Philips QV14.1E Service Manual

For colour television
Hide thumbs
Table of Contents

Advertisement

Quick Links

Colour Television
Contents
11. Styling Sheets
79xx series 49"
79xx series 55"
81x9 and 82x9 series 48" - 55"
88x9 series 55"
89x9 curved series 55"
91xx series 55" - 65"
98xx series 65"
Published by PvH/EL 1443 Consumer Care
©
2014
TP Vision Netherlands B.V.
All rights reserved. Specifications are subject to change without notice. Trademarks are the
property of Koninklijke Philips Electronics N.V. or their respective owners.
TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust
earlier supplies accordingly.
PHILIPS and the PHILIPS' Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
Page
2
2
6
10
34
37
48
49
Drawing PWB
71
128 - 129
130
186 - 187
188
189 - 190
191
210 - 211
212
214
216
218
220
223
226
229
232
234
236
238
239
240
241
242
243
244
Printed in the Netherlands
Chassis
QV14.1E
Subject to modification
EN 3122 785 19573
LA

Advertisement

Table of Contents
loading

Related Manuals for Philips QV14.1E

Summary of Contents for Philips QV14.1E

  • Page 1 Koninklijke Philips Electronics N.V. or their respective owners. TP Vision Netherlands B.V. reserves the right to change products at any time without being obliged to adjust earlier supplies accordingly. PHILIPS and the PHILIPS’ Shield Emblem are used under license from Koninklijke Philips Electronics N.V.
  • Page 2 Revision List EN 2 QV14.1E LA 1. Revision List Manual xxxx xxx xxxx.0 Manual xxxx xxx xxxx.2 • First release. Added CTN’s of 79xx series: • Chapter 2: Table 2-1 updated. • Chapter 4: added cable dressing. Manual xxxx xxx xxxx.1 •...
  • Page 3 Technical Specs, Diversity, and Connections QV14.1E LA EN 3 Mechanics Descr. Block Diagrams Schematics Styling 55PUS8809/12 4-10 10.2 10.4 10.5 11.4 55PUS8809/60 4-11 9.22 10.6 10.8 55PUS8909C/12 4-12 9.10 10.2 10.4 10.8 11.5 4-13 9.11 9.22 10.14 10.15 55PUS9109/12 4-14 9.12...
  • Page 4 Technical Specs, Diversity, and Connections EN 4 QV14.1E LA Connections Side Connectors Rear Connectors SERVICE AUDIO IN NETWORK SCART Bottom Rear Connectors AUDIO OUT ANTENNA SAT 1 SAT 2 HDMI HDMI OPTICAL 19570_007_140513.eps 14-05-13 Figure 2-1 Connection overview Note: The following connector colour abbreviations are used - Data (+) (acc.
  • Page 5 Technical Specs, Diversity, and Connections QV14.1E LA EN 5 - D0- Data channel Rd - Video Pr 0.7 V / 75 ohm 10 - CLK+ Data channel 11 - Shield 17 - Service 12 - CLK- Data channel - Ground...
  • Page 6 3.3.3 Spare Parts external damage. • Check the strain relief of the Mains/AC Power cord for For the latest spare part overview, consult your Philips Spare proper function. Part web portal. • Check the electrical DC resistance between the Mains/AC...
  • Page 7 Precautions, Notes, and Abbreviation List QV14.1E LA EN 7 The third digit in the serial number (example: Abbreviation List AG2B0335000001) indicates the number of the alternative B.O.M. (Bill Of Materials) that has been used for producing the 0/6/12 SCART switch control signal on A/V specific TV set.
  • Page 8 Precautions, Notes, and Abbreviation List EN 8 QV14.1E LA Directions For Use: owner's manual SDI), is a digitized video format used Digital Media Reader: card reader for broadcast grade video. DMSD Digital Multi Standard Decoding Uncompressed digital component or Digital Natural Motion digital composite signals can be used.
  • Page 9 SOPS Self Oscillating Power Supply Serial Peripheral Interface bus; a 4-wire synchronous serial data link standard S/PDIF Sony Philips Digital InterFace SRAM Static RAM Service Reference Protocol Small Signal Board Spread Spectrum Clocking, used to reduce the effects of EMI...
  • Page 10 Mechanical Instructions EN 10 QV14.1E LA 4. Mechanical Instructions Index of this chapter: Notes: 4.1 Cable Dressing • Figures below can deviate slightly from the actual situation, 4.2 Service Positions due to the different set executions. 4.3 Assy/Panel Removal •...
  • Page 11 Mechanical Instructions QV14.1E LA EN 11 19570_177_140728.eps 14-07-28 Figure 4-3 Cable dressing detail 48” and 55" 8109/8159/8209 series (55" shown) back to 2014-Oct-22 div. table...
  • Page 12 Mechanical Instructions EN 12 QV14.1E LA 19572_001_140907.eps 14-09-07 Figure 4-4 Cable dressing 49" 7909 series 19572_002_140907.eps 14-09-07 Figure 4-5 Cable dressing back cover 49" 7909 series back to 2014-Oct-22 div. table...
  • Page 13 Mechanical Instructions QV14.1E LA EN 13 19572_003_140907.eps 14-09-07 Figure 4-6 Cable dressing 55" 7909 series 19572_004_140907.eps 14-09-07 Figure 4-7 Cable dressing back cover 55" 7909 series back to 2014-Oct-22 div. table...
  • Page 14 Mechanical Instructions EN 14 QV14.1E LA 19570_010_140514.eps 14-05-15 Figure 4-8 Cable dressing 55" 8109/8159/8209 series 19570_011_140514.eps 14-07-10 Figure 4-9 Cable dressing back cover 55" 8109/8159/8209 series back to 2014-Oct-22 div. table...
  • Page 15 Mechanical Instructions QV14.1E LA EN 15 19570_012_140514.eps 14-07-10 Figure 4-10 Cable dressing 55" 8809 series 19570_013_140514.eps 14-07-11 Figure 4-11 Cable dressing back cover 55" 8809 series back to 2014-Oct-22 div. table...
  • Page 16 Mechanical Instructions EN 16 QV14.1E LA 19573_003_141015.eps 14-10-16 Figure 4-12 Cable dressing 55" 8909 curved series 19573_004_141015.eps 14-10-16 Figure 4-13 Cable dressing back cover 55" 8909 curved series back to 2014-Oct-22 div. table...
  • Page 17 Mechanical Instructions QV14.1E LA EN 17 19573_001_141008.eps 14-10-08 Figure 4-14 Cable dressing 55" 9109 series 19573_002_141015.eps 14-10-16 Figure 4-15 Cable dressing back cover 55" 9109 series back to 2014-Oct-22 div. table...
  • Page 18 Mechanical Instructions EN 18 QV14.1E LA 19570_190_140804.eps 14-08-05 Figure 4-16 Cable dressing 65" 9109 series 19570_191-140804.eps 14-08-07 Figure 4-17 Cable dressing back cover 65" 9109 series back to 2014-Oct-22 div. table...
  • Page 19 Mechanical Instructions QV14.1E LA EN 19 19570_192_140804.eps 14-08-07 Figure 4-18 Cable dressing 65" 9809 series 19570_193_140804.eps 14-08-07 Figure 4-19 Cable dressing back cover 65" 9809 series back to 2014-Oct-22 div. table...
  • Page 20 Mechanical Instructions EN 20 QV14.1E LA Service Positions care that these always support the cabinet and never only the display. For easy servicing of a TV-set, the set should be put face down Caution: Failure to follow these guidelines can seriously...
  • Page 21 Service Modes, Error Codes, and Fault Finding QV14.1E LA EN 21 5. Service Modes, Error Codes, and Fault Finding Index of this chapter: Every time the TV-set is switched “on/off” 0,5 hours is 5.1 Test Points added to this number.
  • Page 22 Service Modes, Error Codes, and Fault Finding EN 22 QV14.1E LA • Test settings. For development purposes only. When CSM is activated and there is an USB stick connected to • RF4CE pairing tables. Clear paired remote control. the TV-set, the software will dump the CSM content to the USB For re-pairing (coldboot of platform possibly needed) press stick.
  • Page 23 Service Modes, Error Codes, and Fault Finding QV14.1E LA EN 23 consumer upgradeable, it will also be published on the Internet. Example: AND1E-1.2.3.4 • 2.2 Standby software. Displays the build-in standby processor software version. Upgrading this software, embedded with the main software update.5.9 Software...
  • Page 24 Service Modes, Error Codes, and Fault Finding EN 24 QV14.1E LA Start-up The flowcharts on the following pages show the process from start-up. For each phase they show which supplies are active. 5.3.1 Transition Overview Mains Mains WakeUp - WakeUp requested...
  • Page 25 Service Modes, Error Codes, and Fault Finding QV14.1E LA EN 25 5.3.2 “Off” to “Semi Standby” (part 1) Stand by or AC~ Mains is applied Protection Standby Supply starts running. All standby supply voltages become available. st-by µP resets, resulting in a high impedant output stage of the I/O ports.
  • Page 26 Service Modes, Error Codes, and Fault Finding EN 26 QV14.1E LA 5.3.3 “Off” to “Semi Standby” (part 2) Wake up reason coldboot to Active mode? AUDIO-MUTEn is switched by MIPS code Startup screen cfg file later on in the startup process when audio...
  • Page 27 Service Modes, Error Codes, and Fault Finding QV14.1E LA EN 27 5.3.4 “Semi Standby” to “Active” Semi Standby The assumption here is that a fast toggle (<2s) can Wait until previous on-state is left more than 2 only happen during ON->SEMI ->ON.
  • Page 28 Service Modes, Error Codes, and Fault Finding EN 28 QV14.1E LA 5.3.5 “Active” to “Semi Standby” Active Mute all sound outputs according information in the FMS AUDIO Wait 100ms Switch off POK line detection algorithm (see CHS service) Switch Off LCD backlight...
  • Page 29 Service Modes, Error Codes, and Fault Finding QV14.1E LA EN 29 5.3.6 “Semi Standby” to “Standby” Semi Stand by If ambientlight functionality was used in semi-standby (lampadaire mode), switch off ambient light (see CHS ambilight) *) If this is not performed and the set is...
  • Page 30 Service Modes, Error Codes, and Fault Finding EN 30 QV14.1E LA Service Tools 5.5.2 How to Read the Error Buffer 5.4.1 ComPair Use one of the following methods: • On screen via the SAM (only when a picture is visible).
  • Page 31 Service Modes, Error Codes, and Fault Finding QV14.1E LA EN 31 Table 5-1 Error code overview Monitored Error/ Error Buffer/ Description Layer 1 Layer 2 Prot Blinking LED Device Defective Board FE-bus BL / EB Cypress bus BL / EB...
  • Page 32 Service Modes, Error Codes, and Fault Finding EN 32 QV14.1E LA • Related to supplies: presence of the +5V,+2V5, +1V5, - Select the correct database (open file “QFUX.X”, this will set +1V2 and +1V0 needs to be measured, no protection the ComPair interface in the appropriate mode).
  • Page 33 TV, the main software and the default software upgrade application can be upgraded with the “AUTORUN.UPG” from the “Philips” P4C/S website. This can also be done by the consumers themselves, but they will have to get their software from the commercial Philips website or via the Software Update Assistant in the user menu (see eUM).
  • Page 34 Alignments EN 34 QV14.1E LA 6. Alignments Index of this chapter: • LATAM models: an NTSC M TV-signal with a signal 6.1 General Alignment Conditions strength of at least 1 mV and a frequency of 61.25 MHz 6.2 Hardware Alignments (channel 3).
  • Page 35 Alignments QV14.1E LA EN 35 Table 6-2 White tone default settings 48PFS81x9 you can set all options very quickly. All options are controlled via eight option numbers. When the NVM is replaced, all options will require resetting. To White Tone...
  • Page 36 Alignments EN 36 QV14.1E LA Total Overview SAM modes Table 6-6 SAM mode overview Main Menu Sub-menu 1 Sub-menu 2 Sub-menu 3 Description Hardware Info A. SW version e.g. “AND1E_0.7.31.0E Display TV & Standby SW version and CTN serial number B.
  • Page 37 19570_182_140728.eps Introduction 14-07-28 The QV14.1E LA is a new platform launched in Europe in 2014. Figure 7-2 UHD100 This chassis contains the Marvell BQ-2. The major deltas versus its predecessor are DVB-TC; DVB-TC/T2, DVB-TC/S2 with also multimedia, 3D, AmbiLight, WiFi, Smart TV and Light Sensor functionality.
  • Page 38 Circuit Descriptions EN 38 QV14.1E LA Marvell BG2-Q Architecture FHD100 11n 2x2 2x DDR3 2x DDR3 DDR3 2x DDR3 Wifi 1600 1600 1600 1600 eMMC FPGA USB2.0 LX75 USB2.0 =Anaconda 2 Wifi Noise USB3.0 3D-LR 3D-LR 2 Wifi reduction NT72314...
  • Page 39 Circuit Descriptions QV14.1E LA EN 39 Marvell BG2-Q Architecture UHD100 11n 2x2 BoltOn Wifi 2x DDR3 2x DDR3 DDR3 2x DDR3 2x DDR3 1600 1600 1600 1600 1600 eMMC FPGA FPGA USB2.0 LX75 USB2.0 =Anaconda 2 Wifi AL-SPI AL-SPI Noise USB3.0...
