- Page 1 Washer dryer WVH28490AU en Instruction Manual and Installation Instructions...
- Page 2 To meet the high quality demands Caution! required by Bosch, every washer dryer This signal word indicates a possibly that leaves our factory is carefully dangerous situation. Not heeding the checked to ensure that it functions caution can cause property and/or correctly and is in perfect condition.
-
Page 3: Table Of Contents
Contents e n I n s t r u c t i o n M a n u a l a n d I n s t a l l a t i o n I n s t r u c t i o n s Intended use. -
Page 4: Intended Use
Intended use Customer service ... 35 Intended use Technical specifications ..35 For private domestic use only. ■ I n t e n d e d u s e The washer dryer is suitable for ■... -
Page 5: Safety Instructions
Safety instructions Warning Safety instructions Risk of scalding! When washing at high ■ Electrical safety temperatures, you may be scalded S a f e t y i n s t r u c t i o n s if you touch the hot washing water Warning (e.g. -
Page 6: Protection Of The Environment
Protection of the environment Warning Protection of the Risk of poisoning! Detergents and care products may environment cause intoxication if consumed or eye/skin irritation if touched. Packaging/old appliance Keep detergents and care products P r o t e c t i o n o f t h e e n v i r o n m e n t out of the reach of children. -
Page 7: The Main Points In Brief
The main points in brief The main points in brief T h e m a i n p o i n t s i n b r i e f Insert mains plug. Open the washer Select the washing/ Max. load in display dryer door. -
Page 8: Getting To Know Your Appliance
Getting to know your appliance Getting to know your appliance Washer dryer G e t t i n g t o k n o w y o u r a p p l i a n c e Hot air outlet Operating/display panel Door with handle Open the door... -
Page 9: Control Panel
Getting to know your appliance Control panel Change the default settings for the selected @ Start programme. Select the Start/ programme and select additional functions: ReloadA button to start, interrupt (e.g. reload the laundry) and cancel the programme ( Select buttons °C (Temperature), 5 (Finish ~ Page 18 in) time, 0 (Spin speed) and 5 (Drying) for changing default settings ~ Page 24... -
Page 10: Display Panel
Getting to know your appliance Display panel Displays for the programme (: Temperature for washing Ž (cold) – 90°C Temperature in °C programme. 0: Programme information. Time: 1:50* Programme duration after programme selec- tion in h:min (hours:minutes) 1 – 24 h Finish in time in h (h=hour) Capacity: 8.0 kg*... - Page 11 Getting to know your appliance 8: Spin speed $ – 1400* Spin speed in revolutions per minute; $ (Rinse stop = without final drain/spin cycle, laundry remains in the water after the last rinse cycle) Washing @: Programme progress sym- bols Rinsing Draining/Spinning...
-
Page 12: Laundry
Laundry Suitable for washing by hand; Laundry e.g. W Wool program Do not machine wash. Ž P reparing laundry for washing L a u n d r y Protecting your laundry and washer Sorting laundry according to: dryer: Sort your laundry according to the care Caution! instructions and specifications of the Damage to the appliance/textiles... -
Page 13: Preparing Laundry For Drying
Laundry Wash delicates in a net or bag Notes ■ (tights, underwired bras, ect). Before drying, hand-washed textiles ■ Close zips, button up covers. must be spun at the appropriate spin ■ Brush sand out of pockets and speed. ■ collars. -
Page 14: Operating The Appliance
Operating the appliance Selecting the programme/ Operating the Switching on the appliance appliance Note: Preparing the washer dryer If you have activated the childproof lock, O p e r a t i n g t h e a p p l i a n c e you must deactivate it before you can The washer dryer was tested before set a programme. -
Page 15: Adjusting The Drying Programme
Operating the appliance The buttons are sensitive, they only Adjusting the drying ■ need to be touched gently. If the programme button °C (Temperature), 0 (Spin speed), Note: 5 (Finish in) is held down, the If an individual drying programme or setting options are automatically washing and drying without interruption scrolled through. -
Page 16: Loading The Laundry
Operating the appliance Loading the laundry Dosing and adding detergent and care product Warning Danger of death! Caution! Laundry items pretreated with solvent- Damage to the appliance based detergents, e.g. stain remover/ Detergents and agents for the petroleum ether, may cause an pretreatment of laundry (e.g. -
Page 17: Starting The Programme
Operating the appliance Pour in detergent and/or cleaning product. Do not use the measuring aid for Note: gel detergents and washing powder, or for programmes with prewash or when Dispenser I Detergent for prewash. "Finish in" time is selected. Dispenser i Softener, starch. Do not exceed For models without a measuring aid, the maximum load. -
Page 18: Childproof Lock
