Sony HT-S500RF Service Manual
Hide thumbs
Also See for HT-S500RF:
- Operating instructions manual (171 pages) ,
- Startup manual (2 pages) ,
- Startup manual (2 pages)
Table of Contents
Advertisement
2018/11/28 06:27:54 (GMT+09:00)
SERVICE MANUAL
Conditions of Use:
(1)
Please use this information only for the purpose of performing repair, maintenance and/or confi guration services of the Sony products (hereinafter the "Repair services") under the ser-
vice agreement entered into with the Sony group company (hereinafter the "Service agreement"). Using this information for any purpose other than the purpose described foregoing is
forbidden.
(2)
Only the Authorized Servicer's offi cers, employees or subcontractors (including their offi cers and employees) whose duties justify a need-to-know and who have agreed to hold
confi dential this information (collectively hereinafter the "Permitted users") are permitted to access and use this information. To disclose or disseminate to any person other than the
Permitted users is forbidden.
(3)
Destroy or erase any and all portion of this information promptly in an irrecoverable and secure fashion after achieving the purpose described in Section (1) above.
(4)
Do not copy, replicate, reproduce, alter, translate, transmit, sell, lease, or distribute this information in whole or in part without the prior written permission of the author.
(Notwithstanding foregoing, it is permitted to copy and distribute this information to the Permitted users.)
(5)
Please notify immediately any leakage, loss, theft, misappropriation, or other misuse of this information by e-mail to the following address:
somk-gcs-tissnexim-adm@jp.sony.com
(6)
In addition to the above, the terms and conditions of the Service agreement shall be applied to using this information.
Revision of Information:
This information may be changed or updated at any time without any prior notice. Please confi rm that this information is up-to-date before using it.
Note:
Be sure to keep your PC used for service and
checking of this unit always updated with the
latest version of your anti-virus software.
In case a virus affected unit was found during
service, contact your Service Headquarters.
Sony CONFIDENTIAL
For Authorized Servicer
9-896-531-02
2018I33-1
Sony Video & Sound Products Inc.
©
2018.09
HT-S500RF/S700RF
SA-WS500RF/WS700RF/SS-S500RF/S700RF/SS500RF/SS700RF
SYS SET
Advertisement
Table of Contents
Related Manuals for Sony HT-S500RF
Summary of Contents for Sony HT-S500RF
- Page 1 Conditions of Use: Please use this information only for the purpose of performing repair, maintenance and/or confi guration services of the Sony products (hereinafter the “Repair services”) under the ser- vice agreement entered into with the Sony group company (hereinafter the “Service agreement”). Using this information for any purpose other than the purpose described foregoing is forbidden.
- Page 2 Photo: SA-WS700RF HT-S700RF/SA-WS700RF/ SS-S700RF/SS700RF Photo: SS-S500RF or SS-S700RF • All of the units included in the HT-S500RF (SA-WS500RF/SS-S500RF/ SS500RF/Remote control) or HT-S700RF (SA-WS700RF/SS-S700RF/ SS700RF/Remote control) are required to confi rming operation of SA- Photo: SS-SS700RF WS500RF/WS700RF. Check in advance that you have all of the units.
- Page 3 The BLUETOOTH word mark and logos are Woofer: 48 mm × 90 mm cone type registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Sony General Corporation is under license. Other Dimensions (w/h/d) (approx.) trademarks and trade names are those of 900 mm ×...
-
Page 4: Table Of Contents
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer TABLE OF CONTENTS SERVICING NOTES 5-11. Printed Wiring Board ..........- SPK JACK Board (SA-WS500RF/WS700RF) - ..... 33 5-12. Schematic Diagram DISASSEMBLY - SPK JACK Board (SA-WS500RF/WS700RF) - ..... 33 2-1. Disassembly Flow .............. -
Page 5: Servicing Notes
ADVANCE PREPARATION WHEN CONFIRMING OPER- • Abbreviations ATION HT-S500RF (SA-WS500RF/SS-S500RF/SS500RF) All of the units included in the HT-S500RF (SA-WS500RF/SS- : Latin American area (Argentina, Paraguay and Uruguay) S500RF/SS500RF/Remote control) or HT-S700RF (SA-WS700RF/ model SS-S700RF/SS700RF/Remote control) are required to confi rming : Chinese model operation of SA-WS500RF/WS700RF. - Page 6 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 For Authorized Servicer MODEL IDENTIFICATION Surround speaker (SS-SS500RF) (Rear side) Distinguish by the model number label on the rear side or bottom Model Number Label side of the each unit. Note: The print content of the model number label may be changed.