  • Page 40 Circuit Descriptions EN 40 QV14.1E LA Marvell BG2-Q Architecture UHD50 17511n 2x2 2x DDR3 2x DDR3 DDR3 2x DDR3 Wifi 1600 1600 1600 1600 eMMC USB2.0 FPGA LX75 USB2.0 =Anaconda+ 2 Wifi AL-SPI FRC Master USB3.0 FHD: 3D-LR/QFHD 3D-LR 2 Wifi...
  • Page 41 Circuit Descriptions QV14.1E LA EN 41 7.2.3 Marvell Copper Layouts Refer to Chapter 9 for detailed Architecture and Connections: • 9.16 Architecture - FHD, 9.17 Connections - FHD, • 9.18 Architecture - UHD, 9.19 Connections - UHD Rogue, The following Figures show the layout of the different SSB’s •...
  • Page 42 Circuit Descriptions EN 42 QV14.1E LA COMMON INTERFACE POWER BACK-END HDMI to TTL ADV7619 CIMax 4k FPGA eMMC flash MV BG2-Q SOC1 HDMI 6:2 mux PQ FPGA MV Cypress Anaconda SERVICE Audio Class-D HDMI Rogue FRONT-END HDMI 2.0 TAS5760 Channel decoders HDMI 2.0...
  • Page 43 Circuit Descriptions QV14.1E LA EN 43 FRC Master N314 FRC Slave N314 19570_167_140721.eps 14-07-22 Figure 7-9 Bolt-on copper 6 layout back to 2014-Oct-22 div. table...
  • Page 44 QV14.1E LA Power Supply fuse with one with the correct specifications! This part is available in the regular market. Consult the Philips Service web portal for the order codes of the 7.3.1 Power Supply Unit boards. All power supplies are a black box for Service. When any of 7.3.2...
  • Page 45 Circuit Descriptions QV14.1E LA EN 45 +12V +3V3 +12V BE-ENABLE ENABLE+1V5+2V5 U028B U010U Dual DC/DC ENABLE+3V3 DC/DC TPS54494PWP TPS5442 ENABLE+3V3 7DDA +1V0-M +1V5-M +1V2 +3V3 +1V5-BE +1v5-BE U026B +2V5-M RT9187GS U021B Novatec Novatek U029B interface DDR’s +2V5-BE DDR FPGA FPGA LX75...
  • Page 46 Circuit Descriptions EN 46 QV14.1E LA +12V +3V3 +3V3 U010U DC/DC ENABLE+1V2-FPGA TPS5442 7DDA +1V2 +3V3 +3V3 +1V5-BE U021B DDR FPGA FPGA LX25 FPGA LX75 +2V5-BE 1&2 RT9187G (HDMI2,0) Boa (PQ, NR, LC) Anaconda+ +3V3 19570_174_140723.eps 14-07-23 Figure 7-14 Power Architecture UHD50 - Back end 7.3.3...
  • Page 47 Circuit Descriptions QV14.1E LA EN 47 7.3.4 Power Layout 19570_178_140728.eps 14-07-28 Figure 7-18 Power Top View 19570_178_140728.eps 14-07-28 Figure 7-19 Power Bottom View back to 2014-Oct-22 div. table...
  • Page 48 IC Data Sheets EN 48 QV14.1E LA 8. IC Data Sheets This chapter shows the internal block diagrams and pin electrical diagrams (with the exception of “memory” and “logic” configurations of ICs that are drawn as “black boxes” in the ICs).
  • Page 49 Block Diagrams QV14.1E LA EN 49 9. Block Diagrams Wiring Diagram 81x9 and 82x9 series 48" Wiring Diagram 48” 8xx9 series 48PFS8109 8PS316 8TC60 8TC61 8CA26 19570_001_140507.eps 14-05-15 back to 2014-Oct-22 div.table...
  • Page 50 Block Diagrams QV14.1E LA EN 50 Wiring Diagram 81x9 and 82x9 series 48" Backcover Wiring diagram 48" 8xx9 series (inside View Backcover) 48PFS8109 8AL01 8CA05 19570_002_140507.eps 14-05-07 back to 2014-Oct-22 div.table...
  • Page 51 Block Diagrams QV14.1E LA EN 51 Wiring Diagram 79xx series 49" Wiring diagram 49" 79xx series 8TC51 8CA26 PHILIPS 49PUS7909 19572_005_140907.eps 14-09-08 back to 2014-Oct-22 div.table...
  • Page 52 Block Diagrams QV14.1E LA EN 52 Wiring Diagram 79xx series 49" Backcover Wiring diagram 49" 79xx series - Backcover (inside view) 8AL02 8AL01 49PUS7909 Backcover 19572_006_140907.eps 14-09-08 back to 2014-Oct-22 div.table...
  • Page 53 Block Diagrams QV14.1E LA EN 53 Wiring Diagram 79xx series 55" Wiring diagram 55" 79xx series 8AL02 8PS90 8TC51 8AL01 8CA31 8CA26 PHILIPS 55PUS7909 19572_007_140907.eps 14-09-08 back to 2014-Oct-22 div.table...
  • Page 54 Block Diagrams QV14.1E LA EN 54 Wiring Diagram 79xx series 55" Backcover Wiring diagram 55" 79xx series - Backcover (X-ray view = view from outside!) 8AL01 55PUS7909 Backcover 19572_006_140907.eps 14-09-08 back to 2014-Oct-22 div.table...
  • Page 55 Block Diagrams QV14.1E LA EN 55 Wiring Diagram 81x9 and 82x9 series 55" Wiring diagram 55" 8xx9 series 55PFS8109 8PS316 8TC60 8TC61 8CA26 19570_003_140508.eps 14-05-15 back to 2014-Oct-22 div.table...
  • Page 56 Block Diagrams QV14.1E LA EN 56 Wiring Diagram 81x9 and 82x9 series 55" Backcover Wiring diagram 55" 8xx9 series (inside View Backcover) 55PFS8109 8AL01 19570_004_140508.eps 14-05-15 back to 2014-Oct-22 div.table...
  • Page 57 Block Diagrams QV14.1E LA EN 57 Wiring Diagram 88x9 series 55" (including Backcover in X-ray view) Wiring diagram 55" 88x9 series 1171 - Ambilight Module 1172 - Ambilight Module 1171 - Ambilight Module 8AL03 8AL04 8AL05 8AL02 8PS316 8FR91 8PS90...
  • Page 58 Block Diagrams QV14.1E LA EN 58 9.10 Wiring Diagram 89x9 series 55" curved Wiring diagram 55" 89xx curved series 1004 - TFT screen 1111 - SSB 8FR51 5210 - Speaker 1050 - PSU 8FR54 8FR56 Mandatory Attention: Live parts! position...
  • Page 59 Block Diagrams QV14.1E LA EN 59 9.11 Wiring Diagram 89x9 series 55" curved Backcover Wiring diagram 55" 89xx curved series 1170 - Am7ilight Module 7 LED 1171 - Am7ilight Module 8 LED 1170 - Am7ilight Module 7 LED 8AL03 8AL04...
  • Page 60 Block Diagrams QV14.1E LA EN 60 9.12 Wiring Diagram 91x9 series 55" - 65" Wiring diagram 55" - 65" 91x9 series 1004 - TFT screen 0661 - Deco back 65" only 8PS319 8PS316 1111 - SSB 8FR51 8FR54 8FR56 1113 - Ultra HD Module...
  • Page 61 Block Diagrams QV14.1E LA EN 61 9.13 Wiring Diagram 91x9 series 55" - 65" Backcover (in X-ray view) Wiring diagram 55" - 65" 91x9 series - Backcover (X-ray view = view from outside!) 0661 - Deco Back 1170 - AmbiLight module Top...
  • Page 62 Block Diagrams QV14.1E LA EN 62 9.14 Wiring Diagram 98x9 series 65" Wiring diagram 65" 98x9 series 1004 - TFT screen 8FR51 8FR54 1113 - Ultra HD Module 8FR56 1050 - PSU 1111 - SSB 8TC60 8TC61 8CA26 5211 - Speaker...
  • Page 63 Block Diagrams QV14.1E LA EN 63 9.15 Wiring Diagram 98x9 series 65" Backcover (inside view) Wiring diagram 65" 98x9 series (view inside backcover) 1172 - Ambilight Module 9 LED 1171 - Ambilight Module 7 LED 1172 - Ambilight Module 9 LED...
  • Page 64 Block Diagrams QV14.1E LA EN 64 9.16 Architecture - FHD Marvell BG2-Q Architecture FHD100 11n 2x2 2x DDR3 2x DDR3 DDR3 2x DDR3 Wifi 1600 1600 1600 1600 eMMC FPGA USB2.0 LX75 USB2.0 =Anaconda 2 Wifi Noise USB3.0 3D-LR 3D-LR...
  • Page 65 Block Diagrams QV14.1E LA EN 65 9.17 Connections - FHD C&C Architecture 400kHz HDMI EDID0 2014 Marvell BG2-Q 0xA0 SYSTEM-RESETn eMMC-RESETn 400kHz HDMI EDID1 0xA0 DVBS2-Tuner Analog Demod Serial Flash 400kHz 0x84 128Mbit=16MB HDMI EDID2 0xA0 400kHz Hybrid-Tuner I²C-TUNER DVB-T/C/S/T2/C2/S2...
  • Page 66 Block Diagrams QV14.1E LA EN 66 9.18 Architecture - UHD Marvell BG2-Q Architecture UHD100 11n 2x2 2x DDR3 2x DDR3 DDR3 2x DDR3 2x DDR3 BoltOn Wifi 1600 1600 1600 1600 1600 eMMC FPGA FPGA USB2.0 LX75 USB2.0 =Anaconda 2 Wifi...
  • Page 67 Block Diagrams QV14.1E LA EN 67 9.19 Connections - UHD Rogue C&C Architecture 400kHz HDMI EDID0 2014 Marvell BG2-Q 0xA0 SYSTEM-RESETn eMMC-RESETn 400kHz UHD Rogue .1 HDMI EDID1 0xA0 DVBS2-Tuner Analog Demod Serial Flash 400kHz 0xC6 0x84 128Mbit=16MB HDMI EDID2...
  • Page 68 Block Diagrams QV14.1E LA EN 68 9.20 Architecture - UHD50 Marvell BG2-Q Architecture UHD50 17511n 2x2 2x DDR3 2x DDR3 DDR3 2x DDR3 Wifi 1600 1600 1600 1600 eMMC USB2.0 FPGA LX75 USB2.0 =Anaconda+ 2 Wifi AL-SPI FRC Master USB3.0...
  • Page 69 Block Diagrams QV14.1E LA EN 69 9.21 Connections - UHD60 Rogue C&C Architecture 400kHz 400kHz HDMI EDID0 HDMI EDID0 2014 Marvell BG2-Q 0xA0 0xA0 SYSTEM-RESETn eMMC-RESETn 400kHz 400kHz UHD60 Rogue .1 HDMI EDID1 HDMI EDID1 0xA0 0xA0 DVBS2-Tuner Analog Demod...
  • Page 70 Block Diagrams QV14.1E LA EN 70 9.22 Power supply lines - Connector and Front end Connector from PSU X090 +3V5-STANDBY +12V-AL SIP32429DN-GE4 or AOZ1360DIL U022U U003U U001U U004U +3V5-STANDBY WOLAN-ENABLE LDO + Over RT9193- switch current (2 sides AL) 33GB...
  • Page 71 Circuit Diagrams and PWB Layouts QV14.1E LA EN 71 10. Circuit Diagrams and PWB Layouts 10.1 715RLPCB0000000055 SSB 10-1-1 B, DVB DUAL TUNER DVB DUAL TUNER C017F 10pF L007F +3V3-DVB SDA-TUNER R002F 10pF C018F L008F SCL-TUNER R003F L011F IF-N-DVBT2 C097F...
  • Page 72 Circuit Diagrams and PWB Layouts QV14.1E LA EN 72 10-1-2 B, ANALOG DEMOD ANALOG DEMOD L021F I003F +3V3-DVB VDD-3V3 VDD-3V3 VDDA-1V2-1FBO VDD-3V3 VDDA-1V2-1FBO VDDD-1V2-1FB VDDA-1V2-1FBO L026F I002F VDDA-1V2-1FBO +1V2-DVB I008F I013F I014F I016F I009F I012F L022F I001F +1V2-DVB VDDD-1V2-1FB XTAL...
  • Page 73 Circuit Diagrams and PWB Layouts QV14.1E LA EN 73 10-1-3 B, CHANNEL DECODER 1 CHANNEL DECODER 1 L001F I029F +1V2-DVB L002F I027F +3V3-DEMOD1 +3V3-ANA1 +3V3-DEMOD1 +3V3-DVB X004F U002F C022F 100nF L003F I028F +3V3-DVB +3V3-ANA1 XTAL_I|CLK_IN R005F F008F IF-AGC-DVBT2 MP_A MP_B...
  • Page 74 Circuit Diagrams and PWB Layouts QV14.1E LA EN 74 10-1-4 B, SINGLE/ DUAL LNB-SUPPLY SINGLE/ DUAL LNB-SUPPLY +12V I030F +V-LNB U001F LNBH26LSPQR B230LA-M3 D004F F005F I032F I031F VUP-A VOUT-A +V-LNB F22-DISEQC-TX1 LX-A DSQIN-A I035F R012F ISEL F006F +V-LNB-DT I036F VOUT-B...
