Acer Aspire E650 Service Manual

Hide thumbs Also See for Aspire E650:
Table of Contents

Advertisement

Quick Links

See also: Manual
Acer Aspire E650
Service Guide
Service guide files and updates are
available on the ACER/CSD web.
For more information, please refer to
http://csd.acer.com.tw

Advertisement

Table of Contents
loading

Related Manuals for Acer Aspire E650

Summary of Contents for Acer Aspire E650

  • Page 1 Acer Aspire E650 Service Guide Service guide files and updates are available on the ACER/CSD web. For more information, please refer to http://csd.acer.com.tw...
  • Page 2 PRINTED IN TAIWAN...

  • Page 3: Revision History

    Revision History Please refer to the table below for the updates of Aspire E650 service guide. Date Chapter Updates...
  • Page 4 Copyright © 2006 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical,...
  • Page 5 Any Acer Incorporated software described in this manual is sold or licensed “as is”. Should the programs prove defective following their purchase, the buyer (and not Acer Incorporated, its distributor, or its dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or consequential damages resulting from any defect in the software.
  • Page 6 Conventions The following conventions are used in this manual: SCREEN MESSAGES Denotes actual messages that appear on screen. NOTE Gives bits and pieces of additional information related to the current topic. WARNING Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 7 PROVIDERS, your Acer office may have a DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 8: Table Of Contents

    Aspire E650 Rear Panel ..... 9 Acer eRecovery ......10...
  • Page 9 General Information ..... . . 49 Before You Begin 49 Aspire E650 Disassembly Procedure ..50 Opening the Computer 50...
  • Page 10 Power Cable Connectors 63 Front Panel Header 65 IDE Connector 66 SATA Connectors 66 FDD: Floppy Disk Drive Connector 66 Add-on Card Slots 66 Optional Devices 67 I/O Devices 70 Jumper Settings 71 Chapter 6 FRU (Field Replaceable Unit) List 72 Exploded Diagram .

  • Page 11: Chapter 1 System Specification

    System Specification Overview Main Board Specification Item Size System Chipset Memory On-Board Graphic Solution PCI Express / PCI Slots Chapter 1 Description Max. 244 mm x 244 mm, MicroATX Socket type: Intel Socket T (Socket 775) Socket quantity: one Processor type: Intel Prescott / Smithfield / Cedarmill / Presler, FSB 533/800/ 1066MHz Intel Celeron Prescott 775 / FSB 533MHz...
  • Page 12 Item Audio Rear Audio Jack Function Blue Green Pink Orange Black Grey 1394 Description Slot type: 40-pin PATA IDE slot Slot quantity: one Transfer rate support: PIO mode: 0/1/2/3/4 ATA mode: 33/66/100 Slot type: SATA IDE slot Slot quantity: four Storage type support: HDD / CD-ROM / CD-RW / DVD-ROM / DVD-RW / DVD+RW / DVD Dual / DVD Super multiplus Controller: Intel ICH7DH...

  • Page 13: Wake-Up Event Specification

    One three-pin System fan connector with linear circuit One 24-pin + four-pin ATX interface PS3 / PS2 SPS connector One 2*7 pin Acer FPIO specification Power switch / Power state LED / PATA / SATA active LED One buzzer on board...

  • Page 14: System Led Definition

    System LED Definition State Power State LED • S0: Blue steady • S1/S3: Off • S4/S5: Off HDD State LED • IDE active: Red blinking • IDE idle: Off LAN State LED • LAN active: Blue blinking • LAN idle: Off Response Chapter 1...

  • Page 15: Block Diagram

    Block Diagram Chapter 1...

  • Page 16: Main Board Placement

    Main Board Placement Chapter 1...
  • Page 17 Description CPU socket South bridge Super I/O controller Buzzer VIA 1394 BIOS 240-pin DDR2 DRAM slots Primary IDE channel Serial ATA connectors Infrared header Front panel USB headers IEEE 1394a header SPDIF out header Analog audio input header PCI Express x1 slot System cooling fan connector Four-pin power connector PS2 keyboard...