- Page 7 Schematic diagram and printed wiring board are described for refer- struction manual of your Bluetooth device. ence purposes in this service manual. 4. Select the “HT-S500RF” or “HT-S700RF” from the list searched by the Bluetooth device and connect. SPREADING OF COMPOUND Note 2: If a passkey is requested, please input “0000”.
-
Page 8: Disassembly
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL SECTION 2 For Authorized Servicer DISASSEMBLY • This set can be disassembled in the order shown below. 2-1. DISASSEMBLY FLOW Note: SA-WS500RF and SA-WS700RF can be removed using SET (SA-WS500RF/WS700RF) the same procedure. This explanation uses illustrations from the SA-WS500RF. -
Page 9: Catcher Rubber (Rear Side), Rear Panel
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer Note: Follow the disassembly procedure in the numerical order given. 2-2. CATCHER RUBBER (REAR SIDE), REAR PANEL 3 rear panel block 1 three screws (See Fig. A) 5 rear panel (BVTP3.5) rear side... -
Page 10: Amp Block, Catcher Rubber (Front Side)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-3. AMP BLOCK, CATCHER RUBBER (FRONT SIDE) Note: During reassembly, use new cable ties to fasten the cables back in place as they were before disassembly. speaker FFC (BT) FFC (FL~MAIN) – –... -
Page 11: Top Chassis Block, Power Cord
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-4. TOP CHASSIS BLOCK, POWER CORD 3 power cord connector 1 FFC (BT) (24 core) (CN501) FFC (BT) (XP2) (24 core) rear side BT board – – front side rear side claw side... -
Page 12: Bt Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-5. BT BOARD Note 1: When the BT board is replaced, refer to “OPERATION CHECK OF THE BLUETOOTH CONNECTION” on page 7. FFC (BT) (24 core) – – BT board 2 two screws... -
Page 13: Main Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-7. MAIN BOARD 4 screw 1 cable (MAIN SPK JACK) (10 pin) 5 screw claw side (BVTP3 connector (XP10) (BVTT3 rear side 5 three screws 3 POWER board cable (BVTT3 connector (XP1) 2 fan cable... -
Page 14: Power Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-8. POWER BOARD groove 1 POWER board cable connector (XP1) groove 2 five screws (BVTT3 4 POWER board Note: When installing the POWER board, align the three ribs and three grooves. groove rear side... -
Page 15: Front Panel Block
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-9. FRONT PANEL BLOCK 1 Insert a flat-head screwdriver into the two slits on the bottom of the unit, and open a gap between the front 2 Insert the jig into the space and slowly panel block and speaker cabinet. -
Page 16: 2-10. Fl Board, Sw Panel, Led Window W Touch
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-10. FL BOARD, SW PANEL, LED WINDOW W TOUCH boss top side – – 1 FFC (TOUCH) (5 core) (XP902) top side boss hole The opposite side FL board is terminal side. 4 FL board... -
Page 17: Sw Unit (Subwoofer)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-11. SW UNIT (SUBWOOFER) Note 1: When installing the SW unit (subwoofer), make the position of terminals as shown in the figure below. – – top side front side 1 six wood screws (R4.1... -
Page 18: 2-12. Service Position
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 2-12. SERVICE POSITION front side bottom side speaker cabinet block soft cloth, etc. top side BT board SPK JACK board POWER board AMP block MAIN board SYS SET... -
Page 19: Test Mode
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 SECTION 3 For Authorized Servicer TEST MODE SOFTWARE VERSION DISPLAY MODE FACTORY RESET It can check the display of software version, destination and model It can clear all settings and Bluetooth pairing history. name. -
Page 20: Troubleshooting
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL SECTION 4 For Authorized Servicer TROUBLESHOOTING 1. Starting up (SA-WS500RF/WS700RF) Note: Before replacing the board, please check if there is any problem with the soldering, repair the soldering fi rst and retest. Start “HELLO” is displayed in the front panel... - Page 21 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 3. Check the audio output (SA-WS500RF/WS700RF) Note: Before replacing the board, please check if there is any problem with the soldering, repair the soldering fi rst and retest. Start The sound of the “ANALG” function is The cable (WS500RF: WR1/WS700RF: Replace the cable (WR1 or WR2).
