DEV-30/50/50V
SERVICE MANUAL
Ver. 1.0 2013.05
Check the SERVICE NOTE (LEVEL 2) before the service.
DIGITAL RECORDING BINOCULARS
The components identified
Les composants identifiés par
by mark 0 or dotted line with
une marque 0 sont critiques
mark 0 are critical for safety.
pour la sécurité.
Replace only with part number
Ne les remplacer que par une
specified.
pièce portant le numéro spécifié.
DEV-30/50/50V_L3
9-834-736-11
Canadian Model
Chinese Model
Japanese Model
Tourist Model
Photo: DEV-50V
Ver.
Date
3
LEVEL
1.0
2013.05
US Model
AEP Model
Sony Corporation
Revision History
History
Contents
Official Release
—
983473611.pdf
S.M. Rev.
issued
—
2013E08-1
© 2013.05
Published by Sony Techno Create Corporation

Advertisement

Table of Contents
loading

Related Manuals for Sony DEV-30

Summary of Contents for Sony DEV-30

  • Page 1 0 sont critiques mark 0 are critical for safety. pour la sécurité. Replace only with part number Ne les remplacer que par une specified. pièce portant le numéro spécifié. 2013E08-1 DEV-30/50/50V_L3 © 2013.05 Sony Corporation 9-834-736-11 Published by Sony Techno Create Corporation...

  • Page 2: Plastic Parts

    DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO- CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM- NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT サービス，点検時には次のことにご注意ください。...

  • Page 3: Repair Parts List

    (All mounted parts and JK-1005 COMPLETE BOARD are not supplied, but they are < BATTERY HOLDER > included in JKR BLOCK ASSY.) BH8001 1-251-928-21 SOCKET, BATTERY < CAPACITOR > C7501 1-118-417-11 CERAMIC CHIP 0.1uF C7502 1-118-417-11 CERAMIC CHIP 0.1uF C7503 1-118-417-11 CERAMIC CHIP 0.1uF DEV-30/50/50V_L3...
  • Page 4 0.1uF C3602 1-118-417-11 CERAMIC CHIP 0.1uF C1431 1-118-417-11 CERAMIC CHIP 0.1uF C1810 1-118-417-11 CERAMIC CHIP 0.1uF C3603 1-116-720-11 CERAMIC CHIP 10uF 6.3V CN9001 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P C1434 1-118-417-11 CERAMIC CHIP 0.1uF C1811 1-116-720-11 CERAMIC CHIP 10uF 6.3V DEV-30/50/50V_L3...
  • Page 5 L4301 1-460-355-11 INDUCTOR 4.7uH C4311 1-116-720-11 CERAMIC CHIP 10uF 6.3V C5214 1-118-417-11 CERAMIC CHIP 0.1uF F002 1-523-133-31 FUSE (1.4A/50V) L4302 1-460-370-11 INDUCTOR 10uH C4312 1-116-720-11 CERAMIC CHIP 10uF 6.3V C5219 1-100-415-91 CERAMIC CHIP 0.47uF 6.3V L4303 1-460-370-11 INDUCTOR 10uH DEV-30/50/50V_L3...
  • Page 6 R2301 1-218-957-11 METAL CHIP 2.2K 1/16W R4819 1-218-959-11 METAL CHIP 3.3K 1/16W R4830 1-218-977-11 METAL CHIP 100K 1/16W R2302 1-218-957-11 METAL CHIP 2.2K 1/16W R5209 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W R2303 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W DEV-30/50/50V_L3 2-4E...

  • Page 7: Overall Block Diagram

    XGPS_RST XGPS_RST FP-2137 FLEXIBLE LD-1010 BOARD (1/2) 16.368MHz CN1018 BOARD (SUB) (1/2) (1/2) CN5101 CN5104 (1/2) SDIO_SPDIF_IN_IC_3001 SP_+ DAO_D1 SP901 MISO_SDA AV_SI (SPEAKER) SP_- BCK_OUT, LRCK_OUT, AV_SO, AV_SCK IC3001 MCK_INOUT AUDIO XCS_IC_3001 (9/21) OVERALL (3/3) XSYS_RST XSYS_RST (PAGE 3-3) DEV-30/50/50V_L3...
  • Page 8 RS-1004 BOARD XCHARGE_LED SELECTOR SWITCHES S8501 KEY_AD3 KEY_AD3 S8201 - S8203 MANUAL XPOWER_TACT_SW CONTROL XTALLY_LED D8102 KEY_AD1 KEY_AD1 SWITCHES (RECORDING) RV8201 ZOOM_VR_AD ZOOM_VR_AD D8101 XCHARGE_LED ZOOM XPHOTO_LED XPHOTO_LED D8202 (PHOTO) XPOWER_TACT_SW XCHARGE_LED OVERALL (3/3) XCAM_LED XCAM_LED D8203 (CAM) (PAGE 4-3) DEV-30/50/50V_L3...
  • Page 9 PITCH±_S 10, 11 22, 23 23, 24 PITCH_HALL±/BIAS- PITCH_HALL±/BIAS-_S PITCH/YAW 21 - 23 29 - 31 15 - 17 YAW± YAW±_S DRIVE 12, 13 20, 21 25, 26 YAW_HALL±/BIAS- YAW_HALL±/BIAS-_S 17 - 19 26 - 28 18 - 20 DEV-30/50/50V_L3...

