Sony KLV-S40A10 Quick Setup Manual

KLV-S40A10

Quick Setup Guide

Please follow the steps to setup your TV:
Checking the
1
Supplied Accessories
2 Connecting Your TV
(See reverse side)
3
Running Initial
Setup
4 Programming
the Remote Control
If your product is not working properly
DO NOT RETURN TO THE STORE.
For service and technical assistance
Call our Customer Information Service Center (Toll Free):
1-877-899-SONY (7669) for Canadian residents.
Sony Corporation © 2005
Printed in Japan
3
Running Initial Setup
1
Press POWER to turn on the TV.
The Initial Setup screen appears.
2
Press V or v to select the on-screen display language. Then press
.
The message "First please connect cable/antenna" appears.
By default, Auto Program is set to scan cable TV channels.
3
Press CH+ to start Auto Program.
Auto Program automatically creates a list of receivable channels.
When finished, the lowest numbered channel is displayed. When all
the receivable channels are stored, the "Show/Hide Channels"
settings appear.
To scan available VHF/UHF antenna channels instead of the cable
TV channels
1
Select Settings in WEGA GATE, then go to Channels settings.
2
Set Cable to Off.
3
Start Auto Program by pressing CH+.
To perform Auto Program again, follow the above instructions.
Depending on your signal source, be sure to set Cable to On or Off
accordingly (see Operating Instructions).
The Initial Setup menu will appear each time the TV is turned on until you complete the
scanning for the available channels.
2-654-475-11 (1)
1
Checking the Supplied Accessories
• Remote control (RM-YA001) (1) and size AA batteries (2)
• 75-ohm coaxial cable (ferrite core attached) (1)
• AC power cord (1)
• HD15-HD15 cable (1)
• Support belt (1), securing screw (1) and wood screw (1)
• Operating Instructions (1)
• Quick Setup Guide (1)
• Leaflet (Installing the Wall-Mount Bracket) (1)
• Warranty Card (1)
Inserting Batteries into the Remote Control
Insert two size AA batteries (supplied) by matching the
the batteries to the diagram inside the remote control's battery
compartment.
4

