Reindeer : Assembly Instructions
Tools
Scissors
Paste, or woodwork glue
Stencil pen, or bodkin
Ruler
Pencil
The Assembly instructions are divided into three blocks: A (head,
antler), B (front legs, body), and C (waist, hind legs, stand). Follow
the instructions for each block to assemble your reindeer.
marks a basic assembly technique that remains the same
regardless of the part.
Instructions are printed only for the first instance.
<Caution>
Keep scissors and glue away from small children.
Be careful not to cut your fingers when using scissors.
Notation Key
Scissors line
Mountain fold
Valley fold
Glue spot
Parts No.
Assemble the head and antlers
Use pattern: Page2 to Page4.
Cut out A1 by cutting along the lines.
Cut along the line marked
Triangular glue tab
Make a mountain fold and valley fold on A1.
Trace along the mountain fold and valley fold line with a
stencil pen, scoring it to make it easier to fold.
The parts will be easier to assemble if curled.
Using the photo as a guide, move your fingers in the direction of the
arrow, adjusting the pressure to curl the paper.
Add a slight curl to A1 when attaching it.
Attach the triangular glue tabs so that the front side becomes convex.
Using the photo as a guide, attach in the direction of the arrow.
A1 Head
.
Glue tab
A1 Head
Parts name
Page
Scissors line
Parts No.