  • Page 10: Power Block Diagram

    XI_POWER_OFF E10 D- 7 O_INIT_CHARGE XPWR_OFF_S LANC_DC Q4801 XI_POWER_OFF_S K7 POWER (2/3) SEL_UART_LANC BATT/XEXT_CN DC JACK (PAGE 4-5) PUI_BATT_XEXT LOAD_ON_FR2 XPOWER_TACT_SW DETECT O_LOAD_ON_FR2 E3 CN1002 XLANC_PWR_ON XPUI_LANC_PWR_ON D_2.8V XLANC_ON XO_LANC_IC_ON EVER_3.0V XPOWER_TACT_SW XPOWER_TACT_SW POWER (3/3) XPUI_POWER_TACT A3 (PAGE 4-6) DEV-30/50/50V_L3...
  • Page 11 (13/21) ZOOM/FOCUS D_1.8V D_1.8V_HDMI_RX MT_5.0V SWITCH BUFFER MOTOR DRIVE Q4802 IC3602 (2/21) (21/21) LOAD_SW2 HDMI POWER BUFFER ON/OFF A_1.2V IC3501 (13/21) A_1.8V IC1302 HDMI TRANSMITTER RXA_5V (12/21) CLOCK IC3603 GENERATOR IC3701 (2/21) LEVEL SHIFT HDMI RECEIVER (13/21) (SUB) (14/21) DEV-30/50/50V_L3...
  • Page 12 DETECT ZM-1001 BOARD KY-1005 BOARD IC6502 LEVEL SHIFT CN8201 CN8202 CN8101 D8101 EVER_3.0V EVER_3.0V EVER_3.0V IC6501 D_2.8V D_2.8V D_2.8V D8102 D_1.8V D_1.8V EVF SERIAL (RECORDING) INTERFACE RECEIVER S8203 POWER (1/3) D8202 (PAGE 4-4) POWER (PHOTO) XPOWER_TACT_SW D8203 (CAM) DEV-30/50/50V_L3 4-6E...

  • Page 13: Frame Schematic Diagram

    FP-2141 LITHIUM FLEXIBLE BOARD SS-1001 BOARD BATTERY RS-1003 BOARD (SIDE B) (SIDE A) CN8001 SE7501 PITCH/YAW CN8402 MS-1012 BOARD S8401 (SIDE B) SS-1001 BOARD MANUAL RS-1003 BOARD (SIDE A) (SIDE B) BT901 START/STOP BATTERY RS-1004 BOARD TERMINAL S8501 MANUAL DEV-30/50/50V_L3...
  • Page 14 Flexible Flat Cable (FFC-1039) (SIDE A) (Page 5-1) S8203 CN8201 POWER VC-1016 KY-1005 BOARD Flexible Flat Cable (FFC-1038) BOARD (SIDE A) JY-1001 BOARD (SIDE B) (Page 5-1) (SIDE A) S8101 S8601 FP-2136 FLEXIBLE BOARD (L) (MULTI SELECTOR) S8102 START/STOP FINDER 2D/3D DEV-30/50/50V_L3 5-2E...

  • Page 15: Schematic Diagrams And Printed Wiring Boards

    0 are critical 0印の部品，または0印付の点線で囲まれた部品は， for safety. 安全性を維持するために，重要な部品です。 Replace only with part number specified. 従って交換時は，必ず指定の部品を使用してください。 Les composants identifiés par une marque 0 sont critiques pour la sécurité. Ne les remplacer que par une pièce portant le numéro spécifié. DEV-30/50/50V_L3...

