- Page 1 User manual TC222L TC242L The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance.
-
Page 2: Table Of Contents
Table Of Contents BEFORE USING THE Copyright PRODUCT Icons used in this manual Cleaning Securing the Installation Space Precautions for storage Safety Precautions Symbols Electricity and Safety Installation and Safety Operation and Safety Correct posture to use the product PREPARATIONS Checking the Contents Checking the Components Parts... - Page 3 Table Of Contents Using IGEL OS - "Accessories" Network Diagnostics Using IGEL OS - "User Interface" Screen Screen Saver and Screen Lock Using IGEL OS - "Network" LAN Interfaces Using IGEL OS - "Devices" USB Storage Devices CONNECTING AND USING Before Connecting A SOURCE DEVICE Pre-connection Checkpoints...
- Page 4 Table Of Contents SAMSUNG MAGIC Bright Configuring SAMSUNG MAGIC Bright SAMSUNG MAGIC Angle Configuring SAMSUNG MAGIC Angle SAMSUNG MAGIC Upscale Configuring SAMSUNG MAGIC Upscale Image Size Changing the Image Size H-Position & V-Position Configuring H-Position & V-Position Coarse Adjusting Coarse...
- Page 5 INFORMATION MENU AND INFORMATION OTHERS Displaying INFORMATION Configuring Brightness, Contrast and Sharpness from the Initial Screen TROUBLESHOOTING Requirements Before Contacting Samsung Customer Service Center GUIDE Testing the Product Checking the Resolution and Frequency Check the following. Q & A SPECIFICATIONS General...
- Page 6 Table Of Contents APPENDIX Responsibility for the Pay Service (Cost to Customers) Not a product defect A Product damage caused by customer's fault Others Terminology INDEX Table Of Contents...
-
Page 7: Before Using The Product
The contents of this manual are subject to change without notice to improve quality. © 2016 Samsung Electronics Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. Microsoft, Windows are registered trademarks of Microsoft Corporation. -
Page 8: Cleaning
Before Using the Product Cleaning Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched. Take the following steps when cleaning. 1. Power off the monitor and computer. 2. Disconnect the power cable from the monitor. Hold the power cable by the plug and do not touch the cable with wet hands. -
Page 9: Securing The Installation Space
10 cm 10 cm (3.93 inches) (3.93 inches) 10 cm (3.93 inches) Precautions for storage Be sure to contact Samsung Customer Service Center if the inside of the monitor needs cleaning. (Service fee will be charged.) Before Using the Product... -
Page 10: Safety Precautions
Before Using the Product Safety Precautions Caution RISK OF ELECTRIC SHOCK DO NOT OPEN Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL. This symbol indicates that high voltage is present inside. -
Page 11: Electricity And Safety
Before Using the Product Electricity and Safety The following images are for reference only. Real-life situations may differ from what is shown in the images. Warning Do not use a damaged power cable or plug, or a loose power socket. An electric shock or fire may result. -
Page 12: Installation And Safety
The product may become damaged by an electric shock. Do not use the power cable for products other than authorized products supplied by Samsung. An electric shock or fire may result. Keep the power socket where the power cord is connected unobstructed. - Page 13 Before Using the Product Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.). The product may fall and break or cause a personal injury. Using the product in an area with excess vibration may damage the product ...
-
Page 14: Operation And Safety
SAMSUNG period of time) may seriously affect its performance. Be sure to consult Samsung Customer Service Center before installation if you want to install the product at such a place. - Page 15 (paper, match, etc.) into the vent or ports of the product. If water or any foreign substance enters the product, be sure to power off the product, remove the power cable, and contact Samsung Customer Service Center. Product failure, an electric shock or fire may result.
- Page 16 Before Using the Product Caution Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels. If you are not going to use the product for an extended period of time, ...
- Page 17 Before Using the Product Looking at the screen too close for an extended period of time can deteriorate your eyesight. Do not hold the monitor upside-down or move it by holding the stand. The product may fall and break or cause a personal injury. ...