-
Page 22: Diagrams
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL SECTION 5 For Authorized Servicer DIAGRAMS 5-1. BLOCK DIAGRAM Xtal OPTICAL IN SPDIF 1 FLASH SPDIF 2 SN74LVC2G04 SDRAM HDMI I2C1/CEC PWM1 PWM1 P901 Power Stage MTK 8301 IIS_2 TAS5614LA IIS_0 IIS_1 PCM1808 MUTE 74LVC244 74LVC244... - Page 23 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 For Authorized Servicer THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. • IC Block Diagrams (In addition to this, the necessary note is printed in each block.) – MAIN Board –...
-
Page 24: Printed Wiring Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-2. PRINTED WIRING BOARD - MAIN Board (SA-WS500RF/WS700RF) - • See page 23 for Circuit Boards Location. • : Uses unleaded solder. MAIN BOARD (CONDUCTOR SIDE) MAIN BOARD (COMPONENT SIDE) Note: When the U16, U17 or U18 on the MAIN board is replaced, spread the compound to the touching portion between the U16, U17, U18 and the heat sink. -
Page 25: Schematic Diagram - Main Board (1/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-3. SCHEMATIC DIAGRAM - MAIN Board (1/8) (SA-WS500RF/WS700RF) - MAIN BOARD (1/8) 0.1uF/50V/X7R Vout =110K/(10K+10K)*0.8+0.8=5.2 TPS54240DGQR STB_5V PVDD 10uH/3A SYS_12V BOOT 300 /2A 2.2uH/2.1A COMP SS/TR VSNS SS14/40V/1A 110K /±1% RT/CLC PWRGD SYS_5V... -
Page 26: Schematic Diagram - Main Board (2/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-4. SCHEMATIC DIAGRAM - MAIN Board (2/8) (SA-WS500RF/WS700RF) - • See page 39 for IC Pin Function Description. MAIN BOARD (2/8) I2C_CLK1_MCU I2C_SDA1_MCU I2C_SDA_MCU AMP_SDA R287 I2C_CLK_MCU R288 AMP_SCL AMP_SCL TO the page of FAN... -
Page 27: Schematic Diagram - Main Board (3/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-5. SCHEMATIC DIAGRAM - MAIN Board (3/8) (SA-WS500RF/WS700RF) - • See page 39 for IC Pin Function Description. MAIN BOARD (3/8) STB_3V3 A_1V2 A_1V2 15K/±1% 8301_RST 3.9K/+/-1% SD_3V3 DQ15 DQ15 VDDQ VSSQ 4.7K... -
Page 28: Schematic Diagram - Main Board (4/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-6. SCHEMATIC DIAGRAM - MAIN Board (4/8) (SA-WS500RF/WS700RF) - MAIN BOARD (4/8) AUDIO INPUT 5PIN/CKX-3.5-07 R143 4.7K ADC_INR C274 10uF/16V/X5R BT_BCLK BT_BCLK I2S_BCLK 10,6 R146 R241 AD_BCLK BT_LRCK C106 BT_LRCK I2S_LRCK 10,6 R148... -
Page 29: Schematic Diagram - Main Board (5/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-7. SCHEMATIC DIAGRAM - MAIN Board (5/8) (SA-WS500RF/WS700RF) - MAIN BOARD (5/8) R167 STB_5V HDMI_5V B5817W TO the page of MTK8301 SPDIF_ARC R179 SPDIF_ARC TX2+ TX2+ HPLG NC/150K HPLG TX2- TX2- TX1+ HDMI_SDA... -
Page 30: Schematic Diagram - Main Board (6/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-8. SCHEMATIC DIAGRAM - MAIN Board (6/8) (SA-WS500RF/WS700RF) - MAIN BOARD (6/8) SYS_12V FB14 500/500mA PNP_MMBT8550C VCC_FAN C141 From the page of MCU CE16 R206 220K 0.1uF/16V/X7R C142 2PIN/2.0mm SUB+_OUT 47uF/SMD R184 FAN_CTL... -