  • Page 16: Schematic Diagrams

    REG_GND R6705 C6717 CL009 XCLR XFLASH_RST 0.1u REG_GND REG_GND R6728 A_2.8V CL010 R6767 INCK CLK_CMOS_IN R6708 REG_GND REG_GND XCLR C6745 CN6702 C6753 REG_GND R6741 A_2.8V CMOS_A_3.3V R6729 C6728 C6729 REG_GND CM-123 BOARD (MAIN) CMOS IMAGER XX MARK: NO MOUNT DEV-30/50/50V_L3...
  • Page 17 REG_GND R6705 C6717 CL009 XCLR XFLASH_RST 0.1u REG_GND REG_GND R6728 A_2.8V CL010 R6767 INCK CLK_CMOS_IN R6708 REG_GND REG_GND XCLR C6745 CN6702 C6753 REG_GND R6741 A_2.8V CMOS_A_3.3V R6729 C6728 C6729 REG_GND CM-123 BOARD (SUB) CMOS IMAGER XX MARK: NO MOUNT DEV-30/50/50V_L3...
  • Page 18 XFLASH_RST REG_GND REG_GND REG_GND REG_GND XCLR XFLASH_RST INCK_FPC CLK_CMOS_IN REG_GND REG_GND REG_GND REG_GND INCK_FPC CLK_CMOS_IN REG_GND REG_GND FP-2134 FLEXIBLE BOARD FP-2135 FLEXIBLE BOARD CM (MAIN)-VC CONNECTION CM (SUB)-VC CONNECTION (PRINTED WIRING BOARD is omitted.) (PRINTED WIRING BOARD is omitted.) DEV-30/50/50V_L3...
  • Page 19 SCHEMATIC DIAGRAM are omitted. INT_MIC_L AUDIO_GND AUDIO_GND 47 46 Note: MIC901 is not included in LD-1009 COMPLETE BOARD. CN5003 MIC901 AUDIO_GND AUDIO_GND MICROPHONE UNIT INT_MIC_R INT_MIC_R AUDIO_GND INT_MIC_L INT_MIC_L LD-1009 BOARD (1/2) LENS BLOCK (MAIN) XX MARK: NO MOUNT DEV-30/50/50V_L3...
  • Page 20 GY_GND PITCH_AD PITCH_AD GY_GND GY_GND Note: IC7701 and SE7701 are not supplied, but they are included in LD-1009 COMPLETE BOARD. LD-1009 BOARD (2/2) FP-2138 FLEXIBLE BOARD ROLL SENSOR VC-MS CONNECTION XX MARK: NO MOUNT (PRINTED WIRING BOARD is omitted.) DEV-30/50/50V_L3...
  • Page 21 REG_GND and SCHEMATIC DIAGRAM are omitted. INT_MIC_L AUDIO_GND REG_GND 47 46 SP901 (SPEAKER) CN5104 SP_+ SP_+ SP_- SP_- VDR511 VDR512 REG_GND LD-1010 BOARD Note: SP901 is not included in LD-1010 COMPLETE BOARD. LENS BLOCK (SUB) XX MARK: NO MOUNT DEV-30/50/50V_L3...
  • Page 22 Z_PI_C Z_PI_C Z_PI_C F_PI_C F_PI_C F_PI_C F_PI_C D_2.8V_LD D_2.8V_LD D_2.8V_LD D_2.8V_LD REG_GND REG_GND REG_GND REG_GND FP-2137 FLEXIBLE BOARD (MAIN) FP-2137 FLEXIBLE BOARD (SUB) VC-LD (MAIN) CONNECTION VC-LD (SUB) CONNECTION (PRINTED WIRING BOARD is omitted.) (PRINTED WIRING BOARD is omitted.) DEV-30/50/50V_L3...
  • Page 23 Note: J901 is not included in REG_GND VC-1016 COMPLETE BOARD (SERVICE). ET1001 HP_L_OUT HP_L_OUT REG_GND REG_GND HP_R_OUT HP_R_OUT REG_GND REG_GND VC-1016 BOARD (1/21) HP_JACK_IN HP_JACK_IN CONNECTORS JK-1005 CN7901 XX MARK: NO MOUNT Through the Flexible Flat Cable (FFC-1040) (PAGE 6-37) DEV-30/50/50V_L3...
  • Page 24 C1319 C1321 USB_PWR_EN AF21 0.1u AE30 AVSS_PLL1 R1381 USB_ACV_DET AE20 HP_JACK_IN AE29 AVSS_PLL1 AE26 AVSS_PLL2 AVSS_PLL2 AE25 VC-1016 BOARD (2/21) CPU (MAIN), CAMERA DSP, AV SIGNAL PROCESS, LENS CONTROL, MODE CONTROL, HDMI PROCESS (1/3) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-10...
  • Page 25 SATA_TX0SOP PVDD_SATA SATA_TX0SON AVDD18_SATA SATA_CKREFP VTERM0_SATA SATA_CKREFN REG_GND AVSSC_SATA SATA AVSSC_SATA AVSSC_SATA SATA_AMOUT AVSSC_SATA AVSSC_SATA AVSSC_SATA AVSSC_SATA VC-1016 BOARD (3/21) CPU (MAIN), CAMERA DSP, AV SIGNAL PROCESS, LENS CONTROL, MODE CONTROL, HDMI PROCESS (2/3) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-11...
  • Page 26 FSP_XRST_IN AK28 XFLASH_RST N.C. AK31 N.C. COM152 FSP_INT AF23 N.C. N.C. N.C. N.C. N.C. N.C. REG_GND C1517 VC-1016 BOARD (4/21) CPU (MAIN), CAMERA DSP, AV SIGNAL PROCESS, LENS CONTROL, MODE CONTROL, HDMI PROCESS (3/3) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-12...
  • Page 27 AVSS_PLL0 C1619 C1621 USB_PWR_EN AF21 REG_GND 0.1u AE30 AVSS_PLL1 USB_ACV_DET AVSS_PLL1 AE20 AE29 AE26 AVSS_PLL2 AE25 AVSS_PLL2 VC-1016 BOARD (5/21) CPU (SUB), CAMERA DSP, AV SIGNAL PROCESS, LENS CONTROL, MODE CONTROL, HDMI PROCESS (1/3) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-13...
  • Page 28 SATA_TX0SOP PVDD_SATA SATA_TX0SON AVDD18_SATA SATA_CKREFP VTERM0_SATA SATA_CKREFN REG_GND SATA AVSSC_SATA AVSSC_SATA AVSSC_SATA SATA_AMOUT AVSSC_SATA AVSSC_SATA AVSSC_SATA AVSSC_SATA VC-1016 BOARD (6/21) CPU (SUB), CAMERA DSP, AV SIGNAL PROCESS, LENS CONTROL, MODE CONTROL, HDMI PROCESS (2/3) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-14...
  • Page 29 FSP_XRST_IN AK28 XFLASH_RST_S N.C. N.C. AK31 COM183 FSP_INT AF23 N.C. N.C. N.C. N.C. N.C. N.C. REG_GND C1817 VC-1016 BOARD (7/21) CPU (SUB), CAMERA DSP, AV SIGNAL PROCESS, LENS CONTROL, MODE CONTROL, HDMI PROCESS (3/3) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-15...

