8015 0.01u...
  • Page 232 TPJH1 TPJV1 R8065 AG_HD_M AG_VD_M R8067 Q3101 2SD0601A0L C3002 L3003 G1C100K00020 4.7u R3102 R3128 Q3102 C3101 R3129 2SD0601A0L R3103 2.2u Q8019 2SD0601A0L Q3103 R3101 R8089 R3130 2SD0601A0L R3105 R3106 R3104 C3103 R8069 IC3101 2.2u C1AB00002238 5V_M VIDEO BUFFER L3006 SLOT1 G1C100K00020 SLOT2 C3015...

  • Page 233: J-Board (4 Of 4) Schematic Diagram (37 Inch)

    15.22. J-Board (4 of 4) Schematic Diagram (37 inch) IC8014 C0ZBZ0000911 STB3.3V RS232C DRIVER C8084 SHUTDOWN C8080 C8081 0.1u 0.1u AJ_TXD_4 T1_OUT R8124 AJ_RXD_4 R1_IN C8082 R8125 AJ_RXD4 0.1u R1_OUT R8126 ONLINE C8083 AJ_TXD4 T2_OUT T1_IN 0.1u R8127 R2_IN T2_IN R2_OUT STATUS AJ_RXD1...
  • Page 234 J-BOARD TNPA3631AB (4/4) D-BOARD (D5) R3060 D3005 LNJ206R5ARA Q3004 R3007 2SD0601A0L R3023 D3007 MA2J11100L R3116 H-BOARD (H1) D-BOARD (D6) SLOT3.3V STB5V_S R3008 STB5V_S R3024 LAN15V SLOT9V SLOT5V LAN15V R8202 D8200 Q8202 MAZ31500ML 2SD0601A0L R8203 C8200 D8201 R8204 Q8200 MA2J11100L 100k 2SD0601A0L LAN15V R8200...
  • Page 235 15.23. J-Board (1 of 4) Schematic Diagram (42 inch) J-BOARD TNPA3630AB (1/4) IC801 C0DBAMH00013 D_3.3V D_1.8V DIG12V AVR 9V 9V/0.5A R801 C807 C802 4.7u 470u L801 G1C470MA0078 R802 R808 C806 C809 0.1u 2.2u R805 RESET 84.5k C805 R825 C801 C808 R803 8.2k R806...
  • Page 236 D_1.8V IC2301 10W MONO BTL AMP R C1BA00000383 HP_IN HP_OUT C2362 HP-STB HP_D.C 470u R2351 SW_GND C2354 AMP-STB SW_GND R2353 Q2300 SW_B B1BBCF000028 SW_E L2330 JK8500 ON-TIME 220u L8501 K4BC02B00013 SW_OUT G0A2R5H00003 C2352 C2366 SPEAKER +R OUT Vcc(SW) C2412 2.2u C2360 TERMINAL PRE-GND...

  • Page 237: J-Board (2 Of 4) Schematic Diagram (42 Inch)

    15.24. J-Board (2 of 4) Schematic Diagram (42 inch) 3.3V STB3.3V R3125 IC8001 J-BOARD TNPA3630AB (2/4) C0JBAR000241 SYNC SELECT R8001 R3134 100k R8002 R8003 IC3008 R8004 C0JBAS000215 IIC ON/OFF SLOT1 SLOT2 SLOT3 SLOT SLOT SLOT FL3006 SLOT9V F1J1E1040022 C8111 P-BOARD 0.1u (P10) C8105...
  • Page 238 IC8001 C8035 C0JBAR000241 C8003 0.1u R3163 Q8002 0.1u SYNC SELECT 2SD0601A0L C8001 R8072 R8047 L8001 C8049 IC8007 R8036 G1C100K00020 C8027 R8009 R8035 0.01u R8010 C0JBAR000419 2.2u SYNC SWITCH R8011 R8017 5.6k R8012 AE_SW0 AE_SW1 R8025 C8009 6.3V R8018 5.6k C8005 C8007 R8021 2.2k...
  • Page 239 15.25. J-Board (3 of 4) Schematic Diagram (42 inch) IC8003 C1AA00000706 SYNC SIGNAL PROCESSOR L8003 G1C100K00020 H.State Clamp Timing C8036 V.State R8041 V.Pol. 100p C8045 L8005 Green Sep Filter C8029 H.Pol. G1C100K00020 C8025 R8033 0.01u Green IN Clamp OUT 100k 0.01u R8056 C8015...
  • Page 240 TPJH1 TPJV1 R8065 AG_HD_M AG_VD_M R8067 Q3101 2SD0601A0L C3002 L3003 G1C100K00020 4.7u R3128 Q8019 R3102 2SD0601A0L Q3102 R8089 R3103 R3129 2SD0601A0L R8057 R8069 Q3103 R3130 R3101 IC3101 2SD0601A0L R3105 R3106 R3104 5V_M C3103 C3101 C1AB00002238 2.2u 2.2u VIDEO BUFFER L3006 SLOT1 G1C100K00020 SLOT2...
  • Page 241 15.26. J-Board (4 of 4) Schematic Diagram (42 inch) IC8014 C0ZBZ0000911 STB3.3V RS232C DRIVER C8084 SHUTDOWN C8081 C8080 0.1u 0.1u AJ_TXD_4 T1_OUT AJ_RXD1 R8124 AJ_RXD_4 R1_IN C8082 AJ_TXD1 R8125 AJ_RXD4 0.1u R1_OUT R8126 ONLINE C8083 AJ_TXD4 T2_OUT T1_IN 0.1u R8127 R2_IN T2_IN R2_OUT...
  • Page 242 D-BOARD (D5) R3060 D3005 LNJ206R5ARA R3007 Q3004 2SD0601A0L R3023 D3007 MA2J11100L R3116 H-BOARD (H1) D-BOARD (D6) R3008 R3024 D3008 STB5V_S MA2J11100L LAN15V R8202 D8200 Q8202 MAZ31500ML H-BOARD 2SD0601A0L (H2) R8203 C8200 D8201 R8204 Q8200 MA2J11100L 100k 2SD0601A0L LAN15V R8200 D8204 MA2J11100L R8205 R8201...

  • Page 243: D-Board Block Diagram

    15.27. D-Board Block Diagram DIGITAL SIGNAL PROCESSOR FORMAT CONVERTER, PlASMA AI SUB-FIELD PROCESSOR TO J1 IC9002 IC9001 R(M) R/PR(M) P+5V G(M) 3.3V 8bit A/D CONVERTER G/Y(M) +3.3V B(M) R,G,B B/PB(M) MAIN_VIDEO HD(M) 24bit 8-bit Block HD(M) CLAMP Loop VD(M) VD(M) 1.2V 2.5V 3.3V...
  • Page 244 IC9601 TO C11 SIGNAL PROCESSOR VIDEO DATA FORMAT CONVERTER 18bit 1.5V 2.5V 3.3V D11-D16 (D8A D13C) PLASMA AI D21-D26 SUB-FIELD PROCESSOR FL9601 P+3.3V L5VDD3.3V D31-D36 1.5V 2.5V 3.3V ODED ODED CLRD CLRD PCD2 PCD2 VIDEO DATA (D0A D13C) PLASMA AI DIGITAL PICTURE I/P ,FORMAT...

  • Page 245: D-Board (1 Of 12) Schematic Diagram

    15.28. D-Board (1 of 12) Schematic Diagram J-BOARD D-BOARD (1/12) (J1) TZTNP01YLSU (TH-37PWD8GK/GS/UK) R/PR_S TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) R/PR_M TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) G/Y_S G/Y_M B/PB_S B/PB_M HD_S P12V R9951 VD_S C9952 C9951 IC9951 3.3V HD_M 4.7u 220u C0DBAMH00013 DPMS_HD 3.3V VD_M L9951 R9953 SWITCHING REG.
  • Page 246 J-BOARD (J1) R/PR_S *R9028 R/PR_M G/Y_S *R9029 ANF_R_M ANF_G_M G/Y_M ANF_B_M B/PB_S *R9030 FL9051 3.3V J0MAB0000175 C9031 0.1u B/PB_M *R9032 HD_S HD_S R9039 *R9034 VD_S VD_S HD_M R9035 R9040 DPMS_HD R9043 DPMS_HD 1.2k R9037 HD_M VD_M R9036 R9041 R9044 DPMS_VD VD_M 1.2k DPMS_VD...

  • Page 247: D-Board (2 Of 12) Schematic Diagram

    15.29. D-Board (2 of 12) Schematic Diagram R9020 ANF_B_M R9008 ANF_G_M R9010 ANF_R_M R9012 D-BOARD (2/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) DG-BOAR TH-37/42PWD8 SERIES (8/12) D-Board (2 of 12) Schematic Diagram...
  • Page 248 IC9002 C0CBCBC00190 3.3V REG C9019 C9020 6.3V 0.1u 3.3V R9020 C9016 C9017 R9023 6.3V VOUT 0.1u R9006 6.8k R9004 C9006 0.1u C9001 0.1u MA_B0 ANF_B_M MA_B1 MA_B2 R9008 C9007 AVSS BOUT2 CLAMP DVDD MA_B3 R9007 0.01u AVDD AVDD DVDD BOUT3 MA_B4 AVSS DVSS...

  • Page 249: D-Board (3 Of 12) Schematic Diagram

    15.30. D-Board (3 of 12) Schematic Diagram FPGA VCCI(3.3V) 3.3V FPGA3.3V FPGA_MODE C9225 C9201 IC9201 IC9201 IC9201 6.3V IC9201 IC9201 IC9201 IC9201 VCCO_7 C9202 IC9201 IC9201 IC9201 IC9201 VCCO_6 0.1u IC9201 IC9201 IC9201 VCCO_7 C9203 IC9201 IC9201 IC9201 VCCO_7 0.1u IC9201 IC9201 IC9201...
  • Page 250 DATA_DRIVER VCCINT(1.2V) 1.2V IC9201 IO_L23P_2 ODEU IC9201 IO_L39N_2 CLRU IC9201 IO_L39P_2 C9214 C9226 IC9201 IO_L39N_3 6.3V C9201 VCCO_7 IC9201 VCCINT IC9201 IO_L24N_2 PCU2 C9215 C9201 VCCO_6 IC9201 VCCINT 0.1u C9201 VCCO_7 IC9201 VCCINT C9216 C9201 VCCO_7 IC9201 VCCINT 0.1u FP_ODED IC9201 IO_L22P_6 ODED...

