Edge 510 LTE The Dell EMC Edge 510 LTE is a purpose-built, high-value appliance for Edge use case that supports SD-WAN with an integrated LTE adapter. For detailed installation information, including instructions for the wall mount and optional dual rackmount tray installation, see the Dell EMC Edge 510 LTE Installation Guide at www.dell.com/support.
Page 5
1. Connect the two identical antennas (included in the box) to the MAIN and AUX SMA connectors on the back of the Edge. The GPS antenna (not included) is optional. NOTE: An active GPS antenna recommended for an excellent performance. A passive antenna with high gain will work if the unit/antenna is close to a window.
Page 6
Figure 3. Connect the power adapter to the AC power outlet 4. Connect the Edge 510 LTE to an available Internet connection. For wired connections, insert the Ethernet cable in either the GE3 or GE4 ports. For activating LTE, refer to the Configure Edge activation in the Edge 510 LTE Installation guide.
Use ONLY GE1 or GE2 1 Gb Ethernet ports for WAN connection to a laptop or switch. ● GE1 or GE2 ports Activation issues Unable to activate the Edge 510-LTE After following these instructions, if you are still unable to activate the Edge 510-LTE, please contact www.dell.com/support/ Edge 510 LTE...
Specifications Table 1. Edge 510 LTE specifications Feature Specification Size ● 8.1 in x 7.1 in x 1.57 in (W x D x H) ● 20.6 cm x 18.0 cm x 4.0 cm (W x D x H) Weight ● 2.0 lb NOTE: Platform weight does not include power adapter ●...