-
Page 18: Correct Posture To Use The Product
Before Using the Product Correct posture to use the product Use the product in the correct posture as follows: Straighten your back. Allow a distance of 45 to 50 cm between your eye and the screen, and look slightly ... -
Page 19: Preparations
Preparations Checking the Contents 1.1.1 Checking the Components Contact the dealer from whom you purchased the product if any item is missing. The pictures may look different from the actual components. Components Warranty card Quick Setup Guide Regulatory guide (Not available in some locations) Power cable AC/DC power adapter... -
Page 20: Parts
OSD control is locked.) Press [ ] to enable or disable Eye Saver Mode. The items below are not available if the Eye Saver Mode function is enable. SAMSUNG SAMSUNG PICTURE Brightness, Game Mode, Bright, Angle MAGIC MAGIC ... - Page 21 Preparations Icons Description Move to the upper or lower menu or adjust the value for an option on the OSD menu. Confirm a menu selection. Pressing the [ ] button when the OSD menu is not displayed will change the input source (Client/Analog). If you power on the product or change the input source by pressing the [ ] button, a message that shows the changed input source will appear at the top left corner of...
-
Page 22: Rear View
Preparations 1.2.2 Rear View The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. DC 14V DVI-I OUT Port Description Connects to the AC/DC power adapter. Connects to a Monitor device using the DVI or DVI to RGB cable. Connect to a network using the LAN cable. -
Page 23: Side View
Preparations 1.2.3 Side View The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. Port Description Connect to an audio output device such as headphones. Connect to a microphone. Connect to a USB device. -
Page 24: Installation
Preparations Installation 1.3.1 Attaching the Stand Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards. Place a protective cloth or Insert the stand base into the Do not remove the fixing pin until cushion on a flat surface. -
Page 25: Adjusting The Product Tilt And Height
Preparations 1.3.2 Adjusting the Product Tilt and Height The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. -3°(±2°) - 25°(±2°) To adjust the height, remove the fixing pin. ... -
Page 26: Installing A Wall-Mount Kit Or Desktop Stand
Preparations 1.3.4 Installing a Wall-mount Kit or Desktop Stand Before Installation Power the product off and remove the power cable from the power socket. Place a protective cloth or Unfasten the screw from the Lift and detach the stand. cushion on a flat surface. Next, back of the product. - Page 27 Samsung shall not be held liable for any damage or injury caused by using improper screws or attaching the wall-mount kit or desktop stand using excessive force. Samsung shall not be held liable for any product damage or personal injury caused by using a wall- ...
-
Page 28: Anti-Theft Lock
Preparations 1.3.5 Anti-theft Lock An anti-theft lock allows you to use the product securely even in public places. The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details. The lock device is sold separately. To lock an anti-theft locking device: Fix the cable of your anti-theft locking device to a heavy object such as a desk. -
Page 29: Using The Software
Using the Software Using IGEL OS - "common" 2.1.1 General System Information Within the Application Launcher, the Information page has important system data, such as the firmware version, licensed services and hardware specifications. Details of the current network configuration with the IP address and device name are also provided. 2 Using the Software... -
Page 30: Using Igel Os - "Sessions
Using the Software Using IGEL OS - "Sessions" 2.2.1 Citrix ICA Sessions Menu path: Setup Sessions Citrix XenDesktop / XenApp Legacy ICA Sessions If a session is created or edited, you can change the ICA session settings if they differ from the global settings. - Page 31 Using the Software Server Menu path: Setup Sessions Citrix XenDesktop / XenApp Legacy ICA Sessions Session Name Server Browser Protocol Allows you to select the protocol needed for transmission or global standard settings Don't use default server Lists the standard server requirements for each protocol separately location Server By clicking Browse, you send a transmission signal which queries...
- Page 32 Using the Software Logon Menu path: Setup Sessions Citrix XenDesktop / XenApp Legacy ICA Sessions Session Name Logon Use Kerberos Passthrough Enables single sign-on for this ICA session if Log on to the thin authentication for the session client with AD/Kerberos is configured. The server must also be configured for pass-through authentication.
