Version 1.0 | 4/28/14
User Manual
Wireless AC1900
Dual Band Gigabit Cloud Router
DIR-880L

Advertisement

Table of Contents
loading

Related Manuals for D-Link DIR-880L

Summary of Contents for D-Link DIR-880L

  • Page 1 Version 1.0 | 4/28/14 User Manual Wireless AC1900 Dual Band Gigabit Cloud Router DIR-880L...

  • Page 2: Preface

    Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description April 28, 2014 • Initial release for revision A1 Trademarks ©...

  • Page 3: Table Of Contents

    Favorites ................129 Web-based Configuration Utility ..........27 Using SharePort Mobile for Windows® 8/RT ....130 Device Mode ................28 Main Menu ................. 132 Router Mode .................29 Documents ................. 133 Home ..................29 Pictures ................134 Settings (Router Mode)..........33 D-Link DIR-880L User Manual...
  • Page 4 Wireless Modes ................. 166 Networking Basics ............167 Check your IP address ............167 Statically Assign an IP address ..........168 Wireless Security ............169 What is WPA? ..............169 Technical Specifications ..........170 Contacting Technical Support ........171 D-Link DIR-880L User Manual...

  • Page 5: Product Overview

    Quick Install Guide If any of the above items are missing, please contact your reseller. Note: Using a power supply with a different voltage rating than the one included with the DIR-880L will cause damage and void the warranty for this product.

  • Page 6: Minimum Requirements

    For mydlink and mydlink app requirements refer to: mydlink Requirements http://www.mydlink.com For requirements refer to QRS Mobile page at: QRS Mobile Requirements • iTunes Store (App Store > Utilities > D-Link Systems) • Google Play (Click link to www.dlink.com/qrsmobileapp) D-Link DIR-880L User Manual...

  • Page 7: Introduction

    Lite app, which is a useful tool for parents. SharePort technology lets you take advantage of the USB 3.0 port located on the side of your DIR-880L, as well as an additional USB 2.0 port located on the back. Plug in a USB storage drive and you can use the mydlink SharePort™ app for iPad®, iPhone®, iPod Touch®, and Android™...

  • Page 8: Features

    Section 1 - Product Overview Features • Faster Wireless Networking - The DIR-880L uses advanced AC beamforming to provide up to a full 1900 Mbps wireless connection with concurrent 801.11ac and 802.11n wireless clients . It also operates on both the 2.4GHz and 5GHz bands to allow separation of traffic so users can participate in high-bandwidth activities, such as video streaming, online gaming, and real-time audio, without affecting low-priority traffic like email and web surfing.

  • Page 9: Hardware Overview

    Press to power the router on and off. Power Port Connect the supplied power adapter. USB 3.0 Port Connect a USB flash drive to share content , or connect it to a USB printer to share it on your network. D-Link DIR-880L User Manual...

  • Page 10: Leds

    USB LED A solid blue light indicates that a USB device is connected to the USB 2.0 port. SS USB LED A solid blue light indicates that a USB device is connected to the USB 3.0 port. D-Link DIR-880L User Manual...

  • Page 11: Installation

    • Advanced Users - If your ISP provided you with a modem/router combo, you will need to set it to “bridge” mode so the DIR-880L can work properly. For details, contact your ISP or refer to the user manual for your modem/router device.

  • Page 12: Wireless Installation Considerations

    RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines: 1. Keep the number of walls and ceilings between the D-Link router and other network devices to a minimum - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters.) Position your devices so that...

  • Page 13: Antenna Setup

    For best performance, position the router’s antennas with their flat side 45° 45° facing towards the front, and tilt the left and right antennas sideways from the center at a 45 degree angle. D-Link DIR-880L User Manual...

  • Page 14: Wall Mounting

    Section 2 - Installation Wall Mounting You can mount the DIR-880L on a wall or partition for ease and convenience. To wall mount your device: Step 1 Screw the provided screws to the wall to which the router will be mounted.

  • Page 15: Manual Setup

    Modem 2. Connect an Ethernet cable from the Internet port of the router to the Ethernet port on your cable or DSL modem. Ethernet Port DIR-880L RESET POWER INTERNET ON/OFF Internet Port (yellow) Modem Ethernet Cable D-Link DIR-880L User Manual...
  • Page 16 3. Connect another Ethernet cable from the Ethernet port on your computer to one of the LAN ports on the router. RESET POWER INTERNET ON/OFF DIR-880L Computer Ethernet Cable 4. Plug the power back into your cable or DSL modem and wait for about one minute before continuing. RESET POWER INTERNET ON/OFF Modem DIR-880L Computer D-Link DIR-880L User Manual...
  • Page 17 6. After the router has powered up, verify that the Power (blue) and Internet (blue or orange) LEDs are both lit. Proceed with router configuration. Note: This unit is to be used with power supply model WA-36C12R. D-Link DIR-880L User Manual...

  • Page 18: Configuration

    There are several different ways you can configure your router to connect to the Internet and connect to your clients: • D-Link Setup Wizard - This wizard will launch when you log into the router for the first time. Refer to page 15.

