HISTORY
Model Name: KDL-19S5700
SERVICE MANUAL
Click on Page Number to display details of change
Date
Part Number
Description of Revisions
Version
2009.09
9-883-450-01
Original Manual
1.0

Advertisement

Table of Contents
loading

Related Manuals for Sony KDL-19S5700

Summary of Contents for Sony KDL-19S5700

  • Page 1 HISTORY Model Name: KDL-19S5700 SERVICE MANUAL Click on Page Number to display details of change Date Part Number Description of Revisions Version 2009.09 9-883-450-01 Original Manual...
  • Page 2 EX2N-Clove SERVICE MANUAL CHASSIS MODEL DEST KDL-19S5700 OIRT / UK / WE RM-ED07W -  -...

  • Page 3: Table Of Contents

    COMPONENTS IDENTIFIED BY SHADING AND MARKED THE EXPLODED VIEWS AND IN THE PARTS LIST ARE CRITICAL FOR SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. -  -...

  • Page 4: Caution

    Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade. This requires soldering equipment capable of accurate temperature control coupled with a good heat recovery characteristics. For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com UK PLUG WARNING WARNING (UK Models only) The flexible mains lead is supplied connected to a B.S.
  • Page 5 CAUTION 1. MDF-61 Connector (Removal) Slide the slider to release slider Press the centre lock tab to Remove connector lock. release the lock and pull the connector up 2. MDF-61 Connector (Refiitting) Hold the centre of connector Press centre of connector to insert Slide the slider to lock connector - 4 -...
  • Page 6 3. The harness must not be crossed or twisted 4. Wire Dressing at connector The harness must not bend more than 45 degrees from the direction of the connector base to avoid crossing or twisting. 5. Wire distance at connector The distance between each wire must be wider than 4mm to ensure isola- tion from lamp voltage.

  • Page 7: Specifications

    SPECIFICATIONS System Panel System LCD (Liquid Crystal Display) Panel TV System Depending on your country/region selection Analogue: B/G/H, D/K, L, I Digital: DVB-T, DVB-C Colour/Video System Analogue: PAL, PAL60 (only video input), SECAM, NTSC3.58, NTSC4.43 (only video input) Digital: MPEG-2 MP@ML/HL, H.264/MPEG-4 AVC HP@L4.0, MP@L3.0 Channel Coverage Analogue: 46.25 - 855.25 MHz Digital: VHF/UHF...
  • Page 8 PC Input Signal Reference Chart for PC IN Horizontal Vertical Signals Horizontal (Pixel) Vertical (Line) frequency Standard frequency (Hz) (kHz) 31.5 SVGA 37.9 VESA Guidelines 1024 48.4 VESA Guidelines WXGA 1280 47.4 VESA WXGA 1280 47.8 VESA WXGA 1360 47.7 VESA SXGA 1280...

  • Page 9: Connectors

    CONNECTORS  Pin Connector (SCART) Pin No AV-1 AV-2 Signal Signal Level • • Audio Output B Standard Level: 0.5V rms (Right) Impedance: less than 1KΩ* • • Audio Input B Standard Level: 0.5V rms (Right) Impedance: more than 10KΩ* •...

  • Page 10: Self Diagnosis

    EXN SELF DIAGNOSTIC SOFTWARE The identification of errors within the EX2N chassis is triggered in one of two ways :- 1: Busy or 2: Device failure to respond to IIC. In the event of one of these situations arising the software will first try to release the bus if busy (Failure to do so will report with a continuous flash- ing LED) and then communicate with each device in turn to establish if a device is faulty.

  • Page 11: Stand Assy Removal

    SECTION 2 DISASSEMBLY 2-2. Rear Cover Removal 2-1. Stand Assy Removal = > > => > => = > > Remove the 2 stand fixing screws indicated and lift the TV To remove the ‘Rear Cover’ firstly remove the ‘Stand Assy’ set up and away from the ‘Stand Assy’.

