Features of PX8700
1. Wave Type
• CELLULAR : G7W
• PCS : G7W
2. Frequency Scope
Transmit Frequency (MHz)
CELLULAR
824.82 ~ 848.19
3. Rated Output Power : CELLULAR = 0.20W
4. Output Conversion Method : This is possible by correcting the key board channel.
5. Voltage and Current Value of Termination Part Amplifier (Catalogue included)
MODE
CELLULAR
PCS
6. Functions of Major Semi-Conductors
Classification
MSM6550
Memory MCP
(HYI0UGG0MF1P-6SS0E)
RFR6500
RFT6150
7. Frequency Stability
• CELLULAR : ±0.5PPM
• PCS : ±0.1PPM
LG Electronics Inc.
PCS
1850~1910
PCS = 0.20W
Part Name
Voltage
AWT6310R
AWT6310R
Terminal operation control and digital signal processing
Flash Memory (1Mbit) + SDRAM (512Mbit)
Storing of terminal operation program
Converts Rx RF signal to baseband signal
Converts baseband signal to Tx RF signal
Receive Frequency (MHz)
CELLULAR
869.82~893.19
1930~1990
Current
4.2V
600mA
4.2V
600mA
Function
PCS
GPS
1575.42
Power
0.20W
0.20W
