Service Manual TOP NEXT ORDER NO. KM40201784C2 Telephone Equipment KX-TCD725RUM Digital Cordless Phone Metallic Grey Version (for Russia) http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0000000000.html (1 of 2)13.10.2007 10:10:15...
1 LOCATION OF CONTROLS TOP PREVIOUS NEXT 1.1 Base Unit 1.2 Handset TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0100000000x.html13.10.2007 10:11:09...
2 Displays TOP PREVIOUS NEXT 2.1 Handset Display 2.2 Icons 2.3 Characters/Symbols TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0200000000x.html13.10.2007 10:11:23...
2.2 Icons TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0202000000.html13.10.2007 10:11:31...
Page 13
2.3 Characters/Symbols TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0203000000.html13.10.2007 10:11:35...
3 DISASSEMBLY INSTRUCUTIONS TOP PREVIOUS NEXT Shown in Fig.- To Remove Remove Lower Cabinet Screws (2.6 × 10)....(A) × 2 Main P.C.B of base Screw (2.6 × 10)....(B) × 1 http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0300000000x.html (1 of 2)13.10.2007 10:11:44...
Page 15
Main P.C.B of base Charge wire solder Rear Cabinet of handset Screws (2 × 8)......(C) × 2 Main P.C.B of handset Screws (2 × 6)......(D) × 2 3.1 Assembly the LCD to P.C. Board (Handset) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0300000000x.html (2 of 2)13.10.2007 10:11:44...
3.1 Assembly the LCD to P.C. Board (Handset) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0301000000.html (1 of 2)13.10.2007 10:11:51...
Page 17
TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0301000000.html (2 of 2)13.10.2007 10:11:51...
4 SETTINGS TOP PREVIOUS NEXT 4.1 Connections 4.2 Using the Belt Clip 4.3 Batteries 4.3.1 Installing the Batteries in the Handset 4.3.2 Battery Charge 4.3.3 Recharge 4.3.4 Battery Information TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0400000000x.html13.10.2007 10:11:56...
The telephone will not work during a power failure. We therefore recommend you use a standard telephone and automatic change-over switch to connect this Digital Cordless Phone to the line. Your Panasonic Sales Shop can offer you more informationabout connection possibilities. http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0401000000.html (1 of 2)13.10.2007 10:12:05...
Page 20
TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0401000000.html (2 of 2)13.10.2007 10:12:05...
4.2 Using the Belt Clip TOP PREVIOUS NEXT You can hang the handset on your belt or pocket using the belt clip. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0402000000.html13.10.2007 10:12:13...
4.3 Batteries TOP PREVIOUS NEXT 4.3.1 Installing the Batteries in the Handset 4.3.2 Battery Charge 4.3.3 Recharge 4.3.4 Battery Information TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0403000000.html13.10.2007 10:12:18...
4.3.1 Installing the Batteries in the Handset TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0403010000.html13.10.2007 10:12:21...
4.3.4 Battery Information TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0403040000.html13.10.2007 10:12:35...
5 OPERATIONS TOP PREVIOUS NEXT This section is intended to provide a basic overview for KX-TCD725RUM. For a full explanation, refer to the Operating Instructions. 5.1 Turning the Power ON/OFF 5.2 Making a Call 5.3 Answering Call 5.4 Terminating a Call 5.5 Summary of Programmable Function...
5.1 Turning the Power ON/OFF TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0501000000.html13.10.2007 10:12:44...
5.5 Summary of Programmable Function TOP PREVIOUS NEXT 5.5.1 Handset 5.5.2 Base Unit TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0505000000.html13.10.2007 10:12:58...
5.5.1 Handset TOP PREVIOUS NEXT You can program the following function items using the handset near the base unit Make sure that the power is ON, and the unit is in the standby mode. http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0505010000.html (1 of 2)13.10.2007 10:13:05...
Page 34
TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0505010000.html (2 of 2)13.10.2007 10:13:05...
6.1.9 BUZZER CIRCUIT (SEE Fig. 18) 6.1.10 AUDIO PATH-RX AUDIO-LINE INPUT (SEE Fig. 18) 6.1.11 AUDIO PATH - TX AUDIO - LINE OUTPUT (SEE Fig. 18) 6.2 THE LINE INTERFACE SECTION (SEE BLOCK DIAGRAM Fig. 17) 6.2.1 INTRODUCTION http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0600000000x.html (1 of 2)13.10.2007 10:13:15...
Page 37
6.2.6 PULSE DIALING (SEE Fig. 20) 6.2.7 AUDIO CIRCUITS (SEE Fig. 20) 6.2.8 DISCONNECT (SEE Fig. 20) 6.2.9 POWER SUPPLIES (SEE Fig. 21) 6.3 RF MODULE 6.3.1 RF MODULE (SEE BLOCK DIAGRAM Fig.22) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0600000000x.html (2 of 2)13.10.2007 10:13:15...