  • Page 19: Setup Wizard

    IP address of the router (http://192.168.0.1). The wizard will guide you through a step-by-step process to configure your new D-Link router and connect to the Internet. Click Next to continue. Wait a few moments while your router is detecting your Internet connection type.
  • Page 20 Connection (PPPoE), enter your PPPoE username and password and click Next to continue. Note: Make sure you remove your PPPoE software from your computer. The software is no longer needed and will not work through a router. D-Link DIR-880L User Manual...
  • Page 21 (SSID) using up to 32 characters. Create a Wi-Fi password (between 8-63 characters). Your wireless clients will need to have this passphrase or key entered to be able to connect to your wireless network. Click Next to continue. D-Link DIR-880L User Manual...
  • Page 22 The Summary window will display your settings. Click Back if you find it necessary to make changes. When the settings are correct, make a note of the of them so you can configure your Wi-Fi devices. Click Next to continue. D-Link DIR-880L User Manual...
  • Page 23 Note: If you do not want to register at this time, you may click Skip to proceed. If you selected Yes, I have a mydlink account, enter your mydlink Account Name (e-mail address) and Password. Click Next to register your router with your mydlink account. D-Link DIR-880L User Manual...
  • Page 24 If you selected No, I want to create a new mydlink account, enter the requested information and click Next to create your mydlink account. At the end of the wizard, you will see a final summary of your settings. Click Finish to close the wizard. D-Link DIR-880L User Manual...
  • Page 25 Touch, or Android device. For mydlink app requirements, refer to http://www.mydink.com. PC and Mac users can access the mydlink portal at http://mydlink.com. D-Link DIR-880L User Manual...

  • Page 26: Qrs Mobile App

    To con gure your router, go to: http://dlinkrouter.local. Or http://192.168.0.1 Username: “Admin” Password:” “ (leave the eld blank) Step 3 Once you connect to the router, launch the QRS mobile app from the Home screen of your device. D-Link DIR-880L User Manual...
  • Page 27 At this point, make sure that your router is connected to a modem. Plug one end of the provided Ethernet cable into your DSL or cable modem, and plug the other end into the port marked INTERNET on the DIR-880L. Tap Next to automatically detect your Internet connection and proceed to the next step.
  • Page 28 Enter the Device Password (Admin Password) of your choice. Unlike the Wi-Fi password, this password is only required when you need to configure the router. Refer to "Web-based Configuration Utility" on page to learn how this password is used. Tap Next to proceed. D-Link DIR-880L User Manual...
  • Page 29 Step 9 If you would like to receive notification whenever a new firmware update is available, check the Notify me when new firmware is available check box and tap Next. Otherwise, just tap Next to proceed. D-Link DIR-880L User Manual...
  • Page 30 You will see a summary of your chosen settings. If you needto make any changes, tap Back to step back through the previous pages. Otherwise, tap Next to complete the setup. Congratulations, your device has been successfully configured! You may now exit the QRS Mobile app. D-Link DIR-880L User Manual...

  • Page 31: Web-Based Configuration Utility

    The bar at the top of the page has quick access to Settings and Management functions. You may easily navigate back Home at any time. Note: The system will automatically time-out after a period of inactivity. (You will have to log back in as described above.) D-Link DIR-880L User Manual...

  • Page 32: Device Mode

    Device Mode The DIR-880L gives you a choice between two device modes. It can be set to Router Mode or Bridge Mode. The default mode is Router Mode. In Bridge Mode, the DIR-880L creates a wireless link between two existing networks, enabling you to attach up to four wired devices to your wireless network.

  • Page 33: Router Mode

    To view details about your Internet connection, click on the Internet icon. Click Release IP Address to disconnect from the Internet. If you do this and wish to reconnect, click Renew. To reconfigure the Internet settings, refer to "Internet" on page D-Link DIR-880L User Manual...
  • Page 34 Section 3 - Configuration DIR-880L Click on the DIR-880L icon to view details about the router and its wireless settings. Here you can see the router’s current wireless settings, as well as its MAC address. To reconfigure the router's network settings, either click Go to settings on the lower left, or click Settings (at the top of the page) and then Network on the drop-down menu that appears.
  • Page 35 Displays the vendor of the device. IP Address: Enter a specific IP address for this client. Reserve IP: Enable to reserve this IP address for this client. Access: Allow or Block access to the router. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 36 If you have a USB device connected, you can see its name and how much free space it has. To configure your SharePort settings, click Go to settings or click Settings (at the top of the page) and then SharePort on the drop-down menu that appears. and refer to page 60. D-Link DIR-880L User Manual...

  • Page 37: Settings (Router Mode)