  • Page 75 Circuit Diagrams and PWB Layouts QV14.1E LA EN 75 10-1-5 B, CHANNEL DECODER 2 CHANNEL DECODER 2 L004F I038F +1V2-DVB +3V3-DEMOD2 +3V3-ANA2 L005F I039F +3V3-DVB +3V3-DEMOD2 X005F U003F C047F 100nF XTAL_I|CLK_IN R010F F009F DT-IF-AGC-DVBT2 MP_A L009F I040F MP_B +3V3-DVB +3V3-ANA2...
  • Page 76 Circuit Diagrams and PWB Layouts QV14.1E LA EN 76 10-1-6 B, POWER CONNECTOR POWER CONNECTOR +5V-FE +3V3-MRV +3V5-STANDBY BE-ENABLE S001U S001U F001U +12V-AL I045U ENABLE+1V5-BE S001U S001U U025U BC847BS(COL) U003U I044U F002U RT9193 F004U F003U +3V3-STANDBY VOUT X090 X090 GND-AL...
  • Page 77 Circuit Diagrams and PWB Layouts QV14.1E LA EN 77 10-1-7 B, WIFI SUPPLY WIFI SUPPLY S002U S002U S002U F027U S002U +3V3-LAN U001U RT9187GSP +3V5-STANDBY VIN1 VOUT1 VIN2 VOUT2 I002U BP|ADJ GND_HS R103U +3V3 F054U WOLAN-ENABLE +3V5-STANDBY R002U I005U C017U 47nF...
  • Page 78 Circuit Diagrams and PWB Layouts QV14.1E LA EN 78 10-1-8 B, AMBILIGHT PROTECTION AMBILIGHT PROTECTION X011U U004U 2-SIDE AMBILIGHT 3- or 4- SIDE AMBILIGHT SIP32429DN-GE4 F032U AMBI-POWER +12V-AL VIN1 VOUT1 VIN2 VOUT2 common : I009U R050U, C006U, C016U and C018U...
  • Page 79 Circuit Diagrams and PWB Layouts QV14.1E LA EN 79 10-1-9 B, FPGA SUPPLY FPGA SUPPLY L020U L019U L004U L011U +12V +12V R047U R120U L010U F005U R046U C042U C041U R047U F037U +1V2 +1V2 L003U R121U C169U C168U R120U +1V5-BE 1.5uH +1V5-BE I020U 1.5uH...
  • Page 80 Circuit Diagrams and PWB Layouts QV14.1E LA EN 80 10-1-10 B, DDR SUPPLY DDR SUPPLY U011U L002U F006U I080U TPS54319RTE +V-PMIC +1V5-MRV 1.5uH VIN_1 PH_1 VIN_2 PH_2 VIN_3 PH_3 I081U BOOT I082U I085U DDR-OK VSENSE PWRGD COMP DDR-ENABLE I086U I083U...
  • Page 81 Circuit Diagrams and PWB Layouts QV14.1E LA EN 81 10-1-11 B, MARVELL SUPPLY MARVELL SUPPLY D001U I058U +V-PMIC +3V5-STANDBY B230LA-M3 D002U +5V-FE B230LA-M3 F044U +VCPU VCC-PMIC VCC-PMIC I064U R022U +V-PMIC VCC-PMIC U007U I065U L013U 88PG867RB0 1.2uH SW1_1 SVIN SW1_2 I066U...
  • Page 82 Circuit Diagrams and PWB Layouts QV14.1E LA EN 82 10-1-12 B, 3V3 PLATFORM SUPPLY 3V3 PLATFORM SUPPLY L021U L005U I093U +12V L012U +3V3 3.6uH U018U RT7297CHZSP I089U C054U 100nF BOOT I088U ENABLE+3V3 I087U F045U C062U 22nF R082U +3V3 GND-3V3 I092U...
  • Page 83 Circuit Diagrams and PWB Layouts QV14.1E LA EN 83 10-1-13 B, 5V PLATFORM SUPPLY 5V PLATFORM SUPPLY L007U R095U I069U L001U F034U L017U C109U C108U R095U +12V +5V-FE 4.7uH I012U R095U R095U I010U C025U 100nF U017U I014U RT8288AZSP I011U C027U...
  • Page 84 Circuit Diagrams and PWB Layouts QV14.1E LA EN 84 10-1-14 B, AUDIO-VIDEO I/O AUDIO-VIDEO I/O CLOSE TO SCART CLOSE TO CYPRESS F004C R160C I046C C073C 2.2uF AV-SCART-RIN 6.3V F033C R161C I047C C074C 2.2uF AV-SCART-LIN 6.3V F038C C016C 100nF AV-SCART-B X260...
  • Page 85 Circuit Diagrams and PWB Layouts QV14.1E LA EN 85 10-1-15 B, HDMI HDMI X283 RX0-2+ RX0-2- RX0-1+ D001C AIN-5V RX0-1- D002C D003C RX0-0+ AOZ8808DI-05 AOZ8808DI-05 AOZ8808DI-05 RX0-0- RX0-2+ RX0-2+ RX0-C+ RX0-2- RX0-2- RX0-0+ RX0-0+ SCL-0 SCL-0 RX0-0- RX0-0- SDA-0 SDA-0...
  • Page 86 Circuit Diagrams and PWB Layouts QV14.1E LA EN 86 10-1-16 B, ARC +3V3 U009C +3V3 U009C L045C ARC0-HDMI F182C ARC0 I022C I049C HDMI-ARC-BUF L042C ARC1-HDMI F183C ARC1 L043C ARC2-HDMI F184C ARC2 +5V-FE +5V-ARC I024C L044C L046C I050C HDMI-ARC ARC3-HDMI F185C...
  • Page 87 Circuit Diagrams and PWB Layouts QV14.1E LA EN 87 10-1-17 B, CYPRESS SUPPLY CYPRESS SUPPLY U017C VMID VREFN VREFP 88DE6010 I038C L051C VREFP +3V3-MRV I007C I029C I032C VREFP RXVDD3P3_1 C080C 100nF RXVDD3P3_2 RXVDD3P3_3 RXVDD3P3_4 C106C 22uF VMID VMID RXVDD3P3_5 6.3V...
  • Page 88 Circuit Diagrams and PWB Layouts QV14.1E LA EN 88 10-1-18 B, CIMAX+ CIMAX+ +3V3-CIMAX U018C I057C CIMAX-SPI-INT I071C S038C CIMAX+ CONTROL I056C RESET S035C SYSTEM-RESETn U019C SPI_DIN SPI_DOUT U018C SPI_CS U018C CIMAX+ SPI_CLK CIMAX+ CIMAX-SPI-MOSI SPI_M_CS1 GND14 TS-PI-CLK TS_TUNER TS-OUT1-CLK...
  • Page 89 Circuit Diagrams and PWB Layouts QV14.1E LA EN 89 10-1-19 B, PCMCIA SLOTS PCMCIA SLOTS X297 X295 F040C F061C CA-AB-D03 F041C CA-AB-D03 F062C CA-AB-D04 F042C CA-AB-D04 F063C CA-AB-D05 F043C CA-AB-D05 F064C CA-AB-D06 F044C CA-AB-D06 F065C CA-AB-D07 F045C CA-AB-D07 F066C CA-B-CE1n...
  • Page 90 Circuit Diagrams and PWB Layouts QV14.1E LA EN 90 10-1-20 B, ANALOG IO ANALOG IO CLOSE TO SCART CLOSE TO CYPRESS X266 F175C WHITE I052C F173C R162C C075C 2.2uF AV-YPBPR-LIN 6.3V F174C I053C R163C C076C 2.2uF AV-YPBPR-RIN 6.3V X268 I054C...
  • Page 91 Circuit Diagrams and PWB Layouts QV14.1E LA EN 91 10-1-21 B, CYPRESS VIDEO & AUDIO CYPRESS VIDEO & AUDIO U017C 88DE6010 TTL - I2S DVIDEO-D0 R121C TTL_D[0] DVIDEO-D1 R122C TTL_D[1] DVIDEO-D2 R123C TTL_D[2] DB001C DVIDEO-D3 R124C R137C TTL_D[3] I2SOUT_MCLK DVIDEO-D4...
  • Page 92 Circuit Diagrams and PWB Layouts QV14.1E LA EN 92 10-1-22 B, CYPRESS HDMI & CTRL CYPRESS HDMI & CTRL XTAL: NX3225HA EX300A - CH00142 20MHZ 8pF C092C 8.2pF U017C 88DE6010 MISC F196C R179C 4.7K XTAL1 JTCK +3V3-MRV C093C 8.2pF R185C...
  • Page 93 Circuit Diagrams and PWB Layouts QV14.1E LA EN 93 10-1-23 B, DEBUG DEBUG X305C HDMI-RX2-2+ HDMI-RX2-2- HDMI-RX2-1+ HDMI-RX2-1- HDMI-RX2-0+ HDMI-RX2-0- HDMI IN (TO CYPRESS) HDMI-RX2-C+ HDMI-RX2-C- HDMI-CYP-SCL HDMI-CYP-SDA HDMI-CYP-IN-5V S026C R016C R003C HDMI-CYP-IN-HPD X304C HDMI-SOC-RX0-D2+ HDMI-SOC-RX0-D2- HDMI-SOC-RX0-D1+ HDMI-SOC-RX0-D1- HDMI-SOC-RX0-D0+ HDMI-SOC-RX0-D0-...
  • Page 94 Circuit Diagrams and PWB Layouts QV14.1E LA EN 94 10-1-24 B, AUDIO AUDIO PVDD +12V-AUDIO PVDD S001D S004D S020D I007D S021D AUDIO-HPLN 10uF C043D R039D I005D R025D 12V PVDD Only +3V3 I029D I019D L001D AUDIO-HPLP LSPK+ 10uF C035D R023D 10uH...
  • Page 95 Circuit Diagrams and PWB Layouts QV14.1E LA EN 95 10-1-25 B, LVDS OUTPUT LVDS OUTPUT F204B F201B F200B F199B F198B F197B F196B F194B F195B F193B F192B F081B F086B F088B F089B F087B F013B F014B F090B F015B F102B F103B F091B F104B F105B...
  • Page 96 Circuit Diagrams and PWB Layouts QV14.1E LA EN 96 10-1-26 B, MASTER - I/O , FLASH MASTER - I/O , FLASH +3V3 U010B NX3L4684TK SOC-AMBI-SPI-CLK SOC-AMBI-SPI-MOSI X325B SCL-BE R130B SCL-DISP SCL-DISP F146B AMBI-SPI-SWITCH I076B AMBI-SPI-SWITCH F145B SDA-BE R131B SDA-DISP SDA-DISP...
  • Page 97 Circuit Diagrams and PWB Layouts QV14.1E LA EN 97 10-1-27 B, VDISP - QFHD VDISP - QFHD S018B S018B S018B S018B S017B S017B S017B S017B +12V F073B I005B X016B +3V3 F072B +VDISP C296B 22nF PUMD12 U020B I001B I002B C295B 100nF...
  • Page 98 Circuit Diagrams and PWB Layouts QV14.1E LA EN 98 10-1-28 B, FPGA - POWER FPGA - POWER L002B I020B +2V5-BE +VAUX U021B RT9187GSP X004B +1V2 +VCCINT VIN1 VOUT1 F153B F152B +3V3 VIN2 VOUT2 +2V5-BE BP|ADJ L017B I021B GND_HS +3V3 +VCCO0...
  • Page 99 Circuit Diagrams and PWB Layouts QV14.1E LA EN 99 10-1-29 B, FPGA - IO BANKS - LVDS & GPIO FPGA - IO BANKS 0 and 2 - LVDS & GPIO I050B U023B XC6SLX75 BANK 0 HSWAPEN PQ-TX2-0P IO_L1P_HSWAPEN_0 IO_L38P_0 PQ-RESETN...
  • Page 100 Circuit Diagrams and PWB Layouts QV14.1E LA EN 100 10-1-30 B, FPGA - IO BANKS - DDR FPGA - IO BANKS 1 and 3 - DDR U023B XC6SLX75 I080B BANK 1 R057B BEDDRA-RZQ BEDDRA-RZQ BEDDRA-MA5 IO_L1P_A25_1 IO_L40P_GCLK11_M1A5_1 BEDDRA-MA6 +BEDDRA-VREF IO_L1N_A24_VREF_1...
  • Page 101 Circuit Diagrams and PWB Layouts QV14.1E LA EN 101 10-1-31 B, FPGA - CONFIGURATION FPGA - CONFIGURATION D072B U023B R124B +3V3 POWER X344B GREEN +VAUX VCCAUX_1 GND_1 CCLK VCCAUX_2 GND_2 CSO-B VCCAUX_3 GND_3 MOSI DONE U027B VCCAUX_4 GND_4 PDTC114EU MISO...
  • Page 102 Circuit Diagrams and PWB Layouts QV14.1E LA EN 102 10-1-32 B, FPGA - DDR FPGA - DDR X005B X006B +1V5-BE +1V5-BEDDRA +1V5-BE +1V5-BEDDRB +1V5-BEDDRA +1V5-BEDDRB U030B U031B H5TQ1G63BFR-H9C H5TQ1G63BFR-H9C D012B VDDQ VDDQ BEDDRA-DQU0 BEDDRA-MA0 BEDDRB-DQU5 BEDDRB-MA0 BEDDRA-DQU1 BEDDRA-MA1 BEDDRB-DQU3 BEDDRB-MA1...
