- Page 1 2TMD042000D0042 │ 08.02.2021 Product manual ABB-Welcome IP H81402FR-. Outdoor station, IP touch 10, Face Recognition...
-
Page 2: Table Of Contents
Tab le of c ont e nts Notes on the instruction manual ......................4 Safety ..............................4 Intended use ............................5 Environment ............................6 ABB devices ..........................6 Product description ..........................7 Device type ..........................7 Control elements........................8 Terminal description ........................9 Lock type and connection ...................... - Page 3 Table of contents 10.3 Deployment guideline....................... 39 10.4 Upgrading..........................39 10.5 Backup/Restore ........................39 10.6 Malware prevention solution ..................... 39 10.7 Password rule .......................... 39 Notice ..............................40 │3 Product manual 2TMD042000D0042...
-
Page 4: Notes On The Instruction Manual
Please keep this manual in a safe place. If you pass the device on, also pass on this manual along with it. ABB accepts no liability for any failure to observe the instructions in this manual. Safety... -
Page 5: Intended Use
Intended use Intended use As part of the ABB-Welcome IP system, this device can only be used with accessories from that system. Security mode This outdoor station runs in "Security mode" by default to guarantee high security. In "Security mode", this outdoor station requires a certificate issued by the management software before it can function normally. -
Page 6: Environment
ABB devices All packaging materials and devices from ABB bear the markings and test seals for proper disposal. Always dispose of the packing materials and electric devices and their components via an authorized collection facility or disposal company. -
Page 7: Product Description
Product description Product description Device type Article Product ID Product name Colour Size (mm) number Stainless H81402FR-S 2TMA130011X0001 OS, IPtouch 10, FR 408 x 278 x 35 steel │7 Product manual 2TMD042000D0042... -
Page 8: Control Elements
Product description Control elements Function Camera Speaker and microphone IC card reader Keypad End strip 10.1" touch display │8 Product manual 2TMD042000D0042... -
Page 9: Terminal Description
Product description Terminal description Function Connector for device software update (can be carried out at the factory only) Connector for Wiegand output It supports 26 bits and 34 bits Reset button Connector for software debugging (for factory use only) Connector for exit button Connector for the sensor used for door status detection Plug-in clamps (DC+...GND) for power supply Plug-in clamps (LOCK...GND) for door opener... -
Page 10: Lock Type And Connection
Product description Lock type and connection Lock type Operation type Voltage Wiring type Electrical strike ⎓ Power on to open Type A/B 12 V lock, 12V Electrical strike ⎓ Power on to open Type B 24 V lock, 24V Electrical rim ⎓... -
Page 11: Technical Data
Technical data Technical data Designation Value ⎓ Rating voltage 24 V ⎓ Operating voltage range 20-27 V ⎓ 27 V , 630 mA Rating current ⎓ 24 V , 700 mA Operating temperature -20 °C…+55 °C Camera type CMOS Camera viewing angle 90°... -
Page 12: Mounting/Installation
Mounting/Installation Mounting/Installation Warning Electric voltage! Dangerous currents flow through the body when coming into direct or indirect contact with live components. This can result in electric shock, burns or even death. – Disconnect the mains power supply prior to installation and/or disassembly! –... -
Page 13: Mounting
Mounting/Installation Mounting 7.2.1 Preparation Use gloves to protect yourself against cuts. 7.2.2 Installation height Distance and installation height (unit: mm) Distance and installation height (unit: m m ) 15° 30° 53° 53° 53° 2466 2028 1858 1500 1487 1431 1417 1323 1280 1198... - Page 14 Mounting/Installation Note The following installation situations must be avoided without fail to ensure picture quality: ■ Direct light ■ Direct sunlight ■ Extremely bright picture background ■ Highly reflective walls on the opposite side of the door station │14 Product manual 2TMD042000D0042...
-
Page 15: Flush-Mounted Installation
Mounting/Installation 7.2.3 Flush-mounted installation A1: Without pre-installation box with pre-installation box A2: With pre-installation box Flush-mounted installat on │15 Product manual 2TMD042000D0042... -
Page 16: Dismantling
Mounting/Installation 7.2.4 Dismantling │16 Product manual 2TMD042000D0042... -
Page 17: Commissioning
Commissioning Commissioning Welcome screen This outdoor station will display the "Welcome screen" if no operation is carried out within 10 seconds and the screen will play the bulletins or the screensaver images in a circle before it goes off. The screen closing time can be set in "System settings" >> "Display" > "Turn off the screen". -
Page 18: Home Screen
Commissioning Home screen On the welcome screen, when the face is recognized or click any area on the screen to access the home screen. │18 Product manual 2TMD042000D0042... -
Page 19: Entering The "Settings" Screen
Commissioning Entering the "Settings" screen In standby status, on the home screen, tap "PIN code unlock", then press [#] [*] [engineering password] [#] to access the "Settings" screen. │19 Product manual 2TMD042000D0042... - Page 20 Commissioning Note The engineering password must be changed the first time you access the engineering settings. (The system default is 345678. This password should only be used for initial setting work and should be changed to another password. It cannot be used as the actual password) Note If an incorrect engineering password is entered 5 times within 2 minutes, no further attempts are permitted for the next 1 minute.
