PQQX14670ZA.book 1 ページ ２００５年２月２２日　火曜日　午後１２時０分
The unit is Caller ID compatible. To display the caller's phone number, you must
subscribe to Caller ID service.
PLEASE READ BEFORE USE AND SAVE.
Charge the battery for 6 hours before initial use.
Digital Cordless Phone
Operating Instructions
KX-TG2340JX
Model No.
Pulse-or-tone dialing capability

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TG2340JX

Summary of Contents for Panasonic KX-TG2340JX

  • Page 1 PQQX14670ZA.book 1 ページ ２００５年２月２２日　火曜日　午後１２時０分 Digital Cordless Phone Operating Instructions KX-TG2340JX Model No. Pulse-or-tone dialing capability The unit is Caller ID compatible. To display the caller’s phone number, you must subscribe to Caller ID service. PLEASE READ BEFORE USE AND SAVE.
  • Page 2 PQQX14670ZA.book 2 ページ ２００５年２月２２日　火曜日　午後１２時０分 Thank you for purchasing your new Panasonic cordless telephone. Caller ID Service, where available, is a telephone company service. After subscribing to Caller ID, this phone will display a caller’s phone number. For your future reference Serial No.
  • Page 3 PQQX14670ZA.book 3 ページ ２００５年２月２２日　火曜日　午後１２時０分 For Best Performance Battery Charge The handset is powered by a rechargeable Nickel- Metal Hydride (Ni-MH) battery. Charge the battery for 6 hours before initial use (p. 9). Base Unit Location/Noise Calls are transmitted between the base unit and handset using wireless radio waves.

  • Page 4: Table Of Contents

    PQQX14670ZA.book 4 ページ ２００５年２月２２日　火曜日　午後１２時０分 Contents Preparation Advanced Operation Location of Controls ..6 Phone Book ....33 Storing Names and Installation ....8 Numbers .
  • Page 5 PQQX14670ZA.book 5 ページ ２００５年２月２２日　火曜日　午後１２時０分 Contents Useful Information Belt Clip ....50 Shoulder Rest Attachment . . 50 Wall Mounting ... . 51 Optional Headset .

  • Page 6: Location Of Controls

    PQQX14670ZA.book 6 ページ ２００５年２月２２日　火曜日　午後１２時０分 Location of Controls Base unit [DIAL LOCK] Button (p. 47) IN USE Indicator (p. 24) DIAL LOCK Indicator (p. 47) Hook (p. 51) Speaker [*] (TONE) Button (p. 43) Antenna (p. 3) Charge Contacts (p. 10) [LOCATOR/INTERCOM] Button (p.
  • Page 7 PQQX14670ZA.book 7 ページ ２００５年２月２２日　火曜日　午後１２時０分 Location of Controls Handset Ringer Indicator (p. 24) Back side Antenna Speaker Receiver Display Soft Keys (see below) [OFF] Button (p. 11, 20) Headset Jack (p. 52) [MENU] Button (p. 11) [C] (TALK) Button (p. 20) [s] (Speakerphone) Button (p.

  • Page 8: Installation

    (AC 220–240 V, 50/60 Hz) AC Adaptor • USE ONLY WITH Panasonic AC ADAPTOR PQLV1BX. • The AC adaptor must remain connected at all times. (It is normal for the adaptor to feel warm during use.) • If your unit is connected to a PBX which does not support Caller ID, you cannot access Caller ID services.

  • Page 9: Installing The Battery In The Handset

    PQQX14670ZA.book 9 ページ ２００５年２月２２日　火曜日　午後１２時０分 Installation Installing the Battery in the Handset Insert the battery (1), and press it down until it snaps into the compartment (2). Close the cover. To replace the battery: Press the notch on the cover firmly and slide it as indicated by the arrow.
  • Page 10 “Recharge battery” is displayed and/or “7” continues to flash, or “Charge for 6h” and “8” are displayed, the battery may need to be replaced. Please replace with a new Panasonic HHR-P104 battery. To replace the battery, see page 9.

  • Page 11: Programmable Settings

    PQQX14670ZA.book 11 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Programming Guidelines Handset This unit has several programmable functions which can be selected from the function menu on the display (p. 12). The soft keys selects the Back Select functions displayed above [OFF] exits each soft key.