  • Page 103 Circuit Diagrams and PWB Layouts QV14.1E LA EN 103 10-1-33 B, FPGA - LVDS OUT DEBUG FPGA - LVDS OUT DEBUG X331B TYPE PQ-TX2-0N PQ-TX2-0P PQ-TX2-1N PQ-TX2-1P PQ-TX2-2N PQ-TX2-2P PQ-TX2-CLKN PQ-TX2-CLKP PQ-TX2-3N PQ-TX2-3P PQ-TX2-4N PQ-TX2-4P PQ-TX3-0N PQ-TX3-0P PQ-TX3-1N PQ-TX3-1P PQ-TX3-2N...
  • Page 104 Circuit Diagrams and PWB Layouts QV14.1E LA EN 104 10-1-34 B, MASTER - LVDS RX MASTER - LVDS RX U001B NT72314 LVDS_RX AK28 CRE0_N ARE0_N AJ28 CRE0_P ARE0_P AH29 CRE1_N ARE1_N AJ29 CRE1_P ARE1_P AH30 CRE2_N ARE2_N AJ30 CRE2_P ARE2_P...
  • Page 105 Circuit Diagrams and PWB Layouts QV14.1E LA EN 105 10-1-35 B, MASTER - VX1 OUTPUT MASTER - VX1 OUTPUT U001B +3V3-NVT TYPE SYS_LVDS_VX1 VB1-TX0N C029B 100nF NTTX-AE0N TX0N ATE0_N VB1-TX0P C030B 100nF NTTX-AE0P TX0P ATE0_P VB1-TX1N C031B 100nF NTTX-AE1N TX1N...
  • Page 106 Circuit Diagrams and PWB Layouts QV14.1E LA EN 106 10-1-36 B, MASTER - I/O , FLASH MASTER - I/O , FLASH U001B TYPE BL-I-CTRL GPIO AF22 GPIOC_15|PWM_OUT GPIOA_0|I2C_SLAVE_SCL|MULTI_LVSYNC_OUT|MULTI_IVSYNC_IN NT-CTRL-DISP1 GPIOC_14|PWM_IN GPIOA_1|I2C_SLAVE_SDA|MULTI_PVSYNC_OUT|MULTI_PVSYNC_IN MBS8 GPIOC_13|BS8 GPIOA_2|BS0 MBS7 MBS1 GPIOC_12|BS7 GPIOA_3|BS1 MBS6 MBS2...
  • Page 107 Circuit Diagrams and PWB Layouts QV14.1E LA EN 107 10-1-37 B, MASTER - DDR MASTER - DDR DDR1V5-M DDR1V5-M U001B U004B U005B DDR3_32BIT DDRA-DQL0 H5TQ1G63BFR-H9C H5TQ1G63BFR-H9C DDR1_DQL0 DDRA-DQL1 DDR1_DQL1 DDRA-DQL2 DDR1_DQL2 VDDQ VDDQ DDRA-DQL3 DDRA-DQU0 DDR-MA0 DDRB-DQU0 DDR-MA0 D046B D061B...
  • Page 108 Circuit Diagrams and PWB Layouts QV14.1E LA EN 108 10-1-38 B, MASTER - POWER MASTER - POWER MMU-1.5V-M TX-2.5V-M VX-2.5V-M +1V0-M U001B F034B +1V0-M TYPE I/O-3.3V-M CORE_1.0V_1 CORE_1.0V_2 CORE_1.0V_3 CORE_1.0V_4 CORE_1.0V_5 IO_3.3V_1 CORE_1.0V_6 IO_3.3V_2 CORE_1.0V_7 IO_3.3V_4 CORE_1.0V_8 IO_3.3V_5 POWER CORE_1.0V_9 IO_3.3V_6...
  • Page 109 Circuit Diagrams and PWB Layouts QV14.1E LA EN 109 10-1-39 B, MASTER - GND MASTER - GND U001B TYPE GND_120 GND_121 GND_122 GND_123 GND_35 GND_124 GND_34 GND_125 GND_33 GND_126 GND_32 GND_127 GND_31 GND_128 GND_30 GND_129 GND_29 GND_130 GND_28 GND_131 GND_27...
  • Page 110 Circuit Diagrams and PWB Layouts QV14.1E LA EN 110 10-1-40 B, NOVATEK SUPPLY NOVATEK SUPPLY L022B L010B I097B +12V U028B TPS54494PWP VIN1 VIN2 L027B L028B F021B 100nF C293B I090B C294B 100nF +1V0-M VBST1 VBST2 +1V5-M 1.5uH 1.5uH I075B R196B PGND1...
  • Page 111 Circuit Diagrams and PWB Layouts QV14.1E LA EN 111 10-1-41 B, SCALER POWER SCALER POWER F004B F005B F007B 2014-02-21 BG2-QTV FHD 2K14 715RLPCB000000005 19570_060_140523.eps 14-05-23 back to 2014-Oct-22 div.table...
  • Page 112 Circuit Diagrams and PWB Layouts QV14.1E LA EN 112 10-1-42 B, LVDS OUTPUT LVDS OUTPUT X050 TYPE +3V3-NVT F203B X051 TYPE F202B NT-CTRL-DISP1 R319B NTTX-BO0N F168B NT-CTRL-DISP3 R135B I059B NTTX-BO0P F169B SDA-DISP R001B I056B NTTX-BO1N F170B SCL-DISP R044B I055B NTTX-BO1P...
  • Page 113 Circuit Diagrams and PWB Layouts QV14.1E LA EN 113 10-1-43 B, RF4CE RF4CE +3V3-STANDBY I007E X004E I010E U003E +3V3-STANDBY CC2533F96RHA +3V3-STANDBY X003E U004E U001E LFB18 FEED RT9818C-29GVL XOSC_Q1 I004E BAL1 I006E L002E XOSC_Q2 I005E UNBAL 4.7nH F004E RF_P BAL2 RESET|RESET...
  • Page 114 Circuit Diagrams and PWB Layouts QV14.1E LA EN 114 10-1-44 B, MARVELL - AmbiLight + DIAGNOSTIC SERIAL FLASH + EMMC MARVELL - AMBILIGHT + DIAGNOSTIC SERIAL FLASH + EMMC +3V3-MRV U001T 88DE3100 SOC_SPI1 BC26 R198T SOC-SF-SPI-CSn SPI1_SS0N BG26 D006T SOC-AMBI-SPI-CSn...
  • Page 115 Circuit Diagrams and PWB Layouts QV14.1E LA EN 115 10-1-45 B, ETHERNET ETHERNET +3V3-STANDBY +1V8-STANDBY C036T 10nF X296 U001T I009T C022T 100nF 88DE3100 ETHERNET-TXP ETHERNET-TXP F053T ETHERNET-TXN ETHERNET-TXN F052T SM_FE ETHERNET-RXP ETHERNET-RXP F051T FE_TXP ETHERNET-RXN ETHERNET-RXN F050T FE_TXN C037T 10nF...
  • Page 116 Circuit Diagrams and PWB Layouts QV14.1E LA EN 116 10-1-46 B, MARVELL - USB MARVELL - USB X030 +3V3 +3V3 X002T I019T +12V +3V3-STANDBY I018T TYPE 100nF C005T X029 U008T F009T +5V-USB GL850G-OHGXX USB-SKYPE-DM F010T USB-SKYPE-DP F011T USB-EXT1-DP LED2 L007T...
  • Page 117 Circuit Diagrams and PWB Layouts QV14.1E LA EN 117 10-1-47 B, SENSOR BOARD CONNECTION SENSOR BOARD CONNECTION X026 X026 TYPE F023T X025 X025 F024T R025T SDA-SRF F025T R026T SCL-SRF I013T R064T R064T +5V-FE 750mA 750mA R132T F026T F026T +3V3-STANDBY F027T...
  • Page 118 Circuit Diagrams and PWB Layouts QV14.1E LA EN 118 10-1-48 B, MARVELL - DDR3 MARVELL - DDR3 (U002T and U003T) +1V5-MRV +1V5-MRV +1V5-MRV U001T U001T U001T C323T 100nF U002T SOC_SDRAM0 SOC_SDRAM0 SOC_SDRAM0 SOC_SDRAM0 M0-RESETN M0-DQS0P C324T 100nF M0_RSTN M0_RSTN M0_DQSP[0]...
  • Page 119 Circuit Diagrams and PWB Layouts QV14.1E LA EN 119 10-1-49 B, MARVELL - DDR3 MARVELL - DDR3 (U004T and U005T) +1V5-MRV U001T U001T U004T SOC_SDRAM1 SOC_SDRAM1 M1-RESETN M1-DQS0P +1V5-MRV M1_RSTN M1_DQSP[0] M1-CSN M1-DQS0N VDDQ M1_CSN M1_DQSN[0] M1-CKE M1-DQM0 M1-MA0 M1_CKE...
  • Page 120 Circuit Diagrams and PWB Layouts QV14.1E LA EN 120 10-1-50 B, MARVELL - DVIDEO - CONTROL - LVDS MARVELL - DVIDEO - CONTROL - LVDS +3V3-MRV U001T U001T 88DE3100 88DE3100 SOC_SDIO SOC_AV_IN U001T R268T STRAP BK19 SD0_CLK AN49 R269T I061T...
  • Page 121 Circuit Diagrams and PWB Layouts QV14.1E LA EN 121 10-1-51 B, MARVELL - AUDIO MARVELL - AUDIO STRAP +3V3-MRV U001T 88DE3100 SOC_AUDIO R054T SOC-I2S-LRCK I2S0_LRCK R055T SOC-I2S-BCLK I2S0_BCLK R060T I038T SOC-I2S-SDO I2S0_DO[0] CYPRESS-RESETn I2S0_DO[1] CYPRESS-IRQn I2S0_DO[2] R280T AUDIO-RESETn I2S0_DO[3] I2S-SOC-IN-SD1...
  • Page 122 Circuit Diagrams and PWB Layouts QV14.1E LA EN 122 10-1-52 B, MARVELL - POWER MARVELL - POWER F076T L004T +1V8-STANDBY +VCORE U001T U001T U001T 88DE3100 88DE3100 88DE3100 POWER1 POWER2 AA15 AT21 AA19 VSS_1 VSS_57 VDD_SMCORE VDD_1 +VCORE AA17 AT25 AA21...
  • Page 123 Circuit Diagrams and PWB Layouts QV14.1E LA EN 123 10-1-53 B, MARVELL - TRANSPORTSTREAM MARVELL - TRANSPORTSTREAM +3V3-MRV U001T 88DE3100 SOC_CAM BE36 CAM0_RESET BC34 CAM0_WAIT_N R267T CIMAX-SPI-INT CIMAX-SPI-INT BH38 CAM0_IREQ_N BJ38 CAM0_CD1_N BH39 CAM0_CD2_N BG38 CAM0_VS1_N BK38 CAM0_CE1_N BJ41 CAM_OE_N...
  • Page 124 Circuit Diagrams and PWB Layouts QV14.1E LA EN 124 10-1-54 B, MARVELL - HDMI RX / TX MARVELL - HDMI RX / TX U001T +3V3-STANDBY 88DE3100 HDMI_RX HDMI-SOC-RX0-C+ AG49 HDMIRX_RX0_CLK_P HDMI-SOC-RX0-C- AH49 HDMIRX_RX0_CLK_N HDMI-SOC-RX0-D0+ AF50 HDMIRX_RX0_D0_P U001T HDMI-SOC-RX0-D0- AF49 HDMIRX_RX0_D0_N...
  • Page 125 Circuit Diagrams and PWB Layouts QV14.1E LA EN 125 10-1-55 B, MARVELL - CONTROL MARVELL - CONTROL +3V3-STANDBY STRAP +3V3-STANDBY U001T 88DE3100 SM_MISC SOC-XTAL-IN SM_RCLKI SOC-XTAL-OUT SM_RCLKO I058T R153T F044T MCU-RESET-INn SM_RSTIN R111T I039T MCU-RESET-OUTn BB10 U001T SM_SOC_RSTON 88DE3100 R112T...
  • Page 126 Circuit Diagrams and PWB Layouts QV14.1E LA EN 126 10-1-56 B, I2C MUX I2C MUX +3V3-MRV +3V3-MRV U001T 88DE3100 SOC_MISC R127T SOC-RESET-INn BH15 RSTIN R135T I044T BE25 R136T HDMI-HPD0 BJ16 GPIO_A R137T HDMI-HPD1 BE19 GPIO_B BC19 R138T HDMI-HPD2 GPIO_C R139T...
  • Page 127 Circuit Diagrams and PWB Layouts QV14.1E LA EN 127 10-1-57 B, HDMI MUX SiL9287B HDMI MUX SiL9287B I015H VCC33 MICOM-VCC33 SBVCC33 U003H SII9287B VCC33 HPD0 CBUS_HPD0 +AIN-5VF R0PWR5V R018H I027H AIN-5V +AIN-5VF HDMI0-SDA DSDA0 HDMI0-SCL DSCL0 R4PWR5V R4PWR5V RX0-C- R002H...
  • Page 128 Circuit Diagrams and PWB Layouts QV14.1E LA EN 1 10-1-58 B, 715RLPCB0000000055 - LAYOUT TOP back to 2014- div.table...