Programming the Remote Control

The remote control is preset to operate Sony brand video equipment.
Sony Equipment Programmable Code Number
DVD/VCR 601 (Sony Dream System)
SAT/Cable 801 (Sony Satellite Receiver)
Follow the steps below to program your TV's remote control to
operate the other video equipment.
Using the code list on the right, find the three-digit code number for
the manufacturer of your equipment. (If more than one code number
is listed, use the number listed first.)
1 Press and hold the
MTS/ POWER
MUTING DISPLAY SAP
you want to program on the remote control and
1
POWER TV/
SAVING FREEZE VIDEO press the button simultaneously. The selected
DISPLAY
FUNCTION button (DVD/VCR or SAT/CABLE)
will flash.
2
2 Enter the three-digit manufacturer's code number
3
RETURN WEGA GATE
using the --9 buttons while the button is lit,
approximately 10 seconds.
3 Press button.
When the programming is correct, the selected
FUNCTION
1
F1 FUNCTION button will flash twice slowly, and
F2
when not, flashes five times quickly.
TOP MENU MENU GUIDE SLEEP
To check if the code works
Aim your TV's remote control at the equipment, and
MODE
TV/SAT press the green POWER button. If the equipment
SOUND PICTURE WIDE
responds, the programming is completed. If not, try the
next code listed.
If no code is input within the above specified time, or an invalid or incorrect code
number is input, the remote control automatically goes back to the previous setting.
In some cases, you may not be able to program your remote control to operate other
equipment. In such cases, use the equipment's own remote control.
Dead batteries or removing the batteries may cause the programmable codes to be lost
and revert back to factory settings.
Reprogramming the codes may be necessary.
2
Connecting Your TV
•Review the following chart to determine which diagram to use to
connect the components in your system:
For these components
or
or
and on
e E
or
or
or
•See the "Cables Required" chart that appears with the diagram to
determine which cables you'll need. You may need to purchase
extra accessories, such as cables and splitters, depending on the
components you plan to connect.
•Turn off and unplug all components before making connections.
•If you are connecting a digital cable box, you'll need a special bi-
directional splitter that's compatible with your cable box. Contact
your cable provider for details.
Manufacturer's Codes
Manufacturer
Aiwa*
DVD Players
Audio Dynamic
Manufacturer Code
Broksonic
Canon
Sony 751
Citizen
General Electric 755
Hitachi 758 Craig
Curtis Mathes
JVC 756
Daewoo
Magnavox 757
Mitsubishi 761 DBX
Dimensia
Panasonic 753
Emerson
Philips 757
Pioneer 752
Fisher
RCA/PROSCAN 755
Funai
Samsung 758
General Electric
Toshiba 754
Go Video
Zenith 760
Goldstar
Hitachi
DVD Changers
Instant Replay
Manufacturer Code
JC Penney
Sony 765
JVC
Panasonic 766
Kenwood
or FUNCTION button DVD/VCR Combo Units
LG
Manufacturer Code
LXI (SEARS)
Sony 767
Magnavox
Zenith 768
Toshiba 773 Marantz
Marta
Samsung 774
Memorex
JVC 775
Broksonic 776 Minolta
Mitsubishi/MGA
Panasonic 777
Multitech
HDD/DVD Combo Units
NEC
Olympic
Manufacturer Code
Optimus
Sony 770, 771, 772
Orion
Panasonic
5.1ch DVD AV System
Pentax
Manufacturer Code
Philco
Sony (DAV) 601, 602, 603, 604 Philips
Pioneer
AV Receivers
Quasar
RCA/PROSCAN
Manufacturer Code
Sony 764
Realistic
VCRs
Sansui
Manufacturer Code
Samsung
Sony 301, 302, 303
Sanyo
Admiral (M. Ward) 327
Making Video Connections
Your TV includes
several types of video
inputs. Use the inputs
that are available on
your components that
provide the best
See reverse side
video performance, as
shown in the table on
A
the right.
B
Additional Connections
C
For best audio performance, connect your digital audio components
using either digital optical or digital coaxial audio connections.
D
Depending on which components are in your system, you may need
to complete additional connections. For example, if you have a
satellite receiver, you'll need to connect the satellite antenna. If you
have an A/V receiver, you'll need to connect speakers.
E
The connection diagrams shown on the reverse side are recommendations only; other
possible solutions may exist. Connections that include an A/V receiver can often be
very complex, so check your A/V receiver's instruction manual for additional details.
F
See the Operating Instructions when connecting to a personal computer.
Code Manufacturer Code
338, 344 Scott 312, 313, 321, 335,
Enjoy your new TV with WEGA GATE
323, 324, 325, 326
314, 337
Sharp 327, 328
319, 317
Signature 2000 (M.Ward) 338, 327
309, 308
SV 2000 338
332
The WEGA GATE button on your remote control is a new feature
Sylvania 308, 309, 338, 310
302, 332
Symphonic 338 that allows you to easily navigate to the most convenient TV
304, 338, 309
Tashiro 332
341, 312, 309
functions such as Favorite Channels, TV Channel List, External Input
Tatung 314, 336, 337
314, 336, 337
Teac 314, 336, 338, 337 list or Settings. The TV's main menu is found under Settings.
304
Technics 309, 308
319, 320, 316, 317,
318, 341 Toshiba 312, 311
330, 335 Wards 327, 328, 335, 331,
332
338
Yamaha 314, 330, 336, 337
329, 304, 309
Zenith 331
322, 339, 340
332
Cable Boxes
306, 304, 305, 338
309, 308 Manufacturer Code
309, 305, 304, 330,
Sony 230
314, 336, 337
Hamlin/Regal 222, 223, 224, 225,
314, 336, 337, 345,
226
346, 347
Jerrold/G.I./ 201, 202, 203, 204,
314, 336, 332, 337
Motorola 205, 206, 207, 208,
218, 222
332
332, 305, 330, 335, Oak 227, 228, 229
338
Panasonic 219, 220, 221
308, 309, 310
Pioneer 214, 215
314, 336, 337
Scientific Atlanta 209, 210, 211
332
Tocom 216, 217
309, 335
Zenith 212, 213
305, 304
323, 324, 325, 326
Satellite Receivers
325, 338, 321
Manufacturer Code
314, 336, 337
Sony 801
309, 308
Dish Network 810
327
Echostar 810
To adjust Settings related to Video, Audio, Screen, Channel, Parent (V-chip), Clock/
317
General Electric 802
308, 309, 306, 307
Timers or to set up certain features on your TV, press
Hitachi 805
305, 304
WEGA GATE control panel.
Hughes 804
308, 309
Mitsubishi 809
308, 309, 310
Panasonic 803
308
RCA/PROSCAN 802, 808
308, 309, 306
Toshiba 806, 807
304, 305, 308, 309,
Philips 811
311, 312, 313, 310,
329
Samsung 812
309, 330, 328, 335,
324, 338
* If an Aiwa VCR does not
314
work even though you enter
322, 313, 321
330, 335 the code for Aiwa, enter the
code for Sony instead.
Best Video
Connector type
Performance
HDMI*
(High-Definition
Multimedia Interface)
Component video*
S VIDEO
Composite video
RF/Coaxial
* Support 480i, 480p, 720p, 1080i
WEGA GATE
Favorites
TV List
External Inputs
Settings
Show your Favorite Channels
Select: Set: Exit: WEGA GATE
WEGA GATE
then select "Settings" on the
