- Page 1 CP 1628 Preface Description of the device SIMATIC NET Software installation Hardware installation PG/PC - Industrial Ethernet CP 1628 Configuration Technical specifications Operating Instructions Approvals 06/2021 C79000-G8976-C280-09...
- Page 2 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.
-
Page 3: Table Of Contents
Table of contents Preface ..............................5 Description of the device ........................9 Software installation ........................... 13 Installing the driver ......................13 Installing the "SIMATIC NET PC Software" ................13 Uninstalling the "SIMATIC NET PC Software" ............... 14 Hardware installation .......................... 15 Configuration ............................ - Page 4 Table of contents CP 1628 Operating Instructions, 06/2021, C79000-G8976-C280-09...
-
Page 5: Preface
• "SIMATIC STEP 7 Professional" DVD Please check that the consignment you have received is complete. If the consignment is incomplete, contact your supplier or your local Siemens office. Validity of this documentation These operating instructions are valid for the following product: •... - Page 6 • Configuration manual Commissioning PC Stations This provides you with detailed information on commissioning and configuring SIMATIC NET PC communications modules. Entry ID: 77377601 (https://support.industry.siemens.com/cs/ww/en/view/77377601) • SIMATIC NET - Industrial Communication with PG/PC – Volume 1 – Basics (system manual) Entry ID: 77376110 (https://support.industry.siemens.com/cs/ww/en/view/77376110)
- Page 7 HARDNET, SOFTNET, CP 1612, CP 1613, CP 5612, CP 5613, CP 5614, CP 5622 Industry Online Support In addition to the product documentation, you are supported by the comprehensive online information platform of Siemens Industry Online Support at the following Internet address: Link: (https://support.industry.siemens.com/cs/de/en/) Apart from news, there you will also find: •...
- Page 8 In order to protect plants, systems, machines and networks against cyber threats, it is necessary to implement – and continuously maintain – a holistic, state-of-the-art industrial security concept. Siemens’ products and solutions form one element of such a concept. Customers are responsible for preventing unauthorized access to their plants, systems, machines and networks.
-
Page 9: Description Of The Device
CP 1628 purchased after May 2021. Plus, any future security vulnerabilities can no longer be published in a Security Advisory – due to the fact the Siemens no longer has any knowledge of such vulnerabilities – and such vulnerabilities also are no longer removed. - Page 10 Description of the device • Encrypted firmware that is signed and transferred to the CP 1628 • Integrated security (firewall, VPN) Note All CP 1613 and CP 1623 software products can be operated with the CP 1628. Hardware requirements The CP 1628 requires a PCIe slot (PCI express x1; can also be operated in x4, x8 or x16 slots). LED display The following graphic shows the front panel of the CP 1628 communications processor: Connecting socket for optional external power supply...
- Page 11 Description of the device The table describes the LED displays that indicate the operating states: Description Power/fault LED No external power supply con- nected, no fault Green External power supply connect- Red (flashing) Module fault/error 2 port LEDs in each port (green and No cable connected •...
- Page 12 Description of the device CP 1628 Operating Instructions, 06/2021, C79000-G8976-C280-09...
-
Page 13: Software Installation
Install the software as described in the installation manual "SIMATIC NET PC Software". You will find this installation manual on the Product Support pages under the following entry ID: 77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602) You should also note the current information on the "SIMATIC NET PC Software" on the Product Support pages in: (https://support.industry.siemens.com/cs/ww/en/ps/15362/pm) -
Page 14: Uninstalling The "Simatic Net Pc Software
Uninstall the entire software package as described and recommended in the installation manual "SIMATIC NET PC Software". You will find the installation manual on the "SIMATIC NET PC Software" DVD or on the Product Support pages under the following entry ID: 77377602 (https://support.industry.siemens.com/cs/ww/en/view/77377602) CP 1628 Operating Instructions, 06/2021, C79000-G8976-C280-09... -
Page 15: Hardware Installation
"Communication Settings" tool on the "Operating data" properties page. Notes on passive network components You will find important notes on the use of passive network components in the document "Industrial Ethernet / PROFINET Passive network components" (https://support.industry.siemens.com/cs/ww/en/view/84922825). CP 1628 Operating Instructions, 06/2021, C79000-G8976-C280-09... - Page 16 Hardware installation Procedure To install and connect up the CP 1628 follow the steps outlined below: Note When handling the communications processor, make sure that you do not touch the connectors or the electronic components. 1. Turn off your PC and pull out the power cable connector from the socket. 2.
-
Page 17: Configuration
Configuration The following engineering or configuration tools are available to allow you to configure the communications processor: • STEP 7 V5.5 (not included in the scope of delivery) • STEP 7 Professional (TIA Portal) • Communication Settings (COML S7) • "SCT" (Security Configuration Tool) as additional package for STEP 7 as of V5.5.3 (part of the DVD "Security Configuration Tool"... -
Page 18: Configuring Security
Configuration Tool) that can be called up in STEP 7 as of V5.5.3. You will find further information in the configuration manual "Industrial Ethernet Security – Basics and Application". You will find this document on the Internet under the following entry ID: 109738463 (https://support.industry.siemens.com/cs/ww/en/view/109738463) CP 1628 Operating Instructions, 06/2021, C79000-G8976-C280-09... -
Page 19: Technical Specifications
Technical specifications CP 1628 The following technical specifications apply to the CP 1628 communications processor: Data transfer Transmission speed • 10/100 Mbps (half/full duplex) • 1000 Mbps (full duplex) Interfaces Connection to 10BaseT/100BaseTx/ 1000BaseT RJ-45 ports (two) Connector for PG/PC PCI Express x1;... - Page 20 Technical specifications Construction Module format • Standard height • half length Dimensions (H x W x D) in mm 126.3 x 21.6 x 180.5 Weight 124 g Space required PCIe slot External power supply The following technical specifications refer to the external power supply: Requirements of the external power supply Electrical isolation required...
-
Page 21: Approvals
Declaration of conformity You will find the declaration of conformity for this communications processor on the Product Support pages under the following entry ID: 58826997 (https://support.industry.siemens.com/cs/ww/en/view/58826997) C-TICK approval The communications processor meets the requirements of the Australian AS/NZS 3548 standard according to EN 61000-6-3. - Page 22 • Consult the dealer or an experienced radio/TV technician for help. Siemens AG is not responsible for any radio television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Siemens AG. The correction of interference caused by such unauthorized modification, substitution or attachment will be the responsibility of the user.