  • Page 129 Circuit Diagrams and PWB Layouts QV14.1E LA EN 1 10-1-5 B, 715RLPCB0000000055 - LAYOUT O back to 2014- div.table...
  • Page 130 Circuit Diagrams and PWB Layouts QV14.1E LA EN 130 10.2 715RLPCB0000000303 SSB 10-2-1 B, DVB DUAL TUNER DVB DUAL TUNER C017F 10pF L007F +3V3-DVB SDA-TUNER R002F 10pF C018F L008F SCL-TUNER R003F L011F IF-N-DVBT2 C097F 100nF L012F IF-P-DVBT2 C100F 100nF +3V3-TUNER...
  • Page 131 Circuit Diagrams and PWB Layouts QV14.1E LA EN 131 10-2-2 B, ANALOG DEMOD ANALOG DEMOD L021F I003F VDD-3V3 +3V3-DVB VDD-3V3 VDDA-1V2-1FBO VDD-3V3 VDDA-1V2-1FBO VDDD-1V2-1FB VDDA-1V2-1FBO L026F I002F VDDA-1V2-1FBO +1V2-DVB I014F I008F I013F I016F I009F I012F L022F I001F +1V2-DVB VDDD-1V2-1FB XTAL...
  • Page 132 Circuit Diagrams and PWB Layouts QV14.1E LA EN 132 10-2-3 B, CHANNEL DECODER 1 CHANNEL DECODER 1 L001F I029F +1V2-DVB L002F I027F +3V3-DEMOD1 +3V3-ANA1 +3V3-DVB +3V3-DEMOD1 X004F U002F C022F 100nF L003F I028F +3V3-DVB +3V3-ANA1 XTAL_I|CLK_IN R005F F008F IF-AGC-DVBT2 MP_A MP_B...
  • Page 133 Circuit Diagrams and PWB Layouts QV14.1E LA EN 133 10-2-4 B, SINGLE/ DUAL LNB-SUPPLY SINGLE/ DUAL LNB-SUPPLY +12V I030F +V-LNB U001F LNBH26LSPQR D004F F005F I032F I031F VUP-A VOUT-A +V-LNB B230LA-M3 F22-DISEQC-TX1 LX-A DSQIN-A I035F R012F ISEL F006F +V-LNB-DT I036F VOUT-B...
  • Page 134 Circuit Diagrams and PWB Layouts QV14.1E LA EN 134 10-2-5 B, CHANNEL DECODER 2 CHANNEL DECODER 2 L004F I038F +1V2-DVB +3V3-DEMOD2 +3V3-ANA2 L005F I039F +3V3-DEMOD2 +3V3-DVB X005F U003F C047F 100nF XTAL_I|CLK_IN R010F F009F DT-IF-AGC-DVBT2 MP_A L009F I040F MP_B +3V3-DVB +3V3-ANA2...
  • Page 135 Circuit Diagrams and PWB Layouts QV14.1E LA EN 135 10-2-6 B, POWER CONNECTOR POWER CONNECTOR +5V-FE +3V3-MRV +3V5-STANDBY BE-ENABLE S001U S001U F001U +12V-AL I045U ENABLE+1V5-BE S001U S001U U025U BC847BS(COL) U003U I044U F002U RT9193 F004U F003U VOUT +3V3-STANDBY X090 GND-AL GND-AL...
  • Page 136 Circuit Diagrams and PWB Layouts QV14.1E LA EN 136 10-2-7 B, WIFI SUPPLY WIFI SUPPLY S002U S002U S002U F027U S002U +3V3-LAN U001U RT9187GSP +3V5-STANDBY VIN1 VOUT1 VIN2 VOUT2 I002U BP|ADJ GND_HS R103U +3V3 F054U WOLAN-ENABLE +3V5-STANDBY R002U I005U C017U 47nF...
  • Page 137 Circuit Diagrams and PWB Layouts QV14.1E LA EN 137 10-2-8 B, AMBILIGHT PROTECTION AMBILIGHT PROTECTION X011U U004U 2-SIDE AMBILIGHT 3- or 4- SIDE AMBILIGHT SIP32429DN-GE4 F032U +12V-AL AMBI-POWER VIN1 VOUT1 VIN2 VOUT2 common : I009U R050U, C006U, C016U and C018U...
  • Page 138 Circuit Diagrams and PWB Layouts QV14.1E LA EN 138 10-2-9 B, FPGA SUPPLY FPGA SUPPLY L018U L017U L004U +12V L011U +12V R047U R120U F005U L010U R046U C042U C041U R047U F037U +1V2 +1V2 L003U R121U C169U C168U R120U +1V5-BE 1.5uH +1V5-BE I020U 1.5uH...
  • Page 139 Circuit Diagrams and PWB Layouts QV14.1E LA EN 139 10-2-10 B, DDR SUPPLY DDR SUPPLY U011U TPS54319RTE L002U F006U I080U +V-PMIC +1V5-MRV 1.5uH VIN_1 PH_1 VIN_2 PH_2 VIN_3 PH_3 I081U BOOT I082U DDR-OK I085U VSENSE PWRGD COMP DDR-ENABLE I086U I083U...
  • Page 140 Circuit Diagrams and PWB Layouts QV14.1E LA EN 140 10-2-11 B, MARVELL SUPPLY MARVELL SUPPLY D001U I058U +V-PMIC +3V5-STANDBY B230LA-M3 D002U +5V-FE B230LA-M3 F044U +VCPU VCC-PMIC VCC-PMIC I064U R022U +V-PMIC VCC-PMIC U007U L013U I065U 88PG867RB0 1.2uH SW1_1 SVIN SW1_2 I066U...
  • Page 141 Circuit Diagrams and PWB Layouts QV14.1E LA EN 141 10-2-12 B, 3V3 PLATFORM SUPPLY 3V3 PLATFORM SUPPLY L016U R056U I087U L005U F045U L012U C122U C118U R056U +12V +3V3 3.6uH I029U R056U R056U I028U C062U 22nF U018U RT8288AZSP I093U I089U C054U...
  • Page 142 Circuit Diagrams and PWB Layouts QV14.1E LA EN 142 10-2-13 B, 5V PLATFORM SUPPLY 5V PLATFORM SUPPLY L007U R095U I069U L001U F034U L019U C109U C108U R095U +12V +5V-FE 4.7uH I012U R095U R095U I010U C025U 100nF U017U RT8288AZSP I014U I011U C027U...
  • Page 143 Circuit Diagrams and PWB Layouts QV14.1E LA EN 143 10-2-14 B, AUDIO-VIDEO I/O AUDIO-VIDEO I/O CLOSE TO SCART CLOSE TO CYPRESS F004C R160C I046C C073C 2.2uF AV-SCART-RIN 6.3V F033C R161C I047C AV-SCART-LIN C074C 2.2uF 6.3V F038C C016C 100nF AV-SCART-B X260...
  • Page 144 Circuit Diagrams and PWB Layouts QV14.1E LA EN 144 10-2-15 B, HDMI HDMI X283 UHD-RX0-2+ UHD-RX0-2- UHD-RX0-1+ D001C D002C D003C UHD-RX0-1- AOZ8808DI-05 AOZ8808DI-05 AOZ8808DI-05 UHD-RX0-0+ +5V-EDID0 AIN-5V UHD-RX0-0- UHD-RX0-2+ UHD-RX0-2+ UHD-RX0-0+ UHD-RX0-0+ SCL-0 SCL-0 UHD-RX0-C+ UHD-RX0-2- UHD-RX0-2- UHD-RX0-0- UHD-RX0-0- SDA-0...
  • Page 145 Circuit Diagrams and PWB Layouts QV14.1E LA EN 145 10-2-16 B, ARC +3V3 U009C +3V3 U009C L045C ARC0-HDMI F182C ARC0 I022C I049C HDMI-ARC-BUF L042C ARC1-HDMI F183C ARC1 L043C ARC2-HDMI F184C ARC2 +5V-FE +5V-ARC I024C L044C L046C I050C S002C HDMI-ARC ARC3-HDMI...
  • Page 146 Circuit Diagrams and PWB Layouts QV14.1E LA EN 146 10-2-17 B, CYPRESS SUPPLY CYPRESS SUPPLY U017C 88DE6010 VMID VREFN VREFP I038C L051C I007C I029C I032C VREFP VREFP RXVDD3P3_1 +3V3-MRV C080C 100nF RXVDD3P3_2 RXVDD3P3_3 RXVDD3P3_4 C106C 22uF VMID VMID RXVDD3P3_5 6.3V...
  • Page 147 Circuit Diagrams and PWB Layouts QV14.1E LA EN 147 10-2-18 B, CIMAX+ CIMAX+ +3V3-CIMAX U018C CIMAX+ I057C CIMAX-SPI-INT I071C S038C CONTROL I056C RESET S035C SYSTEM-RESETn U019C SPI_DIN U018C SPI_DOUT U018C CIMAX+ SPI_CS CIMAX+ SPI_CLK CIMAX-SPI-MOSI TS_TUNER SPI_M_CS1 GND14 TS-PI-CLK TS-OUT1-CLK...
  • Page 148 Circuit Diagrams and PWB Layouts QV14.1E LA EN 148 10-2-19 B, PCMCIA SLOTS PCMCIA SLOTS X297 X295 F040C F061C CA-AB-D03 F041C CA-AB-D03 F062C CA-AB-D04 F042C CA-AB-D04 F063C CA-AB-D05 F043C CA-AB-D05 F064C CA-AB-D06 F044C CA-AB-D06 F065C CA-AB-D07 F045C CA-AB-D07 F066C CA-B-CE1n...
  • Page 149 Circuit Diagrams and PWB Layouts QV14.1E LA EN 149 10-2-20 B, ANALOG IO ANALOG IO CLOSE TO SCART CLOSE TO CYPRESS X266 F175C WHITE I052C F173C R162C C075C 2.2uF AV-YPBPR-LIN 6.3V F174C I053C R163C C076C 2.2uF AV-YPBPR-RIN 6.3V X268 I054C...
  • Page 150 Circuit Diagrams and PWB Layouts QV14.1E LA EN 150 10-2-21 B, CYPRESS VIDEO & AUDIO CYPRESS VIDEO & AUDIO CYPRESS VIDEO & AUDIO U017C 88DE6010 U017C 88DE6010 TTL - I2S DVIDEO-D0 R121C TTL_D[0] TTL - I2S DVIDEO-D1 R122C DVIDEO-D0 R121C...
  • Page 151 Circuit Diagrams and PWB Layouts QV14.1E LA EN 151 10-2-22 B, CYPRESS HDMI & CTRL CYPRESS HDMI & CTRL XTAL NX3225HA EX300A-CH00142 20MHZ 8pf C092C 8.2pF U017C 88DE6010 MISC F196C R179C 4.7K +3V3-MRV XTAL1 JTCK C093C 8.2pF R185C F195C XTAL2...
  • Page 152 Circuit Diagrams and PWB Layouts QV14.1E LA EN 152 10-2-23 B, DEBUG DEBUG X304C HDMI-SOC-RX0-D2+ HDMI-SOC-RX0-D2- HDMI-SOC-RX0-D1+ HDMI-SOC-RX0-D1- HDMI-SOC-RX0-D0+ HDMI-SOC-RX0-D0- HDMI IN (TO SOC) HDMI-SOC-RX0-C+ HDMI-SOC-RX0-C- HDMI-SOC-RX0-SCL HDMI-SOC-RX0-SDA S025C HDMI-SOC-RX0-5V R237C R002C HDMI-SOC-IN-HPD 2014-02-21 MV UHD HDMI20-420 715RLPCB000000030 19570_108_140603.eps 14-06-03...
  • Page 153 Circuit Diagrams and PWB Layouts QV14.1E LA EN 153 10-2-24 B, AUDIO AUDIO PVDD +12V-AUDIO PVDD S001D S004D S020D I007D S021D 12V PVDD Only +3V3 R025D I005D AUDIO-HPLN 10uF C043D R039D L001D LSPK+ I029D I019D AUDIO-HPLP 10uF C035D R023D 10uH...
  • Page 154 Circuit Diagrams and PWB Layouts QV14.1E LA EN 154 10-2-25 B, MASTER - I/O , FLASH MASTER - I/O , FLASH +3V3 U010B NX3L4684TK SOC-AMBI-SPI-CLK SOC-AMBI-SPI-MOSI X325B SCL-BE R130B SCL-DISP SCL-DISP F146B AMBI-SPI-SWITCH I076B AMBI-SPI-SWITCH F145B SDA-BE R131B SDA-DISP SDA-DISP...
  • Page 155 Circuit Diagrams and PWB Layouts QV14.1E LA EN 155 10-2-26 B, FPGA - POWER FPGA - POWER L002B I020B +2V5-BE +VAUX U021B RT9187GSP X004B +1V2 +VCCINT VIN1 VOUT1 F153B F152B +3V3 VIN2 VOUT2 +2V5-BE BP|ADJ L017B I021B GND_HS +3V3 +VCCO0...
  • Page 156 Circuit Diagrams and PWB Layouts QV14.1E LA EN 156 10-2-27 B, FPGA - IO BANKS - LVDS & GPIO FPGA - IO BANKS (0 and 2) - LVDS & GPIO I050B U023B XC6SLX75 BANK 0 HSWAPEN PQ-TX2-0P IO_L1P_HSWAPEN_0 IO_L38P_0 PQ-RESETN...
