Operating Instructions
LED TV
50-inch model
58-inch model
65-inch model
75-inch model
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and
retain them for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0417-1057
For more detailed instructions, please refer to
[eHELP] (Built-in Operating Instructions).
●
How to use [eHELP]
(p. 25)
EX750H series
TQB4GC1667-1
English
Advertisement
Table of Contents
Related Manuals for Panasonic VIERA EX750H Series
Summary of Contents for Panasonic VIERA EX750H Series
- Page 1 ● How to use [eHELP] (p. 25) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
-
Page 2: Table Of Contents
● For information about the trademarks, refer to [eHELP] (Search by Purpose > Read first > Before use > Licence). The illustration for TH-58EX750H is used in this manual unless otherwise mentioned. Contents Illustrations shown may be different between models and countries. -
Page 3: Important Notice
Panasonic has no authority to and does not grant you that permission and explicitly disclaims any right, ability or intention to obtain such permission on your behalf. -
Page 4: Safety Precautions
Do not use an unapproved pedestal / mounting ● Insert the mains plug fully into the mains socket. equipment. Be sure to ask your local Panasonic ● dealer to perform the setup or installation of approved To turn Off the apparatus completely, you must pull the mains plug out of the mains socket. - Page 5 Do not use the pedestal if it becomes warped or Caution physically damaged. If this occurs, contact your ● nearest Panasonic dealer immediately. The TV uses the 2.4 GHz radio frequency ISM band (Bluetooth ). To avoid malfunctions or slow response ®...
- Page 6 ■ ■ Moving the TV Viewing 3D Images Caution Caution Before moving the TV, disconnect all cables. ● Pay special attention when children are viewing 3D images. 3D images should not be viewed by children ● At least two people are required to move the TV. younger than about 6 years old, as a guideline.
-
Page 7: Accessories
Accessories Optional accessories 3D Eyewear ● If you need 3D Eyewear, please purchase Panasonic optional accessories. Standard accessories ● Use Panasonic 3D Eyewear supporting Bluetooth wireless technology for active shutter 3D. Remote Control ● For information about 3D Eyewear (English only): (p. - Page 8 Cover About the pedestal height 50-inch model 58-inch model 50-inch model 58-inch model ● Select a pedestal height from the following 4 types. ● The pedestal height can be changed according to step 2 in “Assembling the pedestal”. (p. 9) ●...
- Page 9 Preparations Take out the pedestal and the TV from the packing case and put the TV onto a work table with the screen panel down on the clean and soft cloth (blanket, etc.) ● Use a flat and firm table bigger than the TV. ●...
- Page 10 English...
- Page 11 Assembling the pedestal 65-inch model ■ To change the height Be sure to perform the following procedures when you change the height after assembling the pedestal. 1 Remove the cover 2 Remove the assembly screws from the base. 3 Lift the TV and pull out the pole from the base. 4 Put the TV onto a work table with the screen panel down on the clean and soft cloth.
- Page 12 English...
- Page 13 Adjusting the panel to your desired angle 50-inch model 58-inch model 65-inch model ● Do not place any objects within the full rotation range. 15° 15° (View from the top) English...
- Page 14 Removing the pedestal Assembling / Removing the pedestal 75-inch model Be sure to remove the pedestal in the following procedures when you repack the TV. Assembly screw (4) 1 Remove the cover 2 Remove the assembly screws from the base. M4 ×...
- Page 15 Removing the pedestal Be sure to remove the pedestal in the following procedures when you use the wall-hanging bracket or repack the TV. 1 Remove the cover 2 Remove the assembly screws from the pedestal. 3 Pull out the pedestal from the TV. English...
-
Page 16: Connections
Connections Terminals ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. ● Check the terminal type and cable plugs are correct for connection. - Page 17 ● For Digital TV, Analogue TV Network ● Keep RF (aerial) cable away from the mains lead to A broadband network environment is required to be able avoid and minimise mains interference pickup. to use internet services. ● Do not place the RF cable under the TV. ●...