  • Page 251: D-Board (4 Of 12) Schematic Diagram

    15.31. D-Board (4 of 12) Schematic Diagram 3.3V FL9501 C9502 R9503 G1C150KA0038 6.3V C9504 0.1u C9505 IC9500 C1ZBZ0002 C9506 SYNTHESIZ R9502 R9508 R9505 R9518 IC9103 C0JBAE000354 2.5V->3.3V 3.3V LEVEL CONVERTER C9108 0.1u 3.3V R9148 TDO_2V 4.7k TDO_55 R9149 TDI_55 IC9102 C0JBAZ002198 3.3V->2.5V 2.5V...
  • Page 252 IC9153 C0JBAZ000856 3.3V->5V LEVEL CONVERTER FP_NUEL FP_UMH C9153 FP_UML FP_USH FP_USL FP_UEH R9153 EXB2HV103JV FP_NUEL FP_UMH NUEL FP_UML FP_USH FP_USL FP_UEH IC9154 C0JBAZ000856 R9154 IC9500 3.3V->5V FP_LED(R) C1ZBZ0002769 LEVEL CONVERTER FP_CLRD FP_ODED FP_PCD1(R) C9154 SYNTHESIZER FP_PCD2(R) R9155 FP_CLRD EXB38V103JV FP_ODED CLRD FP_PCD1(R) ODED...

  • Page 253: D-Board (5 Of 12) Schematic Diagram

    15.32. D-Board (5 of 12) Schematic Diagram FL9602 FL9601 L5VDD3.3V 3.3V L5P1.5V F1J1E1040022 F1J1E1040022 1.5V C9692 C9693 C9694 C9691 6.3V 6.3V 0.1u 0.1u L5VDD3.3V R9616 R9607 R9609 IC9601 XRST P3V_SDA2 IC9601 R9611 IC9601 XSPLLRST P3V_SCL2 IC9601 R9608 IC9601 R9617 IC9601 XMPLLRST C9682 C9683...
  • Page 254 D-BOARD (5/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) R9616 3V_SDA2 IC9601 3V_SCL2 L5_ADRSA00 IC9601 IC9601 ADRSA00 L5_SDDA00 L5_ADRSB00 IC9601 SDDA00 IC9601 ADRSB00 IC9601 AA13 SDDB00 R9617 L5_ADRSA01 IC9601 ADRSA01 L5_SDDA01 L5_ADRSB01 L5_SDDB01 IC9601 SDDA01 IC9601 AA10 ADRSB01 IC9601 AB13 SDDB01 L5_ADRSA02...

  • Page 255: D-Board (6 Of 12) Schematic Diagram

    15.33. D-Board (6 of 12) Schematic Diagram ZA001 ZA007 K4CD01000013 K4CD01000013 SDRAM-A C9531 C9533 C9532 L5VDD3.3V C9529 C9530 220u 0.1u 0.1u 0.1u 0.1u IC9602 64Mbit SDRAM-A C3ABPJ000071 C9521 C9522 C9523 C9524 C9526 C9527 C9528 C9525 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u...
  • Page 256 C9528 0.1u D-BOARD (6/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) C9548 TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) 0.1u TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) DG-BOARD TH-37/42PWD8 SERIES (12/12) D-Board (6 of 12) Schematic Diagram...

  • Page 257: D-Board (7 Of 12) Schematic Diagram

    15.34. D-Board (7 of 12) Schematic Diagram DG-BOARD (1/12) IC9953 C0DBEJG00001 STB5V->STB3.3V REG. J-BOARD (J3) FL9707 STB5V_M F1J1E1040022 B1ABCF0 STB5V STB3.3V P12V R9982 STB3.3V STB5V AR_IIC_CONT R9881 R9984 IIC_CONT R9983 R9981 1.6k R9882 EXB38VR000V C9991 C9992 3V_SCL1 STB5V_M SCL1 0.1u 3V_SDA1 R9985 C9994...
  • Page 258 D-BOARD (7/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) 3.3V TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) R9993 R9995 TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) Q9953 B1ABCF000138 P12V P12V STB5V R9994 R9992 IIC CONT STB3.3V FACTORY Q9952 R9843 R9844 B1ABCF000138 5.6k R9845 FL9701 Q9951 F1J1E1040022 AR_IIC_CONT AR_IIC_CONT STB3.3V B1ABCF000138 TP9701 R9991 Q9708 C9746 STB3.3V B1CBHD000001...

  • Page 259: D-Board (8 Of 12) Schematic Diagram

    15.35. D-Board (8 of 12) Schematic Diagram R9808 D9707 C9726 DG-BOAR MA2J72800L 1000p (2/12) C9709 STB3.3V 0.1u STB3.3V R9810 C9741 R9826 R9806 R9830 0.1u Q9707 R9701 B1ABCF000138 R9828 AA_REMOCON R9829 R9827 SDA2 R9834 P65/A06 PC4/SDA1 P67/A08 P51/OE SCL2 120 CPUMD0 P64/A05 P84/A21 P52/WE...
  • Page 260 DG-BOARD (2/12) STB3.3V R9805 R9806 R9798 AAE_MCCLK AAE_MCDATA_O 2.5V C9738 2.5V 3.3V R9796 R9803 C9737 100p R9785 0.1u 3.3V IC9704 Q9701 SDA2 R9801 Vout PC4/SDA1 B1CBHD000001 SCL2 C0EBE0000447 PC5/SCL1 R9791 0/WDOUT/SBT2 RESET N.C. N.C. 2.7k R9795 PD1/STOP/SBI2 AAE_MCLD R9297 PD2/SBO2 P_DATA 4.7k STB_ON...

  • Page 261: D-Board (9 Of 12) Schematic Diagram

    15.36. D-Board (9 of 12) Schematic Diagram FPGA DG-BOARD (3/12) R9221 RESE P3V_SCL2 IC9201 IO_L20P_3 IC9201 IO_L16N_7 DA_SWS P3V_SDA2 IC9201 IO_L20N_3 IC9201 IO/VREF_0 DA_SWM DRVMUTE R9222 DRVRST IC9201 IO/VREF_5 NRST IC9201 MODEL SELECT IC9201 IC9201 IO_L31N_1/VREF_1 IC9201 IO/VREF_0 MODEL0 IC9201 IO_L28P_0 IC9201 IO_L31P_1...
  • Page 262 OARD OUTPUT_SUB IC9201 IO_L01N_6/VRP_6 S_ROUT0 R9277 EXB2HV470JV SUB_R0 IC9201 IO_L01P_6/VRN_6 S_ROUT1 RESET SUB_R1 IC9201 IO_L16N_6 S_ROUT2 SUB_R2 DRVMUTE SUB_R3 IC9201 IO_L17N_6 S_ROUT3 IC9201 IO_L17P_2/VREF_2 DRVMUTE SUB_R4 S_ROUT4 DRVRST IC9201 IO_L01N_5/RDWR_B IC9201 IO_L16N_2 DRVRST SUB_R5 NRST SUB_R6 IC9201 IO_L01P_5/CS_B S_ROUT5 IC9201 IO_L30P_1 NRST SUB_R7...

  • Page 263: D-Board (10 Of 12) Schematic Diagram

    15.37. D-Board (10 of 12) Schematic Diagram D-BOARD (10/12) DG-BOARD TZTNP01YLSU (TH-37PWD8GK/GS/UK) (4/12) TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) 3.3V R9145 3.3V C9102 R9129 IC9605 0.1u Vout R9130 C0EBE0000066 C9696 0.1u RESET R9132 ROM_AD18 ROM_A18 R9570 ROM_AD19 ROM_A19 R9569 ROM_AD20 ROM_A20 R9568 R9571...
  • Page 264 DG-BOARD (4/12) FACTORY TCK_BS TMS_BS R9133 TDO_55 R9134 TDO_TED R9108 TRST_BS EXB38V103JV AF_SL0 R9137 P12V AF_SL1 R9139 AF_SL2 AF_SL3 3.3V AF_SL4 R9140 4.7k R9109 4.7k R9142 R9144 R9110 R9145 4.7k EXB38V103JV DO_DA1 DO_DC2 DO_DB2 DO_DA2 R9111 EXB38V103JV DO_DC3 R9113 DO_DB3 R9114 DO_DA3 R9115...

  • Page 265: D-Board (11 Of 12) Schematic Diagram

    15.38. D-Board (11 of 12) Schematic Diagram DG-BO IC9601 (5/12) IC9601 IC9601 IC9601 IC9601 MN84513-A IC9601 SIGNAL PROCESSOR IC9601 C9676 FORMAT CONVERTER IC9601 PLASMA AI IC9601 SUB-FIELD PROCESSOR IC9601 DCK_M MAIN_G0 MAIN_B0 MAIN_R0 IC9601 DCKA IC9601 GYIA0 IC9601 BUIA0 IC9601 RVIA0 IC9601 R9601...
  • Page 266 L5VDD3.3V L5VDD3.3V DG-BOARD (5/12) IC9601 SDIV0 R9633 R9649 IC9601 IICLPFON IC9601 SDIV1 LPF ON R9635 IC9601 SDCLSEL R9651 IC9601 SDIV2 R9637 IC9601 XSPLLPDN R9652 IC9601 SDIV3 IC9601 TEST0 IC9601 XMPLLPDN R9638 R9653 IC9601 TEST1 IC9601 MUTE R9654 IC9601 TEST2 IC9601 MDIV0 IC9601 TEST3...

  • Page 267: D-Board (12 Of 12) Schematic Diagram

    15.39. D-Board (12 of 12) Schematic Diagram LSI55ROM 3.3V C9561 C9562 4.7u 0.1u IC9303 16Mbit FLASH ROM TVRN627 3.3V R9319 R9320 R932 R9313 C9306 TP9001 C9305 R9317 0.1u 4.7u Q9303 3.3V TP9330 B1ABCF000138 R9314 R9318 4.7k 5V DET 100k R9316 D9301 TP9329 B0ACCE000005...
  • Page 268 DG-BOARD (6/12) D-BOARD (12/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) R9321 TP9330 5V DET TP9370 TH-37/42PWD8 SERIES D-Board (12 of 12) Schematic Diagram...

  • Page 269: C1 And C2-Board Block Diagram

    15.40. C1 and C2-Board Block Diagram TO D34 Data +5V(P) 18bit DATA DRIVER IC7101 (RIGHT) BUFFER DATA DRIVER (LEFT) 8bit 8bit 2bit 8bit IC7104 IC7106 IC7105 BUFFER BUFFER BUFFER 6bit 6bit 6bit 6bit +5V(P) +5V(P) +5V(P) +5V(P) 65 64 65 64 /D13 /D11 PANEL DATA DRIVER...
  • Page 270 SUSTAIN SS23 SUSTAIN Data 24bit +5V(P) ATA DRIVER GHT) IC7201 BUFFER 8bit 8bit 8bit IC7203 IC7202 IC7204 BUFFER BUFFER BUFFER 6bit 6bit 6bit 6bit +5V(P) +5V(P) +5V(P) +5V(P) 64 65 PANEL DATA DRIVER TH-37/42PWD8 SERIES C1 and C2-Board Block Diagram...

  • Page 271: C1-Board (1 Of 2) Schematic Diagram (37 Inch)

    15.41. C1-Board (1 of 2) Schematic Diagram (37 inch) C1-BOARD TNPA3541 (1/2) R7175 C7161 R7121 100V 0.47u R7102 R7136 R7137 R7103 C7104 TERM R7162 ZA7101 ZA7102 ZA7103 K4CD01000013 K4CD01000013 K4CD01000013 TH-37/42PWD8 SERIES C1-Board (1 of 2) Schematic Diagram...
  • Page 272 C1_5V C7108 PANEL DATA DRIVER R7125 R7163 R7133 C7153 100p TH-37/42PWD8 SERIES C1-Board (1 of 2) Schematic Diagram...