  • Page 157 Circuit Diagrams and PWB Layouts QV14.1E LA EN 157 10-2-28 B, FPGA - IO BANKS - DDR FPGA - IO BANKS (1 and 3) - DDR U023B XC6SLX75 I080B R057B BEDDRA-RZQ BEDDRA-RZQ BEDDRA-MA5 BANK 1 IO_L1P_A25_1 IO_L40P_GCLK11_M1A5_1 BEDDRA-MA6 +BEDDRA-VREF IO_L1N_A24_VREF_1...
  • Page 158 Circuit Diagrams and PWB Layouts QV14.1E LA EN 158 10-2-29 B, FPGA - CONFIGURATION FPGA - CONFIGURATION D072B U023B R124B +3V3 POWER X344B GREEN +VAUX VCCAUX_1 GND_1 CCLK VCCAUX_2 GND_2 CSO-B VCCAUX_3 GND_3 MOSI DONE U027B VCCAUX_4 GND_4 MISO PDTC114EU...
  • Page 159 Circuit Diagrams and PWB Layouts QV14.1E LA EN 159 10-2-30 B, FPGA - DDR FPGA - DDR X005B X006B +1V5-BE +1V5-BEDDRA +1V5-BE +1V5-BEDDRB +1V5-BEDDRA +1V5-BEDDRB U030B U031B H5TQ1G63BFR-H9C H5TQ1G63BFR-H9C D012B VDDQ VDDQ BEDDRA-DQU0 BEDDRA-MA0 BEDDRB-DQU5 BEDDRB-MA0 BEDDRA-DQU1 BEDDRA-MA1 BEDDRB-DQU3 BEDDRB-MA1...
  • Page 160 Circuit Diagrams and PWB Layouts QV14.1E LA EN 160 10-2-31 B, FPGA - LVDS OUT DEBUG FPGA - LVDS OUT DEBUG X331B TYPE PQ-TX2-0N PQ-TX2-0P PQ-TX2-1N PQ-TX2-1P PQ-TX2-2N PQ-TX2-2P PQ-TX2-CLKN PQ-TX2-CLKP PQ-TX2-3N PQ-TX2-3P PQ-TX2-4N PQ-TX2-4P PQ-TX3-0N PQ-TX3-0P PQ-TX3-1N PQ-TX3-1P PQ-TX3-2N...
  • Page 161 Circuit Diagrams and PWB Layouts QV14.1E LA EN 161 10-2-32 B, FPGA - POWER FPGA - POWER L001B I003B +3V3 +VAUX-FPGA X002B +1V2 +VCCINT-FPGA L005B I004B +3V3 +VCCO0-FPGA L006B +2V5-BE I005B +1V5-BEDDRA-FPGA L003B I006B +3V3 +VCCO2-FPGA L004B +2V5-BE I007B +1V5-BEDDRB-FPGA...
  • Page 162 Circuit Diagrams and PWB Layouts QV14.1E LA EN 162 10-2-33 B, FPGA - IO BANKS - LVDS & GPIO FPGA - IO BANKS (0 and 2) - LVDS & GPIO I008B U005B XC6SLX25-3FGG484I FPGA-HSWAPEN BANK 0 FPGA-TX4-1N IO_L1P_HSWAPEN_0 IO_L38P_0 HDMI-B02...
  • Page 163 Circuit Diagrams and PWB Layouts QV14.1E LA EN 163 10-2-34 B, FPGA - IO BANKS - DDR FPGA - IO BANKS (1 and 3) - DDR U005B XC6SLX25-3FGG484I I012B FPGA-BEDDRA-RZQ FPGA-BEDDRA-RZQ FPGA-BEDDRA-MA5 R069B BANK 1 IO_L1P_A25_1 IO_L40P_GCLK11_M1A5_1 FPGA-BEDDRA-MA6 IO_L1N_A24_VREF_1 IO_L40N_GCLK10_M1A6_1...
  • Page 164 Circuit Diagrams and PWB Layouts QV14.1E LA EN 164 10-2-35 B, FPGA - CONFIGURATION FPGA - CONFIGURATION U005B XC6SLX25-3FGG484I D002B R171B +3V3 POWER X347 GREEN VCCAUX_1 GND_1 FPGA-CCLK +VAUX-FPGA VCCAUX_2 GND_2 FPGA-CSO-B VCCAUX_3 GND_3 FPGA-MOSI FPGA-DONE U001B VCCAUX_4 GND_4 FPGA-MISO...
  • Page 165 Circuit Diagrams and PWB Layouts QV14.1E LA EN 165 10-2-36 B, FPGA - DDR FPGA - DDR X007B X008B +1V5-BE +1V5-BE +1V5-BEDDRA-FPGA +1V5-BEDDRB-FPGA +1V5-BEDDRA-FPGA +1V5-BEDDRB-FPGA U009B U012B H5TQ1G63BFR-H9C H5TQ1G63BFR-H9C D016B VDDQ VDDQ FPGA-BEDDRA-DQU0 FPGA-BEDDRA-MA0 FPGA-BEDDRB-DQU5 FPGA-BEDDRB-MA0 FPGA-BEDDRA-DQU1 FPGA-BEDDRA-MA1 FPGA-BEDDRB-DQU3 FPGA-BEDDRB-MA1...
  • Page 166 Circuit Diagrams and PWB Layouts QV14.1E LA EN 166 10-2-37 B, LVDS OUTPUT LVDS OUTPUT TYPE +3V3 F002B TYPE F001B TYPE FPGA-TX4-0N F079B FPGA-TX4-0P F080B FPGA-TX0-0N FPGA-TX4-1N F009B F082B FPGA-TX0-0P FPGA-TX4-1P F010B F083B FPGA-TX0-1N FPGA-TX4-2N F013B F085B FPGA-TX0-1P FPGA-TX4-2P F034B...
  • Page 167 Circuit Diagrams and PWB Layouts QV14.1E LA EN 167 10-2-38 B, HDMI 2 TTL HDMI 2 TTL U002B ADV7619 TTL OUT R080B HDMI-G07 U002B HDMI-G06 R080B ADV7619 R080B HDMI-G05 HDMI IN HDMIQ1-CK- R080B HDMI-G04 RXA_C_N HDMIQ1-CK+ R081B HDMI-G03 RXA_C_P R108B...
  • Page 168 Circuit Diagrams and PWB Layouts QV14.1E LA EN 168 10-2-39 B, HDMI 2 TTL POWER HDMI 2 TTL POWER L009B I016B +3V3-AD-DVDDIO +3V3 +3V3-AD-TVDD +1V8-AD-DVDD +1V8-AD-PVDD +1V8-AD-CVDD +3V3-AD-DVDDIO L013B I047B +3V3 +3V3-AD-TVDD L011B I017B +1V8 +1V8-AD-DVDD PWR - GND L012B...
  • Page 169 Circuit Diagrams and PWB Layouts QV14.1E LA EN 169 10-2-40 B, RF4CE RF4CE +3V3-STANDBY I007E X004E I010E U003E +3V3-STANDBY CC2533F96RHA +3V3-STANDBY X003E U004E U001E LFB18 FEED RT9818C-29GVL XOSC_Q1 I004E BAL1 I006E L002E XOSC_Q2 I005E UNBAL 4.7nH F004E RF_P BAL2 RESET|RESET...
  • Page 170 Circuit Diagrams and PWB Layouts QV14.1E LA EN 170 10-2-41 B, MARVELL - AL + DIAGNOSTIC SERIAL FLASH + EMMC MARVELL - AMBILIGHT + DIAGNOSTIC SERIAL FLASH + EMMC +3V3-MRV U001T 88DE3100 SOC_SPI1 BC26 R198T SOC-SF-SPI-CSn SPI1_SS0N D006T SOC-AMBI-SPI-CSn BG26...
  • Page 171 Circuit Diagrams and PWB Layouts QV14.1E LA EN 171 10-2-42 B, ETHERNET ETHERNET +3V3-STANDBY +1V8-STANDBY C036T 10nF X296 I009T U001T C022T 100nF 88DE3100 ETHERNET-TXP ETHERNET-TXP F053T ETHERNET-TXN ETHERNET-TXN F052T SM_FE ETHERNET-RXP ETHERNET-RXP F051T FE_TXP ETHERNET-RXN ETHERNET-RXN F050T FE_TXN C037T 10nF...
  • Page 172 Circuit Diagrams and PWB Layouts QV14.1E LA EN 172 10-2-43 B, USB X030 +3V3 +3V3 X002T I019T +12V +3V3-STANDBY I018T TYPE 100nF C005T X029 U008T F009T +5V-USB GL850G-OHGXX USB-SKYPE-DM F010T USB-SKYPE-DP F011T USB-EXT1-DP LED2 L007T F013T DDP_1 USB-EXT1-DM +3V3 VREG...
  • Page 173 Circuit Diagrams and PWB Layouts QV14.1E LA EN 173 10-2-44 B, SENSOR BOARD CONNECTION SENSOR BOARD CONNECTION X020 X025 X026 TYPE F023T F024T R025T SDA-SRF F025T R026T SCL-SRF I013T R064T R064T +5V-FE F026T F026T 750mA 750mA R132T +3V3-STANDBY KEYBOARD KEYBOARD...
  • Page 174 Circuit Diagrams and PWB Layouts QV14.1E LA EN 174 10-2-45 B, MARVELL - DDR3 MARVELL - DDR3 (U002T and U003T) +1V5-MRV +1V5-MRV +1V5-MRV U001T U001T U001T C323T 100nF U002T SOC_SDRAM0 SOC_SDRAM0 SOC_SDRAM0 SOC_SDRAM0 C324T 100nF M0-RESETN M0-DQS0P M0_RSTN M0_RSTN M0_DQSP[0]...
  • Page 175 Circuit Diagrams and PWB Layouts QV14.1E LA EN 175 10-2-46 B, MARVELL - DDR3 MARVELL - DDR3 (U004T and U005T) +1V5-MRV U001T U001T U004T SOC_SDRAM1 SOC_SDRAM1 M1-RESETN M1-DQS0P +1V5-MRV M1_RSTN M1_DQSP[0] M1-CSN M1-DQS0N M1_CSN M1_DQSN[0] VDDQ M1-CKE M1-DQM0 M1-MA0 M1_CKE...
  • Page 176 Circuit Diagrams and PWB Layouts QV14.1E LA EN 176 10-2-47 B, MARVELL MARVELL +3V3-MRV U001T U001T 88DE3100 88DE3100 SOC_AV_IN SOC_SDIO U001T AN49 R268T STRAP BK19 SOG0 SD0_CLK AV43 CTRL-DISP1 88DE3100 BA21 R269T F098T HD1_Y SD0_DAT0 AV45 D016T BC21 HD1_PB SD0_DAT1...
  • Page 177 Circuit Diagrams and PWB Layouts QV14.1E LA EN 177 10-2-48 B, MARVELL - AUDIO MARVELL - AUDIO STRAP +3V3-MRV U001T 88DE3100 SOC_AUDIO R054T SOC-I2S-LRCK I2S0_LRCK R055T SOC-I2S-BCLK I2S0_BCLK R060T I038T SOC-I2S-SDO I2S0_DO[0] CYPRESS-RESETn I2S0_DO[1] CYPRESS-IRQn I2S0_DO[2] R280T AUDIO-RESETn I2S0_DO[3] I2S-SOC-IN-SD1...
  • Page 178 Circuit Diagrams and PWB Layouts QV14.1E LA EN 178 10-2-49 B, MARVELL - POWER MARVELL POWER F076T L004T +1V8-STANDBY +VCORE U001T U001T U001T 88DE3100 88DE3100 88DE3100 POWER1 POWER2 AA15 AT21 AA19 VSS_1 VSS_57 VDD_SMCORE VDD_1 +VCORE AA17 AT25 AA21 VSS_2...
  • Page 179 Circuit Diagrams and PWB Layouts QV14.1E LA EN 179 10-2-50 B, MARVELL - TRANSPORTSTREAM MARVELL - TRANSPORTSTREAM +3V3-MRV U001T 88DE3100 SOC_CAM BE36 CAM0_RESET BC34 CAM0_WAIT_N R267T CIMAX-SPI-INT CIMAX-SPI-INT BH38 CAM0_IREQ_N BJ38 CAM0_CD1_N BH39 CAM0_CD2_N BG38 CAM0_VS1_N BK38 CAM0_CE1_N BJ41 CAM_OE_N...
  • Page 180 Circuit Diagrams and PWB Layouts QV14.1E LA EN 180 10-2-51 B, MARVELL - HDMI RX/TX MARVELL - HDMI RX/TX U001T U001T 88DE3100 88DE3100 HDMI_RX HDMI_TX AG49 HDMI-SOC-RX0-C+ HDMIRX_RX0_CLK_P HDMI_TX_CLK_P HDMI-SOC-RX0-C- AH49 HDMIRX_RX0_CLK_N HDMI_TX_CLK_N HDMI-SOC-RX0-D0+ AF50 HDMIRX_RX0_D0_P HDMI-SOC-RX0-D0- +3V3-STANDBY AF49 HDMIRX_RX0_D0_N...