-
Page 21: Engineering Settings
Commissioning Engineering settings On the "Settings" screen, tap "Engineering settings" to access the corresponding screen. Level 1 Level 2 Level 3 Option Block no. Outdoor station: 001...999 ■ Outdoor station Device type Device attribute ■ Gate station ■ Outdoor station: 01...64 Device no. -
Page 22: Access Control Settings
Commissioning Access control settings On the "Settings" screen, tap "Access control" to access the corresponding screen. Level 1 Level 2 Level 3 Option ■ Private password ■ Off (default) Password ■ On, 3...8 digits Public password ■ Off (default) ■ On (default) Card mode Safe mode... - Page 23 Commissioning When "Safe mode" is set to "On", this outdoor station will only support IC cards with a token. The IC cards enrolled on local outdoor station will sync the data with the management software. When the "Lift control" function is enabled, you need to set the current floor number. The local outdoor station can remove the IC cards enrolled locally or enrolled on the management software, but the management software cannot remove the IC cards enrolled on the local outdoor station.
-
Page 24: System Settings
Commissioning System settings On the "Settings" screen, tap "System settings" to access the corresponding screen. Level 1 Level 2 Level 3 Option Call volume 1...5 System volume 1...5 Sound settings ■ On (default) Voice prompts ■ ■ On (default) Ringtone feedback ■... - Page 25 Commissioning Level 1 Level 2 Level 3 Option Lock-GND NO-NC-COM Subsidiary lock ■ Power lock (ID range: 1...32) IP actuator ■ Relay lock (ID range: 1...32) ■ On (default) Face recognition unlock ■ Unlock mode configuration ■ On (default) QR code unlock ■...
- Page 26 Commissioning Level 1 Level 2 Level 3 Option Reset user Reset settings ■ Major version ■ MCU version ■ Hardware version Version ■ Card version ■ Keypad version The number is used to obtain System settings the certificate issued by the Serial number Help management software.
-
Page 27: Operation
Operation Operation Call a resident via keypad On the home screen, tap "Call", then enter [address] to initiate a call. ■ When the device type is set to "Outdoor station", [address] = room number (e.g. "0101"). When the device type is set to "Gate station", [address] = block number & room number ■... -
Page 28: Call Guard Unit
Operation Call guard unit Precondition On the "Settings" screen, complete the following settings: ■ "Engineering settings" >> "System attribute" >> "Call guard unit" >> "On" >> "Address of default guard unit" >> enter the guard unit number (1~32) Call guard unit On the home screen, tap "Call guard unit"... -
Page 29: Releasing The Lock By Entering A Password
Operation Releasing the lock by entering a password 9.3.1 Releasing the lock with a password set on the indoor station Precondition On the "Settings" screen of the outdoor station, follow the steps below: ■ "Access control" >> "Password" >> "Private password" >> "On" On the "System settings"... - Page 30 Operation Releasing the lock On the home screen of the outdoor station, tap "PIN code unlock", ■ When the "Device type" is set to "Outdoor station", tap [*] [room number] [#] [password] [#] ■ When the "Device type" is set to "Gate station", tap [*] [building number] [#] [room number] [#] [password] [#] followed by "...
-
Page 31: Releasing The Lock With A Password Set On The Local Outdoor Station
Operation 9.3.2 Releasing the lock with a password set on the local outdoor station Precondition On the "Settings" screen, follow the steps below: ■ "Access control" >> "Password" >> "Public password" >> "On" >> enter a 3-8 digit password. Password rule This password must not include continuously increasing or decreasing numbers (e.g. -
Page 32: Releasing The Lock With A Password Set On The Welcome App
Operation 9.3.3 Releasing the lock with a password set on the Welcome App Precondition You need to create an unlock password on the Welcome App. For more information, please see the Welcome App product manual. Note The indoor station should be added to the trusted list of the outdoor station before use. -
Page 33: Releasing The Lock With A Password Set In The Management Software
Operation 9.3.4 Releasing the lock with a password set in the management software Precondition You need to create an unlock password in the management software. For more details, please see the management software product manual. Releasing the lock On the home screen of the outdoor station, tap "PIN code unlock", enter the [password], followed by "... -
Page 34: Releasing The Lock With A Qr Code Set On The Welcome App
Operation Releasing the lock with a QR code set on the Welcome App You need to pair the Welcome App with an indoor station before this function is used. 1. Create an unlock QR code Please see the Welcome App product manual for more details. 2. - Page 35 Operation Releasing the lock Please follow the steps below: [1] On the home screen of the outdoor station, tap "QR code unlock", a green line will be displayed on the screen and moves from top to down. [2] Place the QR code on your mobile in front of the camera on the outdoor station to release the lock.
-
Page 36: Releasing The Lock By Swiping Ic Cards
Operation Releasing the lock by swiping IC cards Swipe a registered IC card on the specified area to release the lock. IC card specification Operating frequency 13.56 MHz Standard ISO 14443A Support card Mifare one S50/S70, Mifare desfire EV1/EV2 Output format Wiegand 26/34 bit │36 Product manual 2TMD042000D0042... -
Page 37: Releasing The Lock By A Face
Operation Releasing the lock by a face If your face has been registered in advance, when you approach the outdoor station, the outdoor station will recognize your face and release the lock ("Face recognize successfully" will be displayed on the screen and the voice prompt (e.g. "Door is open") will be played in the same time if the "Voice prompt"... -
Page 38: Cyber Security
H81402FR-. product, the network, its system and interfaces against any kind of security breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information. ABB and its affiliates are not liable for damages and/or losses related to such security breaches, unauthorized access, interference, intrusion, leakage and/or theft of data or information. - Page 39 Malware prevention solution The H81402FR-. device is not susceptible to malware, because custom code cannot be executed on the system. The only way to update the software is via firmware upgrades. Only firmware signed by ABB can be accepted. 10.7 Password rule The user must change the engineering password when accessing the engineering settings for the first time.