  • Page 18: Aspire E650 Front Panel

    Aspire E650 Front Panel Label Description USB ports Microphone in / out (front) Speaker out / Line out port Power button CD reject button Optical drive door 3.5 inch floppy disk drive Card reader Chapter 1...

  • Page 19: Aspire E650 Rear Panel

    Aspire E650 Rear Panel Label Description Six 7.1 audio jacks Four USB ports CRT / VGA port Serial port PS/2 mouse SPDIF bracket Recovery switch holder Chapter 1 Label Description RJ-45 port 1394a port Parallel port PS/2 keyboard Power cord port...

  • Page 20: Acer Erecovery

    Acer eRecovery Acer eRecovery is a tool to quickly backup and restore the system. Users can create and save a backup of the current system configuration to hard drive, CD, or DVD. Acer eRecovery consists of the following functions: Create backup...

  • Page 21: Re-Install Bundled Software Without Cd

    In the Recovery settings window, select Re-install applications / drivers and click Next. Select the desired driver / application and follow the instructions on screen to re-install. After first launch, Acer eRecovery prepares all the needed software and may take few seconds to bring up the software content window.

  • Page 22: Acer Disc-To-Disc Recovery

    Restart the system. While the Acer logo is showing, press <Alt> + <F10> at the same time to enter the recovery process. The message “The system has password protection. Please enter 000000:” will be displayed.

  • Page 23: Hardware Specification And Configuration

    Hardware Specification and Configuration Major Chips Item System Core Logic Super I/O Controller LAN Controller Memory Controller IDE Controller Audio Controller VGA Controller Keyboard Controller Processor Item Type Slot Core Speed / Host Bus Speed Chapter 1 Specification Intel 945G Intel ICH7DH ITE8712 Intel 82753L...

  • Page 24: Intel 945G

    Intel 945G Item Feature Specification Prescott and Tejas processor FSB at 533/800/ 1066 MT/s support Processor/Host interface: Hyper-Threading Technology support FSB Dynamic Bus Inversion (DBI) support DDR2 DRAM at 533/667MHz operation support Direct Media Interface (DMI): point-to-point interconnect between the 945G and ICH7DH DDR2 DRAM: up to four DIMMs Two channels of memory (each channel consisting of 64 data lines) support...

  • Page 25: Intel Ich7Dh

    Intel ICH7DH Item Feature Chapter 1 Specification Direct media interface: 10Gb/s each direction, full duplex PCI Express: two PCI Express x1 USB controller 2.0 (expanded capability for eight ports) One channel ultra ATA/100 bus master IDE controller Four Serial ATA host controllers I/O APIC SMBUS FWH interface...

  • Page 26: Lpc Super I/O: Ite8712F

    LPC Super I/O: ITE8712F Item Feature AC’97 Audio Codec ALC883 Item Feature Specification LPC I/F: Compliant with Intel LPC interface specification V1.0 LDRQ# (LPC DMA), SERIRQ (Serial IRQ) protocol support PCI PME# interface support ACPI & LANDesk compliant: ACPI V1.0 compliant Enhanced hardware monitor: CPU thermal sense and system sense support Seven external voltage detect inputs...

  • Page 27: Bios Hotkey List

    BIOS Hotkey List Hotkey Feature Access to BIOS Setup Utility System Memory Item Feature LAN Interface Item Feature Chapter 1 Function Press while the system is booting to enter BIOS Setup Utility. Specification 1.8V DIMM DDR2 DRAM configurations Two 64-bit width DDR2 data channel 1.8V Unbuffered 240-pin DDR2 DIMM socket 533/667MHz FSB Maximum memory bandwidth of 10.7GB/s in dual-...

  • Page 28: Ide Interface

    IDE Interface Item Controller Intel ICH7 40-pin PATA slot SATA IDE slot LS-120 support Bootable CD-ROM support Function control Enabled or Disabled by BIOS setup Floppy Disk Drive Interface Item Controller ITE8712F Controller resident LPC bus Disk format support 1.44MB Function control Enabled or Disabled by BIOS setup USB Interface...