Page 38
TXAF TXDA Burst Building Bridge Speech Encoding 16kHz Hook Audio RXAF RXDA Rect. Filter Switch Burst Decoding Speech Decoding Analog ADPCM RSSI Buzzer Front End Codec Filter SYRI Ring Interface ANT1 Det. ANT2 SYEN HOOK RING CHARGE PULSE Det. TXAF Clip A0..
6.1.7 LOCATOR KEY (SEE Fig. 18) 6.1.8 FACTORY SERIAL PORT (SEE Fig. 18) 6.1.9 BUZZER CIRCUIT (SEE Fig. 18) 6.1.10 AUDIO PATH-RX AUDIO-LINE INPUT (SEE Fig. 18) 6.1.11 AUDIO PATH - TX AUDIO - LINE OUTPUT (SEE Fig. 18) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601000000.html13.10.2007 10:13:24...
6.1.1 INTRODUCTION (SEE Fig. 17) TOP PREVIOUS NEXT The base-band section consists of a base-band integrated circuit (BBIC), a Flash PROM, an EEPROM and Flash SERIAL DAA ROM. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601010000.html13.10.2007 10:13:32...
The BBIC interfaces to its external PROM (IC5) via a data/address/control bus. It connects to the EEPROM via a serial interface, and a second serial interface is used during manufacture and service to connect to an external computer. It connects to Serial Flash ROM via serial interface. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601020000.html13.10.2007 10:13:36...
The 2 Mbit (IC5) Flash PROM contains the operational firmware for the microcontroller. It is interfaced to the data/address/control bus using address lines A0 to A17, data lines D0 to D7, and chip select (pin 30), outputenable (pin 32), and write (pin 7). TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601030000.html13.10.2007 10:13:39...
The electrically erasable PROM PQVIT2464WM6 (IC9) is used to store all the temporary operating parameters for the base (see EEPROM LAYOUT (BASE UNIT) ). It uses a two-line serial data interfacewith the BBIC, with bi-directional data on pin 5 (TP104), and clock on pin 6 (TP103). TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601040000.html13.10.2007 10:13:43...
6.1.5 SERIAL FLASH ROM TOP PREVIOUS NEXT The 4Mbit (IC8) Serial Flash ROM contains the audio data for TAM operation. It is interfaced to the clock/input/output using serial interface CS, SI and SO. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601050000.html13.10.2007 10:13:46...
(pin 5, TP101) which is used to drive the PLL circuitry in the RF module. The basic data rate for TXDA (pin 12) and RXDA (pin 20) is 1.152 Mbits/s, which is10.368MHz divided by 9. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601060000.html13.10.2007 10:13:50...
6.1.7 LOCATOR KEY (SEE Fig. 18) TOP PREVIOUS NEXT The “Locator (Page)” button is connected to pin 71 (TP109) of the IC6. When pressed the base transmits a message to the handset, which then beeps. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601070000.html13.10.2007 10:13:55...
To invoke the external communication mode the MODE_SEL terminal (J101) must be connected to the 2.8V terminal (J100). The serial port terminals J100 to J104 are connected to by means of test probe pads on the ground plane side of the pcb. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601080000.html13.10.2007 10:13:59...
A square-wave signal from IC6 pin 76 is used to sound the buzzer via switching transistor T1 (TP98). Various tones and cadences are used dependent on function. Buzzer volume is varied by changing the duty cycle of the drive waveform. D16provides quenching of back-emf generated when T6 turns off. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601090000.html13.10.2007 10:14:02...
The burst mode controller processesthis stream performing encryption and scrambling, adding the various other fields to produce the GAP standard DECT frame, assigning to a time slot and channel etc. to emerge on pin 12 as TXDA. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601100000.html13.10.2007 10:14:05...
It then goes to the DSP where it is turned back into analogue audio. This is amplified by the analogue front end and emerges at pin 123 - i.e. the RXAF signal of the line interface. Circuit Diagram TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0601110000.html13.10.2007 10:14:15...
6.2.3 BELL DETECTOR (SEE Fig. 19) 6.2.4 CLIP CIRCUITS (SEE Fig. 19) 6.2.5 HOOKSWITCH (SEE Fig. 20) 6.2.6 PULSE DIALING (SEE Fig. 20) 6.2.7 AUDIO CIRCUITS (SEE Fig. 20) 6.2.8 DISCONNECT (SEE Fig. 20) 6.2.9 POWER SUPPLIES (SEE Fig. 21) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602000000.html13.10.2007 10:14:24...
TOP PREVIOUS NEXT This section consists of the telephone line interface, bell detector, charge-pulse detector, CLIP detector hook switch, pulse dialing circuits, audio circuits, DC mask & line impedance circuits, power supplies, and battery chargercircuits. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602010000.html13.10.2007 10:14:29...
The telephone line is connected to a bridge rectifier D8. Surge suppressor SA3 protects against excessive line voltages. Test points are TP40 (A), TP26 (B). Bridge rectifier D8 provides for lines of either polarity. The output of D8 is “Line +” (TP50)and “Line -” which is ground. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602020000.html13.10.2007 10:14:33...