  • Page 12: Function Menu Table

    PQQX14670ZA.book 12 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Function Menu Table Handset You can use the following functions to customize your unit. See the corresponding pages for function details. • After pressing [MENU], you can also program menu items directly by pressing [0] to [9], and [*] instead of using the soft keys (p.

  • Page 13: Date And Time

    PQQX14670ZA.book 13 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Date and Time Handset You need to set the date and time to display the time and date the calls were received in the Caller List. Press [MENU]. Scroll to “Date and time” by pressing [d] or Date and time [B], then press Select.

  • Page 14: Dialing Mode

    PQQX14670ZA.book 14 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Dialing Mode Handset If you have touch tone service, set the dialing mode to “Tone”. For rotary or pulse service, set to “Pulse”. The factory preset is “Tone”. Press [MENU]. Scroll to “Initial setting” by pressing [d] Initial setting or [B], then press Select.

  • Page 15: Auto Talk

    PQQX14670ZA.book 15 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Auto Talk Handset The Auto Talk feature allows you to answer calls by simply lifting the handset off the base unit. You do not need to press [C] or [s]. The factory preset is OFF. Press [MENU].

  • Page 16: Ringer Volume

    PQQX14670ZA.book 16 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Ringer Volume You can select the handset or base unit ringer volumes to high, medium, low, or off. The factory preset is HIGH. If the handset and base unit ringer is turned off, the handset or base unit will ring at the low level for intercom calls, and will not ring for outside calls.
  • Page 17 PQQX14670ZA.book 17 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Base Unit Base unit ringer volume Make sure the base unit is not being used. To set the ringer volume to high (preset), medium, or low, press VOLUME [<] or [>]. • To increase volume, press VOLUME [>]. To decrease volume, press VOLUME [<].

  • Page 18: Ringer Tone

    PQQX14670ZA.book 18 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Ringer Tone You can set the handset and base unit ringers to use one of 7 ringer patterns for outside calls. “Tone 1” to “Tone 3” are bell ringer patterns. “Melody 1” to “Melody 4” are melody patterns.

  • Page 19: Lcd Contrast

    PQQX14670ZA.book 19 ページ ２００５年２月２２日　火曜日　午後１２時０分 Programmable Settings Handset Setting the base unit ringer tone by using the Press [MENU]. Scroll to “Initial setting” by pressing [d] Initial setting or [B], then press Select. Back Select Scroll to “Set base unit” by pressing [d] or Set base unit [B], then press Select.

  • Page 20: Making Calls

    PQQX14670ZA.book 20 ページ ２００５年２月２２日　火曜日　午後１２時０分 Making Calls Using the Handset Handset Press [C]. • “Talk” is displayed. Display Dial a phone number. Soft Keys • The dialed number is displayed. [OFF] • After a few seconds, the display will show the length of the call. [d], [B] To hang up, press [OFF] or place the handset on the base...
  • Page 21 PQQX14670ZA.book 21 ページ ２００５年２月２２日　火曜日　午後１２時０分 Making Calls To dial after confirming the entered number Enter a phone number. 3334444| • If you misdial, press Clear. Enter the correct Clear Pause number. • If a pause is required when dialing, press Pause where needed (p.
  • Page 22 Ringer indicator will start to flash rapidly. After 4 additional minutes on hold, the call will be disconnected. Voice Enhancer Technology Panasonic’s Voice Enhancer Technology clarifies the voice of the person you are talking to, reproducing a more natural-sounding voice that is easier to hear and understand.

  • Page 23: Using The Base Unit

    PQQX14670ZA.book 23 ページ ２００５年２月２２日　火曜日　午後１２時０分 Making Calls Using the Base Unit Base Unit Press [SP-PHONE]. • The SP-PHONE indicator lights. [HOLD/CONF] Dial a phone number. [SP-PHONE] When the other party answers, talk and Indicator into the MIC (microphone). [REDIAL] To hang up, press [SP-PHONE]. •...

  • Page 24: Answering Calls

    PQQX14670ZA.book 24 ページ ２００５年２月２２日　火曜日　午後１２時０分 Answering Calls When a call is received, the unit rings, “Incoming call” is displayed, and the Ringer indicator on the handset and the IN USE indicator on the base unit flash rapidly. If you subscribe to Caller ID, see page 25. Handset Ringer Indicator Press [C] or [s].