  • Page 29: Serial Port

    Serial Port Item Controller ITE 8712F Controller resident LPC bus Quantity Two on the rear panel Connector type Nine-pin D type female connector 16550 UART support Environment Requirements Item Temperature Operating Non-operating (unpacked) Humidity Operating 15% to 80% RH, non-condensing Non-operating 10% to 90% RH, non-condensing at 40 Vibration...

  • Page 30: Power Management Function

    Power Management Function (ACPI Support Function) Device Standby Mode Independent power management timer for hard disk drive devices (zero to 15 minutes, time step = one minute). Hard disk drive goes into Standby mode (for ATA standard interface). Disable V-sync to control the VESA DPMS monitor. Resume method: device activated (keyboard for DOS, keyboard &...

  • Page 31: Chapter 2 Setup Utility

    Setup Utility About the Setup Utility The computer uses the latest Award BIOS (Basic Input and Output System) with support for Windows Plug and Play. The CMOS chip on the main board contains the ROM setup instructions for configuring the main board BIOS. The BIOS Setup Utility displays the system’s configuration status and provides you with options to set system parameters.

  • Page 32: Bios Navigation Keys

    BIOS Navigation Keys The BIOS navigation keys are listed below. Exits the current menu Scrolls through the items on a menu +/-/PU/PD Modifies the selected field’s values Saves the current configuration and exits setup Displays a screen that describes all key functions Loads previously saved values to CMOS Loads a minimum configuration for troubleshooting Loads an optimum set of values for peak...

  • Page 33: Product Information

    Product Information This option displays product information about your system. You can press <Esc> to return to the main menu setting page. Chapter 2...

  • Page 34: Standard Cmos Features

    Standard CMOS Features This option displays basic information about the system. Date and Time The Date and Time items show the current date and time set on the computer. If you are running a Windows OS, these items are automatically updated whenever you make changes to the Windows Date and Time Properties utility.
  • Page 35 IDE HDD Auto-Detection Press <Enter> while this item is highlighted to prompt the Setup Utility to automatically detect and configure an IDE device on the IDE channel. NOTE: If you are setting up a new hard disk drive that supports LBA mode, more than one line will appear in the parameter box.
  • Page 36 Halt On This item determines whether the system stops or not if an error occurs during system boot-up. At defaults “All, But Keyboard”, the boot will be interrupted for all errors except a keyboard error. Base Memory, Extended Memory, and Total Memory These items are automatically detected by the system at start-up time.

  • Page 37: Advanced Bios Features

    Advanced BIOS Features This option defines advanced information about your system. CPU Features (Press Enter) Please note that this function is only available for Prescott CPUs. Scroll to this item and press <Enter> to view the following screen. Chapter 2...

  • Page 38: Thermal Management

    Delay Prior to Thermal This item enables you to set the delay time before the CPU enters auto thermal mode. Thermal Management This item displays CPU’s temperature and enables you to set a safe temperature to Prescott CPU. Intel XD Bit This item is a security feature that helps you protect your CPU and operating system against malicious software executing code.

  • Page 39: Hard Disk Boot Priority

    Hard Disk Boot Priority Scroll to this item and press <Enter> to view the following screen. Virus Warning This item enables or disables the boot sector virus protection. Hyper-Threading Technology You can set “Disabled” or “Enabled” to control Hyper-Threading CPU support in OS. You can set “Enabled”...

  • Page 40: Security Option

    Boot Up NumLock Status This item defines if the keyboard NumLock key is active when your system is booted. Gate A20 Option This item defines how the system handles legacy software that was written for an earlier generation of processors. Set this item for the default value. Typematic Rate Setting If this item is enabled, you can use the following two items to set the typematic rate and the typematic delay settings for your keyboard.