    From the Settings menu on, click Wizard to open the Setup Wizard. This is the same wizard that appeared when you first installed the router. After installation, unless you reset the DIR-880L to the factory default settings, you can only access the wizard when the DIR-880L is set to Router Mode.
  • Page 38 The default MAC address is set to the Internet port’s physical interface Clone: MAC address on the router. You can use the drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 39 The default MAC address is set to the Internet port’s physical interface Clone: MAC address on the router. You can use drop-down menu to replace the Internet port’s MAC address with the MAC address of a connected client. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 40 Server: MTU: Maximum Transmission Unit - by default this field will be set to Auto. Select Manual if you need to change the MTU for optimal performance with your ISP. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 41 Enter the PPTP Gateway IP Address provided by your ISP (for Static IP Address: IP only). Enter the Primary DNS Server IP address assigned by your ISP. Primary DNS Server: Secondary DNS Enter the Secondary DNS Server IP address assigned by your ISP. Server: D-Link DIR-880L User Manual...
  • Page 42 Section 3 - Configuration MTU: Maximum Transmission Unit - by default this field will be set to Auto. Select Manual if you need to change the MTU for optimal performance with your ISP. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 43 Enter the L2TP Gateway IP Address provided by your ISP (for L2TP Gateway IP Address: Static IP only). Primary DNS Enter the Primary DNS Server IP address assigned by your ISP. Server: Enter the Secondary DNS Server IP address assigned by your ISP. Secondary DNS Server: D-Link DIR-880L User Manual...
  • Page 44 Section 3 - Configuration MTU: Maximum Transmission Unit - by default this field will be set to Auto. Select Manual if you need to change the MTU for optimal performance with your ISP. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 45 Address: WAN IPv6 Once connected, the WAN IPv6 address will be displayed here. Address: IPv6 WAN Once connected, the IPv6 WAN Default Gateway address will be Default displayed here. Gateway: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 46 For PPPoE refer to page 47. For IPv6 in IPv4 Tunnel refer to page 49. For 6 to 4 refer to page 51. For 6rd refer to page 52. For Local Connectivity Only refer to page 54. D-Link DIR-880L User Manual...
  • Page 47 Enable or disable Automatic DHCP-PD in LAN services. DHCP-PD in LAN: Select SLAAC + RDNSS, SLAAC + Stateless DHCP, or Stateful Autoconfiguration Type: DHCPv6. Router Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 48 Displays the router’s LAN IPv6 Link-Local Address. Local Address: Enable Automatic Enable or disable the Automatic IPv6 Address Assignment feature. IPv6 Address Assignment: Autoconfiguration Select SLAAC + RDNSS, SLAAC + Stateless DHCP, or Stateful DHCPv6. Type: D-Link DIR-880L User Manual...
  • Page 49 Section 3 - Configuration Router Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 50 Enable or disable Automatic DHCP-PD in LAN services. Enable Automatic DHCP-PD in LAN: Autoconfiguration Select SLAAC + RDNSS, SLAAC + Stateless DHCP, or Stateful DHCPv6. Type: Router Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 51 If you selected Use the following DNS, enter the Secondary DNS Server address. Server: Note: When you select Share with IPv4 and Dynamic IP instead of Create a new session and Static IP, less fields are required. See screen shot on the next page. D-Link DIR-880L User Manual...
  • Page 52 Enable or disable the Automatic IPv6 Address Assignment feature. Automatic IPv6 Address Assignment: Auto Select SLAAC + RDNSS, SLAAC + Stateless DHCP or Stateful Configuration DHCPv6. Type: Router Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 53 Enable DHCP- Enable or disable prefix delegation services. LAN IPv6 If you disabled DHCP-PD, enter the LAN (local) IPv6 address for the Address: router. LAN IPv6 Link- Displays the router’s LAN IPv6 Link-Local Address. Local Address: D-Link DIR-880L User Manual...
  • Page 54 Enable or disable Automatic DHCP-PD in LAN services. DHCP-PD in LAN: Autoconfiguration Select SLAAC + RDNSS, SLAAC + Stateless DHCP, or Stateful Type: DHCPv6. Router Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 55 Click to enable the Automatic IPv6 Address Assignment feature. IPv6 Address Assignment: Autoconfiguration Select SLAAC + RDNSS or SLAAC + Stateless DHCP, or Stateful DHCPv6. Type: Router Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 56 Enter the 6rd border relay IPv4 Address supplied by your ISP (for 6rd Border Relay IPv4 manual configuration only). Address: LAN IPv6 Displays the LAN (local) IPv6 address for the router. Address: LAN IPv6 Link- Displays the router’s LAN Link-Local Address. Local Address: D-Link DIR-880L User Manual...
  • Page 57 Check to enable the Automatic IPv6 Address Assignment IPv6 Address feature. Assignment: Autoconfiguration Select SLAAC + RDNSS, SLAAC + Stateless DHCP, or Stateful Type: DHCPv6. Router Enter the IPv6 address lifetime (in minutes). Advertisement Lifetime: Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 58 When ULA is enabled, you may also enable automatic configuration ULA Prefix: of the ULA prefix. Current ULA Will display the Current ULA Prefix. Prefix: LAN IPv6 ULA: Will display the LAN IPv6 ULA. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 59 802.11n wireless clients. For the 5GHz band: Select Auto 20/40/80 MHz if you are using 802.11ac, 802.11n, and non-802.11n wireless devices, or select Auto 20/40 MHz if you are using both 802.11n and non-802.11n wireless devices. D-Link DIR-880L User Manual...
  • Page 60 Use the drop-down menu to select a schedule for enabling the rule. The schedule may be set to Always Enable, or you can create your own schedules in the Schedules section (refer to page 76). Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 61 Internet Access Enabling this option will limit connectivity to the Internet. Guests Only: will not be allowed to access other local network devices. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 62 This section allows you to change the local network settings of the router and to configure the DHCP (Dynamic Host Control Protocol) settings. You can enable the use of the DIR-880L as a DNS server. From the Settings menu, click Network.
  • Page 63 Enable to allow IPv4 multicast traffic to pass through the router from Streams: the Internet. IPv6 Multicast Enable to allow IPv6 multicast traffic to pass through the router from Streams: the Internet. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 64 SharePort drive through a web browser from a device on your network. Click Save when you are done. Note: To manage user accounts for SharePort access, click Create User and refer to the next page for details. D-Link DIR-880L User Manual...
  • Page 65 From the SharePort page, click on the Create User link. The DIR-880L can store a maximum of ten accounts (including the Admin account). If you want to remove an account, click on its trash can icon in the Delete column. If you would like to edit an account, click on its pencil icon in the Edit column.
  • Page 66 Then, click Sign Up to create your new mydlink account. If you already have an existing account, click Yes, I have a mydlink account. Enter your E-mail Address (your username) and your Password. Then, click Sign In and register your DIR-880L with your mydlink account. D-Link DIR-880L User Manual...