  • Page 273: C1-Board (2 Of 2) Schematic Diagram (37 Inch)

    15.42. C1-Board (2 of 2) Schematic Diagram (37 inch) C2-BOARD (C22) C1-BOARD TNPA3541 (2/2) C1_5_3V C1_5V R7161 C1_5_3V_B R7117 R7192 220k C7165 R7177 R7123 100V 0.47u R7110 R7138 R7140 R7111 C7106 TERM R7170 R7171 R7135 C7186 100p C7163 R7176 R7122 100V 0.47u R7106...
  • Page 274 C1_5_3V_B C7101 0.1u AH_CLKR AH_NCLKR AH_LED R7126 47 AD_LE1 DOUTDC[17] C1_5V R7127 47 AD_LE2 DOUTDB[17] R7128 47 AH_PCD2 AD_LE3 DOUTDA[17] R7402 DOUTDC[14] R7130 AH_PCD2 AD_CLK11 DOUTDB[14] AH_LED R7132 DOUTDA[14] AD_CLK21 AH_NCLKR DOUTDC[15] AH_CLKR DOUTDB[15] R7178 DOUTDA[15] AA_ODED ODED AA_CLRD CLRD C1_5_3V PCD2 C7135...

  • Page 275: C1-Board (1 Of 2) Schematic Diagram (42 Inch)

    15.43. C1-Board (1 of 2) Schematic Diagram (42 inch) C1-BOARD TNPA3545 (1/2) R7175 R7172 R7102 C7161 R7121 100V 0.47u R7136 R7137 C7104 TERM R7162 C7153 100p TH-37/42PWD8 SERIES C1-Board (1 of 2) Schematic Diagram...
  • Page 276 R7175 R7172 R7102 7161 R7121 R7136 R7137 C1_5V C7108 PANEL DATA DRIVER R7125 R7163 R7133 ZA7101 ZA7102 ZA7104 K4CD01000013 K4CD01000013 K4CD01000013 TH-37/42PWD8 SERIES C1-Board (1 of 2) Schematic Diagram...

  • Page 277: C1-Board (2 Of 2) Schematic Diagram (42 Inch)

    15.44. C1-Board (2 of 2) Schematic Diagram (42 inch) C2-BOARD (C22) C1_5V C1_5_3V C1-BOARD TNPA3545 (2/2) R7161 C1_5_3V_B R7192 R7117 220k C1_5V(SS) C1_5V R7109 C7165 R7177 R7174 100V 0.47u R7110 R7111 R7138 R7140 C7106 C1_5V TERM R7170 R7171 C7186 R7134 100p C7163 R7173...
  • Page 278 C1_5_3V_B C7101 0.1u C1_5V AH_CLKR _5_3V AH_NCLKR AH_LED R7161 5_3V_B R7126 AD_LE1 R7127 47 AD_LE2 R7192 R7128 AH_PCD2 AD_LE3 DOUTDC[17] V(SS) C1_5V DOUTDB[17] R7108 R7109 DOUTDA[17] DOUTDC[14] DOUTDB[14] R7130 DOUTDA[14] AD_CLK11 R7132 DOUTDC[15] AD_CLK21 DOUTDB[15] DOUTDA[15] R7119 AA_ODED ODED AA_CLRD CLRD R7120 AH_PCD2...

  • Page 279: C2-Board (1 Of 2) Schematic Diagram (37 Inch)

    15.45. C2-Board (1 of 2) Schematic Diagram (37 inch) C2_5V R7247 C023 C2_5_3V_B C7201 0.1u AC_CLKL R7230 AC_NCLKL AB_CLK11 AC_LED R7232 AB_CLK21 R7226 AB_LE4 BA_UEH R7227 AB_LE5 BA_USL R7228 AB_LE6 BA_USH AC_PCD1 BA_UML R7229 AB_LE7 BA_UMH R7278 BA_NUEL NUEL BA_DRV_SOS9 DRV_SOS9 DRV_SOS2 AC_NCLKL...
  • Page 280 SS-BOARD (SS23) C2_5V R7247 C023 C2_5V C2_5_3V R7310 C2_5_3V_B R7311 R7217 220k ZA7201 ZA7202 ZA7203 ZA7204 C1-BOARD K4CD01000013 K4CD01000013 K4CD01000013 K4CD01000013 (C12) R7313 C7268 R7219 100V 0.47u R7207 R7206 R7233 R7234 C7209 C2_5V PANEL DATA DRIVER R7293 R7296 C7254 C2_5V 100p R7316 C7266...

  • Page 281: C2-Board (2 Of 2) Schematic Diagram (37 Inch)

    15.46. C2-Board (2 of 2) Schematic Diagram (37 inch) C2-BOARD TNPA3542 (2/2) R7315 R7221 R7214 R7215 R7237 R723 C7222 C2_5V TERM R7225 R7301 R7245 R7314 R7220 R7210 R7211 R7239 R724 C7219 C2_5V TERM R7297 R7246 TH-37/42PWD8 SERIES C2-Board (2 of 2) Schematic Diagram...
  • Page 282 C7272 100V R7315 R7221 0.47u R7214 R7215 R7237 R7238 C7206 PANEL DATA DRIVER R7304 C7282 100p C7270 100V R7314 R7220 0.47u R7210 R7211 R7239 R7240 C7205 PANEL DATA DRIVER R7300 C7283 100p TH-37/42PWD8 SERIES C2-Board (2 of 2) Schematic Diagram...

  • Page 283: C2-Board (1 Of 2) Schematic Diagram (42 Inch)

    15.47. C2-Board (1 of 2) Schematic Diagram (42 inch) SS-B (SS2 C2_5V(SS) R7213 BA_UEH BA_USL BA_USH C2_5_3V_B C7201 BA_UML 0.1u BA_UMH AC_CLKL BA_NUEL R7230 NUEL AC_NCLKL AB_CLK11 AC_LED BA_DRV_SOS9 R7232 DRV_SOS9 R7226 AB_LE4 AB_CLK21 DRV_SOS2 R7227 AB_LE5 R7228 AB_LE6 AC_CLKL CLK[0](+) AC_PCD1 AC_NCLKL...
  • Page 284 SS-BOARD (SS23) C2_5V C2_5V(SS) C2_5_3V R7251 R7213 C2_5_3V_B C7218 R7259 R7217 C2_5V(SS) C2_5V 220k R7252 C1-BOARD (C12) C7268 R7205 R7253 100V ERJ8GEY0R00V 0.47u R7206 R7207 R7233 R7234 C2_5V PANEL DATA C7209 DRIVER R7293 R7296 C7254 C2_5V 100p R7245 C7266 R7244 R7204 100V ERJ8GEY0R00V...

  • Page 285: C2-Board (2 Of 2) Schematic Diagram (42 Inch)

    15.48. C2-Board (2 of 2) Schematic Diagram (42 inch) C2-BOARD TNPA3546 (2/2) R7209 R7243 R7215 R7214 R7237 R7238 C2_5V C7222 TERM R7225 R7223 R7220 C7270 R7208 R7283 100V 0.47u R7210 R7211 R7239 R7240 C7219 C2_5V TERM R7297 R7221 TH-37/42PWD8 SERIES C2-Board (2 of 2) Schematic Diagram...
  • Page 286 C7272 R7209 R7243 100V 0.47u R7215 R7214 R7237 R7238 PANEL DATA DRIVER C7206 R7254 C7256 100p C7270 R7208 R7283 100V 0.47u R7210 R7211 7239 R7240 PANEL DATA C7205 DRIVER R7255 C7255 100p TH-37/42PWD8 SERIES C2-Board (2 of 2) Schematic Diagram...

  • Page 287: Sc-Board Block Diagram

    15.49. SC-Board Block Diagram COLD CHASSIS GROUND SCAN DRIVE ENERGY RECOVERY IC6602 PHOTO C FET DRIVER D6624 L6611,12,13 Q6621 L6614,15,16 IC6605 TO D20 SC20 BUFFER 1/2 Vo Q6624 IC6607 D6629 AND GATE PHOTO C Vsus GEN. IC6601 S2 CMH FET DRIVER Q6601 VSUS Q6611...
  • Page 288 COLD CHASSIS GROUND FLOATING GROUND TO SD42 SC42 IC6501 A1 B1 PC6505 BUFFER PHOTO COUPLER FCLD A30 B30 FSID FCLU FSID FCLD FCLKD FCLD FCLKD FCLKU FCLKD PROD PROD PC6507 IC6502 VF5V A6 B6 VF5V A7 B7 PHOTO COUPLER BUFFER FSIU FSID PC6509...

  • Page 289: Sc-Board (1 Of 2) Schematic Diagram

    15.50. SC-Board (1 of 2) Schematic Diagram SC-BOARD (1/2) TNPA3543AB (37inch) TNPA3543 (42inch) P-BOARD (P2) 185.1 175V Vsus L6602 185.1 G0ZZ00002183 C6601 C6602 C6603 Vsus 200V 200V 200V 220u 220u 220u Q6621 L6647 42INCH: B1DEKM000001 J0JJC0000021 37INCH: 2SK3996000VP R6641 R6642 R6661 P-BOARD SC23...
  • Page 290 D6491 B0ECHP000003 Q6601 R6611 B1JADN000001 C6611 630V 3900p 190V R6612 C6490 R6499 630V 3300p Q6602 R6613 B1JADN000001 C6612 630V 5600p R6630 Q6621 R6614 200k 42INCH: B1DEKM000001 37INCH: Q6611 2SK3996000VP R6624 R6641 C6621 2SD21850RL 250V Q6603 R6635 B1JADN000001 C6622 R6642 250V C6623 R6636 250V...

  • Page 291: Sc-Board (2 Of 2) Schematic Diagram

    15.51. SC-Board (2 of 2) Schematic Diagram Q6491 D6492 D6471 2SD1263AP0LB B0ECHP000003 MA2J11100L R6461 R6492 R6495 Q6492 200k 150k C6491 400V 2SC1473AEA R6491 R6594 R6493 R6496 100k 100k 270k 150k D6501 MA2J11100L R6497 R6595 Q6461 PC6505 14.3k Q6462 B1BBCJ000004 C6492 R6649 400V R6598...
  • Page 292 C6491 400V ZA6603 K4CD01000013 ZA6602 C6469 K4CD01000013 220u ZA6601 R6621 K4CD01000013 154k C6466 C6479 R6618 Q6461 T6461 R6610 TP45 C6467 2.2k Q6462 0.01u 0.1u B1BBCJ000004 100k ETS13TB139AP D6520 4700p TP40 2SB0709ARL TP64 AB_FSIU B0JCKG000002 R6433 TP41 Q6463 R6616 AB_FCLU R6615 D6519 L6453 2SD0601A0L...