  • Page 41: Silent Boot

    Delay For HDD This item allows the BIOS to support some old or special IDE devices by prolonging this delay time. A larger value will give more delay time to the device for which to initialize and to prepare for activation.

  • Page 42: Advanced Chipset Features

    Advanced Chipset Features These items define critical timing parameters of the main board. You should set these items for their default values unless you are very familiar with the technical specification of your system hardware. If you change the values incorrectly, you may introduce fatal errors or recurring instability into your system.
  • Page 43 DRAM RAS# Precharge Select the number of CPU clocks allocated for the Row Address Strobe (RAS#) signal to accumulate its charge before the DRAM is refreshed. If insufficient time is allowed, refresh may be incomplete and data lost. Precharge Delay (tRAS) The precharge time is the number of cycles it takes for DRAM to accumulate its charge before refresh.

  • Page 44: Integrated Peripherals

    Integrated Peripherals These options display items that define the operation of peripheral components on the system’s input/output ports. OnChip IDE Device Scroll to this item and press <Enter> to view the following screen. Chapter 2...
  • Page 45 IDE HDD Block Mode Block mode is also called block transfer, multiple commands, or multiple sector read/write. If your IDE hard drive supports block mode, select Enabled for automatic detection of the optimal number of block read/write per sector the drive can support. ATA66/100 Cable Msg This item enables or disables the display of the ATA 66/100 Cable MSG.

  • Page 46: Usb Controller

    have to install the UltraDMA driver supplied with this main board in order to use an UltraDMA device. SATA Mode This item allows you to change Serial ATA mode. On-Chip Serial ATA This item can enable or disable the built-in on-chip serial ATA. SATA PORT Speed Settings This item is used to select SATA I or SATA II device support forcedly.

  • Page 47: Onboard Lan Controller

    USB Keyboard Support You can enable this item if you want to use a keyboard connected through the USB port in a legacy operating system (such as DOS) that does not support Plug and Play. USB Mouse Support You can enable this item if you want to use a mouse connected through the USB port in a legacy operating system (such as DOS) that does not support Plug and Play.

  • Page 48: Onboard Fdc Controller

    Onboard FDC Controller If your system has a floppy disk controller (FDC) installed on the system board and you want to use it, you can select Enabled. If you install an add-in FDC or the system has no floppy drive, select Disabled in this field.

  • Page 49: Power Management Setup

    Power Management Setup The system has various power-saving modes including powering down the hard disk, turning off the video, suspending to RAM, and software power down that allows the system to be automatically resumed by certain events. The power-saving modes can be controlled by time-outs. If the system is inactive for a while, the time-outs begin counting.

  • Page 50: Acpi Function

    ACPI Function This item allows users to enable or disable the ACPI power management function. ACPI Suspend Type You can use this item to define how your system suspends. In the default, S3 (STR), the suspend mode is a suspend to RAM, i.e., the system shuts down with the exception of a refresh current to the system memory.
  • Page 51 have to connect the fax/modem to the main board Wake On Modem connector for the feature to work. Soft-Off by PWR-BTTN Under ACPI (Advanced Configuration and Power Management Interface) you can create a software power down. In a software power down, the system can be resumed by Wake Up Alarms. This item lets you install a software power down that is controlled by the power button on your system.
  • Page 52 FDD, COM, LPT Port When this item is enabled, the system will restart the power-saving time-out counters when activity is detected on the floppy disk drive, serial ports, or the parallel port. PCI PIRQ [A-D]# When this item is enabled, activity from one of the listed devices wakes up the system. Power On After Power Fail This item enables your computer to automatically restart or return to its last operating status after power returns from power failure.

  • Page 53: Pnp/Pci Configuration

    PnP/PCI Configuration It configures how PnP (Plug and Play) and PCI expansion cards operate in your system. Both the ISA and PCI buses on the main board use system IRQs (interrupt requests) and DMAs (direct memory access). You must set up the IRQ and DMA assignments correctly through the PnP/PCI Configurations Setup Utility for the main board to work properly.
  • Page 54 reserve for the ISA expansion card. Use the section item Reserve Memory Length to set the amount of reserved memory. Press <Esc> to close the Memory Resources submenu. PCI/VGA Palette Snoop This item is designed to overcome problems that can be caused by some non-standard VGA cards. This board includes a built-in VGA system that does not require palette snooping so you must leave this item disabled.

