- Page 1 ..................... EGD6576NOK EN HOB USER MANUAL...
-
Page 2: Table Of Contents
9. TECHNICAL INFORMATION ..........20 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. -
Page 3: Safety Information
ENGLISH 1. SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible if an incorrect installation and use causes in- juries and damages. Always keep the instructions with the appliance for future reference. 1.1 Children and vulnerable people safety WARNING! Risk of suffocation, injury or permanent disability. -
Page 4: Safety Instructions
• Never try to extinguish a fire with water, but switch off the appliance and then cover flame e.g. with a lid or a fire blanket. • Do not store items on the cooking surfaces. • Do not use a steam cleaner to clean the appliance. - Page 5 ENGLISH socket can make the terminal become • Remove all the packaging, labelling and too hot. protective film (if applicable) before first use. • Make sure that a shock protection is in- stalled. • Use this appliance in a household envi- ronment.
- Page 6 • Do not activate the cooking zones with • Use only the accessories supplied with empty cookware or without cookware. the appliance. • Do not put aluminium foil on the appli- • Do not install a flame diffuser on the ance.
-
Page 7: Product Description
ENGLISH 3. PRODUCT DESCRIPTION 3.1 Cooking surface layout Induction cooking zone 1400 W with the power function 2500 W Rapid burner Semi-rapid burner Control knobs Touch control panel Induction cooking zone 2300 W with the power function 3300 W 3.2 Control knobs Symbol Description minimum gas... -
Page 8: Daily Use
A heat setting display To show the heat setting. Timer indicators of cooking To show for which zone you set the time. zones The timer display To show the time in minutes. To select a cooking zone. - Page 9 ENGLISH Always light the burner before you If the burner accidentally goes out, put cookware. turn the control knob to the off position and try to light the burner To light the burner: again after minimum 1 minute. Turn the control knob counterclock- The spark generator can start au- wise to the maximum position ( tomatically when you switch on...
- Page 10 10 www.electrolux.com • The relation between heat setting and 4.7 Switching on and off the times of the Automatic Switch Off func- power function tion: The power function gives more power to • — 6 hours an induction cooking zone for no longer •...
-
Page 11: Helpful Hints And Tips
ENGLISH goes out. To switch off You can also To start this function touch . The sym- touch at the same time. comes on for 4 seconds. The Timer stays on. When the time elapses, the sound oper- To stop this function touch . - Page 12 12 www.electrolux.com tom (marked as correct by a manufac- Burner Minimum diameters turer). of cookware • not correct: aluminium, copper, brass, Semi-rapid 120 - 220 mm glass, ceramic, porcelain. Cookware is correct for an induction WARNING! hob if … Do not put the aluminium foil on •...
-
Page 13: Care And Cleaning
ENGLISH Heat Use to: Time Hints set- ting Steam potatoes 20-60 Use max. ¼ l water for 750 g of potatoes Cook larger quantities of food, 60-150 Up to 3 l liquid plus ingredi- stews and soups ents Gentle fry: escalope, veal cordon as re- Turn halfway through bleu, cutlets, rissoles, sausages,... -
Page 14: Troubleshooting
14 www.electrolux.com – Stop the appliance and let it Keep these components well clean to cool down before you clean: lime- prevent difficult lighting and check that the scale rings, water rings, fat stains, burner crown holes are not obstructed. - Page 15 ENGLISH Problem Possible cause and remedy • No cookware on the cooking zone. Put cookware comes on on the cooking zone. • Not correct cookware. Use the correct cookware. • The diameter of the bottom of the cookware is too small for the cooking zone.
-
Page 16: Installation
16 www.electrolux.com 7.1 Labels supplied with the accessories bag Stick the adhesive labels as indicated be- low: MOD. MOD. MOD. TYPE PROD.NO. 230V-50Hz PROD.NO. PROD.NO. 0049 SER.NO. IP20 SER.NO SER.NO 03 IT DATA DATA MADE IN ITALY MODEL MODEL Stick it on Guarantee Card and send... - Page 17 ENGLISH Liquid gas: use the rubber pipe holder. 8.3 Adjustment of minimum level Always engage the gasket. Then continue To adjust the minimum level of the burn- with the gas connection. The flexible pipe ers: is prepared for apply when: Light the burner.
- Page 18 18 www.electrolux.com • Do not pull the mains cable to discon- blue neutral cable must be connected nect the appliance. Always pull the to the terminal block label with "N". The mains plug. brown (or black) phase cable (fitted in the terminal block contact marked with •...
- Page 19 ENGLISH min. 38 mm min. 12 mm min. 2 mm CAUTION! Kitchen unit with oven Install the appliance only on a The electrical connection of the hob and worktop with flat surface. the oven must be installed separately for safety reasons and to let easy remove 8.7 Possibilities for insertion oven from the unit.
-
Page 20: Technical Information
20 www.electrolux.com 9. TECHNICAL INFORMATION Front cooking 2.3 kW (3.3 kW in Hob dimensions zone: P setting) Width: 590 mm Total gas power: G20 (2H) 20 mbar Length: 520 mm = 4.6 kW G30 (3+) 28–30 Hob recess dimensions mbar = 334 g/h... - Page 21 ENGLISH with the household waste. Return the product to your local recycling facility or contact your municipal office.
- Page 22 22 www.electrolux.com...
- Page 23 ENGLISH...
- Page 24 www.electrolux.com/shop...