-
Page 33: Citrix Storefront / Web Interface
Using the Software 2.2.2 Citrix StoreFront / Web Interface Menu path: Setup Sessions Citrix XenDesktop / XenApp Citrix StoreFront / Web Interface Some of the settings are already configured under Global settings for ICA and in the ICA session setup. Select the start options for the Citrix XenApp session. -
Page 34: Rdp Sessions
Using the Software 2.2.3 RDP Sessions Menu path: Setup Sessions RDP Sessions The following configuration pages offer you detailed setup options for the session: Server and Logon Allows you to specify a server and a start application for the terminal server session. The necessary logon information is configured here. - Page 35 Using the Software Options Allows you to specify the start application and the work directory for use during the session (how authentication errors are handled during the logon procedure). If, when connecting to the server, a terminal server gateway is to be used, you can configure the relevant settings here (No Gateway is pre-set).
-
Page 36: Horizon Client Sessions
Using the Software Microsoft RemoteApp Like the published applications of a Citrix server, MS Windows Server 2008 offers the option of passing on RemoteApps to the thin client. Detailed instructions regarding server configuration can also be found on the Microsoft website: TS RemoteApp Step-by-Step Guide. On the client side, only a few parameters need to be configured after enabling the RemoteApp mode. - Page 37 Using the Software Connection Settings Menu path: Setup Sessions Horizon Client Horizon Client Sessions Session Name Connection Settings In this area, you can specify the settings for the connection between the Horizon Client and the server. Server URL: URL of the VMware Horizon server ...
-
Page 38: Media Player
Using the Software 2.2.5 Media Player Menu path: Setup Sessions Media Player Set up the Media Player for your multimedia applications here. IGEL Linux supports the following multimedia formats and codecs out of the box: Ogg/Vorbis Ogg/Theora FLAC ... - Page 39 Using the Software Media Player Sessions Menu path: Setup Sessions Media Player Media Player Sessions You can set up your own personal Media Player sessions here. Click on Add to create a new session. Specify a Session Name. Specify which possible ways of launching the session you would like. You may choose a number of options.
-
Page 40: Using Igel Os - "Accessories
Using the Software Using IGEL OS - "Accessories" 2.3.1 Network Diagnostics Menu path: Setup Accessories Network Tools The IGEL Universal Desktop Linux firmware features a number of tools for network analysis. These include: Devices information Ping Netstat Traceroute ... -
Page 41: Using Igel Os - "User Interface
Using the Software Using IGEL OS - "User Interface" 2.4.1 Screen Menu path: Setup User Interface Display Color Depth Allows you to select the desktop color depth. The following options are available: 16 bits per pixel (High Color / 65,000 colors) ... - Page 42 DDC is enabled by default and the native resolution supported by the screen is determined automatically. Screen configuration Extended screen connected to Samsung Linux thin client TC222L or TC242L can be configured independently. The position of the individual screens can be determined in relation to Screen.
-
Page 43: Screen Saver And Screen Lock
Using the Software 2.4.2 Screen Saver and Screen Lock Menu path: Setup User Interface Screen Lock/Saver You can set up the screen saver so that it is activated either automatically or in response to a key combination (Hotkey). You can also select a password option. The look of the taskbar can be configured separately for the logon dialog and the locked screen. -
Page 44: Using Igel Os - "Network
Using the Software Using IGEL OS - "Network" 2.5.1 LAN Interfaces Menu path: Setup Network LAN Interfaces Click on Network LAN Interfaces in the client setup. Choose either automatic network setup with the protocols DHCP and BOOTP or manual network configuration in order to set the thin client for each network interface. -
Page 45: Using Igel Os - "Devices
