Nokia Customer Care
2366i (RM-155)
Mobile Terminals
Disassembly
Issue 2 - February 2007
Company Confidential

Advertisement

Table of Contents
loading

Related Manuals for Nokia 2366i

Summary of Contents for Nokia 2366i

  • Page 1 Nokia Customer Care 2366i (RM-155) Mobile Terminals Disassembly Issue 2 - February 2007 Company Confidential...

  • Page 2: Table Of Contents

    2366i (RM-155) Disassembly Nokia Customer Care Contents Page Safety Information ............................3 ESD Protection ............................. 3 Disassembly Instructions ..........................4 1. Remove the Battery Cover ........................4 2. Remove the Grommets and Screws ....................4 3. Separate the D-cover from the C-cover ................... 5 4.

  • Page 3: Safety Information

    ESD protection. • ESD-protected spare part packages MUST NOT be opened/closed outside an EPA. For more detailed information about ESD protection and EPAs, contact your local Nokia Customer Care representative. Issue 2 - February 2007...

  • Page 4: Disassembly Instructions

    2366i (RM-155) Disassembly Nokia Customer Care Disassembly Instructions Use the following steps to disassemble the mobile terminal. 1. Remove the Battery Cover Press down on the B-cover while sliding it away from the body of the mobile terminal. If installed, remove the battery.

  • Page 5: Separate The D-Cover From The C-Cover

    2366i (RM-155) Nokia Customer Care Disassembly 3. Separate the D-cover from the C-cover Open the grommet that seals the Universal Headphone Jack (UHJ). Use an SRT-6 or an SS-93 tool to unsnap the D-cover from the handset. Lift the D-cover straight off of the assembly, and set the cover aside.

  • Page 6: Remove The Sidekey Switch Assembly

    2366i (RM-155) Disassembly Nokia Customer Care Lift the main PWB and the side key flex assembly from the cover. 5. Remove the Sidekey Switch Assembly Note: only remove the Sidekey Switch Assembly if it is to be replaced with a new one.

  • Page 7: Remove The Uhj Cover

    2366i (RM-155) Nokia Customer Care Disassembly 6. Remove the UHJ Cover Remove the UHJ Cover from the D-cover. If the UHJ cover is damaged, replace it; otherwise, set the UHJ cover aside. 7. Remove the Microphone Module Use plastic tweezers to remove the microphone module from the D-cover.

  • Page 8: Remove The Dc Jack

    2366i (RM-155) Disassembly Nokia Customer Care 8. Remove the DC Jack Use the CA-44 tool to lift the jack and remove it. 9. Remove the Antenna. Remove the RF grommet. Use plastic tweezers to lift the retaining latch. Do not cause damage to the contacts.

  • Page 9: Remove The Keymat And The Sidekey

    2366i (RM-155) Nokia Customer Care Disassembly Remove the antenna. 10. Remove the Keymat and the Sidekey Press the keymat up, and remove it from the C-cover. Use plastic tweezers to lift out the sidekey. Make note of the orientation of the sidekey for later installation.

  • Page 10: Disengage The Hinge Assembly

    2366i (RM-155) Disassembly Nokia Customer Care 11. Disengage the Hinge Assembly Hold the assembly as shown. Flex the C-cover to release the right hinge. Note: do not separate the LEFT hinge first, as damage to the main flex cable may occur.

  • Page 11: Separate The A-Cover From The B-Cover

    2366i (RM-155) Nokia Customer Care Disassembly Lift the C-cover away and set it aside. 12. Separate the A-cover from the B-cover Use the guitar pic to unlock the clasps. Start near the hinge and work counter-clockwise around the assembly. Note: Several tabs require release before the A-cover can be removed. Ensure that you do not damage the tabs with excessive force.

  • Page 12: Remove The Flex Connections

    2366i (RM-155) Disassembly Nokia Customer Care 13. Remove the Flex Connections Use the plastic tweezers and guitar pick to unattach the flex connections. 14. Disassemble the Upper UI Assembly Remove the 4 #6 Torx screws in the order shown. Disengage the upper UI assembly from the B-cover.

  • Page 13: Disassemble The External Display

    2366i (RM-155) Nokia Customer Care Disassembly Use plastic tweezers to guide the main flex cable out of the slot in the B-cover. Separate the Upper UI Assembly from the B-cover and set the cover aside. 15. Disassemble the External Display Use an SRT-6 tool to disconnect the external LCD display connector.

  • Page 14: Remove The Earpiece

    2366i (RM-155) Disassembly Nokia Customer Care Turn the metal mounting frame over to reveal the back of the external LCD display. Use an SRT-6 tool to lift the display clear of the frame. Remove the external LCD display, pulling the flex connector through the access hole.