  • Page 25: Caller Id Service

    PQQX14670ZA.book 25 ページ ２００５年２月２２日　火曜日　午後１２時０分 Caller ID Service This unit is compatible with Caller ID services offered by your telephone company. If you subscribe to Caller ID, caller’s information will be displayed and recorded in the Caller List. How Caller ID information is displayed When a call comes in, the unit will ring and the caller Example information will be received.

  • Page 26: Using Talking Caller Id

    PQQX14670ZA.book 26 ページ ２００５年２月２２日　火曜日　午後１２時０分 Caller ID Service Using Talking Caller ID To use this feature, you need to subscribe to Caller ID. For further information, please contact your telephone company. To activate this feature, you must turn this feature on (p. 27). When a call is received, the unit will ring and receive Example caller information.
  • Page 27 PQQX14670ZA.book 27 ページ ２００５年２月２２日　火曜日　午後１２時０分 Caller ID Service To turn Talking Caller ID on or off You can turn Talking Caller ID on or off for the handset and base unit separately. If this feature is off, the unit will not announce caller names. The factory preset is OFF.

  • Page 28: Using The Caller List

    PQQX14670ZA.book 28 ページ ２００５年２月２２日　火曜日　午後１２時０分 Using the Caller List The unit can record information up to 50 different callers and store this information in the Caller List. Caller information is sorted by the most recent call to the oldest. When the 51 call is received, the information from the 1 call is deleted.

  • Page 29: Calling Back From The Caller List

    PQQX14670ZA.book 29 ページ ２００５年２月２２日　火曜日　午後１２時０分 Using the Caller List • If a call has name information, the caller’s name and JACK SMITH phone number are alternately displayed in step 2 on 3:10P 29JUN. page 28 as shown on the right. Erase Select 15553334444 3:10P 29JUN.

  • Page 30: Editing The Caller's Phone Number

    PQQX14670ZA.book 30 ページ ２００５年２月２２日　火曜日　午後１２時０分 Using the Caller List Editing the Caller’s Phone Number Handset You can edit a phone number in the Caller List to call it back or store it in the phone book. Press Rcvd calls, [ ], or [ ] to enter the 2 missed calls Caller List.

  • Page 31: Storing Caller Information In The Phone Book

    PQQX14670ZA.book 31 ページ ２００５年２月２２日　火曜日　午後１２時０分 Using the Caller List Storing Caller Information in the Phone Book Handset Caller’s phone numbers that are in the Caller List can be stored in the phone book. Press Rcvd calls, [ ], or [ ] to enter the 2 missed calls Caller List.

  • Page 32: Erasing Caller Information

    PQQX14670ZA.book 32 ページ ２００５年２月２２日　火曜日　午後１２時０分 Using the Caller List Erasing Caller Information Handset To erase a specific caller Press Rcvd calls, [ ], or [ ] to enter the 2 missed calls Caller List. Rcvd Phone calls book 2 missed calls =Scroll list All erase Scroll to the desired caller by pressing [...

  • Page 33: Phone Book

    PQQX14670ZA.book 33 ページ ２００５年２月２２日　火曜日　午後１２時０分 Phone Book The handset can store up to 50 names and phone numbers in its phone book. You can make a call by selecting a name or number from the phone book. Storing Names and Numbers Handset Press Phone book.
  • Page 34 PQQX14670ZA.book 34 ページ ２００５年２月２２日　火曜日　午後１２時０分 Phone Book • To store numbers for calling card access (see “Chain Dial” on page 36), we recommend you add pauses after each item. Storing pauses with numbers will prevent misdialing (p. 44). The delay time necessary will depend on your telephone company.

  • Page 35: Dialing From The Phone Book

    PQQX14670ZA.book 35 ページ ２００５年２月２２日　火曜日　午後１２時０分 Phone Book Dialing from the Phone Book Handset Press Phone book. Press Search. Phone book 7 items Search Scroll to the desired item. To scroll down, 0-9=Name search press [ ]. To scroll up, press [ =Scroll list Phone book items are sorted in the following order: Alphabet letters (Alphabetical)

  • Page 36: Chain Dial

    PQQX14670ZA.book 36 ページ ２００５年２月２２日　火曜日　午後１２時０分 Phone Book Index table Keys Index Keys Index Symbols, 1 M, N, O, 6 A, B, C, 2 P, Q, R, S, 7 D, E, F, 3 T, U, V, 8 G, H, I, 4 W, X, Y, Z, 9 J, K, L, 5 0, Space Chain Dial...