Operating the appliance Childproof lock Notes If there is a high water level, high ■ You can secure the washer dryer to temperature or if the drum is prevent the set functions from being rotating, the door remains locked changed inadvertently. To do this, for safety reasons and reloading is activate the childproof lock when the not possible. -
Page 19: End Of The Programme
Operating the appliance For drying programmes: After washing/drying Select Intensive Dry 5 or Gentle Dry ‰. Open the door and remove the Touch button 5 (Drying) and set laundry. drying time to 15 minutes. Turn the programme selector to Select Start/Reload A. Ú... -
Page 20: Overview Of Programmes
Overview of programmes Overview of programmes Programme on the programme O v e r v i e w o f p r o g r a m m e s selector Programme/Type of washing Options/Information Name of the programme maximum load according to EN50229 Brief explanation of the programme and which textiles it is suitable for. - Page 21 Overview of programmes Programme/Type of washing Options/Information Delicates/Silk “ max. 2 kg For delicate, washable textiles, e.g.made of silk, satin, synthetic Ž (cold) – 40 °C fibres or blended fabrics. $ – 800 rpm G, F, O, p – W Wool ã max.
- Page 22 Overview of programmes Programme/Type of washing Options/Information Allergy Plus ; max. 7(4)* kg/4 kg Hard-wearing textiles made of cotton or linen, for particularly sensi- Ž (cold) – 60 °C tive skin, longer wash cycle at the selected temperature, more $ – 1400 rpm water, extra rinsing.
-
Page 23: Drying Table
Overview of programmes Drying table Cottons/coloureds (textiles made of cotton or linen such as underwear, T-shirts, sweaters, trousers, kitchen towels) Dry weight in kg 0,5 ~1,0 1,0 ~ 2,0 2,0 ~ 3,0 3,0 ~ 4,0 ~ 0,5 ~ 1,0 ~ 2,0 ~ 2,5 Estimated drying time in min Adjustable drying time in min Cup-... -
Page 24: Starching
Changing programme default settings Starching Changing programme default settings The laundry should not be Note: treated with fabric softener. You can change the default settings for Liquid starch can be used in all wash C h a n g i n g p r o g r a m m e d e f a u l t s e t t i n g s selected programmes. -
Page 25: Spin Speed)
Changing programme default settings When the programme has started, Notes the preselected time is displayed Programme selection in Intensive ■ e.g.8:00h and counts down until Dry 5 or Gentle Dry ‰ position to the programme starts. Then select an individual drying the programme duration is displayed, programme. -
Page 26: F (Ecoperfect)
Selecting additional functions Selecting additional functions You can select your desired additional S e l e c t i n g a d d i t i o n a l f u n c t i o n s functions by touching the respective buttons. -
Page 27: Setting The Signal
Setting the signal Setting the signal S e t t i n g t h e s i g n a l 1. Activate setting mode for the signal volume Turn to Ú Off. Turn one position Press and hold the ° C button + Release the button. -
Page 28: Cleaning And Maintenance
Cleaning and maintenance Descaling Cleaning and Not required if detergent dosed maintenance correctly. However, if this does occur, follow the instructions of the descaling Warning agent manufacturer. Suitable descalers C l e a n i n g a n d m a i n t e n a n c e Risk of electric shock! can be purchased on our website or Danger of death if live parts are... -
Page 29: Drainage Hose On The Siphon Blocked
Cleaning and maintenance Turn the programme selector to Loosen hose clip, carefully remove Ú Off. Pull out the mains plug. drainage hose. Residual water may Open the service flap. run out. Take the drainage hose out of the Clean drainage hose and siphon holder. -
Page 30: Air Filter Blocked
Faults and what to do about them Clean the filter on the back of the Faults and what to do appliance: Remove the hose from the rear of about them the appliance. Take out the filter with pliers and Emergency release, e.g. if a clean it. -
Page 31: Information On The Display Panel
Faults and what to do about them Information on the display panel Display Cause/Remedy Close the door immediately because of the rising water level. If an interruption A:01 occurs, A:01 and OPEn are displayed alternately. A:02 The door is locked for safety reasons (water level and/or temperature too high). Washing programme: In pause mode A:02 and PAUS are displayed alter- ■... -
Page 32: Faults And What To Do About Them
Faults and what to do about them Faults and what to do about them Faults Cause/Remedy Water is running out. Correctly attach/replace drainage hose. ■ Tighten screw-fitting on the supply hose. ■ Water not flowing in. Start/Reload A not selected? ■... - Page 33 Faults and what to do about them Faults Cause/Remedy Display panel/indicator Power failure? ■ lights do not function Fuse tripped? Switch on/replace fuse. ■ while the appliance is If the fault occurs repeatedly, call customer service. ■ running. The programme duration Not a fault –...
