GE GE2110 Service Manual page 11

Item No.
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
48-TAC001-XX0 TACT SWITCH
08-02175X-PW4 ASS'Y - POWER PARTS
10-0001H8-FBX DIODE 1H8 (FAST RECOVERY)
10-00RU3C-F0X DIODE RU3C (FAST RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-0RL255-EBX DIODE RL255 (POWER RECTIFIER)
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-1N4148-ABX DIODE 1N4148 (SWITCHING)
10-79C8V2-DBX DIODE ZENER 8V2 1/2W 5%
11-SC1815-YBX TRANSISTOR 2SC1815Y
13-TDA168-46P IC TDA16846 (SMPS)
18-CB0102-JNX RES. C.F. 1K OHM 1/6W +/-5%
18-CB0103-JNX RES. C.F. 10K OHM 1/6W +/-5%
18-CB0182-JNX RES. C.F. 1.8K OHM 1/6W +/-5%
18-CB0222-JNX RES. C.F. 2.2k OHM 1/6W +/-5%
18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5%
18-CB0472-JNX RES. C.F. 4.7k OHM 1/6W +/-5%
18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5%
18-CB0563-JNX RES. C.F. 56K OHM 1/6W +/-5%
18-CB0752-JNX RES. C.F. 7.5K OHM 1/6W +/-5%
18-CB0823-JNX RES. C.F. 82K OHM 1/6W +/-5%
18-CD0101-JNX RES. C.F. 100 OHM 1/4W +/-5%
18-CD0153-JNX RES. C.F. 15K OHM 1/4W +/-5%
Description Quantity Req. Designator
1 CH+
1 VOL-
1 VOL+
1 MENU
1 VIDEO
1 DISP
1
1 D810
1 D824
1 D801
1 D802
1 D803
1 D804
1 D832
1 D807
1 D805
1 D833
1 Q806
1 IC801
1 R829
1 R828
1 R804
1 R827
1 R826A
1 R826
1 R812
1 R806
1 R810
1 R803
1 R808
1 R811
11
Remarks
