- Page 1 FUJITSU SEMICONDUCTOR SS01-71064-1E SUPPORT SYSTEM DSU-FR EMULATOR MC-16FX QFP-100P HEADER TYPE 3 MB2198-501 OPERATION MANUAL...
- Page 2 *2 : The package is the FPT-100P-M06 (0.65mm lead pitch, 14mm × 20mm body size). *3 : FR is an abbreviation of FUJITSU RISC CONTROLLER and is a product of Fujitsu Limited. *4 : Referred to as the “header board”...
- Page 3 (i.e., submersible repeater and artificial satellite). Please note that FUJITSU will not be liable against you and/or any third party for any claims or damages arising in connection with above-mentioned uses of the products.
-
Page 4: Handling Precautions
This product forms part of an emulator system when used in combination with an emulator and adapter board (both sold separately). Consult a Fujitsu Limited sales or support representative for information on the adapter boards and emulators that are compatible with this product. - Page 5 3. Notes on Designing ■ Notes on designing the printed circuit board for the user system Once the header board is connected to the user system, the heights of parts mounted around the header board are restricted. When designing the printed circuit board of the user system, consider the height of the parts within range of the header board as shown in Figure 1 such that components mounted on the user system and the header board do not interfere with each other.
- Page 6 ■ MCU footprint design notes Figure 2 shows the recommended dimensions of the footprint for mounting the NQPACK on the printed circuit board of the user system. The printed circuit board of the user system must be designed with due consideration given to this footprint as well as to the mass production MCU.
- Page 7 4. Procedure for Connecting to the User System Before using the header board, mount the supplied NQPACK on the user system. The header board is connected to the adapter board using the 2 flat cables (standard or long) included with the adapter board (which is sold separately). See the operation manual of the adapter board for details on how to connect the flat cables.
- Page 8 Screws for securing the header board Washer Header board YQPACK NQPACK User system Figure 4 Header board connection ■ Disconnection To disconnect the header board from the user system, remove all four screws, and then pull the header board straight out of the NQPACK.
- Page 9 5. Mounting Mass Production MCUs To mount a mass production MCU on the user system, use the supplied HQPACK. ■ Mounting 1. Align the index mark (▲) on the NQPACK mounted on the user system with the index mark (●) on the mass production MCU and mount the MCU on the NQPACK.
-
Page 10: Connector Pin Assignment
6. Connector Pin Assignment The signals from the evaluation MCU that is mounted on the adapter board are connected to the YQ- PACK (which has the same pin configuration as the production MCU) via flat cable connectors A and B on the header board. The adapter board and header board are connected using the 2 flat cables (standard or long) that are included with the adapter (which is sold separately). - Page 11 Table 1 Pin assignment of flat cable connector A Connector Evaluation MCU Production MCU Connector Evaluation MCU Production MCU pin number pin number pin number pin number pin number pin number ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯ ⎯...
- Page 12 Table 2 Pin assignment of flat cable connector B Connector Evaluation MCU Production MCU Connector Evaluation MCU Production MCU pin number pin number pin number pin number pin number pin number AH13 AJ13 AJ12 AK12 AJ11 AH12 AK11 AK10 AH11 AG11 AJ10 AH10...
- Page 13 SS01-71064-1E FUJITSU SEMICONDUCTOR • SUPPORT SYSTEM DSU-FR EMULATOR MC-16FX QFP-100P HEADER TYPE 3 MB2198-501 OPERATION MANUAL March 2007 the first edition Published FUJITSU LIMITED Electronic Devices Edited Business Promotion Dept.