  • Page 181 Circuit Diagrams and PWB Layouts QV14.1E LA EN 181 10-2-52 B, MARVELL - CONTROL MARVELL - CONTROL +3V3-STANDBY STRAP U001T +3V3-STANDBY 88DE3100 SM_MISC SOC-XTAL-IN SM_RCLKI SOC-XTAL-OUT SM_RCLKO I058T R153T F044T MCU-RESET-INn SM_RSTIN MCU-RESET-OUTn BB10 R111T I039T SM_SOC_RSTON R112T F066T MCU-JTAG-TCK...
  • Page 182 Circuit Diagrams and PWB Layouts QV14.1E LA EN 182 10-2-53 B, I2C MUX I2C MUX +3V3-MRV +3V3-MRV U001T 88DE3100 SOC_MISC R127T SOC-RESET-INn BH15 RSTIN R135T I044T BE25 R136T HDMI-HPD0 BJ16 GPIO_A BE19 R137T HDMI-HDCP22-RESETn GPIO_B BC19 R138T HDMI-HPD2 GPIO_C R139T...
  • Page 183 Circuit Diagrams and PWB Layouts QV14.1E LA EN 183 10-2-54 B, HDMI MUX SiL9573CTUC HDMI MUX SiL9573CTUC R018H I027H AIN-5V U003H SII9573CTUC U003H AUDIO SII9573CTUC I007H ARC0 MCLK ARC1 R019H I028H I004H VIDEO I008H SCK0/DDCK BIN-5V SCK0_IN/GPIO10 SCK1_IN/SCK1_OUT WS0_OUT/DR0 HSYNC...
  • Page 184 Circuit Diagrams and PWB Layouts QV14.1E LA EN 184 10-2-55 B, HDMI MUX SiL9573CTUC HDMI MUX SiL9573CTUC U003H U003H SII9573CTUC SII9573CTUC HDMI TX HDMI RX HDMI-RX3-1- RX0-0+ RX3-0+ T0X0+ R0X0+ R3X0+ HDMI-RX3-1+ RX0-0- RX3-0- T0X0- R0X0- R3X0- HDMI-RX3-0- RX0-1+ RX3-1+...
  • Page 185 Circuit Diagrams and PWB Layouts QV14.1E LA EN 185 10-2-56 B, SiI9679CNUC on HDMI1 for HDCP2.2 SiI9679CNUC on HDMI1 for HDCP2.2 L021H L013H I045H L018H F016H R009H I050H VDD5V-IN +1V0-C AVDD10 +5V-FE VDDH33 +3V3 L014H I046H +1V0-C FVDD10 L017H I049H...
  • Page 186 Circuit Diagrams and PWB Layouts QV14.1E LA EN 1 10-2-57 B, 715RLPCB0000000303 - LAYOUT TOP back to 2014- div.table...
  • Page 187 Circuit Diagrams and PWB Layouts QV14.1E LA EN 1 10-2-58 B, 715RLPCB0000000303 - LAYOUT BOTTOM back to 2014- div.table...
  • Page 188 Circuit Diagrams and PWB Layouts QV14.1E LA EN 188 10.3 715RLPCB0000000401 SSB 10-3-1 2014-04-18 MV_eco_UHD HDMI20 715RLPCB000000040 back to 2014-Oct-22 div.table...
  • Page 189 QV14.1E LA Circuit Diagrams and PWB Layouts HF, 715RLPCB0000000 - LAYOUT back to 2014- div.table...
  • Page 190 QV14.1E LA Circuit Diagrams and PWB Layouts HF, 715RLPCB0000000 - LAYOUT BOTTOM...
  • Page 191 Circuit Diagrams and PWB Layouts QV14.1E LA EN 191 10.4 715RLPCB0000000252 BOLT-ON 10-4-1 HF, MASTER - LVDS RX MASTER - LVDS RX X000 X001 X005 U001B NT72314 LVDS_RX RX-CE0N RX-CE0N RX-AE0N RX-AE0N R006B R083B AK28 CRE0_N ARE0_N RX-CE0P RX-CE0P RX-AE0P...
  • Page 192 Circuit Diagrams and PWB Layouts QV14.1E LA EN 192 10-4-2 HF, MASTER - VX1 OUTPUT MASTER - VX1 OUTPUT X061 U001B NT72314 VB1-TX7P X025B SYS_LVDS_VX1 VB1-TX7N VB1-TX0N NTTX-AE0N X026B C029B 100nF TX0N ATE0_N VB1-TX0P NTTX-AE0P C030B 100nF TX0P ATE0_P X027B...
  • Page 193 Circuit Diagrams and PWB Layouts QV14.1E LA EN 193 10-4-3 HF, MASTER - I/O, FLASH, 2D-DIMMING MASTER - I/O, FLASH, 2D-DIMMING GREEN R002B D007B +3V3-NVT U009B R213B BC847BW(COL) U001B NT72314 BL-I-CTRL Multi-Ivsync F214B AF22 R187B GPIO GPIOC_15|PWM_OUT GPIOA_0|I2C_SLAVE_SCL|MULTI_LVSYNC_OUT|MULTI_IVSYNC_IN NT-CTRL-DISP1 F215B...
  • Page 194 Circuit Diagrams and PWB Layouts QV14.1E LA EN 194 10-4-4 HF, MASTER - DDR MASTER - DDR DDR1V5-M DDR1V5-M U001B NT72314 U004B U005B DDR3_32BIT DDRA-DQL0 H5TQ1G63BFR-H9C H5TQ1G63BFR-H9C DDR1_DQL0 DDRA-DQL1 DDR1_DQL1 DDRA-DQL2 VDDQ VDDQ DDR1_DQL2 DDRA-DQL3 DDRA-DQU0 DDR-MA0 DDRB-DQU0 DDR-MA0 D046B...
  • Page 195 Circuit Diagrams and PWB Layouts QV14.1E LA EN 195 10-4-5 HF, MASTER - POWER MASTER - POWER MMU-1.5V-M TX-2.5V-M VX-2.5V-M +1V0-M F025B +1V0-M U001B NT72314 I/O-3.3V-M CORE_1.0V_1 CORE_1.0V_2 CORE_1.0V_3 CORE_1.0V_4 CORE_1.0V_5 IO_3.3V_1 CORE_1.0V_6 IO_3.3V_2 CORE_1.0V_7 IO_3.3V_4 CORE_1.0V_8 IO_3.3V_5 POWER CORE_1.0V_9 IO_3.3V_6...
  • Page 196 Circuit Diagrams and PWB Layouts QV14.1E LA EN 196 10-4-6 HF, MASTER - GND MASTER - GND U001B NT72314 GND_120 GND_121 GND_122 GND_123 GND_35 GND_124 GND_34 GND_125 GND_33 GND_126 GND_32 GND_127 GND_31 GND_128 GND_30 GND_129 GND_29 GND_130 GND_28 GND_131 GND_27...
  • Page 197 Circuit Diagrams and PWB Layouts QV14.1E LA EN 197 10-4-7 HF, SLAVE - LVDS RX SLAVE - LVDS RX U002B LVDS_RX R349B R136B RX2-CE0N RX2-CE0N AK28 NTTX-BE0N NTTX-BE0N CRE0_N ARE0_N RX2-CE0P RX2-CE0P NTTX-BE0P NTTX-BE0P AJ28 CRE0_P ARE0_P R350B RX2-CE1N RX2-CE1N...
  • Page 198 Circuit Diagrams and PWB Layouts QV14.1E LA EN 198 10-4-8 HF, SLAVE - VX1 OUT SLAVE - VX1 OUT U002B NT72314 X060 SYS_LVDS_VX1 VB1-TX8N C046B 100nF R251B TX0N ATE0_N NT-CTRL-DISP2 VB1-TX8P C047B 100nF TX0P ATE0_P NT-CTRL-DISP1 VB1-TX9N R252B C048B 100nF...
  • Page 199 Circuit Diagrams and PWB Layouts QV14.1E LA EN 199 10-4-9 HF, SLAVE - I/O, FLASH, I2C-MUX SLAVE - I/O, FLASH, I2C-MUX U002B NT72314 GPIO Multi-Ivsync F092B AF22 GPIOC_15|PWM_OUT GPIOA_0|I2C_SLAVE_SCL|MULTI_LVSYNC_OUT|MULTI_IVSYNC_IN F093B Multi-Pvsync GPIOC_14|PWM_IN GPIOA_1|I2C_SLAVE_SDA|MULTI_PVSYNC_OUT|MULTI_PVSYNC_IN SBS8 GPIOC_13|BS8 GPIOA_2|BS0 SBS7 SBS1 GPIOC_12|BS7 GPIOA_3|BS1...
  • Page 200 Circuit Diagrams and PWB Layouts QV14.1E LA EN 200 10-4-10 HF, SLAVE - DDR SLAVE - DDR DDR1V5-S DDR1V5-S U002B NT72314 DDR3_32BIT U006B U007B DDRC-DQL0 D010B DDR1_DQL0 DDRC-DQL1 DDR1_DQL1 DDRC-DQL2 DDR1_DQL2 VDDQ VDDQ DDRC-DQL3 DDRC-DQU0 DDR-SA0 DDRD-DQU0 DDR-SA0 DDR1_DQL3 DDRC-DQL4...
  • Page 201 Circuit Diagrams and PWB Layouts QV14.1E LA EN 201 10-4-11 HF, SLAVE - POWER SLAVE - POWER MMU-1.5V-S TX-2.5V-S VX-2.5V-S +1V0-S F026B +1V0-S U002B NT72314 I/O-3.3V-S CORE_1.0V_1 CORE_1.0V_2 CORE_1.0V_3 CORE_1.0V_4 CORE_1.0V_5 IO_3.3V_1 CORE_1.0V_6 IO_3.3V_2 CORE_1.0V_7 IO_3.3V_4 CORE_1.0V_8 IO_3.3V_5 POWER CORE_1.0V_9 IO_3.3V_6...
  • Page 202 Circuit Diagrams and PWB Layouts QV14.1E LA EN 202 10-4-12 HF, SLAVE - GND SLAVE - GND U002B NT72314 GND_120 GND_121 GND_122 GND_123 GND_35 GND_124 GND_34 GND_125 GND_33 GND_126 GND_32 GND_127 GND_31 GND_128 GND_30 GND_129 GND_29 GND_130 GND_28 GND_131 GND_27...
  • Page 203 Circuit Diagrams and PWB Layouts QV14.1E LA EN 203 10-4-13 HF, VDISP - QFHD VDISP - QFHD S018B 8 S018B 7 S018B 6 X319 +VDISP2 S018B 5 +VDISP2 S017B X318 S017B S017B S017B TYPE F208B U018B SI4835DDY-GE3 +12V X016B F073B...
  • Page 204 Circuit Diagrams and PWB Layouts QV14.1E LA EN 204 10-4-14 HF, LVDS INPUT LVDS INPUT +3V3-NVT X051 AMBI-SPI-SWITCH R113B F212B SDA-BE R262B I034B SCL-BE R263B I033B BL-ON R288B I032B 3D-GOGGLES R293B F210B BE-ENABLE F119B R110B I030B NT-AMBI-SPI-CLK F209B R264B I019B...
  • Page 205 Circuit Diagrams and PWB Layouts QV14.1E LA EN 205 10-4-15 HF, - L032B L006B I047B +12V U027B TPS54494PWP VIN1 VIN2 L025B L026B 100nF C289B I039B C290B 100nF F019B +1V0-S VBST1 VBST2 +1V5-S 1.5uH 1.5uH I051B R193B PGND1 PGND2 ENABLE+1V5+2V5 I053B...
  • Page 206 Circuit Diagrams and PWB Layouts QV14.1E LA EN 206 10-4-16 HF, - L033B L010B I059B +12V BE-ENABLE U028B TPS54494PWP VIN1 VIN2 L027B L028B 100nF C293B I056B C294B 100nF F021B +1V5-M +1V0-M VBST1 VBST2 1.5uH 1.5uH I063B R196B PGND1 PGND2 ENABLE+1V5+2V5...
  • Page 207 Circuit Diagrams and PWB Layouts QV14.1E LA EN 207 10-4-17 HF, - L035B L024B I070B +12V L029B +2V5 X006B +2V5-M U030B RT7297CHZSP +2V5 I071B C301B 100nF X005B BOOT I072B +2V5-S ENABLE+1V5+2V5 I074B R241B F027B C379B 22nF +2V5 I075B I073B U025B...
  • Page 208 Circuit Diagrams and PWB Layouts QV14.1E LA EN 208 10-4-18 HF, POWER CONNECTOR POWER CONNECTOR X010 F222B +12V F185B +12V-AL TYPE F186B To SSB From Supply X091 X090 GND-AL GND-AL PIN 1 GND-AL GND-AL GND-AL PIN 2 +12V-AL F187B F188B...
  • Page 209 Circuit Diagrams and PWB Layouts QV14.1E LA EN 209 10-4-19 HF, - PCMCIA SLOTS X297 X295 F040C F061C CA-AB-D03 F041C CA-AB-D03 F062C CA-AB-D04 F042C CA-AB-D04 F063C CA-AB-D05 F043C CA-AB-D05 F064C CA-AB-D06 F044C CA-AB-D06 F065C CA-AB-D07 F045C X054 X056 CA-AB-D07 F066C...
  • Page 210 QV14.1E LA EN 2 Circuit Diagrams and PWB Layouts 10-4-20 HF, 715RLPCB0000000252 - LAYOUT TOP back to 2014- div.table...