  • Page 67: Features (Router Mode Only)

    If you want to remove a priority assignment from a device and return it to the Connected Clients list, click the cross icon in the top right corner of the device card. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 68 Section 3 - Configuration Firewall Settings A firewall protects your network from malicious attacks over the Internet. The DIR-880L offers a high-performance firewall features like SPI (Stateful Packet Inspection). From the Features menu, click Firewall. Enable or disable Demilitarized Zone (DMZ). Enabling this feature...
  • Page 69 NAT devices and work around them. This Application Level Gateway (ALG) may interfere with the operation of such devices. If you are having trouble making VoIP calls, try turning this ALG off. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 70 Use the drop-down menu to select a Schedule when the rule will be enabled. The schedule may be set to Always Enable, or you can create a schedule from the Schedules section (refer to page 76). Click Apply when you are done. D-Link DIR-880L User Manual...
  • Page 71 Use the drop-down menu to select a Schedule when the rule will be enabled. The schedule may be set to Always Enable, or you can create a schedules from the Schedules section (refer to page 76). Click Apply when you are done. D-Link DIR-880L User Manual...
  • Page 72 From the Port Forwarding page click Virtual Server. The DIR-880L can store a maximum of 15 rules. If you wish to remove a rule, click on its trash can icon in the Delete column. If you wish to edit a rule, click on its pencil icon in the Edit column.
  • Page 73 Add Rule. Next, under Website URL/Domain enter the URL or Domain. If you wish to remove a rule, click on its trash can icon in the Delete column. To edit a rule, simply replace the URL or Domain. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 74 A value 1 is the lowest cost and 15 is the highest cost. Interface: Select the interface that the IP packet must use to transit out of the router when this route is used. Click Apply when you are done. D-Link DIR-880L User Manual...
  • Page 75 Metric: Enter the metric value for this rule here. Interface: Select the interface that the IP packet must use to transit out of the router when this route is used. Click Apply when you are done. D-Link DIR-880L User Manual...
  • Page 76 Time Out: Enter a Time Out (in hours). Click Save when you are done. At the bottom of the page are the IPv6 host settings. To configure an IPv6 dynamic DNS host, refer to page 73. D-Link DIR-880L User Manual...
  • Page 77 Enter the Host Name that you registered with your dynamic DNS service provider. IPv6 Address: Enter the IPv6 Address of the dynamic DNS server. Or, select the Computer Name from the drop-down menu. Click Apply when you are done. D-Link DIR-880L User Manual...
  • Page 78 Drive: to your network on an iOS device. Authentication Select either MSCHAPv2, PAP (Password Authentication Protocol), Protocol: or CHAP (Challenge-Handshake Authentication Protocol). MPPE: Select either None, RC4-40, or RC4-128 (encryption). Click Save when you are done. D-Link DIR-880L User Manual...

  • Page 79: Management

    Time & Schedule Time The Time page allows you to configure, update, and maintain the correct time on the DIR-880L's internal system clock. The router's internal clock is used for data logging and schedules. From the Management menu, click Time & Schedule.
  • Page 80 You can add multiple days to the schedule, but only one period per day. To remove a time period from the schedule, click on the cross icon at the end of the row. Click Apply when you are done. D-Link DIR-880L User Manual...
  • Page 81 The schedule may be set to Always Enable, or you can create your own schedule from the Schedules section (refer to page 76). Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 82 Internet by a web browser. A password is still required to access the web management interface. Remote Admin The port number used to access the DIR-880L is used in the URL. Port: Example: http://x.x.x.x:8080 where x.x.x.x is the Internet IP address of the DIR-880L and 8080 is the port used for the web management interface.
  • Page 83 Section 3 - Configuration System This page allows you to save the DIR-880L’s current configuration, load a previously saved configuration, and reset the router to the factory default settings. From the Admin page click System. Click Save to save the current router configuration settings to a file on...
  • Page 84 *Note: When you click Check for New Firmware you will see a message that says, "Checking". If what you have currently installed is the latest version, you will see a message that says, "This firmware is the latest version". D-Link DIR-880L User Manual...
  • Page 85 You can view the Internet, LAN, Wi-Fi 2.4GHz, or Wi-Fi 5GHz statistics by clicking on the respective tabs at the top. The graph will update in real time. To clear the information on the graph, click Clear. The traffic counter will reset if the device is rebooted. D-Link DIR-880L User Manual...

  • Page 86: Bridge Mode

    Settings When the DIR-880L is in Bridge Mode, the Settings menu will be different than it was for the DIR-880L set to Router Mode. The Internet section allows you to configure your Internet connection type for Bridge Mode, or you can change the Device Mode back to Router Mode.
  • Page 87 This address is usually obtained automatically from your ISP. MTU: Maximum Transmission Unit - by default this field will be set to Auto. Select Manual if you need to change the MTU for optimal performance with your ISP. Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 88 Section 3 - Configuration Static IP The factory default IP address for the DIR-880L in Bridge Mode is 192.168.0.50. If you select Static IP, assign an IP Address as 192.168.0.XX, and a Subnet Mask as 255.255.255.0. Enter the IP Address as 192.168.0.XX.
  • Page 89 You can see the wireless signal strength of each network, and the padlock icon means that a password is required to connect to that network. Click Select to finalize your choice, then Save when you are done. D-Link DIR-880L User Manual...

  • Page 90: Management (Bridge Mode)

    Time & Schedule Time The Time page allows you to configure, update, and maintain the correct time on the DIR-880L's internal system clock. The device's internal clock is used for data logging and schedules. From the Management menu, click Time & Schedule.
  • Page 91 You can add multiple days to the schedule, but only one period per day. To remove a time period from the schedule, click on the cross icon at the end of the row. Click Apply when you are done. D-Link DIR-880L User Manual...
  • Page 92 The schedule may be set to Always Enable, or you can create your own schedule from the Schedules section (refer to "Schedule" on page 87). Click Save when you are done. D-Link DIR-880L User Manual...
  • Page 93 Internet by a web browser. A password is still required to access the web management interface. Remote Admin The port number used to access the DIR-880L is used in the URL. Port: Example: http://x.x.x.x:8080 where x.x.x.x is the Internet IP address of the DIR-880L and 8080 is the port used for the web management interface.
  • Page 94 Section 3 - Configuration System This page allows you to save the DIR-880L’s current configuration, load a previously saved configuration, and reset the router to the factory default settings. From the Admin page click System. Save Settings Click Save to save the current router configuration settings to a file on To Local Hard your computer's hard drive.
  • Page 95 *Note: When you click Check for New Firmware you will see a message that says, "Checking". If what you have currently installed is the latest version, you will see a message that says, "This firmware is the latest version". D-Link DIR-880L User Manual...
  • Page 96 You can view the Internet, LAN, Wi-Fi 2.4GHz, or Wi-Fi 5GHz statistics by clicking on the respective tabs at the top. The graph will update in real time. To clear the information on the graph, click Clear. The traffic counter will reset if the device is rebooted. D-Link DIR-880L User Manual...

