- Page 1 INSTRUCTION MANUAL LINEAR PISTON ACTUATORS Type “LP” Simple Cylinder Actuators PN25008...
- Page 2 Selection of materials and/or equipment is at the sole risk of the user of this publication. This document contains proprietary information of ABB Inc. and is issued in strict confidence. Its use, or reproduction for use, for the reverse engineering, development or manufacture of hardware or software described herein is prohibited.
-
Page 3: Table Of Contents
LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL TABLE OF CONTENTS READ FIRST........................2 1.0 SPECIFICATIONS / FEATURES ................3 2.0 THRUST RATINGS....................4 3.0 MODEL NUMBER DETAILS ..................5 4.0 OUTLINE DIMENSIONS ................... 6 2 ½ in. Sizes (LP10)....................6 4 in. Sizes (LP20) ...................... 7 6 in. -
Page 4: Read First
ABB Inc. instructions and manuals, otherwise injury or damage may result. RETURN OF EQUIPMENT All equipment being returned to ABB Inc. for repair must be free of any hazardous materials (acids, alkalis, solvents, etc). A Material Safety Data Sheet (MSDS) for all process liquids must accompany returned equipment. -
Page 5: Specifications / Features
Simple Cylinder Actuators From 2 ” dia. x 5” Stroke to 10”dia. x 16” Stroke LP linear piston actuators are used to control the Linear Piston Actuator Assemblies position of air dampers or louvers on furnaces, boilers, and air distribution systems. They are The LP series of damper drives provide a linear also used on burner and SOFA Tilts. -
Page 6: Thrust Ratings
LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL 2.0 THRUST RATINGS basic thrust rating LP Cylinder Thrust @ 80psi pneumatic piston is equal to the area 2.5” d x 5” s 353 lbs. of the piston times the supply 4” d x 4” s 905 lbs pressure. -
Page 7: Model Number Details
LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL 3.0 MODEL NUMBER DETAILS “Simple Cylinder” type Linear pneumatic piston actuators are supplied with either type AV conventional or type TZID intellegent positioners mounted on the cylinder. Cylinders are supplied with a threaded clevis on the rod end and a standard MP pivot on the base. -
Page 8: Outline Dimensions
LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL 4.0 OUTLINE DIMENSION DRAWINGS (Certified Drawings available on request). LP 10: 2.5 x 5 Linear Piston Shown with TZID-C Smart Positioner... -
Page 9: In. Sizes (Lp20)
LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL LP 20 : 4 x 4 Linear Piston Shown with AV15 Positioner. -
Page 10: In. Sizes (Lp32)
LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL LP 32 : 6 x 16 Linear Piston Shown with AV15 Positioner. -
Page 11: Parts
LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL 5.0 PARTS... - Page 12 LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL...
- Page 13 LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL...
- Page 14 LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL...
- Page 15 LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL...
- Page 16 LP LINEAR PISTON ACTUATORS INSTRUCTION MANUAL...
- Page 18 The Company’s policy is one of continuous product improvement and the right is reserved to modify the information contained herein without notice. © 2002 ABB Inc. Printed in USA ABB Inc. ABB Instrumentation Ltd ABB Instrumentation S.p.A ABB Automation Products GmbH 125 East County Line Road Howard Road, St.