DC from the line is blocked by C2. The other components D2, D3, and R3 reduce current and increase the circuit impedance in line withnational requirements. When ringing is detected IC2 will turn on, and the RING line will be dragged to a low voltage. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602030000.html13.10.2007 10:14:37...
R86, C93, C37, and R1. The combination depends upon the CLIP requirements of the specific country - often there is no requirements for the CLIP_STATE impedance. T10 disables the CLIP signal during the off-hook condition. Circuit Diagram TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602040000.html13.10.2007 10:14:41...
BBIC will be a high logic level (+2.8V), and both transistors will be on, thus T8 will “loop” theline. The zenner diode D10 protects transistors T11 to T13 against transient line voltages. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602050000.html13.10.2007 10:14:44...
During pulse dialing the hookswitch (T8, T9) is used to generate the pulses using the HOOK control signal, which is set high during pulses. To force the line impedance low during the “pause” intervalsbetween dial pulses, the PULSE-DIAL signal turns on T11. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602060000.html13.10.2007 10:14:49...
The line input signal TXAF is taken from the junction of R41 and R49. Phase cancellation is provided at this point by R70 so that only the incoming line audio should be passed to the BBIC on TXAF. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602070000.html13.10.2007 10:14:53...
The second telephone will cause the current through the unit to drop. This is manifests as a reduced voltage across R56 which is detected at the AD3 input port (pin 140) of the BBIC. Circuit Diagram TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602080000.html13.10.2007 10:14:57...
The 3.8V supply from IC7 is used for the RF module, and is further reduced by IC1 to 2.80V for the BBIC supply. R17, 18 and 19 provide short circuit/over current protection at the handset charge terminal. Circuit Diagram TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0602090000.html13.10.2007 10:15:01...
6.3 RF MODULE TOP PREVIOUS NEXT BLOCK DIAGRAM RF MODULE 6.3.1 RF MODULE (SEE BLOCK DIAGRAM Fig.22) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0603000000.html13.10.2007 10:15:08...
Page 63
ANT1 ANT2 PAON VCC1 Diversity 3.8V VCC2 Switching PAON PMB6610 voltage voltage regulator regulator PMB6818 DECT transceiver TXDA Power amp. VCC1 Printed balun Loop filter TX Part :N/A 32/33 DRON RXON SYRI PLL & Printed SYEN control logic SYDA SYCL RXDSG Printed RXDA...
The RSSI (Radio Signal Strength Indicator) signal enables the implementation of diversity switching whereby two antennae can be mounted in different orientations and their signals compared. The one with better reception can be selected by the BBIC usingthe ANT1 and ANT2 lines. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0603010000.html13.10.2007 10:15:15...
7.1.8 CLOCK GENERATION (SEE Fig. 25) 7.1.9 KEYBOARD (SEE Fig. 26) 7.1.10 LCD DISPLAY, AND DISPLAY DRIVER (SEE Fig. 26) 7.1.11 BATTERY SUPPLY (SEE Fig. 27) 7.1.12 2.65V REGULATOR (SEE Fig. 27) 7.1.13 BATTERY CHARGING CIRCUIT (SEE Fig. 27) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701000000.html13.10.2007 10:15:29...
Page 67
SPEAKER Amplifier SP_CTR Speaker RXDA EARPIECE RX-AF Speech Decoding Burst Decoding Buffer TXDA TX-AF Speech Encoding Burst Encoding Section HEADSET RSSI ADPCM Analog Codec SYRI Inter- Front Filter SYEN face SP_CTR XTAL CHARGE CHARGE CHARGE 10.368 CIRCUIT CONTACTS SENSE SUPEEP ON SWITCH EEPROM VDDBAT...
7.1.1 INTRODUCTION TOP PREVIOUS NEXT The base-band section consists of a base-band integrated circuit (BBIC), a Flash PROM, an EEPROM, an LCD Display, a Microphone, an Earpiece, and power supply/battery management circuits. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701010000.html13.10.2007 10:16:43...
The BBIC interfaces to its external PROM (IC3) via a data/address/control bus. It connects to the EEPROM (IC2) via a serial interface (SDA and SDC). This serial interface is also used during manufacture and service to connect toan external computer. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701020000.html13.10.2007 10:16:47...
The 1Mbit Flash PROM IC3 contains the operational firmware for the BBIC´s general purpose microprocessor. It is interfaced to the BBIC using address lines A0 to A17, data lines D0 to D7, and control lines CE (Chip Enable), WE (WriteEnable) and OE (Output Enable). TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701030000.html13.10.2007 10:16:50...
The electrically erasable PROM IC2 is used to store all the temporary operating parameters for the handset (see EEPROM LAYOUT ). It uses a two-line serial data interface with the BBIC, with bi- directional data on IC2 pin5 (TP52),and a 45 kHz clock on pin6 (TP53). TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701040000.html13.10.2007 10:16:54...