  • Page 55: Pc Health Status

    PC Health Status On the main board that supports hardware monitoring, you can monitor the parameters of critical voltage, temperature and fan speed. Smart Fan Control This item incorporates linear control metrics to provide optimal cooling. Under normal condition, Smart Fan keeps the fan speed low, minimizing acoustic noise. When the load increases, Smart Fan increases the fan speed to provide optimal cooling.

  • Page 56: Frequency/Voltage Control

    Frequency/Voltage Control It enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the processor you have installed in your system. CPU Speed This item displays the current CPU speed. Users can not make any changes. Auto Detect PCI Clk When it is enabled, BIOS will disable the clock signal of free DIMM and PCI slots.

  • Page 57: Load Default Settings

    Load Default Settings This option opens a dialog box that lets you install optimized defaults for all appropriate items in the Setup Utility. Press <OK> and then <Enter> to install the defaults. Press <Cancel> and then <Enter> to not install the defaults. If you only want to install setup defaults for a specific option, select and display that option, and then press <F9>.

  • Page 58: Chapter 3 Machine Disassembly And Replacement

    Machine Disassembly and Replacement This chapter contains step-by-step procedures on how to disassemble the desktop for maintenance and troubleshooting. To disassemble the computer, you need the tools below: Wrist ground strap and conductive mat for preventing electrostatic discharge Small Philips screw driver Plastic flat head screw driver NOTE: The screws for the different components vary in size.

  • Page 59: General Information

    General Information Before You Begin Before proceeding with the disassembly procedure, you have to make sure that: The system and all peripherals are powered off. The AC adaptor and all power and signal cables from the system are unplugged. NOTE: There are several types of screws used to secure the main unit. The screws vary in length. Group the same type of screws together during the disassembly procedure.

  • Page 60: Aspire E650 Disassembly Procedure

    Aspire E650 Disassembly Procedure This section tells you how to disassemble the system when you need to perform system maintenance or troubleshooting. NOTE: Before you begin, make sure you have turned off the system and all peripherals connected to it.
  • Page 61 Release the three claws marked No. 1. Release the three claws marked No. 2. Then open the front panel. Chapter 3...

  • Page 62: Removing The Optical Disk Drive

    Removing the Optical Disk Drive Disconnect the data cable. Disconnect the power cable. Slide the optical disk drive rails. Remove the optical disk drive in the direction of arrow. Removing the Card Reader and the Floppy Disk Drive Disconnect the data cable and the power cable of floppy disk drive as you do to remove the optical disk drive.

  • Page 63: Removing The Hard Disk Drive

    Removing the Hard Disk Drive Disconnect the SATA cable. Disconnect the power cable. Disconnect the SATA cable linked on the main board. Slide the rails. Pull the hard disk drive holder in the direction of arrow. Chapter 3...

  • Page 64: Removing The Add-On Cards

    Removing the Add-on Cards Reverse the add-on card lock (the black plastic lever) as shown. Remove the VGA card. Remove the TV-Tuner card. Remove the modem card. Chapter 3...

  • Page 65: Removing The Power Supply

    Removing the Power Supply Release the four screws fastening the power supply. Disconnect the ATX power cable and the ATX_12V power cable. Pull out the power supply in the direction of arrow. Chapter 3...

  • Page 66: Removing The System Fan

    Removing the System Fan Release the four screws fastening the system fan. Disconnect the system fan power cable. Remove the system fan. Chapter 3...

  • Page 67: Removing The Memory

    Removing the Memory Push down on the two clips at the same time to unlatch the memory. Remove the memory by grasping two ends and pulling straight up. Chapter 3...