  • Page 97: Using The Mydlink Shareport™ App

    The mydlink SharePort app is a mobile application that allows you to conveniently stream media and share files stored on a USB drive connected to your DIR-880L. Once the router is set up, you can start the app and easily connect from a local network or through the Internet to access your photos, videos, music, and documents.
  • Page 98 • Wi-Fi Network Name (SSID): dlink-XXXX* • Password: (leave this blank) *Note: For the 2.4GHz band, the SSID is dlink-XXXX, with XXXX representing the last four digits of your router’s MAC address. For the 5GHz band, the SSID is dlink-XXXX-5GHz. D-Link DIR-880L User Manual...
  • Page 99 Remote mode will connect you to storage on your router in a different location. For example, from your office connecting to your router at home. If you are directly connected to the DIR-880L’s wireless network, tap Local Access and enter the Admin Password of your router, then tap Log If you are connecting through the Internet tap Remote Access and enter your mydlink login information, then tap Log In.
  • Page 100 Remote Access. Note: If you see a red wireless icon, your router’s network environment may not be suitable for a direct network connection and you may experience slow network speeds. D-Link DIR-880L User Manual...

  • Page 101: Main Menu

    Tap on the movie icon to play videos. Tap on the music icon to play audio files. Tap on the folder icon to browse all files in a folder view. Tap on the star icon to access your favorite files. D-Link DIR-880L User Manual...

  • Page 102: Documents

    Section 4 - SharePort Documents The Documents section allows you to share, print, and view documents streamed from your DIR-880L to your mobile device. Tap the document icon on the main menu to browse the documents on your mobile device. Search Bar: Enter a filename here to search your storage.
  • Page 103 Tap on a file to start the document viewer. In the viewer: Tap to add/remove the file from your Favorites. Tap to bring up the same options as (>) on the previous page. Note: Some files may require a third-party app to view them. D-Link DIR-880L User Manual...

  • Page 104: Pictures

    Section 4 - SharePort Pictures The Pictures section allows you to stream images from your DIR-880L to your mobile device. Tap the camera icon on the main menu to browse your photo collection on your removable storage. Search Bar: Enter a filename here to search your storage.
  • Page 105 Tap on a file to start the photo viewer. In the viewer: Tap to add/remove the current image from your Favorites. Tap to start the slideshow. Tap to bring up the same image options as (>) on the previous page. D-Link DIR-880L User Manual...

  • Page 106: Videos

    Section 4 - SharePort Videos The Videos section allows you to stream video clips and movies from your DIR-880L to your mobile device. Tap the movie icon on the main menu to browse your videos on your removable storage. Search Bar: Enter a filename here to search for a specific file.
  • Page 107 Tapping this icon gives you these additional options: • Mail: Lets you e-mail the video. • iCloud: Lets you store the video on iCloud. • Open In...: Lets you use a third-party app to open the file. D-Link DIR-880L User Manual...

  • Page 108: Music

    Section 4 - SharePort Music The Music section allows you to stream songs from your DIR-880L to your mobile device. Tap the music icon on the main menu to browse your music collection on your removable storage. Search Bar: Enter a filename here to search your storage.
  • Page 109 • Tap Edit > Add Playlist. The New Playlist window will open. • Enter a name for the playlist, then tap Save. • The name of the playlist will appear in the browser next to the icon. D-Link DIR-880L User Manual...
  • Page 110 • Tap Done. The playlist will be saved. To delete songs from the playlist: • Tap Edit in the playlist browser and mark the files to be deleted. • Tap Delete. D-Link DIR-880L User Manual...

  • Page 111: Folders

    Tap Home to go back to the main menu. Tap Upload to upload files from your device to your removable storage. Tap Refresh to update the list of files. Tap Sort to reorder the files alphabetically. D-Link DIR-880L User Manual...
  • Page 112 • Browse to the directory you wish to create a new folder in. • Tap Edit at the top right. • Tap Add Folder to add a new folder. • Enter the Name of the new folder, then tap Save. • Tap OK to confirm folder creation. D-Link DIR-880L User Manual...
  • Page 113 • Tap Done. During the upload process, the size of the file and the upload progress will be displayed. To upload more files, tap the + icon at the top right and repeat the steps listed above. D-Link DIR-880L User Manual...

  • Page 114: Favorites

    Tap on a file to start the file viewer. In the viewer: Tap to add/remove the file from your Favorites. Tap to bring up additional options. Note: The file options available will vary depending on the file type. D-Link DIR-880L User Manual...

  • Page 115: Using The Mydlink Shareport™ App For Android

    The mydlink SharePort™ app is a mobile application that allows you to conveniently stream media and share files stored on a USB drive connected to your DIR-880L. Once the router is set up, you can start the app and easily connect from a local network or through the Internet to access your photos, videos, music, and documents.
  • Page 116 • Wi-Fi Network Name (SSID): dlink-XXXX* • Password: (leave this blank) *Note: For the 2.4GHz band, the SSID is dlink-XXXX, with XXXX representing the last four digits of your router’s MAC address. For the 5GHz band, the SSID is dlink-XXXX-5GHz. D-Link DIR-880L User Manual...
  • Page 117 Remote Access: Remote mode will connect you to storage on your router in a different location. For example, you are at your office connecting to your router at home. D-Link DIR-880L User Manual...
  • Page 118 Section 4 - SharePort If you are directly connected to the DIR-880L’s wireless network, tap Local Access and enter the Admin Password of your router, then tap Log In. If you are connecting through the Internet tap Remote Access and enter your mydlink login information, then tap Log In.