I2CLK pin (65). Test probe pads SDA and SDC are provided for Flash PROM download with I2DAT and I2CLK respectively. To invoke the flash PROM download mode the MODE_SEL test pad must be connected to the 2.65V pad. A Ground reference Test pad is also provided. Circuit Diagram TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701050000.html13.10.2007 10:16:58...
The burst mode controller processes this stream performing encryption and scrambling, adding the various other fieldsto produce the GAP standard DECT frame, assigning to a time slot and channel etc. to emerge on pin 14 as TXDA. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701060000.html13.10.2007 10:17:00...
HF_AM1 amplifier is deactivated by the SP_CTR control signal at pin 93 from the BBIC. The earpiece speaker LS1 is driven directly from the HON and HOP output lines, pins 40 and 41, without any amplification. A 2.5mm jack J6 is provided for connecting a headset. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701070000.html13.10.2007 10:17:04...
(pin 21, TP101) which is used to drive the PLL circuitry in the RF module. The basic data rate for TXDA (pin 14) and RXDA (pin 10) is 1.152 Mbits/s, whichis 10.368MHz divided by 9. Circuit Diagram http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701080000.html (1 of 2)13.10.2007 10:17:07...
Page 76
TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701080000.html (2 of 2)13.10.2007 10:17:07...
All other keys are connected in a row/column matrix. They are scanned in five rows usingscan pulses (only active when keys are pressed) from IC1 pins 15 to 19. The five key matrix columns are input to the BBIC on pins 51, 52, 53, 57 and 58. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701090000.html13.10.2007 10:17:10...
TOP PREVIOUS NEXT The LCD display receives data via a serial interface. Serial data is sent to the display on pin 6 of the J5 socket, with control lines at pin3 thru 6. Circuit Diagram TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701100000.html13.10.2007 10:17:15...
24 (TP13). A resistor on theSource of the FET provides a current sense at pin 25 (TP12). T3 switches the current through L1. When T3 switches off the back emf conducts through D16 and charges the reservoir cap C4. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701110000.html13.10.2007 10:17:18...
A 2.65V supply is provided for the BBIC and is regulated by the BBIC’s on board control signal LRB (pin 37). This reference is fed to the base of T6 to keep the “VREG+” line at 2.65V. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701120000.html13.10.2007 10:17:22...
D21 protects against the high voltage present on the charge contacts (J3 and J4) when there is no battery in the handset. R42 and C50 provide a signal to the BBIC (pin 27) to detect that the handset has been placed on the base charger. Circuit Diagram http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701130000.html (1 of 2)13.10.2007 10:17:26...
Page 82
TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0701130000.html (2 of 2)13.10.2007 10:17:26...
7.2 RF SECTION TOP PREVIOUS NEXT 7.2.1 BLOCK DIAGRAM RF SECTION (HANDSET) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0702000000.html13.10.2007 10:17:39...
In the transceiver the 10.368MHz clock signal SYCL is multiplied to around 1.9GHz using PLL (Phase Locked Loop) control. The TXDA signal is used to control the modulation of this frequency to 1.87GHz to 1.93GHz. Received signals are demodulated, filtered and sent to the BBIC via the RXDA line. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0702010000.html13.10.2007 10:17:46...
Page 85
DRON VCC1 3.8V VCC2 PAON PMB6610 voltage voltage regulator regulator PMB6818 DECT transceiver TXDA Power amp. VCC1 Printed balun Loop filter TX Part :N/A 32/33 PAON RXON SYRI Printed PLL & SYEN control logic SYDA SYCL RXDSG Printed RXDA Demodulator balun Low IF band pass...
8 CHECK PROCEDURE (BASE UNIT) TOP PREVIOUS NEXT 8.1 EQUIPMENT REQUIRED 8.2 INITIAL POWER TESTS 8.3 SET THE CLOCK FREQUENCY 8.4 LOOPBACK TESTS 8.5 TELEPHONE LINE TESTS 8.6 CHARGE CURRENT TESTS 8.7 TAM VOICE PROMPT DOWN LOAD TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0800000000x.html13.10.2007 10:18:01...
2. Check for approx. 100mA current on the 9V supply line. 3. Check the 3.8V supply rail at TP91. It must be 3.8V ± 0.2V. 4. Check the 2.8V supply rail at J100. It must be 2.8V ± 0.2V. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0802000000.html13.10.2007 10:18:28...
6. The clock frequency should be within 10,368,000Hz ± 10Hz. If not then enter "SETFREQ nn nn" where nn nn are the clock frequency adjustment values. An increase in the value will lower the clock frequency and vice versa. The maximum valueis 03 FF. 7. Switch off the 9V supply. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0803000000.html13.10.2007 10:18:32...