Using the Software Using IGEL OS - "Devices" 2.6.1 USB Storage Devices Menu path: Setup Devices Storage Devices USB storage devices can be configured here. Hotplug storage devices Menu path: Setup Devices Storage Devices Storage Hotplug In this area, you can set up the connection for hotplug storage devices. These can be, for example, USB mass storage devices or MMC card readers. -
Page 46: Connecting And Usinga Source Device
Connecting and Using a Source Device Before Connecting 3.1.1 Pre-connection Checkpoints Before connecting a source device, read the user manual provided with it. The number and locations of ports on source devices may differ from device to device. Do not connect the power cable until all connections are completed. ... -
Page 47: Connecting To A Dual Monitor
Connecting and Using a Source Device 3.2.2 Connecting to a Dual Monitor Do not connect the power cable before connecting all other cables. Ensure you connect a source device first before connecting the power cable. DVI-I OUT RGB IN DVI-I OUT DVI IN Connect [DVI-I OUT] on the product to [DVI IN] or [RGB IN] on another monitor using a DVI or DVI to D-SUB cable. -
Page 48: Connecting To Headphones
Connecting and Using a Source Device 3.2.3 Connecting to Headphones Do not connect the power cable before connecting all other cables. Ensure you connect a source device first before connecting the power cable. Connect an audio output device (headphones) to [ ] on the back of the product. -
Page 49: Connecting The Power
Connecting and Using a Source Device 3.2.5 Connecting the Power Connecting parts may differ in different products. The exterior may differ depending on the product. Power connection using detachable AC/DC power adapter Connect the power cable to the AC/DC power adapter. ... -
Page 50: Setting Optimum Resolution
Connecting and Using a Source Device 3.2.6 Setting Optimum Resolution An information message about setting optimum resolution will appear if you power on the product for the first time after purchase. Select a language and change the resolution to the optimum value. Setup Guide The optimal resolution for this monitor is as follows:... -
Page 51: Screen Setup
Configure the screen settings such as brightness and color tone. Brightness You can adjust the general brightness of the picture. (Range: 0~100) A higher value will make the picture appear brighter. SAMSUNG This menu is not available when Bright is set to Dynamic Contrast mode. -
Page 52: Contrast
Screen Setup Contrast Adjust the contrast between the objects and background. (Range: 0~100) A higher value will increase the contrast to make the object appear clearer. SAMSUNG This menu is not available when Bright is in Cinema Dynamic Contrast mode. -
Page 53: Sharpness
Screen Setup Sharpness Make the outline of objects more clear or blurry. (Range: 0~100) A higher value will make the outline of objects clearer. SAMSUNG This menu is not available when Bright is in Cinema Dynamic Contrast mode. MAGIC... -
Page 54: Eye Saver Mode
The following screen will appear. PICTURE Set to an optimum picture quality suitable Brightness for eye relaxation. Contrast Sharpness Eye Saver Mode Game Mode SAMSUNG MAGIC Bright Custom SAMSUNG MAGIC Angle AUTO AUTO AUTO AUTO Press [ ] to move to the option you want and press [ The selected option will be applied. -
Page 55: Game Mode
PICTURE Optimizes image settings for playing Brightness games. Contrast Sharpness Eye Saver Mode Game Mode Custom SAMSUNG MAGIC Bright Always On SAMSUNG MAGIC Angle AUTO AUTO AUTO Press [ ] to move to the option you want and press [ The selected option will be applied. -
Page 56: Samsung Magic Bright
product. You can customize the brightness to suit your preferences. 4.6.1 Configuring SAMSUNG MAGIC Bright Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 57: Samsung Magic Angle
product. This feature provides the viewing angle, brightness, and tint to suit your preferences. 4.7.1 Configuring SAMSUNG MAGIC Angle Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. - Page 58 Screen Setup Custom: Lean Back Mode 1 will be applied by default if Custom is selected. Press [ ] to move to the option you want and press [ The selected option will be applied. 4 Screen Setup...