  • Page 119: Main Menu

    Tap on the folder icon to browse files in a folder view. Tap on the star icon to access your favorite files. Note: Available features may differ depending on the Android OS version of your device. D-Link DIR-880L User Manual...

  • Page 120: Documents

    Section 4 - SharePort Documents The Documents section allows you to share, print, and view documents streamed from your DIR-880L to your mobile device. Tap the document icon on the main menu to browse the files on your mobile device. Search Bar: Type in the name of a file to search for it.
  • Page 121 • Drag the screen up or down to scroll between pages. • Tap to perform File, Find, Zoom, Reading View, Go to Page, and Bookmarks actions. Note: Available actions may differ depending on your Android OS. D-Link DIR-880L User Manual...

  • Page 122: Pictures

    Section 4 - SharePort Pictures The Pictures section allows you to view images streamed from your DIR-880L to your mobile device. Tap the camera icon on the main menu to browse your photo collection on your removable storage. Search Bar: Type in the name of a file to search for it.
  • Page 123 Tap the icon to delete the current image. Tap OK to confirm. Tap the icon to bring up additional options using other applications. Tap the icon to access the image editor. Note: This function may vary depending on the version of your Android OS. D-Link DIR-880L User Manual...

  • Page 124: Videos

    Section 4 - SharePort Videos The Videos section allows you to stream video clips and movies from your DIR-880L to your mobile device. Tap the movie icon on the main menu to browse your videos on your removable storage. Search Bar: Type in the name of a file to search for it.
  • Page 125 Tap on a file to start playing it. Tap on the screen to bring up the scroll bar, pause button, and play button. Tap to resume playback. Tap to pause the video. Note: Available features may vary depending on the Android OS version installed on your device. D-Link DIR-880L User Manual...

  • Page 126: Music

    Section 4 - SharePort Music The Music section allows you to stream songs from your DIR-880L to your mobile device. Tap the music icon on the main menu to browse your music collection on your removable storage. Search Bar: Type in the name of a file to search for it.
  • Page 127 • Tap Add new playlist... • Enter a name for the playlist, then tap OK. The name of the playlist will appear in the browser next to the icon. • You can tap then to refresh the playlist page. D-Link DIR-880L User Manual...
  • Page 128 • Tap the check boxes by the songs you wish to add, and tap to save. To delete songs from the playlist: • Tap Edit in the playlist browser and tap the check boxes by the files you would like to delete. then tap OK to confirm. • Tap D-Link DIR-880L User Manual...

  • Page 129: Folders

    Tap the icon to return to the main menu. Tap the icon to upload files. Tap the icon to refresh, sort, create a new folder, or mark files for deletion and copying. (See the list beginning on the next page for details.) D-Link DIR-880L User Manual...
  • Page 130 To copy files: • Tap on to select files for copying. Tap the check box next to each file to be copied. • Tap on to browse for a destination folder for the copies of the files. D-Link DIR-880L User Manual...
  • Page 131 To create a new folder: • Browse to the directory you wish to create a new folder in. • Tap then • Enter the Name of the folder in the box, then tap OK. D-Link DIR-880L User Manual...
  • Page 132 During the upload process, the size of the file and the upload progress will be displayed under the file name. • To remove a file from the upload queue, tap the X at the end of the row. D-Link DIR-880L User Manual...

  • Page 133: Favorites

    Tap the icon to update the list of files. Tap the icon to sort the files by name, size, type, or date. Tap the check box to check a file, then tap the trash icon to delete it. D-Link DIR-880L User Manual...

  • Page 134: Using Shareport Mobile For Windows® 8/Rt

    Connect from a local network to access your photos, videos, music, and documents. You can upload files and photos from your mobile device to your router’s USB drive via the app wirelessly! 1. Make sure the DIR-880L is powered on. Then plug your USB drive into the USB port on the back of your router.
  • Page 135 Settings. Then tap SharePort Settings and enter your admin Password. Tap on the back icon (<) to exit settings and log in. 6. You will see the SharePort Mobile main menu. D-Link DIR-880L User Manual...

  • Page 136: Main Menu

    Tap on the movie icon to play videos. Tap on the music icon to play audio files. Tap on the folder icon to browse all files in a folder. Tap on the star icon to access your favorite files. D-Link DIR-880L User Manual...

  • Page 137: Documents

    Section 4 - SharePort Documents The Documents section allows you to share, print, and view documents streamed from your DIR-880L to your mobile device. Tap the document icon on the main menu to browse the documents stored on your USB drive.

  • Page 138: Pictures

    Section 4 - SharePort Pictures The Pictures section allows you to stream images from your DIR-880L to your mobile device. Tap the camera icon on the main menu to browse your photo collection stored on your USB drive. In the image browser, tap the image to open it.
  • Page 139 After tapping Edit: Tap Quit Edit to leave the editing screen. Tap Favorite to add the file to Favorite and download it to your local device. Tap Delete to delete the selected file or files. D-Link DIR-880L User Manual...

  • Page 140: Movies

    Movies The Movies section allows you to stream video clips and movies from your DIR-880L to your mobile device. Tap the movie icon on the main menu to browse your videos stored on your USB drive. In the movies browser, tap the file to play it.
  • Page 141 Tap to add file to Favorite or delete the file. (See list below.) After tapping Edit: Tap to leave the editing screen. Tap to return to the main menu. Tap to add the file to Favorite and download it to your local device. Tap to delete the file. D-Link DIR-880L User Manual...