  • Page 293: Su-Board Block Diagram

    15.52. SU-Board Block Diagram SCAN OUT (UP) BOARD IC6901 PDP SCAN DRIVER TO SC45 SU45 HV64 HV63 HV62 FCLK 48 PIN FCLK OUTPUT VF5V HV18 To 1st 80pins of VF5V HV17 SCAN ELECTRODES TO SC41 SU41 FSO1 Q6901 FCLK FCLK IC6902 VF5V VF5V...
  • Page 294 To 1st 80pins of SCAN ELECTRODES To 2nd 80pins of SCAN ELECTRODES To 3rd 80pins of SCAN ELECTRODES TH-37/42PWD8 SERIES SU-Board Block Diagram...

  • Page 295: Su-Board Schematic Diagram (37 Inch)

    15.53. SU-Board Schematic Diagram (37 inch) SU-BOARD TNPA3232 To 1st 80pins of SCAN ELECTRODES AD_27 AD_38 AC_75 AC_86 AD_26 AD_39 AC_74 AC_87 AD_25 AD_40 AC_73 AC_88 AD_24 AD_41 AC_72 AC_89 OUT41 OUT24 OUT41 OUT24 OUT35 OUT30 OUT35 OUT30 AD_23 AD_42 AC_71 AC_90 OUT42...
  • Page 296 To 2nd 80pins of To 3rd 80pins of SCAN ELECTRODES SCAN ELECTRODES TPSU1 AC_86 AB_139 AB_150 AA_203 AA_214 AC_87 AB_138 AB_151 AA_202 AA_215 AC_88 AB_137 AB_152 AA_201 AA_216 AC_89 AB_136 AB_153 AA_200 AA_217 OUT41 OUT24 OUT41 OUT24 OUT35 OUT30 OUT35 OUT30 AC_90 AB_135...

  • Page 297: Su-Board Schematic Diagram (42 Inch)

    15.54. SU-Board Schematic Diagram (42 inch) SU-BOARD TNPA3242 To 1st 80pins of SCAN ELECTRODES AD_27 AD_38 AC_75 AC_86 AB_139 AD_26 AD_39 AC_74 AC_87 AB_138 AD_25 AD_40 AC_73 AC_88 AB_137 AD_24 AD_41 AC_72 AC_89 AB_136 OUT41 OUT24 OUT41 OUT24 OUT35 OUT30 OUT35 OUT30 AD_23...
  • Page 298 To 3rd 80pins of SCAN ELECTRODES To 2nd 80pins of SCAN ELECTRODES TPSU1 AB_139 AB_150 AA_203 AA_214 AB_138 AB_151 AA_202 AA_215 AB_137 AB_152 AA_201 AA_216 AB_136 AB_153 AA_200 AA_217 OUT41 OUT41 OUT24 OUT24 OUT35 OUT30 OUT35 OUT30 AB_135 AB_154 AA_199 AA_218 OUT42 OUT36...

  • Page 299: Sd-Board Block Diagram

    15.55. SD-Board Block Diagram SCAN OUT (DOWN) BOARD IC6955 PDP SCAN DRIVER TO SC46 HV64 SD46 FCLK HV33 64 PIN HV32 FCLK OUTPUT HV03 FS01 HV02 VF5V To 1st 80pins of HV01 VF5V SCAN ELECTRODES TO SC42 SD42 FCLK FCLK IC6956 VF5V VF5V...
  • Page 300 To 1st 80pins of SCAN ELECTRODES To 2nd 80pins of SCAN ELECTRODES To 3rd 80pins of SCAN ELECTRODES TH-37/42PWD8 SERIES SD-Board Block Diagram...

  • Page 301: Sd-Board Schematic Diagram (37 Inch)

    15.56. SD-Board Schematic Diagram (37 inch) SD-BOARD TNPA3233 To 1st 80pins of SCAN ELECTRODES AD_27 AD_38 AC_91 AC_102 AB_155 AD_26 AD_39 AC_90 AC_103 AB_154 AD_25 AD_40 AC_89 AC_104 AB_153 AD_24 AD_41 AC_88 AC_105 AB_152 OUT41 OUT24 OUT41 OUT24 OUT35 OUT30 OUT35 OUT30 AD_23...
  • Page 302 DOWN To 2nd 80pins of To 3rd 80pins of SCAN ELECTRODES SCAN ELECTRODES TPSD1 AB_155 AB_166 AA_219 AA_230 AB_154 AB_167 AA_218 AA_231 AB_153 AB_168 AA_217 AA_232 AB_152 AB_169 AA_216 AA_233 OUT41 OUT24 OUT41 OUT24 OUT35 OUT30 OUT35 OUT30 AB_151 AB_170 AA_215 AA_234 OUT42...

  • Page 303: Sd-Board Schematic Diagram (42 Inch)

    15.57. SD-Board Schematic Diagram (42 inch) SD-BOARD TNPA3243 To 1st 80pins of SCAN ELECTRODES AD_27 AD_38 AC_91 AC_102 AB_155 AD_26 AD_39 AC_90 AC_103 AB_154 AD_25 AD_40 AC_89 AC_104 AB_153 AD_24 AD_41 AC_88 AC_105 AB_152 OUT41 OUT24 OUT41 OUT24 OUT35 OUT30 OUT35 OUT30 AD_23...
  • Page 304 DOWN To 3rd 80pins of SCAN ELECTRODES To 2nd 80pins of SCAN ELECTRODES TPSD1 AB_155 AB_166 AA_219 AA_230 AB_154 AB_167 AA_218 AA_231 AB_153 AB_168 AA_217 AA_232 AB_152 AB_169 AA_216 AA_233 OUT41 OUT24 OUT41 OUT24 OUT35 OUT30 OUT35 OUT30 AB_151 AB_170 AA_215 AA_234 OUT42...

  • Page 305: Ss-Board Block Diagram

    15.58. SS-Board Block Diagram SS Sustain Drive TO P12 SS12 SS34 STB PS STB-PS STB12V STB12V TP15V +15V L6003 TPVDA L6004 TO P11 SS11 TPVSUS VSUS L6002 VSUS TO C23 SS23 Vsus GEN. IC6006 IC6001 BUFFER FET DRIVER Q6001 Q6011 Q6002 Q6012 Q6003...
  • Page 306 SS34 STB-PS STB12V SS41 SS42 Panel Sustain Electrode SS43 (42inch) SS44 SS41A SS42A Panel Sustain Electrode SS43A (37inch) SS44A TH-37/42PWD8 SERIES SS-Board Block Diagram...

  • Page 307: Ss-Board Schematic Diagram

    15.59. SS-Board Schematic Diagram SS-BOARD TNPA3544AB (37inch) TNPA3544 (42inch) TPVSUS P-BOARD SS11 (P11) 175V 175V VSUS L6002 C6001 C6003 C6004 VSUS G0ZZ00002183 200V 200V 200V 220u 220u 220u R6033 Q6021 200k 42INCH: B1DEKM000001 37INCH: 2SK3996000VP R6041 C6021 250V R6042 C6022 P-BOARD SS12 TP15V...
  • Page 308 Q6001 B1JADN000001 C6011 PANEL PANEL 630V SUSTAIN SUSTAIN 3900p R6011 ELECTRODE ELECTRODE 42INCH ONLY 37INCH ONLY R6012 SS41 SS41A Q6002 C6012 B1JADN000001 630V 5600p R6013 R6014 Q6003 B1JADN000001 R6033 200k R6015 R6016 C6021 D6015 Q6011 250V B0ECHP000003 2SD21850RL L6018 C6022 J0JJC0000021 250V Q6012...
  • Page 309 INPUT Equipment Setting Alignment menu Procedure Note: · Before adjustment, color signal has not been displayed 1 PC (VGA) Color Picture menu: on panel. Gray Scale Analyzer Standard · The pedestal adjustment has been done. Pattern Picture: · The signal root must be A side. 1) Set G cut off to "...
  • Page 310 Color temperature High A0-11AD A0-11AE A0-11AF Medium A0-11B0 A0-11B1 A0-11B2 A0-11B3 A0-11B4 A0-11B5 Table 2 Drive data addresses (PC/RGB) Color temperature High A0-1180 A0-1181 A0-1182 Medium A0-1183 A0-1184 A0-1185 A0-1186 A0-1187 A0-1188 Table 3 Drive data addresses (NTSC) Color temperature High A0-1189 A0-118A...
  • Page 311 INPUT Equipment Setting Alignment menu Procedure Note: · Before adjustment, color signal has not been displayed Color Picture menu: on panel. (YUV2_HD) Analyzer Standard · The pedestal adjustment has been done. Gray Scale Picture: · The signal root must be A side. Pattern 1) Set G cut off to "...
  • Page 312 Color temperature High A0-119B A0-119C A0-119D Medium A0-119E A0-119F A0-11A0 A0-11A1 A0-11A2 A0-11A3 Table 2 Drive data addresses (YUV2_HD) Color temperature High A0-1192 A0-1193 A0-1194 Medium A0-1195 A0-1196 A0-1197 A0-1198 A0-1199 A0-119A Table 3 Drive data addresses (YUV1_525ip) Color temperature High A0-11A4 A0-11A5...

