Sony MDR-NC60 Operating Instructions

Noise Canceling
Headphones
Operating Instructions
Manual de instrucciones
MDR-NC60
© 2007 Sony Corporation Printed in Malaysia
English
Installing a battery
Before operating the unit, please read this manual
1
Push the "BATT Z" button located at the
thoroughly and retain it for future reference.
bottom of the right housing.
The lid of the battery box opens slightly.
WARNING
To reduce the risk of fire or
electric shock, do not expose
this apparatus to rain or
moisture.
To reduce the risk of electrical
2
Open the lid of the battery box of the
shock, do not open the cabinet.
headphone to insert one size AAA
Refer servicing to qualified
battery.
personnel only.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
You are cautioned that any changes or
Note
modifications not expressly approved in this
The lid of the battery box opens only so far,
manual could void your authority to operate this
as shown in the illustration. Do not further
equipment.
force open the lid as it may damage it.
Owner's Record 3
Close the lid.
The model number is located on the housing, and
the serial number is located inside the battery box.
Record the serial number in the spaces provided
below. Refer to them whenever you call upon
your Sony dealer regarding this product.
Model No. MDR-NC60
Serial No.
The validity of the CE marking is restricted to Battery life
only those countries where it is legally enforced,
Battery
mainly in the countries EEA (European Economic
Sony alkaline LR03/AM-4
Area).
(N) (size AAA) battery
Sony manganese R03/ UM-4
(NU) (size AAA) battery
Features
* 1 1 kHz, 0.1 mW + 0.1 mW output
* 2 Time stated above may vary, depending on the
• Noise canceling headphones reduce unwanted
temperature or conditions of use.
ambient noise, providing a quieter environment
Note
to enhance your listening experience. A
microphone inside each earpiece works with Because the supplied battery was included in the
electronic circuitry to create an opposite sound package from the time of manufacture (as a
convenience to the user), it is possible that the
wave to cancel out the noise. Up to 85 %
battery life may be somewhat depleted by the
ambient noise cancellation (Over 16.5 dB is
reduced at 200 Hz) time of purchase. The actual life of the supplied
battery may be shorter than the standard time
• Slim, folding design for easy portability
described in this manual when using a fresh
• Premium piano black design
• Neodymium magnets for powerful sound battery.
• Dual-use capability allows option to listen to
When to replace the battery
music with or without noise cancellation
Replace the battery with a new one when the
• Built-in monitor function lets you silence the
POWER indicator dims. The noise canceling feature
audio to listen outside
may not work correctly if battery power is low.
• Supplied plug adapter for easy connectivity to
stereo or dual jack for in-flight music services
To remove the battery
3-100-028-11(1)
Open the lid of the battery box, then push the
position marked with "PUSH G". The e side of
the battery comes up. Remove the battery by
pulling it.
1
If the lid of the battery box is
detached
Follow the procedure below to reattach the lid.
1
Attach the lower side of the lid.
2
Push the upper side of the lid straight
forward until it clicks into position.
Right housing
Listening to music
1
Connect the headphones to the AV
equipment.
Headphones
When connecting to dual
or stereo mini jacks of
in-flight music services.
Match the e on the
1
battery to the e in the
Plug adapter (supplied)
battery case.
2
To headphone jack on airplane seats
When connecting to the
stereo mini jack of a
WALKMAN*, etc.
Remote control
When connecting to the stereo
mini jack of the remote control's
jack supplied with a WALKMAN,
etc.
* "WALKMAN" and "WALKMAN" logo are
registered trademarks of Sony Corporation.
Notes
• When connecting the cord, insert the plug into
the jack until the green portion of the plug
disappears.
Approx. hours* 1
30 hours* 2
OK
15 hours* 2
• To disconnect the cord, pull it out by the plug,
not the cord, as the inner conductors may
break.
2
Turn on the power on the right side of the
headphones.
The POWER indicator lights in red. When the
power is turned on, ambient noise is reduced,
and you can listen to music more clearly at a
lower volume.
R
Noise canceling microphone
3
Put on the headphones so that the ear
pads cover your ears.
R L
2
4
Turn on the power of the AV equipment.
Hearing environmental sound for
safety
If the MONITOR switch is pressed and held
while the POWER switch is set to ON, playback
silences so you can hear the surrounding
environment.