14. Check deviation or modulation (max ± B field) with data type "FIG 31": must be 320kHz to 400kHz. 15. Press Menu Up "↑" on the CMD60. 16. Press POWER RAMP. 17. Check that the burst fits the mask. http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0804000000.html (1 of 2)13.10.2007 10:18:35...
Page 91
21. Press Menu Up "↑" on the CMD60. 22. Press BEARER RELEASE and switch off the 9V supply. 23. Disconnect the RF cable from the PCB. Note: These tests can also be repeated on TRAFFIC CARRIERS 5 and 9. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0804000000.html (2 of 2)13.10.2007 10:18:35...
15. Check that the lower frequency is detected by the line/DTMF test set. Must be 852Hz ± 1.5%. 16. Switch off the 9V power supply. 17. Disconnect the telephone line and reconnect the base to the Bell oscillator. 18. Switch on the 9V supply. http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0805000000.html (1 of 2)13.10.2007 10:18:38...
Page 93
20. Switch the bell oscillator on to 23Hz, 30V RMS. 21. Send the batch file "RINGDET". 22. Check that the Number on the PC display has changed to "1". 23. Switch off the 9V power supply. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0805000000.html (2 of 2)13.10.2007 10:18:38...
1. Switch on the 9V power supply. 2. Connect an ammeter directly across the charge terminals (effectively short circuiting them). 3. Measure 270mA ± 15% through the meter. 4. Switch off the 9V power supply. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0806000000.html13.10.2007 10:18:41...
2. Connect the serial cable from the PROM DOWN LOADER to J102, J103 and J104 of base P.C.B. 3. Switch on the 9V supply. 4. Invoke “vploadenable” batch file from the PC. 5. Invoke “go” batch file from the PC. 6. Display of “Save EW Function OK” from PC and conplete. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0807000000.html13.10.2007 10:18:44...
9 CHECK PROCEDURE (HANDSET) TOP PREVIOUS NEXT 9.1 EQUIPMENT REQUIRED 9.2 INITIAL POWER TESTS 9.3 SET CLOCK FREQUENCY 9.4 LOOPBACK TESTS TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0900000000x.html13.10.2007 10:19:04...
4. Check the 3.8V supply rail at TP11. It must be 3.8V ± 0.2V. 5. Check the 2.65V supply rail at the collector of transistor T6. It must be 2.65V ± 0.2V. 6. Switch off the 2.4V supply. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0902000000.html13.10.2007 10:19:11...
8. The clock frequency should be within 10,368,000Hz ± 10Hz. If not then enter "SETFREQ nn nn" where nn nn are the clock frequency adjustment values. An increase in the value will lower the clock frequency and vice versa. The maximum valueis 01 FF. 9. Switch off the 2.4V supply. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0903000000.html13.10.2007 10:19:14...
14. Check frequency drift: must be 0 ± 35 kHz/ms. 15. Check frequency offset: must be 0 ± 40 kHz. 16. Check deviation or modulation (max ± B field) with data type "FIG 31": must be 320kHz to 400kHz. http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0904000000.html (1 of 2)13.10.2007 10:19:17...
Page 101
25. If the "SETBASE" operation above was carried out then enter "RESBASE" to de-register. 26. Disconnect the RF cable. Note: Step 2 to 24 can be repeated for TRAFFIC CARRIERS 0 and 9. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s0904000000.html (2 of 2)13.10.2007 10:19:17...
10.3 HANDSET: DOES NOT LINK 10.4 BATTERY DOES NOT CHARGE 10.5 NO VOICE RECEPTION 10.6 NO VOICE TRANSMISSION 10.7 BASE UNIT: DOES NOT LINK 10.8 BASE UNIT : CALLER ID PROBLEMS 10.9 BASE UNIT: TAM VOICE PROMPT PROBLEMS TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1000000000x.html13.10.2007 10:19:23...
10.1 HANDSET: DOES NOT OPERATE TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1001000000.html13.10.2007 10:19:27...
Page 106
TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1002000000.html (3 of 3)13.10.2007 10:19:32...
Page 107
10.3 HANDSET: DOES NOT LINK TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1003000000.html13.10.2007 10:19:36...
10.4 BATTERY DOES NOT CHARGE TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1004000000.html13.10.2007 10:19:39...
10.6 NO VOICE TRANSMISSION TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1006000000.html13.10.2007 10:19:47...
10.7 BASE UNIT: DOES NOT LINK TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1007000000.html13.10.2007 10:19:51...
10.8 BASE UNIT : CALLER ID PROBLEMS TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1008000000.html13.10.2007 10:19:55...
10.9 BASE UNIT: TAM VOICE PROMPT PROBLEMS TOP PREVIOUS NEXT Cross Reference TAM VOICE PROMPT DOWN LOAD HANDSET: LINK HANDSET: DOES NOT LINK NO VOICE RECEPTION EEPROM LAYOUT (BASE UNIT) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1009000000.html13.10.2007 10:19:59...
11 CABINET AND ELECTRICAL PARTS LOCATION (BASE UNIT) TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1100000000x.html13.10.2007 10:20:07...