-
Page 59: Samsung Magic Upscale
The functions available on the monitor may vary depending on the model. Refer to the actual product. 4.8.1 Configuring SAMSUNG MAGIC Upscale Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 60: Image Size
Press [ ] to move to Image Size and press [ ] on the product. The following screen will appear. PICTURE Choose the size and SAMSUNG aspect ratio of the MAGIC Upscale picture displayed on screen. Auto Image Size H-Position... -
Page 61: Configuring H-Position & V-Position
H-Position or V-Position, and press [ The following screen will appear. PICTURE PICTURE Move the image Move the image SAMSUNG SAMSUNG displayed on the displayed on the MAGIC Upscale MAGIC Upscale screen to the left or screen up or down. -
Page 62: Coarse
[ ] on the product. Press [ ] to move to Coarse and press [ ] on the product. The following screen will appear. PICTURE Adjust the screen SAMSUNG frequency. MAGIC Upscale Image Size Wide H-Position V-Position Coarse 2200 Fine... -
Page 63: Fine
] on the product. Press [ ] to move to Fine and press [ ] on the product. The following screen will appear. PICTURE Fine-tune the SAMSUNG MAGIC Upscale screen to get a vivid Image Size Wide picture. H-Position V-Position... -
Page 64: Configuring Tint
Configuring Tint A detailed description of each function is provided. Refer to your product for details. Adjust the tint SAMSUNG of the screen. This menu is not available when Bright is in Cinema Dynamic Contrast MAGIC mode. This menu is not available when... -
Page 65: Green
Configuring Tint Green Adjust the value of the color green in the picture. (Range: 0~100) A higher value will increase the intensity of the color. 5.2.1 Configuring Green Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 66: Blue
Configuring Tint Blue Adjust the value of the color blue in the picture. (Range: 0~100) A higher value will increase the intensity of the color. 5.3.1 Configuring Blue Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 67: Color Tone
Configuring Tint Color Tone Adjust the general color tone of the picture. SAMSUNG This menu is not available when Angle is enabled. MAGIC 5.4.1 Configuring the Color Tone Settings Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 68: Gamma
Configuring Tint Gamma Adjust the mid-range brightness (Gamma) of the picture. SAMSUNG This menu is not available when Angle is enabled. MAGIC 5.5.1 Configuring Gamma Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 69: Resizing Or Relocating The Screen
Resizing or Relocating the Screen A detailed description of each function is provided. Refer to your product for details. Language Set the menu language. A change to the language setting will only be applied to the onscreen menu display. It will not be applied to other functions on your PC. -
Page 70: Menu H-Position & Menu V-Position
Resizing or Relocating the Screen Menu H-Position & Menu V-Position Menu H-Position: Move the menu position to the left or right. Menu V-Position: Move the menu position up or down. 6.2.1 Configuring Menu H-Position & Menu V-Position Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 71: Display Time
Resizing or Relocating the Screen Display Time Set the on-screen display (OSD) menu to automatically disappear if the menu is not used for a specified period of time. Display Time can be used to specify the time after which you want the OSD menu to disappear. 6.3.1 Configuring Display Time Press any button on the front of the product to display the Function Key Guide. -
Page 72: Transparency
Resizing or Relocating the Screen Transparency Set the transparency for the menu windows: 6.4.1 Changing Transparency Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. Press [ ] to move to MENU SETTINGS... -
Page 73: Setup And Reset
Setup and Reset Reset All Return all the settings for the product to the default factory settings. 7.1.1 Initializing Settings (Reset All) Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. -
Page 74: Smart Eco Saving
Setup and Reset Smart Eco Saving Smart Eco Saving function reduces power consumption by controlling the electric current used by the monitor panel. This menu is not available when Eye Saver Mode is enabled. Game Mode will automatically turn off when Smart Eco Saving is enabled. -
Page 75: Off Timer Plus
Setup and Reset Off Timer Plus You can set the product to automatically turn off. The functions available on the monitor may vary depending on the model. Refer to the actual product. 7.3.1 Configuring Off Timer Off Timer Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. - Page 76 Setup and Reset On: Activate the off timer so that the product powers off automatically. Press [ ] to move to the option you want and press [ The selected option will be applied. Turn Off After Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen.
-
Page 77: Configuring Eco Timer
Setup and Reset 7.3.2 Configuring Eco Timer Eco Timer Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. Press [ ] to move to SETUP&RESET and press [ ] on the product. - Page 78 Setup and Reset Eco Off After Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. Press [ ] to move to SETUP&RESET and press [ ] on the product.