  • Page 313: Press To Confirm

    How to access the Option menu Press to display the Setup menu. Press to select “OSD Language”. SET UP SIGNAL COMPONENT/RGB-IN SELECT INPUT LABEL POWER SAVE STANDBY SAVE POWER MANAGEMENT AUTO POWER OFF ENGLISH ( US ) OSD LANGUAGE Press and hold until the Options menu is displayed. Setting the Option menus Press to select your preferred menu.
  • Page 314 SUSTAIN TO D34 SS23 SUSTAIN Data Data 24bit +5V(P) 18bit +5V(P) DATA DRIVER IC7101 (RIGHT) BUFFER IC7201 DATA DRIVER BUFFER (LEFT) 8bit 8bit 2bit 8bit 8bit 8bit IC7104 IC7106 IC7105 IC7203 IC7202 IC7204 BUFFER BUFFER BUFFER BUFFER BUFFER BUFFER 6bit 6bit 6bit 6bit...
  • Page 315 DIGITAL SIGNAL PROCESSOR FORMAT CONVERTER, PlASMA AI SUB-FIELD PROCESSOR IC9601 TO J1 IC9002 IC9001 R(M) TO C11 SIGNAL PROCESSOR R/PR(M) P+5V VIDEO DATA G(M) 3.3V 8bit A/D CONVERTER FORMAT CONVERTER 18bit G/Y(M) 1.5V 2.5V 3.3V +3.3V (D8A D13C) D11-D16 PLASMA AI B(M) R,G,B B/PB(M)
  • Page 316 HB BNC COMPOSITE/S VIDEO IC3104 IC3201 RESET MEMORY FIFO IC3103 IC3251 GC2M LVDS TRANSMITTER IC3003 J-BOARD SLOT MEMORY CONTROLLOR TX0+ TX0+ TX0- Q3006 Q3101,3102 TX0- TX1+ BUFFER BUFFER TX1+ Q3002 Color TX1- JK3001 IC3003 2DScalar Output TX1- Analog Adaptive Decoder Comb Formatter Front-End...
  • Page 317 PC TYPE INPUT TERMINAL IC3502 DDC EEPROM PC-R TO J14 PC-G PC-G PC-G PC-B PC-B PC-B PC-R PC-R JK3511 PC-HD PC-HD_HX PC-HD PC IN PC-VD PC-VD_HX PC-VD PC_AUDIO_IN_R STB5V STB+5V PC-AUDIO_IN_L PC-TXD PC-RXD JK3513 AUDIO IN JK3509 RS232C TH-37/42PWD8 SERIES TH-37/42PWD8 SERIES HX-Board Block Diagram HX-Board Block Diagram...
  • Page 318 J SLOT INTERFACE/SYNC PROCESSOR/SOUND PROCESSOR S_CLOCK3 S_DATA3 RESET TO P5 AUDIO MUTE DIG+12V DIG+12V AUDIO L DR15V AUDIO R AUDIO+12V AUDIO+12V AUDIO+12V Q2370 Q2371 12V DET 12V DET Q2372 MUTE SW Q2334 Q2333 D2303 12V DET 12V DET IC8100 AVR 12V IC801 AVR 9V AMP_STB_SW...
  • Page 319 TO HX1 STB5V SLOT INTERFACE/SYNC PROCESSOR/SOUND PROCESSOR STB3.3V S_CLOCK3 AA_SCL3 IC3008 S_DATA3 IC3004 AA_SDA3 IIC ON/OFF STB5V IC3007 IC3003 EX I/O(VIDEO/AUDIO SELECT) STB5V EX.I/O(SLOT DET IIC CONTROL) AB_SCL3 AB_SCL3 STB5V IIC ON/OFF AB_SDA3 AB_SDA3 IC8014 AH_SLOT1_DET AC_SW0 AC_SCL3 AA_SCL3 RESET 3.3V OUTPUT PORT OUTPUT PORT(SW0)
  • Page 320 DIGITAL SIGNAL PROCESSOR/FORMAT CONVERTER SCAN OUT SC23 PLASMA AI PROCESSOR (1.2V)3.3V POWER DC/DC 1.5V CONVERTER VSUS STB3.3V SUPPLY DISCHARGE STBY5V SC20 +12V CONTROL VSUS VSUS ON/OFF SS11 SUSTAIN DRIVE CONTROL PROCESS VOLTAGE MAIN MPU SUSTAIN RECTIFIER VOLTAGE SDRAM SDRAM RECTIFIER SOS1 EEPROM SOS2...
  • Page 321 COLD POWER SUPPLY D539 D417 Q527 PR401 SS12 D419 T404 D531 395V Vda 75V Q412 D532 D420 T401 D542 D544 D545 Q408 +15V Q404 Q406 D534 STB12V D536 IC512 L402 STB_PS D415 ERROR DET PR402 Q413 (Vda) R665 Q409 DC15V C405 T402 D535...
  • Page 322 COLD CHASSIS GROUND FLOATING GROUND SCAN DRIVE TO SD42 SC42 ENERGY RECOVERY IC6501 A1 B1 PC6505 IC6602 BUFFER PHOTO COUPLER FET DRIVER D6624 FCLD L6611,12,13 A30 B30 Q6621 L6614,15,16 FSID IC6605 FCLU FSID TO D20 SC20 BUFFER FCLD FCLKD FCLD 1/2 Vo FCLKD FCLKU...
  • Page 323 SCAN OUT (DOWN) BOARD IC6955 PDP SCAN DRIVER TO SC46 HV64 SD46 FCLK HV33 64 PIN HV32 FCLK OUTPUT HV03 FS01 HV02 VF5V To 1st 80pins of HV01 VF5V SCAN ELECTRODES TO SC42 SD42 FCLK FCLK IC6956 VF5V VF5V PDP SCAN DRIVER HV64 FS01 FCLK...
  • Page 324 SS Sustain Drive TO P12 SS12 SS34 STB PS STB-PS STB12V STB12V TP15V +15V L6003 TPVDA L6004 TO P11 SS11 TPVSUS VSUS L6002 VSUS TO C23 SS23 Vsus GEN. IC6006 IC6001 BUFFER FET DRIVER Q6001 Q6011 Q6002 Q6012 Q6003 Q6006 Q6013 Q6007 Q6014...
  • Page 325 SCAN OUT (UP) BOARD IC6901 PDP SCAN DRIVER TO SC45 SU45 HV64 HV63 HV62 FCLK 48 PIN FCLK OUTPUT VF5V HV18 To 1st 80pins of VF5V HV17 SCAN ELECTRODES TO SC41 SU41 FSO1 Q6901 FCLK FCLK IC6902 VF5V VF5V PDP SCAN DRIVER HV64 FS01 FCLK...
  • Page 326 Parts Location C1-BOARD IC7101 IC7104 IC7105 IC7106 C1-BOARD (FOIL SIDE) TNPA3541 1 2 3 TNPA3541 SEE REVERSE FOR ORDER NO. C1-BOARD (COMPONENT SIDE) TNPA3541 R184 R186 R185 R128 R183 R189 C170 IC101 R132 C181 C169 R105 ZA101 R127 C166 ZA103 C157 C1MM1 R163...
  • Page 327 Parts Location C1-BOARD IC7101 IC7104 IC7105 IC7106 IC7107 C1-BOARD(FOIL SIDE) TNPA3545 TNPA3545 1 C1 SEE REVERSE FOR ORDER NO. 1 2 3 C1-BOARD(COMPONENT SIDE) TNPA3545 FL106 R131 1 C1 C190 TNPA3545 C193 R156 R155 R158 R157 C1MM1 CR No.7 ORDER R159 ZA101 R192...
  • Page 328 Parts Location C2-BOARD IC7201 IC7202 IC7203 IC7204 C2-BOARD (FOIL SIDE) TNPA3542 TNPA3542 1 2 3 REVERSE FOR ORDER C2-BOARD (COMPONENT SIDE) TNPA3542 R274 R253 C223 FL202 R284 R283 R288 R287 R286 R285 R225 R247 R243 C2MM2 C2MM1 R217 C261 C252 C280 C255 IC204...
  • Page 329 Parts Location C2-BOARD IC7201 IC7202 IC7203 IC7204 IC7205 C2-BOARD(FOIL SIDE) TNPA3546 1 C2 TNPA3546 SEE REVERSE FOR ORDER NO. 1 2 3 C2-BOARD(COMPONENT SIDE) TNPA3546 R213 C2MM1 C261 IC205 TNPA3546 C291 C293 R225 R278 R277 C2MM2 FL201 C2MM3 C222 R285 R284 R280 C218...
  • Page 330 D-BOARD(COMPONENT SIDE) TZTNP01YLSU (TH-37PWD8GK/GS/UK) TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) R981 C767 DMM1 FL703 C762 DMM2 R835 C761 C708 R777 R768 C991 R776 FL706 FL704 DMM3 R795 R806 C709 C733 C965 C525 R581 C526 C524 R583 C734 C966 C763 C964 R749 R748 R747...
  • Page 331 D-BOARD(FOIL SIDE) TZTNP01YLSU (TH-37PWD8GK/GS/UK) TZTNP01YLSE (TH-37PWD8BK/BSEK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) R894 R896 Q701 C764 R898 D702 C715 D706 C720 FL705 R891 R984 R893 R770 C716 R897 R899 R764 R892 R895 IC953 D703 R961 R142 R101 R143 R133 Q702 R861 Q703 Q704 R102 D711...
  • Page 332 HA-BOARD(FOIL SIDE) HA-BOARD(COMPONENT SIDE) TXNHA10RBS TXNHA10RBS TNPA2845 ORDER TP034 TP036 CR NO.3 JS009 JS007 C022 Parts Location JS008 R038 JS010 R040 R041 R042 HA-BOARD IC3001 TP3032 IC002 IC3002 TP3033 C017 TP3034 JS001 C018 TRANSISTOR C016 R037 TP3035 C021 R036 TP3036 JS004 Q3001 Q3002...
  • Page 333 HB-BOARD(FOIL SIDE) HB-BOARD(COMPONENT SIDE) TXNHB10QXS TXNHB10QXS 2 HV TNPA2844 A1 A2 A1 A2 ORDER Parts Location HB-BOARD C324 C324 C329 C329 C330 C330 C321 C321 TRANSISTOR L308 L308 L307 L307 IC251 IC251 C319 C319 IC3001 Q3001 R300 C266 C266 IC3002 Q3002 C265 C265...
  • Page 334 HX-BOARD(FOIL SIDE) HX-BOARD(COMPONENT SIDE) TZTNP020YLS TZTNP020YLS CR NO.3 ORDER NO. TNPA2842 TNPA2842 SEE REVERSE FOR ORDER NO. CR NO.3 C405 C404 C409 IC502 R400 L526 D502 L555 R589 C523 R778 C563 C524 R788 D504 R789 R794 D506 R586 Q537 C551 R593 R592 R591...
  • Page 335 HX-BOARD(FOIL SIDE) HX-BOARD(COMPONENT SIDE) TZTNP020YNS TZTNP020YNS TNPA3400 TNPA3400 REVERSE FOR ORDER ORDER CR NO.3 CR NO.3 C409 C405 C404 IC502 R400 L555 R589 C523 R778 C563 D502 C524 R788 D504 R789 R794 D506 R586 Q537 C551 R593 R592 R591 R528 R527 R526 C550...