12 CABINET AND ELECTRICAL PARTS LOCATION (HANDSET) TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1200000000x.html13.10.2007 10:20:15...
13 ACCESSORIES AND PACKING MATERIALS TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1300000000x.html13.10.2007 10:20:23...
3. The S mark means the part is one of some identical parts. For that reason, it may be different from the installed part. 4. RESISTORS & CAPACITORS Unless otherwise specified; All resistors are in ohms (Ω) K=1000Ω, M=1000kΩ All capacitors are in MICRO FARADS (μF) P=μμF *Type & Wattage of Resistor http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1400000000p.html (1 of 2)13.10.2007 10:20:32...
Page 121
14.1 Base Unit 14.1.1 CABINET AND ELECTRICAL PARTS 14.1.2 MAIN P.C.BOARD PARTS 14.1.3 RF MODULE 14.2 Handset 14.2.1 CABINET AND ELECTRICAL PARTS 14.2.2 MAIN P.C.BOARD PARTS 14.2.3 ACCESSORIES AND PACKING MATERIALS TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1400000000p.html (2 of 2)13.10.2007 10:20:32...
14.1 Base Unit TOP PREVIOUS NEXT 14.1.1 CABINET AND ELECTRICAL PARTS 14.1.2 MAIN P.C.BOARD PARTS 14.1.3 RF MODULE TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1401000000.html13.10.2007 10:20:38...
LOWER CABINET PQSA10124Z ANTENNA, MAIN PQBC10324Z1 PAGE BUTTON PQGT14747Z NAME LABEL PQJT10173Z CHARGE TERMINAL PQKE10121Z5 CHARGE CASE PQKE10122Z5 CHARGE CASE HOLDER PQKE10123Z1 CHARGE TERMINAL CASE S PQKM10473W5 UPPER CABINET PQUS10266Z CRICK SPRING QUSA00001Z ANTENNA, SUB TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1401010000.html13.10.2007 10:20:40...
14.1.3 RF MODULE TOP PREVIOUS NEXT Ref. No. Part No. Part Name & Description Remarks PCB2 PQLZ10015Z RF MODULE (IC4) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1401030000.html13.10.2007 10:20:48...
14.2 Handset TOP PREVIOUS NEXT 14.2.1 CABINET AND ELECTRICAL PARTS 14.2.2 MAIN P.C.BOARD PARTS 14.2.3 ACCESSORIES AND PACKING MATERIALS TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1402000000.html13.10.2007 10:20:54...
Part No. Part Name & Description Remarks PQJA10075Z TEL CORD PQKE10120Z2 BELT CLIP PQLV1CEZ AC ADAPTOR PQQX13084Z INSTRUCTION BOOK XZB18X22A02 POLY BAG (for Base Unit) PQPP10084Z POLY BAG (for Handset) PQPK13351Y CARTON BOX PQPN11679Z ADAPTOR PAD TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1402030000.html13.10.2007 10:21:05...
15.3.4 Audio Setup 15.3.5 BsNalTask 15.3.6 PSTN Line 15.3.7 Clip configuration 15.3.8 TADTASK 15.3.9 BsUiTask 15.3.10 Bs Model Settings 15.4 Appendix 15.4.1 Gain for transmit and receive 15.4.2 Gain for tonegenerator 15.4.3 Amplification by Shift& Add coeffecients http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1500000000x.html (1 of 2)13.10.2007 10:21:13...
Page 144
15.4.4 Gain index values 15.4.5 Speakerphone gain TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1500000000x.html (2 of 2)13.10.2007 10:21:13...
0000 and 0001, some are set by the user configuration e.g. ringer volume at address0210, and some are set during normal use of the phone e.g. meter pulse billing at address 1040..015F. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1501000000.html13.10.2007 10:21:16...
1’s (byte: 0xFF, word FFFFh), i, e.it has never been set. EEPROM location which is not set at all. default Same as D but best-guess value and/or not verified. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1502000000.html13.10.2007 10:21:22...
Ipui for handset 5. If set to FF .. FF the handset is not enrolled. 0049-004D FF .. FF IPUI_6 Ipui for handset 6. If set to FF .. FF the handset is not enrolled. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503010000.html13.10.2007 10:21:32...
Meter-pulse billing total for HS3 0153-0156 00..00 MpBill.Hs4 Meter-pulse billing total for HS4 0157-0159 00..00 MpBill.Hs5 Meter-pulse billing total for HS5 015A-015D 00..00 MpBill.Hs6 Meter-pulse billing total for HS6 015E-015F FF..FF Freeblock0 Free block 0 TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503020000.html13.10.2007 10:21:36...
Name Type Description RunTimeErrorLogConfig Reserved Not used yet 161-162 00..00 RunTimeErrorLogAddress Last RunTime error (unit16) 163-164 00..00 RunTimeErrorCounter Number of runtime errors since last default programming (unit16) 0165 - 01FF FF..FF FreeBlock1 Free Block 1 TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503030000.html13.10.2007 10:21:39...