  • Page 37: Editing An Item In The Phone Book

    PQQX14670ZA.book 37 ページ ２００５年２月２２日　火曜日　午後１２時０分 Phone Book Editing an Item in the Phone Book Handset Press Phone book. Press Search. Scroll to the desired item by pressing [ ] or Jane ], then press Edit. 3456789 Erase Edit • To search for the item by initial, see page 35. Edit the name (p.

  • Page 38: Intercom

    PQQX14670ZA.book 38 ページ ２００５年２月２２日　火曜日　午後１２時０分 Intercom Intercom calls can be made between the handset and the base unit. Making Intercom Calls Handset From Press [HOLD/INTERCOM]. Calling Base • The base unit will ring for 1 minute. • To stop paging, press [OFF]. When the paged party answers, start talking.

  • Page 39: Answering Intercom Calls

    PQQX14670ZA.book 39 ページ ２００５年２月２２日　火曜日　午後１２時０分 Intercom Answering Intercom Calls Handset When the handset is paged, it rings and the Ringer indicator flashes rapidly. Press [C], [s] or [HOLD/INTERCOM]. Call from Base • You can also answer a call by pressing any button except [d], [B] or [OFF].

  • Page 40: Transferring A Call

    PQQX14670ZA.book 40 ページ ２００５年２月２２日　火曜日　午後１２時０分 Transferring a Call You can transfer an outside call to the base unit or the handset. Handset Base Unit From the to the Handset: (1) During a call, press [HOLD/INTERCOM]. Line on hold. Transfer to • The call is put on hold. Base (2) Press Base.
  • Page 41 PQQX14670ZA.book 41 ページ ２００５年２月２２日　火曜日　午後１２時０分 Transferring a Call Quick call transfer You can transfer a call without waiting for the paged party to answer. Handset During a call, press [HOLD/INTERCOM], then press Base. Press [OFF] to hang up. Base Unit During a call, press [LOCATOR/INTERCOM]. Press [SP-PHONE] to hang up.

  • Page 42: Conference Calls

    PQQX14670ZA.book 42 ページ ２００５年２月２２日　火曜日　午後１２時０分 Conference Calls While you are talking with an outside caller, the base unit user or the handset user can join the conversation and establish a conference call. Handset Base Unit During a call, press During a call, press [HOLD/INTERCOM].

  • Page 43: Special Features

    PQQX14670ZA.book 43 ページ ２００５年２月２２日　火曜日　午後１２時０分 Special Features Temporary Tone Dialing (For Rotary or Pulse Service Users) Handset Base Unit Press (TONE) before entering access numbers which require tone dialing. • The dialing mode changes to tone. You can enter numbers to access an answering service, electronic banking service, etc.

  • Page 44: Using The Pause Key (For Pbx Line/Long Distance Calls)

    PQQX14670ZA.book 44 ページ ２００５年２月２２日　火曜日　午後１２時０分 Special Features Using the PAUSE Key Handset (For PBX Line/Long Distance Calls) We recommend you press Pause or P if a pause is Example 9P15556667777| required for dial with a PBX or to make a long distance call. Ex.

  • Page 45: Incoming Call Tone

    PQQX14670ZA.book 45 ページ ２００５年２月２２日　火曜日　午後１２時０分 Special Features Incoming Call Tone Handset Base Unit During an intercom call (p. 38), you can be informed of incoming calls by two tones. If this feature is turned on, incoming call tones will be heard for as long as the line is ringing.

  • Page 46: Key Tone

    PQQX14670ZA.book 46 ページ ２００５年２月２２日　火曜日　午後１２時０分 Special Features Key Tone Handset You can select whether or not the handset keys will sound tones (key tone, confirmation tone, error tone). The factory preset is ON. Press [MENU]. Scroll to “Initial setting” by pressing [ Initial setting or [ ], then press Select.

  • Page 47: Dial Lock

    PQQX14670ZA.book 47 ページ ２００５年２月２２日　火曜日　午後１２時０分 Special Features Dial Lock Handset Base Unit The Dial Lock feature allows you to prevent others from making calls with the handset and base unit. You can turn the Dial Lock on for both the handset and base unit using the handset or the base unit.
  • Page 48 — using the base unit, the base unit beeps 3 times. • Please write down your password. If you forget your password, consult your nearest Panasonic service center. To cancel the Dial Lock (use either the handset or the base unit) Handset Press [MENU].

