Sealey AK462DX.V2 Quick Start Manual

thank you for purchasing a sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear protective
instruction gloves
manual
1. safety
i
1.1. generaL safety
Warning: ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this
‰
equipment.
Familiarise yourself with the application and limitations of the oil drainer, as well as the potential hazards.
9
Warning: disconnect the drainer from the air supply before changing accessories, servicing or performing any maintenance.
‰
maintain the drainer in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Keep the work area clean, uncluttered and ensure there is adequate lighting.
9
Keep the drainer clean for best and safest performance.
9
maintain correct balance and footing. ensure the floor is not slippery and wear non-slip shoes.
9
Keep children and unauthorised persons away from the working area.
9
Warning: ensure correct air pressure is maintained and not exceeded.
‰
Keep air hose away from heat, oil and sharp edges.
9
Check air hose for wear before each use, and ensure that all connections are secure.
9
do not use the drainer for any purpose other than that for which it is designed.
8
do not operate the drainer if any parts are damaged or missing as this may cause failure and/or personal injury.
8
do not stand on the drainer.
8
do not adjust or tamper with the safety valve.
8
do not move the drainer by the hose, or pull the hose sharply from the air supply.
8
do not place attachments close to your face and do not point hose at other persons or animals.
8
do not allow untrained persons to operate the drainer.
8
do not operate the drainer when you are tired, under the influence of alcohol, drugs or intoxicating medication.
8
do not leave the drainer operating unattended.
8
do not direct air from the air hose at yourself or others.
8
When not in use disconnect from the air supply, vent reservoir and store in a safe, dry, childproof area.
9
dispose of waste oil in accordance with local authority regulations.
9
Warning: do not pollute the environment by allowing uncontrolled discharge of waste oil.
‰
2. introduction
Steel fabricated 80ltr reservoir with suction probes and air discharge. Unit features cantilever oil drain pan which is suitable for use
either under a lift or on the forecourt. Drain pan utilises vacuum suction when in the down position and is fitted with a bogey wheel for
easy manoeuvring. Fitted with oil level indicator tube and supplied with mercedes adaptor plus a selection of probes.
3. specification
Model no: ........................................................aK462dX.v2
Capacity: ........................................................................ 80ltr
minimum Height to Pan: ............................................ 150mm
maximum Height to Pan: ......................................... 1600mm
Gravity Feed: .................................................................. Yes
Suction Feed: .................................................................. Yes
Gravity discharge: ........................................................... no
Air discharge: ................................................................. Yes
4. asseMbLy
note: numbers in brackets refer to item numbers on the parts diagram
4.1.
Remove the bolt, washer and nut (48, 49 & 50) from the support bar (82).
4.2. Align the holes in the support bar (82) and the bracket on the oil pan (42), fit the bolt (48) and secure using the washer and nut (49 & 50).
4.3. loosen the handle retaining bolts at the back of the reservoir, insert the handle and tighten the bolts.
4.4. The oil drainer is now ready for use.
© Jack Sealey limited
gravity & suction feed air discharge
cantiLever oiL drainer
model no:
Wear eye Wear protective
protection clothing
Original Language Version
aK462dX.v2
AK462dX Issue 5 (H, 3, 4, F) 20/06/19