Page 31: Schematic Diagram - Main Board (7/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-9. SCHEMATIC DIAGRAM - MAIN Board (7/8) (SA-WS500RF/WS700RF) - • See page 23 for IC Block Diagrams. MAIN BOARD (7/8) P_3V3 C153 4700pF/50V/X7R C154 4700pF/50V/X7R P_3V3 FB15 300 /2A R209 SYS_3V3 From the page of 8301... -
Page 32: Schematic Diagram - Main Board (8/8) (Sa-Ws500Rf/Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-10. SCHEMATIC DIAGRAM - MAIN Board (8/8) (SA-WS500RF/WS700RF) - • See page 23 for IC Block Diagrams. MAIN BOARD (8/8) PVDD SYS_12V R260 CE13 C206 0.1uF/50V/X7R C207 C209 820uF/50V C280 10uF/16V/X5R C210 0.033uF/50V/X7R... -
Page 33: Printed Wiring Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-11. PRINTED WIRING BOARD - SPK JACK Board (SA-WS500RF/WS700RF) - • See page 23 for Circuit Boards Location. • : Uses unleaded solder. SPK JACK BOARD (COMPONENT SIDE) SPK JACK BOARD (CONDUCTOR SIDE) 5-12. -
Page 34: Printed Wiring Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-13. PRINTED WIRING BOARD - BT Board (SA-WS500RF/WS700RF) - • See page 23 for Circuit Boards Location. • : Uses unleaded solder. BT BOARD BT BOARD (SIDE A) (SIDE B) Note: When the complete BT board is replaced, refer to “OPERATION CHECK OF THE BLUETOOTH CONNECTION”... -
Page 35: Printed Wiring Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-15. PRINTED WIRING BOARD - FL Board (SA-WS500RF/WS700RF) - 5-16. SCHEMATIC DIAGRAM - FL Board (SA-WS500RF/WS700RF) - • See page 23 for Circuit Boards Location. • : Uses unleaded solder. FL BOARD FL BOARD... -
Page 36: Printed Wiring Board
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-17. PRINTED WIRING BOARD - TOUCH Board (SA-WS500RF/WS700RF) - 5-19. PRINTED WIRING BOARD - POWER Board (SA-WS500RF/WS700RF) - • See page 23 for Circuit Boards Location. • : Uses unleaded solder. • See page 23 for Circuit Boards Location. -
Page 37: Schematic Diagram - Power Board (Sa-Ws500Rf: E3, Ea, Sp, Ar, Ind/Ws700Rf: E3, Ea, Sp, Ind, Ru)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-20. SCHEMATIC DIAGRAM - POWER Board (SA-WS500RF: E3, EA, SP, AR, IND/WS700RF: E3, EA, SP, IND, RU) - POWER BOARD C508 D505 HER203 R533 0.0022uF(222)400V CY504 VOUT-GND R503 470pF/250VAC R501 D504 R502 20A/300V... -
Page 38: Schematic Diagram - Power Board (Sa-Ws500Rf: La/Ws700Rf: Br, La)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 5-21. SCHEMATIC DIAGRAM - POWER Board (SA-WS500RF: LA/WS700RF: BR, LA) - POWER BOARD C508 D505 HER203 R533 0.0022uF(222)400V CY504 VOUT-GND R503 470pF/250VAC R501 D504 R502 20A/300V 22K/2W CE501 CE502 CE5011 CE5021 C502 C501 0.0022uF(222)400V... - Page 39 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer • IC Pin Function Description MAIN BOARD U5 STM32F070RBT6 (MCU) Pin No. Pin Name Description Power supply terminal (+3.3V) PC13 Not used PC14/OSC32_IN Not used PC15/OSC32_OUT Not used PF0/OSC_IN Ground terminal PF1/OSC_OUT Ground terminal...
- Page 40 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer MAIN BOARD U7 MT8301OXE (DIGITAL AUDIO INTERFACE RECEIVER, DSP) Pin No. Pin Name Description AVDD12_2 Power supply terminal (+1.2V) AVDD33_1 Power supply terminal (+3.3V) XTALI System clock input terminal XTALO System clock output terminal...