  • Page 12: Power Unit Removal

    2-5. Power Unit Removal 2-6. B Board Removal Screws Screws Screws To remove the ‘Power Unit’ disconnect all the connectors and To remove the ‘B’ board disconnect all the connectors and then remove the 4 screws circled and ease the board gently then remove the 9 screws circled and ease the board gently away from the back of the TV set.

  • Page 13: Service Menus

    SECTION 3 SERVICE MENUS 3-1. How to enter the Service Mode 3-2. Service Menu Structure Service adjustments to this model can be performed using the The following descriptions show the items that can be supplied Remote Commander (See front cover). viewed and/or adjusted using the Service Menu.

  • Page 14: Osd Service Menu

    3-2-3. OSD Service Menu 3-2-4. Country Selection The following menu appears on the screen when you enter The following menu appears on the screen when you enter the ‘OSD Service Menu’ (See Pic.4). This menu allows the ‘Country Selection’ menu (See Pic.5). Using this menu viewing and adjustment of the AGC and viewing of the the destination country of the TV can be set.

  • Page 15: Tt Mode

    ECS mode toggle (ON/OFF) Set DVB-T channel table Set DVB-C channel table Full HD HDMI EDID Write WXGA HDMI EDID Write Re-initialise NVM Select Dual Sound "A" Select Dual Sound "B" Select Dual Sound "Mono" Select Dual Sound "Stereo" Set NVM as non-virgin Set NVM as virgin Clear authenticated CAM History Clear service shunning cache Enable/Disable DVB-C manual tuning Set KDL-19S5700 model Set KDL-19S5710 model Set KDL-19S5720 model Set KDL-19S5730 model Set KDL-19S5740 model Set Centred Balance Set Volume to Max Set Volume to Min Set Balance Full Left Set Balance Full Right Digital BER Display TS CI Path Through Front Panel Button Test LED Test TS CI Path Through With Reed Solomon Off - 14 -...

  • Page 16: Block Diagram

    4-1. BLOCK DIAGRAM PANEL CLOCK module NAND DDR2 DDR2 CONTROL LVDS FLASH CA module PNX8543 HDMI AV Switch Color Decoder 3D Comb HDMI SCART1_CVBS SWITCH PC/HD ADC SCART1_RGB Audio Decoder SCART1_CVBS_OUT SCART1_LR_IN MPEG2 Decoder SCART1_LR_OUT 4-Field MADI HDMI 1 SCART2_CVBS Scaler SCART2_RGB Noise Reduction...

  • Page 17: Circuit Board Location

    • : earth - chassis. NOTE: The Power unit and Clock module boards are not Sony boards so their schematic diagrams and printed wiring boards are not shown in this Service Manual. Schematic diagrams are for reference only. Please refer to the electrical parts list for the correct value and part number of components.