-
Page 79: Key Repeat Time
Setup and Reset Key Repeat Time Control the response rate of a button when the button is pressed. The functions available on the monitor may vary depending on the model. Refer to the actual product. 7.4.1 Configuring Key Repeat Time Press any button on the front of the product to display the Function Key Guide. -
Page 80: Information Menu And
INFORMATION Menu and Others INFORMATION View the current input source, frequency and resolution. 8.1.1 Displaying INFORMATION Press any button on the front of the product to display the Function Key Guide. Next, press [ MENU to display the corresponding menu screen. Press [ ] to move to INFORMATION. -
Page 81: Configuring Brightness, Contrast And Sharpness From The Initial Screen
Initial Screen Adjust the Brightness, Contrast Sharpness setting using the [ ] buttons in the initial screen (where no OSD menu is displayed). Brightness SAMSUNG This menu is not available when Bright is set to Dynamic Contrast mode. MAGIC... -
Page 82: Troubleshooting Guide
Requirements Before Contacting Samsung Customer Service Center 9.1.1 Testing the Product Before calling Samsung Customer Service Center, test your product as follows. If the problem persists, contact Samsung Customer Service Center. Check if your product is operating normally by using the product test function. - Page 83 Troubleshooting Guide Screen issue Issues Solutions The power LED is off. The screen will not switch Check that the power cable is connected properly. (Refer to "3.2 Connecting and Using a PC") The message Check Signal Cable appears. Check that the cable is properly connected to the product.
- Page 84 Troubleshooting Guide Issues Solutions There is no image on the screen and the power The product is operating in power-saving mode. LED blinks every 0.5 to 1 second. Press any key on the keyboard or move the mouse to return to normal operating mode. Sound issue Issues Solutions...
- Page 85 Troubleshooting Guide Q & A Question Answer How can I change the Set the frequency on your graphics card. frequency? Windows XP: Go to Control Panel Appearance and Themes Display Settings Advanced Monitor, and adjust Refresh rate under Monitor settings. Windows ME/2000: Go to Control Panel Display ...
- Page 86 Troubleshooting Guide Question Answer How can I change the Windows XP: Go to Control Panel Appearance and resolution? Themes Display Settings, and adjust the resolution. Windows ME/2000: Go to Control Panel Display Settings, and adjust the resolution. Windows Vista: Go to Control Panel Appearance and ...
-
Page 87: Specifications
This does not affect product performance. The above specifications are subject to change without notice to improve quality. This device is a Class A digital apparatus. For detailed device specifications, visit the Samsung Electronics website. (USA only) Dispose unwanted electronics through an approved recycler. -
Page 88: Standard Signal Mode Table
If the LCD monitor does not support 85 Hz, change the vertical frequency to 60 Hz using the CDT monitor before you exchange it with the LCD monitor. Model Name TC222L TC242L Synchronization Horizontal Frequency 31 - 80 KHz... - Page 89 Specifications Horizontal Vertical Pixel Clock Sync Polarity Frequency Frequency Display Mode (MHz) (H/V) (kHz) (Hz) MAC, 1152 x 870 68.681 75.062 100.000 VESA, 1280 x 720 45.000 60.000 74.250 VESA, 1280 x 800 49.702 59.810 83.500 VESA, 1280 x 1024 63.981 60.020 108.000...
- Page 90 use of supplies or separately sold product unspecified by Samsung. repair from a person besides an engineer of outsourcing service company or partner of Samsung Electronics Co., Ltd. remodeling or repairing the product by customer.
- Page 91 Appendix Terminology OSD(On Screen Display) On screen display (OSD) allows you to configure on-screen settings to optimize the picture quality as required. It allows you to change the screen brightness, tint, size and many other settings using menus displayed on the screen. Coarse Coarse refers to the frequency of radio wave vibrations per second.
- Page 92 Appendix Vertical Frequency One image is made of numerous horizontal lines. The vertical frequency is measured in Hz and represents how many images can be created per second by those horizontal lines. A vertical frequency of 60 means that an image is transmitted 60 times per second. The vertical frequency is also called "refresh rate"...
- Page 93 Connecting and Using a PC Parts Contrast Copyright Correct posture to use the product Q & A Display Time Requirements Before Contacting Samsung Customer Service Center Eye Saver Mode Reset All Responsibility for the Pay Service (Cost to Customers) Fine...
- Page 94 Index Using IGEL OS - Accessories Using IGEL OS - common Using IGEL OS - Devices Using IGEL OS - Network Using IGEL OS - Sessions Using IGEL OS - User Interface Index...