RingerVolumeDataSpkr 0 during power up in non-buzzer models! 0212 RingerVolumeData 1 Volume data for ringer volume step 1. Range 0-50. Buzzer models only. This location is overwritten by the RingerVolumeDataSpkr 1 during power up in non-buzzer models! http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503040000.html (1 of 2)13.10.2007 10:21:43...
Page 152
ToneFilter 1 A1 register 022D 0xF4 ToneFilter 2 K register 022E 0x09 ToneFilter 2 GE register 022F 0x21 SoftLimiter1 LIM_HIGH 0230 0x18 SoftLimiter1 LIM_LOW 0231 0x40 SoftLimiter2 LPOR + TIM_OVR 0232 0x21 SoftLimiter2 TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503040000.html (2 of 2)13.10.2007 10:21:43...
5: InterDigitLowImp. controls interdigit impedance. 1: keep low-impedance during interdigit pause normal impedance during interdigit pause 6: LowImpLineSeizure. Special low-imp line seizure (Australian) , 1=enable, 0=disable 7: TwoLines. line config 0= one line ,1=two lines Defaults to 0000 0111B. http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503060000.html (1 of 3)13.10.2007 10:21:51...
Page 156
RingTermToU100 Ring terminate time-out period. This is the max time that must elapse between two ring-voltage bursts before the new ring-voltage is registered as a new incoming call. Unit: 100 ms.defaults to approx 10 sec http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503060000.html (2 of 3)13.10.2007 10:21:51...
Page 157
Bit4..7: init dial pause if DTMF dial-mode. if 0fH then normal dial-pause is used. Unit : 500 ms, min/max: 00/0F. Defaults to 3 sec and 3 sec 0F17..1BB FF..FF Reserved[5] TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503060000.html (3 of 3)13.10.2007 10:21:51...
7: DSC time selection 0: immediately / 1:1.6sec 0F62 0x00 Tam PrgRings Current number of rings for answer ON Range:0-7(0=Auto) 0F63-64 0xFFFF Tam Prg Rmt Code Current Remote code e.g. 123 Address 0x0F63 0xF1 Address 0x0F64 0x23 http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503080000.html (1 of 2)13.10.2007 10:21:58...
Page 160
Tam Rings DefNum Number of rings default data 0: Default is Automatically Turn on for Toll saver Other: Default of the number of rings for Turn on. 0F6B-0FF7 Free block Free Block TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503080000.html (2 of 2)13.10.2007 10:21:58...
0x04 = TCD725 0x05 = TCD735 Warning: if this locationcontains 0xFF the EEPROM is considered un-initialized and application will be disabled! In this case only bus access is available to allow the EEPROM to be defaulted. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1503100000.html13.10.2007 10:22:05...
15.4 Appendix TOP PREVIOUS NEXT 15.4.1 Gain for transmit and receive 15.4.2 Gain for tonegenerator 15.4.3 Amplification by Shift& Add coeffecients 15.4.4 Gain index values 15.4.5 Speakerphone gain TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1504000000.html13.10.2007 10:22:10...
19/0x13 -2 dB 0x1C86 20/0x14 -1 dB 0x2001 21/0x15 0 dB 0x23E8 22/0x16 +1 dB 0x284A 23/0x17 +2 dB 0x2D35 24/0x18 +3 dB 0x32B9 25/0x19 +4 dB 0x38E9 26/0x1A +5 dB 0x3FDB 27/0x1B +6 dB http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1504050000.html (1 of 2)13.10.2007 10:22:33...
Page 171
0x47A6 28/0x1C +7 dB 0x5064 29/0x1D +8 dB 0x5A33 30/0x1E +9 dB 0x6534 31/0x1F +10 dB 0x718E 32/0x20 +11 dB 0x7F69 33/0x21 +12 dB TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1504050000.html (2 of 2)13.10.2007 10:22:33...
0000..01, some are set by the user when configuring the handset e.g. ringer volume at0F38, and some during normal use of the phone e.g. redial memory at 0311..0392. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1601000000.html13.10.2007 10:22:43...
The EEPROM location is set during the production test and should not be overwritten. The value is set by the eeprom default loader only if the location contains 0xFF, i, e. it has never been set. EEPROM location which is not set at all. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1602000000.html13.10.2007 10:22:47...
16.3 EEPROM contents TOP PREVIOUS NEXT 16.3.1 General Setup 16.3.2 MMI parameters 16.3.3 Audiosettings 16.3.4 MMI 16.3.5 MMI Bits TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1603000000.html13.10.2007 10:22:51...
Service class for registration 2 0136 LAL_2 Location area level for registration 2 0137 IPUI_LEN_2 IPUI length for registration 2 0138-0144 ?? .. ?? IPUI_2 IPUI for registration 2 0145 ZAP_2 ZAP for registration 2 http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1603010000.html (1 of 2)13.10.2007 10:22:56...