  • Page 49: Handset

    PQQX14670ZA.book 49 ページ ２００５年２月２２日　火曜日　午後１２時０分 Special Features Re-registering the Handset Handset & Base Unit If “No link to base. Move closer to base, try again.” is displayed even when using the handset near the base unit, the handset may have lost communication with the base unit.

  • Page 50: Belt Clip

    PQQX14670ZA.book 50 ページ ２００５年２月２２日　火曜日　午後１２時０分 Belt Clip You can hang the handset on your belt or pocket using the included belt clip. To attach the belt clip To remove the belt clip Shoulder Rest Attachment Use the shoulder rest attachment if you need to keep your hands free during a phone conversation.

  • Page 51: Wall Mounting

    PQQX14670ZA.book 51 ページ ２００５年２月２２日　火曜日　午後１２時０分 Wall Mounting This unit can be mounted on a wall. Install screws using the wall Push the hook and turn it template below. Connect the upward. Turn the hook until a telephone line cord. Mount the click is heard.

  • Page 52: Optional Headset

    PQQX14670ZA.book 52 ページ ２００５年２月２２日　火曜日　午後１２時０分 Optional Headset Connecting the optional headset to the handset allows hands-free phone conversation. Please use only the Panasonic KX-TCA89BX headset. Connecting the optional headset Open the headset jack cover, and insert the headset plug into the headset jack as shown below.

  • Page 53: Direct Commands

    PQQX14670ZA.book 53 ページ ２００５年２月２２日　火曜日　午後１２時０分 Direct Commands Handset After pressing [MENU], you can also program menu items directly by pressing [0] to [9], and [*] instead of using the soft keys. Menu item Command Selection items Page Ringer volume [1] [1] [0] : Off [1] : Low [2] : Medium p.

  • Page 54: If The Following Appear On Your Display

    PQQX14670ZA.book 54 ページ ２００５年２月２２日　火曜日　午後１２時０分 If the Following Appear on Your Display... The following will be displayed when the unit needs your attention. Display message Cause & Remedy • The battery needs to be charged. Recharge the Recharge battery battery (p. 9). •...

  • Page 55: Troubleshooting

    PQQX14670ZA.book 55 ページ ２００５年２月２２日　火曜日　午後１２時０分 Troubleshooting If the handset display shows error messages, see “If the Following Appear on Your Display...” (p. 54) for the Cause & Remedy. Problem Cause & Remedy “No link to base. Move • You are too far from the base unit. Walk closer to the base unit.
  • Page 56 PQQX14670ZA.book 56 ページ ２００５年２月２２日　火曜日　午後１２時０分 Troubleshooting Problem Cause & Remedy While programming or • A call is coming in. To answer the call, press searching, the handset starts [C], [s] or [SP-PHONE]. Start again from to ring and the program/ the beginning after hanging up. search stops.
  • Page 57 PQQX14670ZA.book 57 ページ ２００５年２月２２日　火曜日　午後１２時０分 Troubleshooting Problem Cause & Remedy The handset and/or base unit • Name pronunciation may vary. does not announce the • The handset and/or base unit will announce displayed caller’s name each letter of abbreviations, such as “Co.” properly.

  • Page 58: Safety Instructions

    PQQX14670ZA.book 58 ページ ２００５年２月２２日　火曜日　午後１２時０分 Safety Instructions Take special care to follow the safety suggestions listed below. Safety 1) The unit should be connected to a power supply only of the type described in the operating instructions or as marked on the unit. 2) When left unused for a long period of time, the base unit should be unplugged from the household AC outlet.

  • Page 59: Specifications

    PQQX14670ZA.book 59 ページ ２００５年２月２２日　火曜日　午後１２時０分 Safety Instructions WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN OR ANY TYPE OF MOISTURE. If there is any trouble, disconnect the unit from the telephone line and connect a known working phone.
  • Page 60 PQQX14670ZA.book 60 ページ ２００５年２月２２日　火曜日　午後１２時０分 Panasonic Communications Co., Ltd. 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan PQQX14670ZA F0205-0...