  • Page 68: Removing The Cpu

    Removing the CPU Release the CPU cover lock and reverse it as shown. Open the CPU cover. Detach the CPU carefully because the socket contains pins that are fragile and can be damaged easily. Grease (in the surface at the splatter) Note: When heat sink is removed from CPU, wipe off the thermal diffusion grease and put new silicon compound to the place shown in the figure.

  • Page 69: Removing The Main Board

    Removing the Main Board Release the screws in a crisscross pattern, making each screw partially loosened. Repeat the steps to finally remove all screws on the second round. time can damage the CPU and the socket because of the pressure of the spring coils. Disconnect the CPU fan cable.

  • Page 70: Chapter 4 Troubleshooting

    Troubleshooting Please refer to generic troubleshooting guide in the service guide database for information with respect to following topics: Power-On Self-Test (POST) POST Check Points POST Error Messages List Error Symptoms List Chapter 4 Chapter 4...

  • Page 71: Chapter 5 Jumper And Connector Information

    Chapter 5 Jumper and Connector Information Introduction of Connectors Main Board Placement Chapter 5...
  • Page 72 Name CPU socket CPU_FAN DIMM1~4 ATX1 IDE1 SATA1~4 BIOS_WP IRDA F_PANEL F_USB1~2 CLR_CMOS 1393CN1 COM2 SPDIF F_AUDIO CD_IN PCI1~2 PCIE2 PCIEX16 SYS_FAN R_USB ATX12V Description LGA775 socket for Pentium 4 / Celeron D / Pentium D CPU CPU cooling fan connector 1.8V 240-pin DDR2 SDRAM slots ATX power supply connector Primary IDE channel...

  • Page 73: Power Cable Connectors

    Power Cable Connectors Please note that the 20-pin and 24-pin power cables can both be connected to the ATX1 connector. With the 20-pin power cable, just align the 20-pin power cable with the pin one of the ATX1 connector. However, using 20-pin power cable may make the system unbootable or unstable because of insufficient electricity.
  • Page 74 SYS_FAN: FAN Power Connector Signal Name +12V Sense ATX1: ATX 24-pin Power Connector Signal Name +3.3V +3.3V PWR OK 5VSB +12V +12V +3.3V ATX12V: ATX 12V Power Connector Signal Name Ground Ground +12V +12V Function System Ground Power +12V Sensor Signal Name +3.3V -12V...

  • Page 75: Front Panel Header

    Front Panel Header The front panel header (F_PANEL) provides a standard set of switch and LED headers commonly found on ATX or Micro ATX cases. Refer to the table below for information. Signal Name HDD_LED_P HDD_LED_N RST_SW_N RST_SW_P ODD_LED_P ODD_LED_N Hard Drive Activity LED Connecting pin one and pin three provides visual indication that data is being read from or written to the SATA hard drive, while pin 11 and pin 13 shows that of the IDE hard drive.

  • Page 76: Ide Connector

    IDE Connector The main board supports four high data transfer SATA ports with each runs up to 3.0 Gb/s. To get better system performance, users can connect the CD-ROM to the IDE channel, and set up the hard drives on the SATA ports. IDE devices enclose jumpers or switches used to set an IDE device as Master or Slave.

  • Page 77: Optional Devices

    PCI1~2 This main board is equipped with two standard PCI slots. The PCI slots on this main board are PCI v2.3 compliant. NOTE: Before installing an add-on card, check the user guideline for the card carefully. If the card is not Plug and Play, you may have to manually configure the card before installation.
  • Page 78 SATA1~4: Serial ATA Connectors These connectors are used to support the new Serial ATA devices for the higher date transfer rates (3.0 Gb/s), simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface but still maintains the register compatibility and software compatibility with Parallel ATA.
  • Page 79 F_USB1~2 / R_USB: Front Panel USB Headers The main board has four USB ports laid on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connector to connect the front-mounted ports.

