Sealey VSE127H Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to instruction Wear eye
manual protection
1. SAFETY
WARNING! Ensure Health and Safety, local authority and general workshop practice regulations are adhered to when using tools.
‰
IMPORTANT: These instructions are provided as a guide only. Always refer to the vehicle manufacturer's service instructions, or a
‰
proprietary manual, to establish the current procedure and data, also any warnings or cautions particular to the vehicle.
DO NOT use the set if any parts are missing or damaged.
8
DO NOT use this tool for any purpose other than that for which it is designed.
8
Switch off vehicle's ignition before commencing work under the car.
9
Ensure the vehicle is adequately supported with axle stands, ramps and chocks as necessary.
9
Wear approved eye and hand protection. A full range of personal safety equipment is available from your Sealey stockist.
9
Wear suitable clothing to avoid snagging. DO NOT wear jewellery and tie back long hair.
9
IMPORTANT: The force screw must be kept well lubricated.
‰
IMPORTANT: Mark a line giving installation position of ball joint on control arm in order to show correct position when installing new
‰
ball joint (fig.2).
Keep children and other unauthorised persons away from the working area.
9
Maintain the tool components in good and clean condition for best and safest performance.
9
When work on the vehicle is finished, ensure all connections on vehicle are restored, and that there are no tools left in or on the
9
vehicle.
Replace tools in the carrying case and store in a safe, dry, childproof location.
9
Use only on vehicles specified.
9
2. INTRODUCTION
Remove and install press-fit control arm ball joints on BMW 3 Series E36 vehicles. Use in situ, there is no requirement to remove the
control arm from the vehicle. Includes all necessary adaptors. Simple, easy hydraulic ram action.
3. CONTENTS
Item Part No.
1 VSE127H.01
2 VSE127H.02
3 VSE127H.03
4 VSE127H.04
5 VSE127H.05
6 VSE127H.06
7 VSE127H.07
8 VSE127H.08
© Jack Sealey Limited
HYDRAULIC BALL JOINT INSTALLATION AND
REMOVAL KIT - BMW
VSE127H
MODEL NO:
Wear protective
gloves
Description
Force screw
T-Handle
Main frame
Adaptor ring
Adaptor - A
Adaptor - B
Adaptor - C
Adaptor - D
Original Language Version
VSE127H Issue:2 (2,4) - 14/03/19