- Page 18 ■ Amplifier (listening with external speakers) [Mode2]: For the 4K compatible equipment that has the ● Use HDMI2 to connect the TV to an amplifier which function to output the image precisely with the has ARC (Audio Return Channel) function. expanded colour gamut If connecting to an amplifier without ARC function, ●...
- Page 19 Bundle the cable Cable arrangement Fix the cables using the cable clamp, cable tie, etc. and then attach the cable cover / terminal cover to the TV. ■ Fixing the mains lead using the cable clamp 50-inch model 58-inch model To release: Keep pushing the tab To remove from the TV:...
- Page 20 75-inch model 50-inch model 58-inch model ■ Fixing the cables using the cable band Attach the cable tie Insert the cable tie in a hole Attach the cable band Hole Bundle the cables Bundle the cables Set the tip in the hooks Hooks To loosen: ●...
- Page 21 English...
-
Page 22: Identifying Controls
Identifying Controls 7 OK ● Confirms selections and choices. ● Press after selecting channel positions to quickly change channel. ● Displays channel list. Remote Control 8 [Option Menu] ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ●... - Page 23 ■ Installing / Removing batteries 6 Volume Up / Down ● Cursor Left / Right (when in the menu system) 7 Mains power On / Off switch Pull open ● Use to switch the mains power. ● To turn Off the apparatus completely, you must pull Hook the mains plug out of the mains socket.
-
Page 24: First Time Auto Tuning
First time Auto Tick the TV signal mode to tune, and then select [Start Auto Tuning] Tuning : tune (search for the available channels) : skip tuning ■ When you select the analogue TV signal, When the TV is turned on for the first time, it will select your area. -
Page 25: Watching
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... -
Page 26: Viewing 3D Images
To view the 3D images ● Use Panasonic 3D Eyewear supporting Bluetooth wireless technology for active shutter 3D. ■ Playing back 3D-compatible Blu-ray disc (Frame Sequential format) ●... - Page 27 Note ● Turn off the 3D Eyewear after using it. ● Use the 3D Eyewear within approximately 3.2 m from the TV. You cannot view the 3D images with the 3D Eyewear too far from the TV, because of the difficulty of receiving radio waves from the TV.
-
Page 28: Faqs
FAQs Parts of the TV become hot ● Parts of the TV may become hot. These temperature rises do not pose any problems in terms of performance or quality. Before requesting service or assistance, please follow these simple guides to solve the problem. When pushed with a finger, the display panel moves ●... -
Page 29: Maintenance
Maintenance Specifications ■ First, remove the mains plug from the mains socket. Model No. : TH-50EX750H Display panel, Cabinet, Pedestal 50-inch model : TH-58EX750H 58-inch model Regular care: : TH-65EX750H 65-inch model Gently wipe the surface of the display panel, cabinet, : TH-75EX750H 75-inch model or pedestal by using a soft cloth to remove dirt or... - Page 30 75-inch model HDMI 1 / 2 / 3 / 4 input 62.5 Net (With Pedestal) TYPE A Connectors 54.0 Net (TV only) HDMI1 / 3 / 4: 4K, 3D (3D content of 4K format is Power source not supported.), Content Type, Deep Colour, x.v.Colour™...
- Page 31 Receiving channels (Analogue TV) *2: Not all the Bluetooth compatible devices are available with this TV. Up to 5 devices can be used VHF BAND simultaneously (except the 3D Eyewear). 2-12 (PAL/SECAM B, K1) Note 0-12 (PAL B AUST.) ● Design and Specifications are subject to change 1-9 (PAL B N.Z.) without notice.
- Page 32 Please contact your local Panasonic dealer to purchase the recommended wall-hanging bracket. ● Holes for wall-hanging bracket installation Rear of the TV 50-inch model 58-inch model 65-inch model a: 400 mm b: 200 mm 75-inch model a: 600 mm b: 300 mm...
- Page 36 Warranty Service purposes. Model Number Serial Number English Web Site: http://www.panasonic.com © Panasonic Corporation 2017 Printed in Malaysia...