Page 177
IPUI for registration 4 01A5 ZAP_4 ZAP for registration 4 01A6 STATUS_4 Status for registration 4 01A7-01B6 ?? .. ?? UAK_4 UAK for registration 4 01B7-01FF ?? .. ?? Reserved Protocol data TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1603010000.html (2 of 2)13.10.2007 10:22:56...
08 = Greek 09 = Turkish 0A = Hungarian 0B = Portugese 0C = Russian 0D = Polish 0E = Slovakian 0F = Czech 10 = German 11 = English Language Language code (see table above) http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1603020000.html (1 of 2)13.10.2007 10:22:59...
Page 179
Bit 7: 0:Disable, 1:Enable Czech Bit 0: 0:Disable, 1:Enable German Bit 1: 0:Disable, 1:Enable English Bit 2-7: Reserved 2B1-2BA 0x41 Category RunTimeErrorLogConfig 00 = Show RunTimeErrorLog disabled. 2BC-2BD 0000 RunTimeErrorLogAddress 0000 = No error. TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1603020000.html (2 of 2)13.10.2007 10:22:59...
Melody played when alarm is sounded EERingerVolume Volume of the ringer EEVoiceVolume Volume of the earpice EESpVolume Volume of the speakerphone EETAMVoiceVolume Volume of the earpice when in TAM EETAMSpPhVolume Volume of the speakerphone when in TAM TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1603030000.html13.10.2007 10:23:02...
High byte of sorted list checksum for Phonebook 1EF0 PhbSortListChecksumLow Low byte of sorted list checksum for Phonebook 1EF1 PhbSortListFlag Byte used as a flag in the Phonebook 1EF2 AlphabetKeyMode Stored keyboard alphabet mode Default to Alphabet (“ABC”) TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1603040000.html13.10.2007 10:23:06...
17 SCHEMATIC DIAGRAM (BASE UNIT) TOP PREVIOUS NEXT 17.1 Main 17.2 RF Module TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1700000000x.html13.10.2007 10:23:17...
17.1 Main TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1701000000.html13.10.2007 10:23:19...
Page 185
+48V DC ON-HOOK +6.8V DC OFF-HOOK LINE VOLTAGE 48V DC +100mVrms at 1kHz (at 40mA) N.M. N.M. 48V DC CLIP (CALLER ID 1.4V DC IC10 +2.8V PULLS TOWARDS N.M. N.M. 0V DURING RING 3.8V DC 2.8V DC CHARGE PULSE 12V DC RING HANDSET ON CHARGE +12V...
Page 186
0V DC ON-HOOK 0V DC ON-HOOK +6.7V DC OFF-HOOK +3.6V DC OFF-HOOK N.M. RX-AF TX-AF 470K 0V DC ON-HOOK +2.8V DC OFF-HOOK FREQUENCY: 96kHz 2.8V 10.368MHz burst +2.0V peak RX-DATA TX-DATA KX-TCD725RUM: SCHEMATIC DIAGRAM BASE UNIT...
18 SCHEMATIC DIAGRAM (HANDSET) TOP PREVIOUS NEXT 18.1 Main 18.2 RF Section 18.3 Memo TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1800000000x.html13.10.2007 10:23:39...
18.1 Main TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1801000000.html13.10.2007 10:23:42...
Page 192
Frequency 160kHz 4.1V 3.8V DC 2.4V 2.65V DC 3.4V to 4.8V SWITCHING DURING CHARGE 7.2V 2.2V LED ON 0V LED OFF 2.65V...
Page 193
3.8V DC Frequency 10.368MHz RX-AF TX-AF 1.8V DC IN TALK MODE To RF SECTION 2.65V RX-DATA TX-DATA 10.368MHz burst 2.65V s typically 0.8V KX-TCD725RUM: SCHEMATIC DIAGRAM (HANDSET) Handset...
18.3 Memo TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1803000000.html13.10.2007 10:24:00...
Page 198
19 CIRCUIT BOARD (BASE UNIT) TOP PREVIOUS NEXT 19.1 Component View 19.2 Flow Solder Side View TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1900000000x.html13.10.2007 10:24:31...
Page 199
19.1 Component View TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1901000000.html13.10.2007 10:24:34...
Page 201
19.2 Flow Solder Side View TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s1902000000.html13.10.2007 10:24:43...
Page 203
20 CIRCUIT BOARD (HANDSET) TOP PREVIOUS NEXT 20.1 Component View 20.2 Flow Solder Side View TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s2000000000x.html13.10.2007 10:24:52...
Page 204
20.1 Component View TOP PREVIOUS NEXT TOP PREVIOUS NEXT http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s2001000000.html13.10.2007 10:24:54...
Page 206
20.2 Flow Solder Side View TOP PREVIOUS TOP PREVIOUS http://202.224.189.179/view_new/OT/KX-TCD725RUM/SVC/s2002000000.html13.10.2007 10:25:03...