  • Page 336 Parts Location J-BOARD (COMPONENT SIDE) Q8181 IC8009 Q3104 Q8182 IC8014 Q3105 IC804 IC8016 Q3106 Q8183 IC2301 IC8020 Q8001 Q8184 IC2302 Q8200 IC8021 Q8002 IC2303 Q8201 IC8100 Q8010 IC3002 Q8202 IC8181 Q8011 IC3003 Q8012 Q8203 IC3005 TRANSISTOR Q8013 Q8204 IC3006 Q2333 Q8014 IC3007 Q2334...
  • Page 337 Parts Location J-BOARD (COMPONENT SIDE) IC8003 Q3004 Q8024 IC8004 Q3101 Q8025 IC801 IC8005 Q3102 Q8026 IC802 IC8007 Q3103 Q8181 IC803 Q8182 IC8008 Q3104 IC804 IC8009 Q3105 Q8183 IC2301 IC8014 Q3106 Q8184 IC2302 IC8016 Q8001 Q8200 IC2303 IC8020 Q8002 Q8201 IC2305 Q8202 IC8021 Q8010...
  • Page 338 Parts Location J-BOARD (FOIL SIDE) TRANSISTOR IC801 Q2300 IC802 Q2331 IC803 IC2301 IC2302 IC2305 IC3001 IC3004 IC8003 IC8004 J-BOARD(FOIL SIDE) TNPA3631AB TNPA3631 R2408 REVERSE ORDER R2409 D3061 C2356 C2350 R2368 C830 C2360 R2388 C823 R2355 R8087 Q2300 R820 R2359 R3109 R3113 L2330 C3114...
  • Page 339 Parts Location J-BOARD (FOIL SIDE) TRANSISTOR IC2301 Q3002 IC2302 Q3003 IC8003 IC8004 J-BOARD(FOIL SIDE) TNPA3630AB R2365 TNPA3630 R2408 R2409 R2374 REVERSE FOR ORDER L2330 D3061 C3203 C3202 C3201 IC2301 L2331 R3111 R813 R3204 R2399 IC2302 R3142 C3126 R8022 R3160 C803 C2369 C8185 C2365...
  • Page 340 P-BOARD (COMPONENT SIDE) TNPA3570 TH-37/42PWD8 SERIES TH-37/42PWD8 SERIES P-BOARD TNPA3570 P-BOARD TNPA3570...
  • Page 341 P-BOARD (FOIL SIDE) TNPA3570 TH-37/42PWD8 SERIES TH-37/42PWD8 SERIES P-BOARD TNPA3570 P-BOARD TNPA3570...
  • Page 342 Parts Location Parts Location P-BOARD (FOIL SIDE) P-BOARD (COMPONENT SIDE) TRANSISTOR TRANSISTOR Q441 Q553 Q501 Q554 IC401 Q401 IC406 Q404 Q502 Q557 IC402 Q403 IC503 Q406 Q503 Q558 Q404 IC403 IC504 Q412 Q505 Q559 IC404 Q406 IC509 Q413 Q506 Q560 IC406 Q407 IC512...
  • Page 343 SC-BOARD(COMPONENT SIDE) TNPA3543AB (37inch) TNPA3543 (42inch) R605 R606 R607 ZA603 ZA601 SC42 R554 C598 R557 R553 R552 R435 D500 C526 Q511 Q512 TPSC1 R434 Q542 Q543 Q544 Q545 Q546 Q547 Q548 Q549 SC41 C491 R432 R513 D526 R527 D523 R528 D496 R585 R526...
  • Page 344 SC-BOARD(FOIL SIDE) TNPA3543AB (37inch) TNPA3543 (42inch) TP41 TP42 TP48 TP47 TP49 TP43 TP40 TP46 TP54 TP55 TP56 TP57 TP58 TP59 TP60 TP61 TP62 TP63 R554 TP45 C598 TP51 C551 SC41 SC42 TP64 1 2 3 R513 Q491 C491 4 5 6 R510 R461 Q492...
  • Page 345 Parts Location Parts Location SC-BOARD (FOIL SIDE) SC-BOARD (COMPONENT SIDE) TRANSISTOR TRANSISTOR Q6541 TP6032 Q6542 TP6033 Q6451 TP6001 IC6451 Q6451 TPSC1 Q6543 TP6034 Q6454 Q6454 TP6002 IC6452 TPV15V Q6544 TP6035 Q6491 TP6004 IC6453 Q6461 TPVAD Q6545 TP6038 Q6492 TP6005 IC6454 Q6462 TPVSCN Q6546...
  • Page 346 Parts Location SD-BOARD IC6955 TPSD1 IC6956 TPSD2 IC6957 IC6958 SD-BOARD (FOIL SIDE) TNPA3233 TNPA3233 SEE REVERSE FOR ORDER NO. SD-BOARD (COMPONENT SIDE) TNPA3233 R6959 C6975 C6980 D6962 C6974 C6977 TPSD1 IC6958 IC6956 R6979 TNPA3233 TPSD2 IC6955 ORDER NO. R6958 IC6957 C6958 R6956 C6955...
  • Page 347 Parts Location SD-BOARD TRANSISTOR IC6955 TPSD1 IC6956 TPSD2 IC6957 IC6958 SD-BOARD (FOIL SIDE) TNPA3243 TNPA3243 REVERSE FOR ORDER SD-BOARD (COMPONENT SIDE) TNPA3243 R6959 C6975 C6980 D6962 TPSD1 C6977 IC6956 IC6957 TNPA3243 IC6958 IC6955 TPSD2 ORDER R6958 SD46 R6956 C6955 C6957 C6956 R6978 R6957...
  • Page 348 Parts Location SS-BOARD (COMPONENT SIDE) TRANSISTOR Q6045 Q6046 IC6001 Q6001 Q6051 IC6002 Q6002 Q6052 IC6003 Q6003 Q6055 IC6004 Q6006 Q6056 IC6005 Q6007 IC6006 Q6008 IC6011 Q6011 TPSS1 Q6012 TPSUS Q6013 TPV15 Q6014 TPVDA Q6021 TPVE Q6024 Q6025 Q6041 Q6042 SS-BOARD(COMPONENT SIDE) TNPA3544AB (37 inch) TNPA3544 (42 inch) SS41A...
  • Page 349 Parts Location SS-BOARD (FOIL SIDE) TRANSISTOR TP6016 TP6017 Q6001 TP6001 TP6018 Q6002 TP6002 TP6019 Q6003 TP6003 TP6020 Q6006 TP6004 TP6021 Q6007 TP6005 TP6022 Q6008 TP6006 TP6023 Q6021 TP6007 TP6024 Q6024 TP6008 TP6025 Q6051 TP6009 TP6026 Q6052 TP6010 TP6027 TP6011 TP6028 TP6012 TP6029 TP6013...
  • Page 350 Parts Location SU-BOARD TRANSISTOR IC6901 Q6901 IC6902 IC6903 IC6904 TPSU1 TPSU2 SU-BOARD (FOIL SIDE) TNPA3232 TNPA3232 SEE REVERSE FOR ORDER NO. SU-BOARD (COMPONENT SIDE) TNPA3232 TPSU2 C6933 TPSU1 C6934 C6931 D6910 R6924 TNPA3232 ORDER NO. SU 1 R6904 C6914 R6903 C6901 R6902 SU45...
  • Page 351 Parts Location SU-BOARD TRANSISTOR IC6901 Q6901 IC6902 IC6903 TPSU1 IC6904 TPSU2 SU-BOARD (FOIL SIDE) TNPA3242 TNPA3242 REVERSE FOR ORDER SU-BOARD (COMPONENT SIDE) TNPA3242 C6932 TPSU2 C6933 TPSU1 C6934 C6931 D6910 TNPA3242 IC6901 IC6904 IC6903 ORDER IC6902 R6920 C6903 R6903 SU45 C6914 R6904 C6904...
  • Page 352 V2-BOARD(FOIL SIDE) TNPA3641 TNPA3641 REVERSE ORDER NO. V2-BOARD(COMPONENT SIDE) TNPA3641 SW1554 SW1553 SW1550 SW1551 SW1552 VOL.UP VOL.DOWN TV/VTR V1-BOARD(FOIL SIDE) V1-BOARD(COMPONENT SIDE) TNPA3640 TNPA3640 TNPA3640 RM001 Q1540 R1500 D1550 R1555 L1504 R1552 D1552 R1550 D1553 R1551 SN1550 REVERSE ORDER NO. R1556 S1-BOARD(FOIL SIDE) S1-BOARD(COMPONENT SIDE)
  • Page 353 C1-BOARD TNPA3541 (1/2) R7175 C7161 R7121 100V 0.47u R7102 R7136 R7137 R7103 C1_5V C7104 C7108 PANEL DATA DRIVER TERM R7125 R7162 R7163 R7133 C7153 100p ZA7101 ZA7102 ZA7103 K4CD01000013 K4CD01000013 K4CD01000013 TH-37/42PWD8 SERIES TH-37/42PWD8 SERIES C1-Board (1 of 2) Schematic Diagram C1-Board (1 of 2) Schematic Diagram...
  • Page 354 C1-BOARD TNPA3545 (1/2) R7175 R7172 C7161 R7102 R7121 100V 0.47u R7136 R7137 C7104 C1_5V C7108 PANEL DATA DRIVER TERM R7125 R7163 R7162 R7133 C7153 100p ZA7101 ZA7102 ZA7104 K4CD01000013 K4CD01000013 K4CD01000013 TH-37/42PWD8 SERIES TH-37/42PWD8 SERIES C1-Board (1 of 2) Schematic Diagram C1-Board (1 of 2) Schematic Diagram...
  • Page 355 C1_5_3V_B C7101 C2-BOARD 0.1u (C22) AH_CLKR AH_NCLKR AH_LED C1-BOARD TNPA3541 (2/2) R7126 47 AD_LE1 C1_5_3V C1_5V DOUTDC[17] R7127 47 AD_LE2 R7161 DOUTDB[17] R7128 47 AH_PCD2 AD_LE3 DOUTDA[17] C1_5_3V_B R7117 R7192 220k R7402 DOUTDC[14] R7130 AH_PCD2 AD_CLK11 DOUTDB[14] AH_LED R7132 DOUTDA[14] AD_CLK21 AH_NCLKR DOUTDC[15]...
  • Page 356 C1_5_3V_B C2-BOARD C7101 (C22) 0.1u C1_5V AH_CLKR C1_5_3V AH_NCLKR C1-BOARD TNPA3545 (2/2) R7161 AH_LED C1_5_3V_B R7126 AD_LE1 R7127 47 AD_LE2 R7192 R7117 AH_PCD2 R7128 AD_LE3 220k DOUTDC[17] C1_5V(SS) C1_5V DOUTDB[17] R7108 R7109 DOUTDA[17] DOUTDC[14] DOUTDB[14] R7130 DOUTDA[14] AD_CLK11 DOUTDC[15] R7132 AD_CLK21 DOUTDB[15] DOUTDA[15]...
  • Page 357 SS-BOARD (SS23) C2_5V R7247 C023 C2_5V C2_5_3V R7310 C2_5_3V_B R7217 R7311 220k C2_5_3V_B C7201 0.1u ZA7201 ZA7202 ZA7203 ZA7204 C1-BOARD K4CD01000013 K4CD01000013 K4CD01000013 K4CD01000013 (C12) AC_CLKL R7230 AC_NCLKL AB_CLK11 AC_LED R7232 AB_CLK21 R7226 AB_LE4 BA_UEH R7227 AB_LE5 BA_USL R7228 AB_LE6 BA_USH AC_PCD1 R7313...
