Operating & Installation
Fully Automatic Washing Machine
NA-F75S6
Model No.
NA-F70S6
NA-F75G6
NA-F70G6
NA-F65G6
NA-F62G6
Thank you for purchasing this
product.
- Read these instructions carefully for
- Keep this manual for future reference.
Instructions
(Domestic use)
NA-F70H6
NA-F65H6
NA-F62H6
Contents
optimum performance and safety
before use.
W9901-9LH00
Printed in India
March 2015
2
3
4
6
8
9
10
12
12
14
16
17
18
A0315-0
Advertisement
Table of Contents
Related Manuals for Panasonic NA-F75S6
Summary of Contents for Panasonic NA-F75S6
-
Page 1: Table Of Contents
Operating & Installation Instructions Fully Automatic Washing Machine (Domestic use) NA-F75S6 NA-F70H6 Model No. NA-F70S6 NA-F65H6 NA-F75G6 NA-F62H6 NA-F70G6 NA-F65G6 NA-F62G6 Contents Safety Precautions Part Names Operation Panel Variety of Programs Detergent Washing Washing Options • Gentle Hand Wash • Delicate •... -
Page 2: Safety Precautions
Safety Precautions Read and follow these safety precautions. WARNING Never disassemble, repair or modify the appliance yourself. ● In case of malfunction or failure, immediately stop May cause serious use, unplug the power cord, and ask your nearest injury or death. service centre for repair. -
Page 3: Part Names
● Bottom cover (1) ● Screw (6) operation. For the bottom cover (To prevent water leakage) This appliance is only suitable for ■ NA-F75S6 / NA-F70S6 / textiles labelled washing machine NA-F75G6 / NA-F70G6 / washable. ● External drain NA-F65G6 / NA-F62G6 water hose (1) ●... -
Page 4: Operation Panel
Gentle Hand Wash Indicates the approximate Delicate remaining time (min). Air Dry Tub Hygiene • Operation panel of the NA-F75S6 Wash / Rinse / Spin (P. 11) Program selection (P. 6) Start/Pause ECONAVI lamp Child Lock lamp (P. 5) (P. 12) - Page 5 Pre-laundry check To prevent damage to clothes, malfunction and ECONAVI drainage failure (NA-F75S6 / NA-F70S6 / NA-F75G6 / NA-F70G6 / ● Remove coins, pins, paper clips, nails, etc. NA-F65G6 / NA-F62G6) ● Fasten buttons and close zippers. ● Do not wash items (such as paper diapers) other Available in the Normal program, this function than laundry.
-
Page 6: Variety Of Programs
Variety of Programs ■ NA-F75S6 / NA-F70S6 / NA-F75G6 / NA-F70G6 / NA-F65G6 / NA-F62G6 Maximum capacity Purpose Program NA-F75S6 NA-F70S6 NA-F65G6 NA-F62G6 NA-F75G6 NA-F70G6 Everyday Normal Daily washing 7.5 kg 7.0 kg 6.5 kg 6.2 kg (P. 9) clothes... - Page 7 ■ NA-F70H6 / NA-F65H6 / NA-F62H6 Maximum capacity Purpose Program NA-F70H6 NA-F65H6 NA-F62H6 Everyday Normal Daily washing 7.0 kg 6.5 kg 6.2 kg (P. 9) clothes Speedy washing Quick 2.0 kg 2.0 kg 2.0 kg (P. 9) for light soil Washing Delicates Delicate...
-
Page 8: Detergent
Detergent Putting in detergent Put in detergent, bleach and softener according to the water Do not put detergent directly into the tub. level displayed. Detergent may remain undissolved. ● Follow the instructions on each package. ■ Liquid detergent/liquid bleach ■ Softener ●... -
Page 9: Washing
Washing Preparation: ● Check if the washing machine is properly installed. (P. 14) ● Turn on the water faucet. ● When using Temp Setting, turn on both hot and cold water faucets. Timer reservation Temp Setting After loading laundry Turn the power on. Select a program. -
Page 10: Washing Options
Washing Options NA-F75S6 / NA-F70S6 / NA-F75G6 / NA-F70G6 / NA-F65G6 / NA-F62G6 NA-F70H6 / NA-F65H6 / NA-F62H6 Gentle Hand Wash Delicate Use this program to gently wash delicate Use this program to gently wash delicate clothes and stylish garments. -
Page 11: Power Soak
Power Soak Air Dry Use this program to wash heavily soiled Water is removed from clothes by the air laundry. blown from the tub rotation. ■ Preparation: Turn on the water faucet. Clothes that can be dried • Material: Synthetic fi bre After loading laundry •... -
Page 12: Convenient Functions
● Turn the tub by hand if it is diffi cult to remove the fi lter. ● If the fi lter is broken, purchase a new one at nearest Panasonic Service Centre. NOTE ● If there is water in the tub or “Start” is pressed, the... - Page 13 Water supply fi lter If water does not fl ow smoothly Once a week <Air Dry> ● Follow the procedure below to prevent After operation ends splashing of water. Run the Air Dry program without After turning off both hot and loading laundry.
-
Page 14: Installation
Installation 1. Check the location. ■ Avoid the following locations for installation. • Locations with a possibility of freezing • Locations exposed to direct sunlight HOT COLD (To prevent malfunction or deformation) Water supply • Uneven or unstable locations valve screw (on blocks, timbers, a table with wheels, etc.) Water tap 2. - Page 15 ■ If the installation, test run and inspection of the washing machine are not carried out following this installation method, Panasonic will not be liable for any accident or damage caused. 4. Connect the water tap adaptor and water supply hose.
-
Page 16: Troubleshooting
Troubleshooting Symptoms Points to be checked Time indication ● Time indication is approximate. Remaining time is corrected during increases or does not operation and displayed. change Operation time is longer than the time indication. ● The operation time may be longer if laundry is concentrated on one Operation does not stop side or the water supply or drainage is not good. -
Page 19: Error Display
Error Display ● The buzzer sounds and “U”/“H” and a number are alternately displayed. ● Cancel Child Lock (P. 12) if it is set. Error display Points to be checked Water cannot drain. Check the drain water hose for the following abnormalities: ●... -
Page 20: Specifi Cations
SCHEDULE II a nearby authorized Collection Centre, registered of the e-waste Rules: Dismantler or Recycler, or Panasonic Service Centre 1. Lead (Pb) – not over 0.1 % by weight; when disposing of this product.