R L
MONITOR
switch
Monitor microphone
Note
The environmental sound might not be heard if
the microphone is covered with your fingers.
Notes on using on the
airplane
• The supplied plug adapter can be connected to
dual and stereo mini jacks.
for dual jacks for stereo mini jacks
R L
• Do not use the headphones when use of
electronic equipment is prohibited or when use
of personal headphones for in-flight music
services is prohibited.
If you have any questions or problems concerning
the system that are not covered in this manual,
please consult the nearest Sony dealer.
After listening to music
Connecting
Turn off the power of the headphones.
cord 1.5 m
(supplied)
Folding the
headphones
Folding
The housings rotate to make them flat for easy
storage in the carrying case (supplied), or in a seat
pocket.
Restore to their usual position before using.
L
Putting the headphones in the
Troubleshooting
carrying case
Fold the headphones before putting them in the
No sound
carrying case. The supplied cord, unimatch plugs
or reserve batteries can also be stored in the • Check the connection of the headphones and
the AV equipment.
pocket.
• Check that the connected AV equipment is
turned on.
• Turn up the volume of the connected AV
equipment.
Muffled sound
• Turn down the volume of the connected AV
equipment.
• Replace the battery.
Power does not turn on
• Check if the battery has expired (the POWER
indicator dims).
• Replace the battery with a new one.
Howling
• Make sure you are wearing the headphones
correctly.
Specifications
Note on storing the connecting
General
cord
Type
Store the connecting cord in the carrying case
Driver units
with both plugs together to avoid short circuiting Power handling capacity
the battery.
Impedance
Precautions
Sensitivity
The headphones contain a noise canceling circuit.
Frequency response
What is noise canceling?
The noise canceling circuit actually senses outside
Frequency range of active noise attenuation
noise with built-in microphones and sends an
equal-but-opposite canceling signal to the
headphones.
Power source
Mass
• The noise canceling effect may not be
pronounced in a very quiet environment, or
Supplied accessories
some noise may be heard. In such a case, turn
Connecting cord (1.5 m, gold plated L type stereo
the POWER switch off.
mini plug)(1)
• The noise canceling effect may vary depending
Sony R03 (size AAA) battery (1)
on how you wear the headphones.
Carrying case (1)
• When you turn the POWER switch on, the
Plug adapter for in-flight use* (single/dual)(1)
operation sound of the noise canceling may be
Gold-plated unimatch plug adapter (stereo phone
noticeable. This is not a malfunction.
plug y stereo mini jack)(1)
• The noise canceling function is only effective
Operating Instructions (1)
for noise in the low frequency band. Although
Card warranty (1)
noise is reduced, it is not canceled completely.
* May not be compatible with some in-flight
• When you use the headphones in a train or a
music services.
car, noise may occur depending on street
conditions. In such a case, turn the POWER
Design and specifications are subject to change
switch off.
without notice.
• You can use the headphones without turning on
the power. In this case, the noise canceling
function is not active, and the headphones
operate as passive headphones.
• Howling may occur if you do not wear the
headphones correctly.
• Mobile phones may cause noise. Keep the
headphones away from mobile phones.
Notes on usage
• Clean the headphones with a soft dry cloth.
• Do not leave the plug dirty otherwise the sound
may be distorted.
• Be sure to consult a Sony dealer when the
earpads become dirty or damaged, or when the
headphones require repair work.
• Do not leave the stereo headphones in a
location subject to direct sunlight, heat or
moisture.
Note on headphones
Preventing hearing damage
Avoid using headphones at high volume. Hearing
experts advise against continuous, loud and
extended play. If you experience a ringing in your
ears, reduce the volume or discontinue use.
Do not listen with the
headphones while driving or
cycling
As your headphones reduce outside sounds, it
may cause traffic accident. Also avoid using them
where hearing must not be impaired, for example,
at a railroad crossing, a site of construction, etc.
Dynamic, closed
40 mm, dome type (CCAW adopted)
100 mW
40 Ω at 1 kHz
(when the power is on)
100 Ω at 1 kHz
(when the power is off)
102 dB/mW
(when the power is on)
100 dB/mW
(when the power is off)
14 – 24,000 Hz
40 – 1,500 Hz, more than 16.5 dB at
200 Hz
DC 1.5 V, 1 × R03 (size AAA) battery
Approx. 230 g (8 oz) including battery