  • Page 358 SS-BOARD (SS23) C2_5V C2_5V(SS) C2_5_3V R7251 C2_5_3V_B R7213 C7218 BA_UEH R7259 R7217 C2_5V(SS) C2_5V BA_USL 220k BA_USH C2_5_3V_B R7252 C7201 BA_UML 0.1u BA_UMH AC_CLKL C1-BOARD BA_NUEL R7230 NUEL AC_NCLKL AB_CLK11 (C12) AC_LED BA_DRV_SOS9 R7232 DRV_SOS9 AB_LE4 R7226 AB_CLK21 DRV_SOS2 R7227 AB_LE5 R7228 AB_LE6...
  • Page 359 C2-BOARD TNPA3542 (2/2) C7272 100V R7221 R7315 0.47u R7214 R7215 R7237 R7238 C7222 C2_5V C7206 PANEL DATA DRIVER TERM R7225 R7301 R7304 R7245 C7282 100p C7270 100V R7314 R7220 0.47u R7210 R7211 R7239 R7240 C7219 C2_5V C7205 PANEL DATA DRIVER TERM R7297 R7300...
  • Page 360 C2-BOARD TNPA3546 (2/2) C7272 R7209 R7243 100V 0.47u R7214 R7215 R7237 R7238 C2_5V C7222 PANEL DATA DRIVER C7206 TERM R7225 R7223 R7254 R7220 C7256 100p C7270 R7208 R7283 100V 0.47u R7210 R7211 R7239 R7240 PANEL DATA C7219 C7205 C2_5V DRIVER TERM R7297 R7255...
  • Page 361 J-BOARD D-BOARD (1/12) (J1) TZTNP01YLSU (TH-37PWD8GK/GS/UK) R/PR_S TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) *R9028 TZTNP01YNSU (TH-42PWD8GK/GS/UK) R/PR_M TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) G/Y_S *R9029 ANF_R_M ANF_G_M G/Y_M ANF_B_M B/PB_S *R9030 FL9051 3.3V J0MAB0000175 C9031 0.1u B/PB_M *R9032 HD_S P12V HD_S R9951 R9039 *R9034 VD_S C9951 C9952 IC9951 VD_S 3.3V HD_M...
  • Page 362 IC9002 C0CBCBC00190 3.3V REG C9019 C9020 6.3V 0.1u R9020 3.3V C9016 C9017 R9023 6.3V VOUT 0.1u R9006 6.8k R9004 C9006 0.1u C9001 0.1u MA_B0 ANF_B_M MA_B1 MA_B2 R9008 C9007 AVSS BOUT2 CLAMP DVDD MA_B3 R9007 0.01u AVDD AVDD DVDD BOUT3 MA_B4 AVSS DVSS...
  • Page 363 FPGA VCCI(3.3V) DATA_DRIVER VCCINT(1.2V) 3.3V 1.2V IC9201 IO_L23P_2 ODEU FPGA3.3V IC9201 IO_L39N_2 CLRU FPGA_MODE IC9201 IO_L39P_2 C9225 C9201 C9226 C9214 IC9201 IC9201 IC9201 6.3V 6.3V IC9201 IO_L39N_3 IC9201 IC9201 IC9201 IC9201 VCCO_7 IC9201 VCCINT IC9201 IO_L24N_2 PCU2 C9202 C9215 IC9201 IC9201 IC9201 IC9201...
  • Page 364 IC9153 C0JBAZ000856 3.3V->5V LEVEL CONVERTER FP_NUEL FP_UMH C9153 FP_UML FP_USH FP_USL FP_UEH R9153 EXB2HV103JV FP_NUEL FP_UMH NUEL 3.3V FP_UML FP_USH FL9501 C9502 R9503 G1C150KA0038 6.3V FP_USL FP_UEH C9504 0.1u IC9154 C9505 C0JBAZ000856 R9154 IC9500 3.3V->5V FP_LED(R) C1ZBZ0002769 LEVEL CONVERTER FP_CLRD FP_ODED C9506 FP_PCD1(R)
  • Page 365 D-BOARD (5/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TZTNP01YNSU (TH-42PWD8GK/GS/UK) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) FL9601 FL9602 3.3V L5VDD3.3V L5P1.5V F1J1E1040022 F1J1E1040022 1.5V C9691 C9692 C9693 C9694 6.3V 6.3V 0.1u 0.1u L5VDD3.3V R9616 R9607 R9609 IC9601 XRST P3V_SDA2 IC9601 R9611 IC9601 XSPLLRST P3V_SCL2 L5_ADRSA00 IC9601 IC9601 ADRSA00 L5_SDDA00...
  • Page 366 ZA001 ZA007 K4CD01000013 K4CD01000013 SDRAM-A C9533 C9532 C9531 L5VDD3.3V C9530 C9529 220u 0.1u 0.1u 0.1u 0.1u IC9602 64Mbit SDRAM-A C3ABPJ000071 C9521 C9522 C9523 C9524 C9526 C9527 C9528 C9525 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u 0.1u SDRAM-B R9550 R9553 R9552 R9551 R9549 L5VDD3.3V...
  • Page 367 DG-BOARD (1/12) D-BOARD (7/12) IC9953 C0DBEJG00001 TZTNP01YLSU (TH-37PWD8GK/GS/UK) 3.3V STB5V->STB3.3V TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) R9993 REG. J-BOARD R9995 TZTNP01YNSU (TH-42PWD8GK/GS/UK) (J3) TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) FL9707 STB5V_M Q9953 F1J1E1040022 B1ABCF000138 STB5V STB3.3V P12V P12V R9982 STB3.3V STB5V AR_IIC_CONT R9881 R9984 IIC_CONT R9983 STB5V R9981 1.6k R9882 EXB38VR000V...
  • Page 368 D9707 R9808 C9726 DG-BOARD MA2J72800L 1000p (2/12) C9709 STB3.3V 0.1u STB3.3V R9810 STB3.3V C9741 R9826 R9806 R9805 R9798 R9830 0.1u AAE_MCCLK Q9707 AAE_MCDATA_O R9701 2.5V C9738 2.5V B1ABCF000138 3.3V R9828 R9803 R9796 C9737 100p AA_REMOCON R9785 0.1u 3.3V R9829 IC9704 Q9701 R9827 SDA2...
  • Page 369 FPGA DG-BOARD OUTPUT_SUB (3/12) IC9201 IO_L01N_6/VRP_6 S_ROUT0 R9277 EXB2HV470JV R9221 SUB_R0 IC9201 IO_L01P_6/VRN_6 S_ROUT1 RESET P3V_SCL2 IC9201 IO_L20P_3 SUB_R1 IC9201 IO_L16N_7 DA_SWS IC9201 IO_L16N_6 S_ROUT2 P3V_SDA2 SUB_R2 IC9201 IO_L20N_3 IC9201 IO/VREF_0 DA_SWM DRVMUTE SUB_R3 IC9201 IO_L17N_6 S_ROUT3 R9222 IC9201 IO_L17P_2/VREF_2 DRVMUTE SUB_R4 DRVRST...
  • Page 370 D-BOARD (10/12) DG-BOARD (4/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) FACTORY TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) TCK_BS TZTNP01YNSU (TH-42PWD8GK/GS/UK) TMS_BS R9133 TDO_55 R9134 TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) TDO_TED R9108 TRST_BS EXB38V103JV AF_SL0 R9137 P12V AF_SL1 R9139 AF_SL2 AF_SL3 3.3V AF_SL4 R9140 4.7k R9109 R9142 4.7k R9110 R9145 R9144 4.7k EXB38V103JV DO_DA1 DO_DC2...
  • Page 371 L5VDD3.3V L5VDD3.3V DG-BOARD IC9601 (5/12) IC9601 SDIV0 R9633 R9649 IC9601 IC9601 IICLPFON IC9601 SDIV1 IC9601 IC9601 LPF ON R9635 IC9601 SDCLSEL R9651 IC9601 IC9601 SDIV2 MN84513-A R9637 IC9601 XSPLLPDN IC9601 R9652 IC9601 SDIV3 IC9601 TEST0 SIGNAL PROCESSOR IC9601 XMPLLPDN R9638 IC9601 R9653 C9676...
  • Page 372 DG-BOARD (6/12) D-BOARD (12/12) TZTNP01YLSU (TH-37PWD8GK/GS/UK) TZTNP01YLSE (TH-37PWD8BK/BS/EK/ES) LSI55ROM TZTNP01YNSU (TH-42PWD8GK/GS/UK) 3.3V TZTNP01YNSE (TH-42PWD8BK/BS/EK/ES) C9561 C9562 0.1u 4.7u IC9303 16Mbit FLASH ROM TVRN627 3.3V R9319 R9320 R9321 R9313 TP9001 C9305 C9306 R9317 4.7u 0.1u Q9303 3.3V TP9330 B1ABCF000138 R9314 R9318 4.7k 5V DET 100k...
  • Page 373 HA-BOARD TXNHA10RBS L3001 J0HABB000004 LAN15V LAN15V JS3011 JS3014 COMPONENT HA BNC TP032 L3002 VIDEO IN J0HABB000004 COMPONENT VIDEO JS3012 JS3015 TP033 TP034 L3003 J-BOARD J0HABB000004 JK3001 SLOT -0.8 JS3013 JS3016 K1QBB3BB0002 JK3001 COMPONENT VIDEO IN PB/B AB_AUD_R PLUG_DET PR/R JK3002 R3041 AUD_R TP035...
  • Page 374 IC3101 AVR 2.5V C0DBEZG00004 HB-BOARD TXNHB10QXS (1/2) C3127 3.3V IC3104 R3145 C3159 220u AD2R5V C0EBE0000066 R3112 1.5k RESET R3159 C3105 C3102 R3113 C3103 R3144 R3185 0.1u 1.5k 220u R3143 C3142 C3144 C3132 C3133 C3179 0.1u 0.1u 0.1u 0.1u GC3R3V GC2R5V IC3003 C3012 220u...
  • Page 375 HB-BOARD TXNHB10QXS (2/2) C3266 C3265 220u 0.1u 3.3V TS3100 AE_V_Y TS3101 TS3102 AL_S2_DET R3251 AM_HS IC3251 LVDS TRANSMITTER C0ZBZ0000684 AM_VS AE_R AE_L SCL2 SDA2 3.3V L3252 L3251 ELJPA2R2MF ELJPA2R2MF 3.3V C3261 C3264 220u 0.1u 3.3V AI_TX3+ AI_TX3- AJ_TXC+ AJ_TXC- AH_TX2+ AH_TX2- AK_TX1+ AK_TX1-...
  • Page 376 HX-BOARD TZTNP020YNS (FOR 42 INCH MODELS) HX-BOARD TZTNP020YLS (FOR 37 INCH MODELS) L3555 L3555 ELJPA100KF ELJPA100KF C3404 C3405 R3653 C3405 R3653 C3550 C3551 C3550 C3551 C3404 C3561 Q3531 C3561 Q3531 0.01u 0.1u 2SD0601A0L 0.01u 0.1u 2SD0601A0L JK3513 JK3513 K2HC103B0105 R3776 K2HC103B0105 R3776 R3654...