  • Page 211 QV14.1E LA EN 2 Circuit Diagrams and PWB Layouts 10-4-2 HF, 715RLPCB0000000252 - LAYOUT back to 2014- div.table...
  • Page 212 Circuit Diagrams and PWB Layouts QV14.1E LA EN 212 10.5 715RLPCB0000000094 AmbiLight 10-5-1 AL1, Ambilight 7-LED Ambilight 7-LED AL01 AL01 2k14 C003 100nF +3V3 +3V3 +12v +12v XA02 XA05 R012 +3V3 S002 U001 F010 D100 AMBI-TEMP BAT54 COL F001 F002...
  • Page 213 Circuit Diagrams and PWB Layouts QV14.1E LA EN 213 10-5-2 AL2, Ambilight 7-LED Ambilight 7-LED AL02 AL02 2k14 R015 R015 PWM2-R3 R015 D001 D002 R015 R013 PWM2-G3 +12v R013 R013 PWM2-B3 R013 RED/GREEN/BLUE RED/GREEN/BLUE R016 R016 PWM2-R2 R016 D003 D004...
  • Page 214 Circuit Diagrams and PWB Layouts QV14.1E LA EN 214 10.6 715RLPCB0000000103 AmbiLight 10-6-1 AL1, Ambilight 8-LED Ambilight 8-LED AL01 AL01 2k14 +12v XA05 +12v XA02 C003 100nF +3V3 +3V3 R012 +3V3 S002 U001 F001 F010 D100 AMBI-TEMP F002 BAT54 COL...
  • Page 215 Circuit Diagrams and PWB Layouts QV14.1E LA EN 215 10-6-2 AL2, Ambilight 8-LED Ambilight 8-LED AL02 AL02 2k14 R015 R015 PWM2-R3 R015 D001 D002 D003 R015 R013 PWM2-G3 +12v R013 R013 PWM2-B3 R013 RED/GREEN/BLUE RED/GREEN/BLUE RED/GREEN/BLUE R016 R016 PWM2-R2 R016...
  • Page 216 Circuit Diagrams and PWB Layouts QV14.1E LA EN 216 10.7 715RLPCB0000000113 AmbiLight 10-7-1 AL1, AmbiLight 9 LED 2k14 Ambilight 9-LED AL01 AL01 2k14 +12v +12v XA02 XA05 C003 100nF +3V3 +3V3 R012 +3V3 F001 S002 U001 F010 F002 D100 AMBI-TEMP...
  • Page 217 Circuit Diagrams and PWB Layouts QV14.1E LA EN 217 10-7-2 AL2, AmbiLight 9 LED 2k14 Ambilight 9-LED AL02 AL02 2k14 R015 R015 PWM2-R3 R015 D001 D002 D003 R015 R013 PWM2-G3 +12v R013 R013 PWM2-B3 R013 RED/GREEN/BLUE RED/GREEN/BLUE RED/GREEN/BLUE R016 R016...
  • Page 218 Circuit Diagrams and PWB Layouts QV14.1E LA EN 218 10.8 715RLPCB0000000123 AmbiLight 10-8-1 AL1, AmbiLight 10-LED 2k14 Ambilight 10-LED AL01 AL01 2k14 +12v +12v XA02 XA05 C003 100nF +3V3 +3V3 R012 +3V3 F001 S002 U001 F010 F002 D100 AMBI-TEMP BAT54 COL...
  • Page 219 Circuit Diagrams and PWB Layouts QV14.1E LA EN 219 10-8-2 AL2, AmbiLight 10-LED 2k14 Ambilight 10-LED AL02 AL02 2k14 R015 R015 PWM2-R4 R015 D001 D002 D003 R015 R013 PWM2-G4 +12v R013 R013 PWM2-B4 R013 RED/GREEN/BLUE RED/GREEN/BLUE RED/GREEN/BLUE R016 R016 PWM2-R3...
  • Page 220 Circuit Diagrams and PWB Layouts QV14.1E LA EN 220 10.9 715RLPCB0000000194 AmbiLight 10-9-1 AL1, AmbiLight 48-55" CENTRAL BAR - 2k14 AL 2k14 48"-55" CENTRAL BAR AL01 AL01 +12V +12V X002 X005 +12V S006 +3V3AL +3V3 SCKI F006 F007 AMBI-TEMP +3V3...
  • Page 221 Circuit Diagrams and PWB Layouts QV14.1E LA EN 221 10-9-2 AL2, AmbiLight 48-55" CENTRAL BAR - 2K14 AL 2k14 48"-55" CENTRAL BAR AL02 AL02 R030 R022 R023 R022 R023 PWM1-R1 PWM1-R2 R022 D001 D002 D003 R023 D004 D005 D006 R022...
  • Page 222 Circuit Diagrams and PWB Layouts QV14.1E LA EN 222 10-9-3 AL3, AmbiLight 48-55" CENTRAL BAR - 2K14 AL 2k14 48"-55" CENTRAL BAR AL03 AL03 R025 S020 S021 S022 R025 S020 S021 S022 PWM2-R1 S020 S021 S022 R025 D301 D302 D303...
  • Page 223 Circuit Diagrams and PWB Layouts QV14.1E LA EN 223 10.10 715RLPCB0000000223 AmbiLight 10-10-1 AL1, AmbiLight 55" LEFT 2K14 AL 2k14 55" LEFT - DRIVERS AL01 AL01 +12V X005 +12V S006 +3V3AL +3V3 SCKI F006 F007 AMBI-TEMP +12V F001 +3V3 C003...
  • Page 224 Circuit Diagrams and PWB Layouts QV14.1E LA EN 224 10-10-2 AL2, AmbiLight 55” LEFT 2K14 AL 2k14 55" LEFT - LEDS AL02 AL02 R030 R022 R023 R022 R023 PWM1-R1 PWM1-R2 R022 R023 D001 D002 D003 D004 D005 D006 R022 R031...
  • Page 225 Circuit Diagrams and PWB Layouts QV14.1E LA EN 225 10-10-3 AL3, AmbiLight 55" LEFT 2K14 AL 2k14 55" LEFT - LEDS AL03 AL03 R025 R025 PWM2-R1 R024 R025 D013 D014 D015 R024 R025 PWM1-R3 R017 R024 D007 D008 D009 PWM2-G1...
  • Page 226 Circuit Diagrams and PWB Layouts QV14.1E LA EN 226 10.11 715RLPCB0000000232 AmbiLight 10-11-1 AL1, AmbiLight 55" RIGHT 2K14 AL 2k14 55" RIGHT - DRIVERS AL01 AL01 +12V X002 S006 +3V3 +3V3AL F006 F007 C003 100nF +3V3 +3V3 R012 F001 +3V3...
  • Page 227 Circuit Diagrams and PWB Layouts QV14.1E LA EN 227 10-11-2 AL2, AmbiLight 55” RIGHT 2K14 AL 2k14 55" RIGHT - LEDS AL02 AL02 R030 R022 R023 R022 R023 PWM1-R1 PWM1-R2 R022 R023 D001 D002 D003 D004 D005 D006 R022 R031...
  • Page 228 Circuit Diagrams and PWB Layouts QV14.1E LA EN 228 10-11-3 AL3, AmbiLight 55" RIGHT 2K14 AL 2k14 55" RIGHT - LEDS AL03 AL03 R025 R025 PWM2-R1 R025 D013 D014 D015 R025 R017 R024 PWM2-G1 +12V R024 R017 PWM1-R3 R017 R024...
  • Page 229 Circuit Diagrams and PWB Layouts QV14.1E LA EN 229 10.12 715RLPCB0000000312 AmbiLight 10-12-1 AL1, AmbiLight 9100 TOP 2K14 AmbiLight DRIVER AL01 AL01 +12v +12v X002 C003 100nF S006 +3V3 +3V3AL +3V3 +3V3 X005 F006 F007 R012 +12V +3V3 +12V +12V...
  • Page 230 Circuit Diagrams and PWB Layouts QV14.1E LA EN 230 10-12-2 AL2, AmbiLight 9100 TOP 2K14 AmbiLight LED 1 AL02 AL02 R024 R022 R024 R022 PWM1-R3 PWM1-R1 R024 R022 D123 D132 D133 R024 D102 D103 R022 R016 R014 PWM1-G3 +12V PWM1-G1...
  • Page 231 Circuit Diagrams and PWB Layouts QV14.1E LA EN 231 10-12-3 AL3, AmbiLight 9100 TOP 2K14 AmbiLight LED 2 AL03 AL03 R025 R025 PWM2-R1 R025 D101 D104 R025 R017 PWM2-G1 +12V R017 R017 PWM2-B1 MT1 MT2 MT1 MT2 R017 COLOUR COLOUR...
  • Page 232 Circuit Diagrams and PWB Layouts QV14.1E LA EN 232 10.13 715RLPCB0000000322 AmbiLight 10-13-1 AL1, AmbiLight 9100 SIDE 2K14 AmbiLight DRIVER AL01 AL01 +12v +12v X002 C003 100nF S006 +3V3 +3V3AL +3V3 +3V3 X005 F006 F007 R012 +12V +3V3 +12V +12V...
  • Page 233 Circuit Diagrams and PWB Layouts QV14.1E LA EN 233 10-13-2 AL2, AmbiLight 9100 SIDE 2K14 AmbiLight LED 1 AL02 AL02 R024 R022 R024 R022 PWM1-R3 PWM1-R1 R024 R022 D123 D132 D133 R024 D102 D103 R022 R016 R014 PWM1-G3 +12V PWM1-G1...
  • Page 234 Circuit Diagrams and PWB Layouts QV14.1E LA EN 234 10.14 715RLPCB0000000451 AmbiLight 10-14-1 AL1, AmbiLight 7LED curved 2k14 AmbiLight Driver AL01 AL01 C003 100nF +3V3 +3V3 +12v +12v XA02 XA05 R012 +3V3 S002 U001 LMV321IDCKR F010 D100 AMBI-TEMP TYPE F001...
  • Page 235 Circuit Diagrams and PWB Layouts QV14.1E LA EN 235 10-14-2 AL2, AmbiLight 7 LED curved 2K14 AmbiLight LED AL02 AL02 R019 R020 PWM2-R3 R021 D001 D002 R022 R015 PWM2-G3 +12v R023 R024 PWM2-B3 R025 COLOUR COLOUR R013 R026 PWM2-R2 R027...
  • Page 236 Circuit Diagrams and PWB Layouts QV14.1E LA EN 236 10.15 715RLPCB0000000461 AmbiLight 10-15-1 AL1, AmbiLight 8LED curved 2k14 AmbiLight Driver AL01 AL01 +12v XA05 +12v XA02 C003 100nF +3V3 +3V3 R012 +3V3 S002 U001 F001 F010 D100 AMBI-TEMP F002 TYPE...
  • Page 237 Circuit Diagrams and PWB Layouts QV14.1E LA EN 237 10-15-2 AL2, AmbiLight 8LED curved 2k14 AmbiLight LED AL02 AL02 R019 R020 PWM2-R3 R021 D001 D002 D003 R022 R015 PWM2-G3 +12v R016 R027 PWM2-B3 R028 COLOUR COLOUR COLOUR R023 R024 PWM2-R2...
  • Page 238 Styling Sheets QV14.1E LA EN 238 11. Styling Sheets 11.1 79xx series 49" 7800 and 7900 series 49" 1111 1163 0155 0050 0061 0052 5211 1050 0011 1163 0430 0111 1010 Description Remarks 0003 0002 Frame 0003 Bottom profile 0011...
  • Page 239 Styling Sheets QV14.1E LA EN 239 11.2 79xx series 55" 7800 and 7900 series 55" 1111 1163 0155 0050 5211 0061 0052 1050 0011 1163 0430 0111 1010 0003 Description Remarks 0002 Frame 0003 Bottom profile 0011 Back cover 0040...
  • Page 240 Styling Sheets QV14.1E LA EN 240 11.3 81x9 and 82x9 series 48" - 55" 81x9 and 82x9 series 48 - 55" 1171 0011 1170 0155 0050 1111 5211 0155 5212 0052 0061 1050 0111 0155 1010 5212 Pos No. Description...
  • Page 241 Styling Sheets QV14.1E LA EN 241 11.4 88x9 series 55" 88x9 series 55" 1172 1171 1170 0155 1113 1111 0050 0052 0011 5211 0101 0103 0061 0100 1171 1170 0155 0430 1050 5211 Pos No. Description Remarks 1028 0011 Back cover...
  • Page 242 Styling Sheets QV14.1E LA EN 242 11.5 89x9 curved series 55" 8900 curved series 55" 1171 1170 1172 5210 1113 101x 1111 0056 0050 0052 0054 1170 0061 0011 1172 0112 0111 1028 1050 Description Remarks 0430 0060 1010 0008...
  • Page 243 Styling Sheets QV14.1E LA EN 243 11.6 91xx series 55" - 65" 0074 9100 series 55" - 65" 1170 1171 1172 1111 0050 1170 0155 5211 0052 0061 0110 0011 0112 1113 1171 10xx 1172 1011 0661 1050 0430 Description...
  • Page 244 Styling Sheets QV14.1E LA EN 244 11.7 98xx series 65" 9800 series 65" 1172 1171 1171 1113 1111 1171 0050 0052 5211 1172 0011 0102 0061 1171 0105 1170 0045 0112 0114 1171 1011 1171 0106 1170 0091 0110 1050...

Table of Contents