  • Page 18: B Board Schematic Diagram

    B-EX2N +3V3_STANDBY +3V3 SUPPLY_FAULT 1005 CHIP CHIP 1/16W FB6002 R6016 1/16W PZU5.6B2 R6018 1/16W JL6009 D6005 LFBK1608HS601 R6048 JL6012 CHIP PZU5.6B2 MM3143DNRE D6024 1005 IC6010 Q6004 C6008 2SC5950G0LS0 R6149 JL6028 JL6039 R6146 VDDA_AUDIO 1005 JL6004 1/16W CHIP 6.3V POWER_ON 1608 JL6005 C6096 AC_OFF_DET...
  • Page 19 B-EX2N CVBS INPUT & OUTPUT Y/C INPUT SCART1 COMPONENT & CVBS INPUT SCART1 ‚ÆSCART2 ªzu AEP¨O }Eg JL3017 AUDIO_OUT_RIGHT R3032 R3051 1005 470k R9816 1/16W CHIP AV1_BLK 100p R9815 1005 C3021 JL3018 Y_VIDEO1 AV1_RIGHT AV2_RGB_R/C R3029 C3022 CN3000 1000p R3052 1/16W 470k VD9802...
  • Page 20 B-EX2N CL5524 D5500 CL5501 HPD1 DDC+5V_1 +3V3 DDC +5V R5535 JL5500 C5500 FL5501 0 . 1 CHIP +3V3_HDMI DDC DA T SDA_HDMI1 2012 DDC CLK SCL_HDMI1 6.3V C5510 D5505 C5512 0 . 1 C5529 C5514 C5517 C5513 C5519 C5520 C5523 C5525 C5526 C5527...
  • Page 21 B-EX2N +5V_TUN_MOPLL 1005 C2097 L2001 R2006 1005 1005 2 0 1 2 CL2003 10uH + B a c t i v e a n t 4700p C2004 CHIP 0 . 1 330p C2071 C2017 C2018 CL2004 C2012 +5V_TUN_RF_AMP L2017 CL2005 10uH +33V +5V_TUN_33V...
  • Page 22 B-EX2N +1V2F +1V2FB C4061 R4011 FL4002 FL4001 CHIP CL4003 CL4012 RESERVED AJ12 AA14 +1V2 +1V2 1V2A_AADC 1V2_CORE1 VSS58 VSS1 C4014 C4037 C4041 C4044 C4047 C4050 C4054 C4057 C4058 C4056 1005 AJ13 1005 1005 1005 1005 1005 2012 AA15 1005 1005 1005 DV-IN 1V2_CORE2...
  • Page 23 B-EX2N AV1_RGB_R/C C4333 R4389 R4331 0 . 0 2 2 0.5% RN-CP 1/16W 1/16W CHIP RN-CP 1005 0.5% R4325 C4353 C4352 AV2_RGB_R/C C4334 PTD2+ 0 . 0 2 2 R4390 R4332 0.5% RN-CP 1/16W VDISP 1/16W CHIP RN-CP +3V3 1005 VIDEO ANALOGUE 0.5% R4326...
  • Page 24 B-EX2N CHIP 1/16W +3V3 R7329 7/12 VIDEO STREAMS 1005 RB7300 74LVC541APW CA_MDO0 CA_MDO0 CA_MDI0 CA_MDI2 0 . 1 IC7304 C7304 CHIP CA_MDO1 1/16W CA_MDO1 CA_MDI1 CA_MDI1 R7318 +3V3 PCMCIA_D3 CA_MDO2 CA_MDO2 CA_MDI2 CA_MDI0 FB7302 CA_MDO3 PCI_AD16 CA_CD1 CD1# CA_MDO3 CA_MDI3 CA_MDI3 PCMCIA_D4 CA_MDO4...
  • Page 25 B-EX2N +1V8F DDR2_VREF RB4708 DDR2_D4 DDR2_D3 CHIP RB4715 CHIP 1/16W DDR2_A0 DDR2_D20 1/16W 5 . 6 k DDR2_D1 R4709 R4708 1608 DDR2_A1 DDR2_D19 DDR2_D6 DDR2_A0 1608 0 . 1 DDR2_A2 DDR2_D27 C4703 DDR2_D0 DDR2_A1 AB32 AH34 VREF DDR2_A3 DDR2_D28 0 . 1 RB4709 C4701 AA31...
  • Page 26 B-EX2N CL4153 EJTAG_DETECT EJTAG_DETECT CL4137 EJTAG_TRSTN R4122 1/16W CL4143 CHIP EJTAG_TDI CL4144 R4143 EJTAG_TD0 9/12 R4145 CL4138 CHIP EJTAG_TMS 1005 CL4139 EJTAG_TCK R4146 CL4140 CL4141 R4144 AN16 USB_DM RESET_SYS_DETECT +3V3_STANDBY +3V3 +3V3 CL4142 CHIP AP16 USB_DP 1005 *CN4104 +3V3_STANDBY +3V3 AL16 USB_FAULT CHIP...
  • Page 27 B-EX2N R7824 1/10W RN-CP 0.5% R7804 1/10W RN-CP 0.5% Audio 1005 1005 1005 RB7800 0 . 1 0 . 1 0 . 1 C7827 C7829 C7832 C7811 AL13 AV1_RIGHT AIN1R ADAC1_P VDDA_AUDIO R7809 4 . 7 2012 C7812 AP14 AV1_LEFT 4 .
  • Page 28 B-EX2N TFA9810 AUDIO AMPLIFIER 12V_UNREG_AUDIO 1608 1608 1608 0 . 1 C7901 0 . 1 0 . 1 C7921 C7906 C7907 C7908 GND_AU 1608 GND_AU 11/12 0 . 1 C7922 SPDET_LN 016:15D R7922 GND_AU 220k 1/16W SPDET_LP CHIP 016:15D SPDET_LN TFA9810T 016:15D R7903...
  • Page 29 B-EX2N EVI1 RB4601 R4608 RB4602 C4600 R4601 C4631 CL4604 CL4605 R4610 FB4600 L4600 C4627 CL4606 C4606 C4609 C4611 C4623 12/12 R4606 C4626 C4635 VDDE1 VDDE75 CL4600 TEST2 CL4601 C4603 C4605 C4607 C4610 FB4601 L4601 TEST1 CL4602 XTOUT HPD0 VXSS HPD1 XTAL HPD2 C4604...

