- Page 1 MIB3E_MQB37w_BTWIFI USER MANUAL for Skoda Octavia 24.01.2019 Continental...
-
Page 2: Table Of Contents
CONTENT GENERAL INSTRUCTIONS ..…………………………………………….3 TECHNICAL INFORMATION ..………………………………….…..…..4-5 INTRODUCTION TO OPERATION ..………………………………..6 PRIVACY SETTINGS INFORMATION……………………………..7 MANAGE FAVOURITES……………………………..…..……………..8 RADIO OVERVIEW……………………………..…..……………………..9 BLUETOOTH - SEARCHING FOR MOBILE PHONES .…….10 BLUETOOTH - CREATING A CONNECTION ………………….….…11 BLUETOOTH - DEAUTHORIZE A MOBILE TELEPHONE ………12 BLUETOOTH - INTERACTING WITH MOBILE PHONE .………..13 SMART LINK ...……………………………………………………………..…14... -
Page 3: General Instructions
GENERAL INSTRUCTIONS Caution - In some countries, some Infotainment functions can no Warning! longer be selected when the vehicle is running faster than The MIB3 can distract your attention from the traffic a certain speed. This is not a malfunction, but complies conditions. -
Page 4: Technical Information
TECHNICAL INFORMATION The product MIB3 is developed and produced by Panasonic Automotive Systems Europe GmbH. The product is an integrated car entertainment systems. The MIB3 Entry series can support (depending on purchased configuration) several sources like MP3, USB (external connection box), Bluetooth, Wifi, AM/FM radio, android auto, Apple CarPlay and MirrorLink. - Page 5 TECHNICAL INFORMATION For units with Wifi RF technical specification – 5GHz Wifi: Frequency Range (no DFS): Bandwith1: 5 150 - 5 350 MHz: 5180 MHz; 5200 MHz; 5220 MHz; 5240 MHz 5 735 - 5 835 MHz: 5745 MHz; 5765 MHz; 5785 MHz, 5805 MHz, 5825 MHz Bandwith2: 5 150 - 5 350 MHz: 5190 MHz;...
-
Page 6: Introduction To Operation
INTRODUCTION TO OPERATION Long press on left control dial ① allows to switch the device on and off. Turning left control dial ① allows to change settings like volume. The MIB3 allows access to different menus with the function keys ② located around the display or the icons directly on the touch screen ④. -
Page 7: Privacy Settings Information
PRIVACY SETTTINGS INFORMATION -- No available in Octavia -- ① The MIB3 allows to adjust the privacy settings. The user can choose, which information will be provided to connected services. 1. Touch and hold a finger at the position of the green arrow. Moving the finger down will open a second menu. -
Page 8: Manage Favourites
MANAGE FAVOURITES ① The MIB3 allows to create shortcuts (‚favourites‘) for user friendly control of the device. 1. Touch and hold at the position of the green arrow and move down. This will open a second menu. 2. Long press on one of the ‚Empty‘ icon ②... -
Page 9: Radio Overview
RADIO - OVERVIEW ① Press the left control dial to switch the radio on. 1. The AM/FM/DAB Radio can be started by pressing the function key ‚AUDIO‘ or the touch screen by toching the icon ‚Audio‘. ② 2. The main Media screen of MIB3_EI HU, shows a favorite list. The currently played radio channel or media source can be added by pressing the ‘+’... -
Page 10: Bluetooth - Searching For Mobile Phones
BLUETOOTH - SEARCHING FOR MOBILE PHONES ① The MIB3 will search for devices that support Bluetooth´s Hands Free Profile (HFP) and Audio Streaming Profile (A2DP/AVRCP). 1. Activate Bluetooth on your mobile phone. If necessary make the ② mobile phone visible to other devices. 2. -
Page 11: Bluetooth - Creating A Connection
BLUETOOTH – CREATING A CONNECTION ① Each mobile phone needs to be paired by exchanging a password. The pairing process can be started either from MIB3 or the mobile phone, if the car device does not show the mobile phone. 1. -
Page 12: Bluetooth - Deauthorize A Mobile Telephone
BLUETOOTH – DEAUTHORIZE A MOBILE PHONE -- this function is currently unavailable – ① Deauthorization can be conducted in the menu ‚Telephone‘. 1. Enter the menu ‚Telephone‘ or press function key ‚Phone‘. 2. Select on the connected device on the screen. 3. -
Page 13: Bluetooth - Interacting With Mobile Phone
BLUETOOTH – INTERACTING WITH A MOBILE PHONE ① After successfully connecting to a mobile phone several new options will be available. 1. Select the function key ‚Phone‘ or the icon ‚Telephone‘on the touch screen to receive more options. 2. The ‚Telephone‘ screen will show the name of the connected ②... -
Page 14: Smart Link
SmartLink – Android Auto & MirrorLink ① 1. Select the menu ‚SmartLink‘. 2. Connect the mobile phone with the USB cable. 3. Select one of two options: Android Auto or MirrorLink. Confirm the pairing (exchange of key) on the MIB3 and the mobile phone. Allow ②... -
Page 15: Vehicle Information
VEHICLE INFORMATION ① Vehicle information can be displayed by the MIB3. 1. On the default menu screen, select the ‘Vehicle’ icon or press the ‘CAR’ function key. 2. Several menus can be accessed by selecting the icon ‘!Vehicle stat’. ② 3. -
Page 16: Media - Radio, Usb, Bt And Smartlink
MEDIA – RADIO, USB, BT AND SMARTLINK ① In this menu, several audio media sources can be selected for playing. 1. On the default menu screen, select the ‘Audio’ icon or press the ‘Audio’ function key. ② 2. When touching ‘!Media’, different media sources can be selected such as USB1 or USB2, Bluetooth audio or Smart link. -
Page 17: Driver Assistance
Driver Assistance -- this function is currently unavailable – ① In this menu, driver assistance functions can be accessed and adjusted such as cruise control, lane assist, driver alert system, etc.. 1. On the default menu screen, select the ‘Driver assist.’ icon to access driver assistance functionalities. -
Page 18: Sound Adujstments
SOUND ADJUSTMENT ① MIB3 provides several options to individualize the sound in the car. 1. Select the icon ‚Sound‘ to view more options. 2. The ‚Equalizer‘ menu allows basic adjustments to the sound. ② 3. The ‚Sound focus‘ allows to control the focus point within the car. 4. -
Page 19: System Settings
SYSTEM SETTINGS MIB3 system settings allow making a various amount of changes. 1. Select the icon ‚Settings‘ on the touch screen. 2. The following options are available: No. Name Description 1 Screen Screen off (in seconds), brightness and other functions 2 Time and date Time and date 3 Language... -
Page 20: Legal Information
LEGAL INFORMATION ① The MIB3 system allows to obtain fast legal information about the system. 1. On second page of the default menu screen (swipe left) then select the ‘Legal’ Icon. 2. The ‘Legal’ screen shows brief legal information and additional QR codes. -
Page 21: Regulatory Information - Ce Market
EC Market Declaration of Conformity (DoC) Hereby, Panasonic Automotive Systems Europe GmbH declares that the radio equipment type Car Radio System with Bluetooth is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.doc.panasonic.de... -
Page 22: Regulatory Information - Fcc / Ised
REGULATORY INFORMATION - USA/Canada market Modification statement / Déclaration de modification Panasonic Automotive & Industrial Systems Europe GmbH has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user's authority to operate the equipment.