  • Page 377 J-BOARD TNPA3631AB (1/4) IC801 C0DBAMH00013 DIG12V AVR 9V D_1.8V D_3.3V R801 C802 IC2301 C807 10W MONO L801 4.7u 470u C1BA00000383 BTL AMP R G1C470MA0078 R802 R2397 R808 5.1k 9V/0.5A HP_IN C809 C801 C806 HP_OUT 2.2u 470u 0.1u R805 R2351 HP-STB C2402 HP_D.C 84.5k...
  • Page 378 J-BOARD TNPA3630AB (1/4) IC801 C0DBAMH00013 D_3.3V D_1.8V DIG12V AVR 9V 9V/0.5A R801 C807 C802 4.7u 470u L801 G1C470MA0078 R802 R808 C806 C809 0.1u 2.2u R805 RESET 84.5k IC2301 10W MONO C805 BTL AMP R R825 C808 C801 C1BA00000383 R803 8.2k R806 0.1u 470u...
  • Page 379 3.3V IC8001 STB3.3V C8035 C0JBAR000241 0.1u R3125 C8003 Q8002 SYNC SELECT J-BOARD TNPA3631AB (2/4) 2SD0601A0L 0.1u C8001 R3163 L8001 G1C100K00020 R8072 R8047 R8001 IC3008 IC8007 R8036 C8027 C8049 R8035 R8010 0.01u 2.2u C0JBAS000215 C0JBAR000419 R8003 R8004 R8011 SYNC SWITCH IIC ON/OFF R8017 R3134 R8012...
  • Page 380 3.3V STB3.3V R3125 IC8001 C8035 J-BOARD TNPA3630AB (2/4) C0JBAR000241 C8003 0.1u R3163 Q8002 0.1u SYNC SELECT 2SD0601A0L C8001 R8072 R8047 R8001 L8001 R3134 C8049 IC8007 G1C100K00020 R8036 100k R8002 R8009 C8027 R8035 0.01u R8010 C0JBAR000419 2.2u R8003 IC3008 SYNC SWITCH R8004 R8011 R8017...
  • Page 381 IC8003 C1AA00000706 SYNC SIGNAL PROCESSOR L8003 G1C100K00020 C8036 H.State Clamp Timing 100p R8041 V.State V.Pol. C8045 L8005 Green Sep Filter H.Pol. G1C100K00020 C8025 R8033 Green IN Clamp OUT C8029 100k 0.01u R8056 C8015 0.01u D8001 MA2J11100L Comp/H IN HD-OUT C8030 D8003 R8055 Comp/H Det...
  • Page 382 IC8003 C1AA00000706 SYNC SIGNAL PROCESSOR L8003 G1C100K00020 H.State Clamp Timing C8036 V.State R8041 V.Pol. 100p C8045 Green Sep Filter L8005 C8029 H.Pol. G1C100K00020 C8025 R8033 Green IN 0.01u 100k Clamp OUT 0.01u R8056 C8015 C8030 Comp/H IN HD-OUT R8055 D8001 D8003 C8016 MA2J11100L...
  • Page 383 IC8014 C0ZBZ0000911 STB3.3V RS232C DRIVER C8084 SHUTDOWN C8080 C8081 0.1u 0.1u AJ_TXD_4 T1_OUT R8124 AJ_RXD_4 R1_IN C8082 R8125 AJ_RXD4 0.1u R1_OUT R8126 ONLINE C8083 AJ_TXD4 J-BOARD TNPA3631AB (4/4) T2_OUT T1_IN 0.1u R8127 R2_IN T2_IN R2_OUT STATUS AJ_RXD1 AJ_TXD1 IC3150 D-BOARD C0JBAA000419 (D5) STB5V_S...
  • Page 384 IC8014 C0ZBZ0000911 STB3.3V RS232C DRIVER C8084 SHUTDOWN C8081 C8080 0.1u 0.1u AJ_TXD_4 T1_OUT AJ_RXD1 R8124 AJ_RXD_4 C8082 R1_IN R8125 AJ_TXD1 AJ_RXD4 0.1u R1_OUT R8126 ONLINE C8083 AJ_TXD4 T2_OUT T1_IN 0.1u R8127 R2_IN T2_IN R2_OUT STATUS IC3150 D-BOARD (D5) C0JBAA000419 R3060 STB5V_S D3005 LNJ206R5ARA...
  • Page 385 P-BOARD TNPA3570 (1/6) D504 MA165 D503 RL402 MA165 DG12D1-O(M)-2 0.25W TV-8 COLD COLD RL403 DJ12D2-O(M)0.25W C461 330p C449 ZH73 ZH75 C443 Z451 Z450 1000p EYF52BCY EYF52BCY PR401 F401 ZH54 ZH55 0216005.MXEP L404 ZH30 ZH31 ZH32 ZH33 ZH34 ZH35 SC06-120J ZH67 R410 ZH10 10/5W...
  • Page 386 P-BOARD TNPA3570 (2/6) COLD 67.0 SS-BOARD C605 Q527 150u/160V 15.0 (SS12) ZH57 ZH58 +15V B1DEHL000018 ZH84 ZH83 R631 R674 R676 T404 12.0 G4D4A0000109 STB_PS ZH79 12.0 C624 ZH99 ZH65 STB12V D543 1[KB] ZH86 C604 MAZ41500MF R662 150u/160V Q412 ZH63 ZH56 K1KA05A00139 130K[F] D539...
  • Page 387 P-BOARD (1/6) P-BOARD TNPA3570 (3/6) COLD Q518 B1DEHL000018 Q519 B1DEHF000002 L501 C562 EXCELSA35T D507 0.1[KB] R926 MA4150-M 220K R555 PR501 D508 K5H502Z00003 MA4150-M D566 ZH68 ZH69 D1NL20U-7070 R564 470K T410 C529 R550 R413 G4D2A0000229 D404 1[KB] R570 10/5W S1WB(A)80-7101 1000 Q560 ZH89 R635...
  • Page 388 P-BOARD P-BOARD TNPA3570 (4/6) (2/6) C525 820/25V K1KA06A00220 14.0 F_STB_14V 14.0 F_STB_14V 14.0 F_STB_14V PA-BOARD (PA10) SS-BOARD (SS11) K1KA07A00096 PR601 185.1 Vsus 185.1 R620 R622 ZH47 T 3.15A 250V ZH25 Vsus ZH29 150K[F] R648 D501 R589 150K[F] RU30ALF014-102 ZH26 IC506 ZH46 ZH39 R636...
  • Page 389 P-BOARD (3/6) IC411 COMPARATOR Q417 C0BBAA000040 B1CHND000004 IC402 C0BBAA000040 R404 C405 100K 0.01[KB] COMPARATOR R494 R487 R416 560K[F] 6800 3300 R408 R495 100K R486 560K[F] 6800 COLD R496 R453 560K[F] 1000 Q403 Q421 R497 B1CBGD000001 Q418 C482 24K[F] 2SD1819ARL R693 0.1[KB] 2SD1819ARL C421...
  • Page 390 P-BOARD (4/6) P-BOARD TNPA3570 (6/6) D-BOARD (D25) K1KA20A00085 12.0 12.0 FAN_CONT STB5V F_STBY_ON FAN_SOS ECO_ON PS_SOS Panel_Main_ON ALL_OFF RUSH_ON KILL_SOS K1KA05A00177 15.4 +15V FAN_SOS FAN_CONT TH-37/42PWD8 SERIES TH-37/42PWD8 SERIES P-Board (6 of 6) Schematic Diagram P-Board (6 of 6) Schematic Diagram...
  • Page 391 SC-BOARD (1/2) TNPA3543AB (37inch) D6491 B0ECHP000003 TNPA3543 (42inch) Q6601 R6611 B1JADN000001 C6611 630V 3900p 190V R6612 P-BOARD R6499 C6490 (P2) 185.1 630V 175V Vsus 3300p Q6602 185.1 L6602 C6601 C6602 C6603 R6613 Vsus G0ZZ00002183 B1JADN000001 200V 200V 200V C6612 630V 220u 220u 220u...
  • Page 392 Q6491 D6492 D6471 2SD1263AP0LB B0ECHP000003 MA2J11100L R6461 R6492 R6495 Q6492 200k 150k C6491 400V 2SC1473AEA ZA6603 R6491 R6594 K4CD01000013 R6493 R6496 100k 100k ZA6602 270k 150k C6469 K4CD01000013 220u ZA6601 D6501 R6621 K4CD01000013 MA2J11100L R6497 C6466 154k R6618 C6479 PC6505 R6595 Q6461 T6461...
  • Page 393 SD-BOARD TNPA3233 DOWN To 1st 80pins of To 2nd 80pins of To 3rd 80pins of SCAN ELECTRODES SCAN ELECTRODES SCAN ELECTRODES TPSD1 AD_27 AD_38 AC_91 AC_102 AB_155 AB_166 AA_219 AA_230 AD_26 AD_39 AC_90 AC_103 AB_154 AB_167 AA_218 AA_231 AD_25 AD_40 AC_89 AC_104 AB_153...
  • Page 394 SD-BOARD TNPA3243 DOWN To 1st 80pins of To 3rd 80pins of SCAN ELECTRODES SCAN ELECTRODES To 2nd 80pins of SCAN ELECTRODES TPSD1 AD_27 AD_38 AC_91 AC_102 AB_155 AB_166 AA_219 AA_230 AD_26 AD_39 AC_90 AC_103 AB_154 AB_167 AA_218 AA_231 AD_25 AD_40 AC_89 AC_104 AB_153...
  • Page 395 SS-BOARD Q6001 TNPA3544AB (37inch) B1JADN000001 C6011 PANEL PANEL TNPA3544 (42inch) 630V SUSTAIN SUSTAIN 3900p R6011 ELECTRODE ELECTRODE 42INCH ONLY 37INCH ONLY R6012 SS41 SS41A Q6002 C6012 B1JADN000001 630V TPVSUS SS11 P-BOARD 5600p (P11) R6013 175V 175V VSUS R6014 L6002 C6001 C6003 C6004 VSUS...
  • Page 396 SU-BOARD TNPA3232 To 1st 80pins of To 2nd 80pins of To 3rd 80pins of SCAN ELECTRODES SCAN ELECTRODES SCAN ELECTRODES TPSU1 AD_27 AD_38 AC_75 AC_86 AB_139 AB_150 AA_203 AA_214 AD_26 AD_39 AC_74 AC_87 AB_138 AB_151 AA_202 AA_215 AD_25 AD_40 AC_73 AC_88 AB_137 AB_152...
  • Page 397 SU-BOARD TNPA3242 To 1st 80pins of To 3rd 80pins of SCAN ELECTRODES SCAN ELECTRODES To 2nd 80pins of SCAN ELECTRODES TPSU1 AD_27 AD_38 AC_75 AC_86 AB_139 AB_150 AA_203 AA_214 AD_26 AD_39 AC_74 AC_87 AB_138 AB_151 AA_202 AA_215 AD_25 AD_40 AC_73 AC_88 AB_137 AB_152...
  • Page 398 TO J2 V1-BOARD TNPA3640 R1554 D1550 STB+3.3V RM001 J-BOARD LED G LED_G REMOTE RECIEVER LED R (J2) R1553 LED_R D1550 LNJ107W5PRW L1501 STB3.3V REMOTE_IN R1550 R1551 STB3.3V LED G D1551 C1530 L1502 R1554 LED R LED_G L1503 LED_R L1504 R1553 L1505 R1500 R1551...

This manual is also suitable for:

Th-42pwd8wsTh-37pwd8wkTh-37pwd8ws

Table of Contents