  • Page 30: H1 Board Schematic Diagram

    H1-EX2N +3V3_STANDBY REC_LED LED1 LED3 LED2 LED4 R1013 BL_IN JL1003 JL1004 CHIP JL1001 JL1002 +3V3 CN1000 IC1000 KSM-511M2Q RN-CP RN-CP 1/10W 1/10W RN-CP 1/10W R1001 C1000 R1000 R1002 R1003 RN-CP 1/10W C1004 2 . 2 k C1005 R1012 R1004 6.3V 1/10W RN-CP 2012...

  • Page 31: B Printed Wiring Board

    Text Search ~ B Printed Wiring Board Side A ~ C N 6 0 0 0 C N 7 9 0 0 PS6001 PS6002-P6005 F6000 24V 5A 24V 3.15A 24V 3.15A PS6005 P S 6 0 0 1 I C 4 6 0 0 J 9 8 0 2 J 9 8 0 1 I C 4 7 0 1...

  • Page 32: H1 Printed Wiring Board

    Text Search ~ B Printed Wiring Board Side B ~ I C2 0 0 0 I C2 0 0 1 W2 4 1 CN4 3 0 1 1 - 8 7 8 - 9 9 9 - 2 1 ~ H1 Printed Wiring Board Side A ~ ~ H1 Printed Wiring Board Side B ~ C N 1 0 0 0 1 - 8 7 8 - 9 9 5 - 1 1 ( 1 7 3 0 5 9 8 1 1 )

  • Page 33: Exploded Views

    SECTION 5 EXPLODED VIEWS NOTE : Non-serviceable items with no part number and no Items marked “*” are not stocked description are not stocked because they are not since they are seldom required for required for routine service. routine service. Some delay should The construction parts of an assembled part are indicated be anticipated when ordering these items.
  • Page 34 5-1. CHASSIS & STAND ASSY Cont. REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK X-2342-565-1 STAND ASSY 1-487-362-11 SWITCH UNIT 1-487-410-22 CLOCK MODULE 12 4-122-538-01 PLATE, VESA - 33 -...

  • Page 35: Bezel Assy

    5-2. BEZEL ASSY REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK 51 X-2342-561-1 BEZEL (19CL) ASSY - 34 -...

  • Page 36: Rear Cover & Power Supply Cords

    5-3. REAR COVER & POWER SUPPLY CORDS UK MODELS ONLY REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK 4-119-968-01 REAR COVER (19) £ 1-833-265-11 POWER-SUPPLY CORD (OIRT/WE) X-2190-287-3 HANDLE ASSY £ 1-832-170-31 POWER-SUPPLY CORD (UK) 4-122-617-21 COVER, ECS(S) 4-124-091-01 COVER, AC - 35 -...