- Page 34 Faults and what to do about them Faults Cause/Remedy The drying result is not Excessively high ambient temperature (above 30 °C) or inadequate ventila- ■ satisfactory (laundry is tion in the room in which the washer dryer is situated. Ensure adequate ven- not dry enough).
-
Page 35: Customer Service
Customer service Customer service Technical specifications If you cannot correct the fault yourself, C u s t o m e r s e r v i c e see section, Faults and what to do about them, please contact our T e c h n i c a l s p e c i f i c a t i o n s Dimensions 60 x 59 x 84,5 cm... -
Page 36: Consumption Values
Consumption values Consumption values C o n s u m p t i o n v a l u e s Energy Water Programme Load consumption consumption duration *** Programme Option (kg) (kWh) (liter) (min) Cottons i 20 °C 0,25 Cottons i 30 °C 0,35 Cottons i 40 °C... -
Page 37: Installation And Connection
Installation and connection Note: Installation and A hose clip Ø 24–40 mm (specialist store) is also required for connection connection to a siphon. Connecting the water ~ Page 40 Standard accessories I n s t a l l a t i o n a n d c o n n e c t i o n Useful tools: Check the washer dryer for Note:... -
Page 38: Installation Area
Installation and connection Installation area Installing the appliance under/ between kitchen units Stability is important to prevent Note: the washer dryer from wandering! Warning The installation area must be firm ■ Risk of electric shock! and level. Danger of death if live parts are Soft floors and floor coverings are ■... -
Page 39: Removing The Transportation Protection Devices
Installation and connection Removing the transportation protection devices Caution! Damage to the appliance Before using the washer dryer for the ■ first time, it is essential to remove all Insert the covers. Lock firmly by 4 transportation protection devices. pressing on the locking hook. Insert Keep the transportation protection the hose holder. -
Page 40: Connecting The Water
Installation and connection Water supply Available from dealer/customer service: Extension for Aqua-Stop or cold Notes ■ water inlet hose (approx. 2.50 m). Do not kink, crush, alter or cut ■ Order no. WMZ 2380, WZ 10130, through the water supply hose CZ 11350, Z 7070X0. -
Page 41: Water Drainage
Installation and connection Carefully turn on the tap and check and damage the washer dryer and/or that the connection points are not textiles. leaking. Ensure that: the sealing plug does not block the ■ outflow of the washbasin. the water drains quickly enough. ■... -
Page 42: Alignment
Installation and connection Alignment Electrical connection Loosen the lock nut in a clockwise Electrical safety direction with a wrench. Check the alignment of the washer Warning dryer with a spirit level and, if Risk of electric shock! required, correct. Adjust the height Risk of death if live parts are touched. -
Page 43: Before Washing/Drying For The First Time
Installation and connection Before washing/drying for the Transportation first time Preparatory work Turn off the tap. The washer dryer was inspected Release the water pressure in the thoroughly before leaving the factory. To supply hose. remove any residual test water, run the Filter in the water inlet hose blocked Fluff Clean l programme the first time ~ Page 29... - Page 44 The tap only needs to be turned off if you are away from home for a long period, e.g. for several weeks' holiday. Robert Bosch Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY...