  • Page 142: Music

    Section 4 - SharePort Music The Music section allows you to stream songs from your DIR-880L to your mobile device. Tap the music icon on the main menu to browse your music collection stored on your USB drive. In the music browser, tap a file to play it with the music player.
  • Page 143 • Enter a name for the playlist, then tap Save. The playlist will appear in the browser as an icon. To add songs to a playlist: • Tap your playlist to see its current contents. • Tap the Edit icon. • Tap the Add icon. D-Link DIR-880L User Manual...
  • Page 144 • Tap your playlist to see its current contents. • Tap the Edit icon in the playlist browser and tap to mark the files to be deleted. • Tap the Delete icon to remove the file. D-Link DIR-880L User Manual...

  • Page 145: Folder

    Tap Home to return to the main menu. Tap Upload to upload a file from your device. Tap New Folder to create a new folder. *Note: Refer to the next page for the additional Edit options available when you select a file. D-Link DIR-880L User Manual...
  • Page 146 To copy files: • Tap to select the file to be copied, and tap the Copy icon. • Browse to and select the destination folder. • Tap the Choose icon to copy the file to that destination folder. D-Link DIR-880L User Manual...
  • Page 147 • During the upload process, you may tap the upload queue files to delete them from the queue. • To upload more files, tap the Upload icon at the top right and repeat the steps above. D-Link DIR-880L User Manual...

  • Page 148: Favorite

    Tap Edit to to add file to Favorite or delete the file. (See list below.) Tap Edit and select a file for the following options: Tap Quit Edit to leave the editing screen. Tap Delete to delete the selected file or files. Tap Clear Selection to deselect all selected files. D-Link DIR-880L User Manual...

  • Page 149: Connect A Wireless Client To Your Router

    Blu-ray DVD players, wireless printers and cameras will have a WPS button (or a software utility with WPS) that you can press to connect to the DIR-880L router. Refer to your user manual for the wireless device you want to connect to make sure you understand how to enable WPS.

  • Page 150: Windows® 8

    Wireless Icon Clicking on this icon will display a list of wireless networks that are within connecting proximity of your computer. Select the desired network by clicking on the network name. D-Link DIR-880L User Manual...
  • Page 151 WPS button on your router during this step to enable the WPS function. When you have established a successful connection to a wireless network, the word Connected will appear next to the name of the network to which you are connected to. D-Link DIR-880L User Manual...

  • Page 152: Windows® 7

    If you are joining an existing network, you will need to know the security key or passphrase being used. 1. Click on the wireless icon in your system tray (lower-right corner). Wireless Icon 2. The utility will display any available wireless networks in your area. D-Link DIR-880L User Manual...
  • Page 153 If you get a good signal but cannot access the Internet, check your TCP/ IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. 4. The following window appears while your computer tries to connect to the router. D-Link DIR-880L User Manual...
  • Page 154 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as the one on the wireless router. D-Link DIR-880L User Manual...

  • Page 155: Wps

    Section 5 - Connecting to a Wireless Network The WPS feature of the DIR-880L can be configured using Windows® 7. Carry out the following steps to use Windows® 7 to configure the WPS feature: 1. Click the Start button and select Computer from the Start menu.
  • Page 156 Section 5 - Connecting to a Wireless Network 3. Double-click the DIR-880L. 4. Input the WPS PIN number (on the router label) in the Setup > Wireless Setup menu in the Router’s Web UI) and click Next. D-Link DIR-880L User Manual...
  • Page 157 Section 5 - Connecting to a Wireless Network 5. Type a name to identify the network. 6. To configure advanced settings, click the icon. Click Next to continue. D-Link DIR-880L User Manual...
  • Page 158 Make a note of the security key as you may need to provide this security key if adding an older wireless device to the network in the future. 9. Click Close to complete WPS setup. D-Link DIR-880L User Manual...

  • Page 159: Windows Vista

    (displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check you TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. D-Link DIR-880L User Manual...

  • Page 160: Wpa/Wpa2

    1. Open the Windows Vista® Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower right corner of screen). Select Connect to a network. 2. Highlight the Wi-Fi name (SSID) you would like to connect to and click Connect. D-Link DIR-880L User Manual...
  • Page 161 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as the one on the wireless router. D-Link DIR-880L User Manual...

  • Page 162: Troubleshooting

    1. Why can’t I access the web-based configuration utility? When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website, nor do you have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility.
  • Page 163 Mode, it will be assigned a new IP address based on your router/network’s DHCP settings. You will have to access your other router's DHCP table to see what IP address was assigned to the DIR-880L. (Refer to the manufacturer's user manual if it is not a D-Link device.) If you are using a D-Link router, follow these instructions to find the IP address that was assigned: Using the router’s Web-based configuration utility, go to Setup >...
  • Page 164 Bridge mode, which will turn off the device's NAT functions. If you are using the DIR-880L in Bridge mode, and you need to connect it to a router, connect an Ethernet cable from the LAN port on your router to the WAN port on the DIR-880L.
  • Page 165 • To change the MTU, enter the number in the MTU field and click Save Settings to save your settings. • Test your e-mail. If changing the MTU does not resolve the problem, continue changing the MTU in increments of ten. D-Link DIR-880L User Manual...

  • Page 166: Wireless Basics

    D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business, or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when, and where you want it. You will be able to enjoy the freedom that wireless networking delivers.

  • Page 167: What Is Wireless

    D-Link is the worldwide leader and award winning designer, developer, and manufacturer of networking products. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network. How does wireless work? Wireless works similarly to how cordless phones work, through radio signals that transmit data from one point A to point B.
  • Page 168 Who uses wireless? Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home Uses/Benefits • Gives everyone at home broadband access •...