  • Page 37: Parts List

    ....................50 Note: To ensure safety and reliability it is Sony policy that power supply boards should not be repaired at component level in the field as a result... The Power Unit and Clock Module boards are regarded as non service items for exchange only and are not indicated in the parts list of this service manual.
  • Page 38 Note : The components identified by mark contain confidential information. Strictly follow the instructions when ever the components are repaired and/or replaced. REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK A-1743-321-A B Board, Complete C2052 1-100-916-11 CERAMIC CHIP 0.1UF C2054 1-100-905-11 CERAMIC CHIP 0.001UF <...
  • Page 39 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C3015 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V C4039 1-100-916-11 CERAMIC CHIP 0.1UF C3016 1-164-874-11 CERAMIC CHIP 100PF 5.00% 50V C4040 1-100-916-11 CERAMIC CHIP 0.1UF C3017 1-100-831-91 CERAMIC CHIP 0.001UF C4041 1-100-916-11 CERAMIC CHIP 0.1UF C3018 1-164-874-11 CERAMIC CHIP 100PF...
  • Page 40 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C4308 1-112-778-11 CERAMIC CHIP 0.022UF C4716 1-114-325-11 CERAMIC CHIP 0.1UF C4309 1-112-778-11 CERAMIC CHIP 0.022UF C4717 1-100-831-91 CERAMIC CHIP 0.001UF C4310 1-112-778-11 CERAMIC CHIP 0.022UF C4718 1-100-831-91 CERAMIC CHIP 0.001UF C4311 1-112-777-11 CERAMIC CHIP 0.01UF C4719 1-114-325-11...
  • Page 41 F4 A B REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C6001 1-114-130-11 CERAMIC CHIP 1UF 6.3V C6096 1-114-130-11 CERAMIC CHIP 1UF 6.3V C6002 1-100-769-21 ELECT CHIP 470UF C6098 1-100-909-11 CERAMIC CHIP 10UF 6.3V C6004 1-100-916-11 CERAMIC CHIP 0.1UF C6099 1-114-130-11 CERAMIC CHIP 1UF 6.3V...
  • Page 42 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK C7833 1-114-802-11 CERAMIC CHIP 0.0033UF C7911 1-164-882-11 CERAMIC CHIP 220PF 5.00% 16V C7836 1-114-802-11 CERAMIC CHIP 0.0033UF C7912 1-164-882-11 CERAMIC CHIP 220PF 5.00% 16V C7837 1-100-769-21 ELECT CHIP 470UF C7913 1-164-866-11 CERAMIC CHIP 47PF 5.00% 50V C7838 1-114-802-11...
  • Page 43 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK D6014 6-502-252-01 DI KDZTR5.6B FB6001 1-400-331-11 FERRITE D6015 6-502-248-01 DI KDZTR3.9B FB6002 1-400-331-11 FERRITE D6017 6-502-248-01 DI KDZTR3.9B FB6003 1-400-331-11 FERRITE D6020 6-501-614-01 DIODE PZU5.6B2 FB6004 1-400-915-21 FERRITE D6021 6-501-614-01 DIODE PZU5.6B2 FB6005 1-400-915-21 FERRITE...
  • Page 44 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK IC4703 6-712-189-01 IC EDE5116AJBG-6E-E L2025 1-412-052-21 INDUCTOR IC5503 6-713-962-01 IC TDA9995HL/C1 L2026 1-412-052-21 INDUCTOR IC6000 6-706-419-01 IC LM393DT (A) L4101 1-457-374-21 INDUCTOR IC6001 6-709-932-01 IC MM3141CNRE L4300 1-456-583-11 INDUCTOR IC6002 6-709-607-01 IC LA5795T-TLM-E L4301 1-456-583-11 INDUCTOR...