  • Page 80: I/O Devices

    I/O Devices The backplane of the main board has the following I/O ports: Part Name PS2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard. Parallel Port (LPT1) Use LPT1 to connect printers or other parallel communication devices.

  • Page 81: Jumper Settings

    Jumper Settings This section explains how to set jumpers for correct configuration of the main board. Jumper Type BIOS_WP 3 pins CLR_CMOS 3 pins Chapter 5 Description Flash Protect 1-2: WRITE 2-3: PROTECT CLR_CMOS 1-2: CLR CMOS 2-3: NORMAL Before clearing the CMOS, make sure to turn off the system.

  • Page 82: Chapter 6 Fru (Field Replaceable Unit) List

    NOT be noted on the printed service guide. For Acer authorized service providers, your Acer office may have a different part number code from those given in the FRU list of this printed service guide. You MUST use the local FRU list provided by your regional Acer office to order FRU parts for service.

  • Page 83: Exploded Diagram

    Exploded Diagram Chapter 6...
  • Page 84 Item Description 5.25” ROTATE COVER A451 BEZEL CD-ROM FDD WITH PANEL HDD-DISK MOTHER BOARD HDD-LOCK-SLIDE FDD-LOCK-SLIDE CDROM-LOCK-SLIDE USB BOARD USB BKT RIGHT-SIDE CHASSIS POWER-SUPPLY PCC-BKT LEFT-SIDE Chapter 6...

  • Page 85: Parts

    "FRONT BEZEL W/ POWER BUTTON, 5.25"" 3.5"" EMPTY COVER" POWER BUTTON ODD COVER 1 W/ HOLDER ODD COVER 2 W/ HOLDER TOP COVER ASSY FRONT COVER WITH ACER LOGO CHASSIS W/O SIDE DOOR W/O I/O SHIELD H401 SIDE DOOR-LEFT Description AXX0000-3833EP...
  • Page 86 "P4 830 (3.0G / 800FSB / 2X1MB / DUAL CORE/ LGA-775 / EM64T), B-0 STEPPING, 870801" "P4 820 (2.8G / 800FSB / 2X1MB / DUAL CORE/ LGA-775 / EM64T) B-0 STEPPIN, MM#870800" Acer Part No. 60.S46VF.006 42.S46VF.004 42.S46VF.005 42.S46VF.006 42.S46VF.007 42.S46VF.008...
  • Page 87 "USB BALL MOUSE, 2 BUTTON+WHEEL, LEAD-FREE" "RF MOUSE,RAF95, LOGITECH" "LOGITECH WIRELESS MOUSE, RAF95, WITH STK LABEL" "USB OPTICAL MOUSE, MUV ACR1(BLACK),LEAD-FREE" "LOGITECH USB OPTICAL MOUSE, MUV ACR1, LEAD-FREE, W/ STK LABEL" Acer Part No. KF.25602.003 54.ATIX3.H03 54.ATIX6.H51 VG.62LET.C21 VG.62LET.C32 VG.66LE1.C01 TU.63802.003 TV.HAUDV.BT2 TV.HAUDV.BT3 TV.AMITY.H21...
  • Page 88 EKEY),LF BLACK" "PS/2 KEYBOARD,KB2971,UK VER.,104KS,JPN ABS(WITH EKEY),LF BLACK" "PS/2 KEYBOARD,KB2971,FRENCH VER.,105KS,JPN ABS(WITH EKEY),LF BLACK" "PS/2 KEYBOARD,KB2971,GERMANY VER.,105KS,JPN ABS(WITH EKEY),LF BLACK" "PS/2 KEYBOARD,KB2971,ITALIAN VER.,105KS,JPN ABS(WITH EKEY),LF BLACK" Acer Part No. MS.PS201.002 MS.V6901.003 MS.V6901.004 KB.KBP03.215 KB.KBP03.217 KB.KBP03.218 KB.KBP03.219 KB.KBP03.220 KB.KBP03.221 KB.KBP03.222 KB.KBP03.223 KB.KBP03.224 KB.KBP03.225...
