Summary of Contents for Panasonic SC-TMAX40
- Page 1 Operating Instructions Wireless Speaker System SC-TMAX40 Model No. Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully. Please keep this manual for future reference. GS GW TQBJ2194...
-
Page 2: Table Of Contents
Your system and the illustrations can look differently. Table of contents Note on AC mains lead ......2 Safety precautions . -
Page 3: Safety Precautions
About Bluetooth mobile telephones during use. If such interference occurs, please increase separation between this unit Panasonic bears no responsibility for data and/or and the mobile telephone. information that is compromised during a wireless • This unit utilizes a laser. Use of controls or adjustments transmission. -
Page 4: Transporting The Unit
® trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license. Other trademarks and trade names are those of their respective owners. Android and Google Play are trademarks of Google Maintenance LLC. -
Page 5: Making The Connections
Making the connections Connect the AC mains lead only after all the other Conserving power connections have been made. The system consumes a small amount of power even when it is in standby mode. Disconnect the power supply if you do not use the system. Some settings will be lost after you disconnect the system. -
Page 6: Overview Of Controls
Overview of controls Do the procedures with the remote control. You can also use the buttons on the unit if they are the same. Standby/on switch [`], [1] Press to switch the unit from on to standby mode or vice versa. In standby mode, the unit is still consuming a small amount of power. - Page 7 Top panel ILLUMINATION SOUND ALBUM/ TRACK KARAOKE SELECT JUKEBOX Remote control sensor Open or close the disc tray Point the remote control at the remote control DJ function direct buttons sensor, away from obstacles and within the Press [DJ] to switch on the DJ function. operation range.
-
Page 8: Preparing Media
Note: The MAC address (example: 6C:5A:B5:B3:1D:0F) • This function disconnects all connected devices. may be shown before “SC-TMAX40” is shown. • A device is disconnected when you: The name of the connected device is shown for a few – Select a different source. -
Page 9: Media Playback
Play menu Media playback :USB The following marks indicate the availability of the feature. CD-R/RW in CD-DA format or with MP3 Press [PLAY MENU]. files. :USB USB device with MP3 files. Press [PLAY MENU] repeatedly to select :USB Bluetooth device. ®... -
Page 10: Radio
█ Note on disc Radio • This system can play CD-R/RW with CD-DA or MP3 format content. • Before playback, finalise the disc on the device it was Preparation recorded on. Press [SELECT <, >] repeatedly to select “FM”. • Some CD-R/RW cannot be played because of the condition of the recording. -
Page 11: Sound Effects
You can download and install the free Android™ app FM MONO “MONO” is selected as the “FM MODE”. “Panasonic MAX Juke” on Google Play™ for additional The FM signal is in monaural. features, such as to request song playback from multiple devices simultaneously. -
Page 12: Using A Microphone
Note: DJ sampler The system switches to repeat mode automatically when you switch on DJ jukebox. (Except for D-IN and AUX source) █ Changing the repeat setting By unit only You can apply a scratch sound or sample sound to the Press [PLAY MENU] repeatedly to select track you are playing. -
Page 13: Karaoke
Karaoke Clock and timers Preparation Select the music source. Setting the clock Note: This is a 24-hour clock. The Karaoke function is switched off when you switch off the system. Press [SETUP] repeatedly to select “CLOCK”. Press [R, T] to set the time and then press [OK]. Karaoke effect To check the time You can use the Karaoke effect function to add sound... -
Page 14: External Equipment
To start the timer Note: • This system supports linear PCM signal. Prepare the source you want to listen to (disc, • Multi-channel source will be converged to 2 channels. USB or radio). • Sampling frequency: 32 kHz, 44.1 kHz, 48 kHz, up to 96 kHz •... -
Page 15: Others
Playback does not start. • You have not put in the disc correctly. Put it in correctly. Occasionally, Panasonic may release updated software • Disc is dirty. Clean the disc. for this unit that may add or improve the way a feature •... - Page 16 • There is no album or track in the USB device. ® audio output to “SC-TMAX40” manually. Read the operating • Examine the content. You can only play supported format. instructions of the device for details.
- Page 17 Remote control code When other Panasonic equipment responds to the remote control of this system, change the remote control code for this system. Preparation Press [SELECT] repeatedly on the unit to select “AUX”. █ To set the code to “REMOTE 2”...
-
Page 18: Specifications
Specifications █ General █ Terminal section USB port Power supply AC 220 V to 240 V, 50/60 Hz USB standard USB 2.0 full speed Power consumption 196 W Media file format support MP3 (*.mp3) Power consumption in standby mode (approximate) USB device file system FAT12, FAT16, FAT32 With “BLUETOOTH STANDBY”... - Page 19 1. Subject to the conditions of this warranty Panasonic or its Authorised Service Centre will perform necessary service on the product, without charge for parts or labour, if in the opinion of Panasonic the product is found to have a manufacturing defect within one (1) year or (12 months) (the “warranty period”) from the date of purchase appearing on your purchase receipt.
- Page 20 Panasonic Corporation Web Site: http://www.panasonic.com TQBJ2194 72-TM40GS-120B1 L0819YS1079 © Panasonic Corporation 2019...