  • Page 45 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK Q6008 8-729-905-35 TRANSISTOR 2SC4081-R R2052 1-216-833-11 METAL CHIP 1/10W Q6009 8-729-028-28 TRANSISTOR 2SK2036(TE85L) R2053 1-218-990-81 SHORT CHIP Q6010 6-551-776-01 TR 2SC5950G0LS0 R2055 1-218-990-81 SHORT CHIP Q6012 6-550-354-01 TRANSISTOR RTQ035P02TR R2056 1-218-990-81 SHORT CHIP Q6013 6-551-775-01 TR 2SA2122G0LS0...
  • Page 46 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4130 1-218-965-11 METAL CHIP 1/16W R3044 1-216-853-11 METAL CHIP 470K 5% 1/10W R3045 1-216-853-11 METAL CHIP 470K 5% 1/10W R4131 1-218-965-11 METAL CHIP 1/16W R4132 1-218-941-81 METAL CHIP 1/16W R3046 1-208-860-81 METAL CHIP 0.5% 1/16W R3047 1-218-985-11...
  • Page 47 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4198 1-218-965-11 METAL CHIP 1/16W R4345 1-220-876-81 METAL CHIP 0.5% 1/16W R4199 1-218-965-11 METAL CHIP 1/16W R4346 1-220-876-81 METAL CHIP 0.5% 1/16W R4200 1-218-965-11 METAL CHIP 1/16W R4347 1-220-876-81 METAL CHIP 0.5% 1/16W R4201 1-218-941-81 METAL CHIP...
  • Page 48 H5 D2 B REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R4742 1-218-935-11 METAL CHIP 1/16W R6029 1-216-864-11 SHORT CHIP R4743 1-218-935-11 METAL CHIP 1/16W R6033 1-218-959-11 METAL CHIP 3.3K 5% 1/16W R4744 1-218-935-11 METAL CHIP 1/16W R6037 1-218-990-81 SHORT CHIP R4745 1-218-935-11 METAL CHIP...
  • Page 49 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK R6137 1-216-864-11 SHORT CHIP R7817 1-218-990-81 SHORT CHIP R6138 1-208-709-11 METAL CHIP 0.5% 1/16W R7818 1-218-990-81 SHORT CHIP R6139 1-216-864-11 SHORT CHIP R7819 1-218-990-81 SHORT CHIP R6140 1-216-864-11 SHORT CHIP R7820 1-208-935-11 METAL CHIP 100K 0.5% 1/16W R6141...
  • Page 50 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK RB7801 1-234-380-21 RES, NETWORK 47K (1005X4) RB2004 1-242-963-21 RES, NETWORK 33 (1005X4) RB2005 1-242-963-21 RES, NETWORK 33 (1005X4) RB7802 1-239-706-81 RESISTOR, NETWORK 47K RB7806 1-239-694-81 RESISTOR, NETWORK 4.7K RB4002 1-242-963-21 RES, NETWORK 33 (1005X4) RB4003 1-242-963-21...
  • Page 51 REF.NO. PART.NO DESCRIPTION REMARK REF.NO. PART.NO DESCRIPTION REMARK ACCESSORIES AND CONNECTORS A-1643-232-A H1 Board, Complete 19 INCHES < CAPACITOR > 1-836-485-11 LVDS HARNESS (B(CN4300)-PANEL) C1002 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V *1-910-058-80 CONNECTOR ASSY 5P (B(CN4101)-CLOCK MODULE) C1004 1-100-909-11 CERAMIC CHIP 10UF 6.3V *1-910-058-81 CONNECTOR ASSY 30P (B(CN6000)-G2/H1/INV) *1-910-058-82 SPEAKER HARNESS(19) (B(CN7900)-SPEAKERS)
  • Page 52 English Sony Corporation 09IP7100-1 Sony UK Printed in U.K. Service Promotions Dept. © 2009.09 9-883-450-01...