  • Page 169: Tips

    The wireless connection in public places is usually called “hotspots”. Using a D-Link Cardbus Adapter with your laptop, you can access the hotspot to connect to the Internet from remote locations like: Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers.

  • Page 170: Wireless Modes

    • Ad-Hoc – Directly connecting to another computer for peer-to-peer communication using wireless network adapters on each computer, such as two or more DIR-880L wireless network Cardbus adapters. An Infrastructure network contains an Access Point or wireless router. All the wireless devices, or clients, will connect to the wireless router or access point.

  • Page 171: Networking Basics

    Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below.

  • Page 172: Statically Assign An Ip Address

    Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP. Step 5 Click OK twice to save your settings. D-Link DIR-880L User Manual...

  • Page 173: Wireless Security

    Appendix B - Networking Basics Wireless Security This section will show you the different levels of security you can use to protect your data from intruders. The DIR-880L offers the following types of security: • WPA2 (Wi-Fi Protected Access 2) •...

  • Page 174: Technical Specifications

    1 Maximum wireless signal rate derived from IEEE Standard 802.11a, 802.11g, and 802.11n specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. 2 Frequency Range varies depending on country’s regulation. D-Link DIR-880L User Manual...

  • Page 175: Contacting Technical Support

    • Hardware Revision (located on the label on the bottom of the router (e.g. rev A1)) • Serial Number (s/n number located on the label on the bottom of the router). You can find software updates and user documentation on the D-Link website as well as frequently asked questions and answers to technical issues.
  • Page 176 WRITTEN OFFER FOR GPL AND LGPL SOURCE CODE Where such specific license terms entitle you to the source code of such software, D-Link will provide upon written request via email and/or traditional paper mail the applicable GPL and LGPLsource code files via CD-ROM for a nominal cost to cover shipping and media charges as allowed under the GPL and LGPL.
  • Page 177 To prevent this, the GPL assures that patents cannot be used to render the program non-free. The precise terms and conditions for copying, distribution and modification follow. D-Link DIR-880L User Manual...
  • Page 178 A “Standard Interface” means an interface that either is an official standard defined by a recognized standards body, or, in the case of interfaces specified for a particular programming language, one that is widely used among developers working in that language. D-Link DIR-880L User Manual...
  • Page 179 Conveying under any other circumstances is permitted solely under the conditions stated below. Sublicensing is not allowed; section 10 makes it unnecessary. D-Link DIR-880L User Manual...
  • Page 180 If the work has interactive user interfaces, each must display Appropriate Legal Notices; however, if the Program has interactive interfaces that do not display Appropriate Legal Notices, your work need not make them do so. D-Link DIR-880L User Manual...
  • Page 181 Corresponding Source of the work are being offered to the general public at no charge under subsection 6d. A separable portion of the object code, whose source code is excluded from the Corresponding Source as a System Library, need not be included in conveying the object code work. D-Link DIR-880L User Manual...
  • Page 182 If additional permissions apply only to part of the Program, that part may be used separately under those permissions, but the entire Program remains governed by this License without regard to the additional permissions. D-Link DIR-880L User Manual...
  • Page 183 Additional terms, permissive or non-permissive, may be stated in the form of a separately written license, or stated as exceptions; the above requirements apply either way. D-Link DIR-880L User Manual...
  • Page 184 Corresponding Source of the work from the predecessor in interest, if the predecessor has it or can get it with reasonable efforts. D-Link DIR-880L User Manual...
  • Page 185 D-Link DIR-880L User Manual...
  • Page 186 Free Software Foundation. If the Program specifies that a proxy can decide which future versions of the GNU General Public License can be used, that proxy’s public statement of acceptance of a version permanently authorizes you to choose that version for the Program. D-Link DIR-880L User Manual...
  • Page 187 Program, unless a warranty or assumption of liability accompanies a copy of the Program in return for a fee. D-Link DIR-880L User Manual...
  • Page 188 Any repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. The replacement hardware need not be new or have an identical make, model or part. D-Link may, at its option, replace the defective Hardware or any part thereof with any reconditioned product that D-Link reasonably determines is substantially equivalent (or superior) in all material respects to the defective Hardware.
  • Page 189 Software or to refund the portion of the actual purchase price paid that is attributable to the Software. Except as otherwise agreed by D-Link in writing, the replacement Software is provided only to the original licensee, and is subject to the terms and conditions of the license granted by D-Link for the Software.
  • Page 190 • The customer must submit with the product as part of the claim a written description of the Hardware defect or Software nonconformance in sufficient detail to allow D-Link to confirm the same, along with proof of purchase of the product (such as a copy of the dated purchase invoice for the product) if the product is not registered.
  • Page 191 Purolator Canada or any common carrier selected by D-Link. Return shipping charges shall be prepaid by D-Link if you use an address in Canada, otherwise we will ship the product to you freight collect. Expedited shipping is available upon request and provided shipping charges are prepaid by the customer.
  • Page 192 FOR WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NONCONFORMING PRODUCT.
  • Page 193 The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination. The firmware setting is not accessible by the end user. D-Link DIR-880L User Manual...
  • Page 194 Les conditions de fonctionnement sont sujettes à deux conditions: (1) Ce périphérique ne doit pas causer d’interférence et. (2) Ce périphérique doit accepter toute interférence, y compris les interférences pouvant perturber le bon fonctionnement de ce périphérique. D-Link DIR-880L User Manual...
  • Page 195 Appendix G - Registration Registration Product registration is entirely voluntary and failure to complete or return this form will not diminish your warranty rights. Version 1.0 April 28, 2014 D-Link DIR-880L User Manual...

Table of Contents