- Page 41 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer Pin No. Pin Name Description SPDIF/GPIO12 Not used GPIO10/HPLG Hot plug detection signal input terminal (for HDMI) EXT_RES Ground terminal AVDD33_12 Power supply terminal (+3.3V) TXCN TMDS clock (negative) signal input terminal (for HDMI)
-
Page 42: Exploded Views
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 SECTION 6 For Authorized Servicer EXPLODED VIEWS Note: • -XX and -X mean standardized parts, so • The mechanical parts with no reference The components identifi ed by mark 0 they may have some difference from the... -
Page 43: Subwoofer Amp Section (Sa-Ws500Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 For Authorized Servicer 6-2. SUBWOOFER AMP SECTION (SA-WS500RF) Note 1: Refer to page 45 for the SA-WS700RF. not supplied not supplied not supplied supplied supplied not supplied not supplied not supplied not supplied Note 2: When the complete BT board (Ref. No. 55) is replaced, refer to “OPERATION CHECK OF THE BLUETOOTH CONNEC-... -
Page 44: Subwoofer Front Section (Sa-Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer 6-3. SUBWOOFER FRONT SECTION (SA-WS700RF) Note: Refer to page 42 for the SA-WS500RF. supplied not supplied subwoofer AMP section Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 9-885-223-46 FOOT (SW) -
Page 45: Subwoofer Amp Section (Sa-Ws700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 For Authorized Servicer 6-4. SUBWOOFER AMP SECTION (SA-WS700RF) Note 1: Refer to page 43 for the SA-WS500RF. not supplied not supplied not supplied supplied supplied not supplied not supplied not supplied not supplied Note 2: When the complete BT board (Ref. No. 155) is replaced, refer to “OPERATION CHECK OF THE BLUETOOTH CONNEC-... -
Page 46: Bar Speaker, Surround Speaker Section (Ss-S500Rf/Ss500Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 For Authorized Servicer 6-5. BAR SPEAKER, SURROUND SPEAKER SECTION (SS-S500RF/SS500RF) Note: Refer to page 47 for the SS-S700RF/SS700RF. – L-ch – – R-ch – Ref. No. Part No. Description Remark Ref. No. Part No. -
Page 47: Bar Speaker, Surround Speaker Section (Ss-S700Rf/Ss700Rf)
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 For Authorized Servicer 6-6. BAR SPEAKER, SURROUND SPEAKER SECTION (SS-S700RF/SS700RF) Note: Refer to page 46 for the SS-S500RF/SS500RF. – L-ch – – R-ch – Ref. No. Part No. Description Remark Ref. No. Part No. -
Page 48: Electrical Parts List
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 SECTION 7 For Authorized Servicer MAIN POWER ELECTRICAL PARTS LIST SPK JACK TOUCH Note: • Due to standardization, replacements in • CAPACITORS When indicating parts by reference number, uF: μF the parts list may be different from the parts please include the board name. - Page 49 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 For Authorized Servicer Ref. No. Part No. Description Remark SP203 A-2223-105-A MAIN (SS-SS500RF SR) (Surround speaker for R-ch) (SS-SS500RF: CH) SP251 A-2223-140-A MAIN (SS-S700RF) (Bar speaker) (SS-S700RF: E3, EA, SP, TH, IND, LA) SP251...
-
Page 50: Accessories
2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL Ver. 1.1 SECTION 8 For Authorized Servicer ACCESSORIES HT-S500RF HT-S700RF Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-735-136-11 MANUAL, INSTRUCTION (Operating Instructions) 4-735-136-11 MANUAL, INSTRUCTION (Operating Instructions) (ENGLISH) (IND) (ENGLISH) (IND) - Page 51 2018/11/28 06:27:54 (GMT+09:00) HT-S500RF/S700RF Sony CONFIDENTIAL For Authorized Servicer REVISION HISTORY Ver. Date Description of Revision 2018.07 2018.09 Addition of CH model (HT-S500RF/SA-WS500RF/SS-S500RF/SS500RF) Addition of TH model (HT-S700RF/SA-WS700RF/SS-S700RF/SS700RF) SYS SET...