  • Page 30: Audio Processor

    C2321 AUDIO_GND C2314 C2315 C2316 C2317 C2320 0.001u 0.001u 0.001u 0.001u C2319 0.0047u R2311 220k BEEP_PWM_P C2318 470p SP_+ SP_- XSYS_RST C2301 R2301 2200 AUDIO_L_I/O AUDIO_R_I/O R2302 C2302 2200 VC-1016 BOARD (8/21) AUDIO PROCESSOR XX MARK: NO MOUNT DEV-30/50/50V_L3 6-16...
  • Page 31 B3 B4 A2 A3 A4 C3003 C3002 C3001 0.1u DAO_D1 CLOCK CL3001 MCLK IC3001 DBDA CS48L10-CWZR AUDIO DSP DBCK R3001 XSYS_RST XRESET CLK/SCL COM303 C3004 RB3001 AV_SCK AV_SO MISO_SDA XCS_IC_3001 VC-1016 BOARD (9/21) AUDIO DSP XX MARK: NO MOUNT DEV-30/50/50V_L3 6-17...
  • Page 32 EVF_B_4_R EVF_B_4_R EVF_B_3_R EVF_B_3_R EVF_B_2_R EVF_B_2_R EVF_B_1_R EVF_B_1_R EVF_B_0_R EVF_B_0_R Note: IC3106, IC3107, IC3108, IC3109 and IC3110 are not supplied, but they are included in VC-1016 COMPLETE BOARD (SERVICE). VC-1016 BOARD (10/21) 2D/3D SWITCH XX MARK: NO MOUNT DEV-30/50/50V_L3 6-18...
  • Page 33 EVF_XHD_R PCLK EVF_CLK_R EVF_R_7_R EVF_R_6_R EVF_R_5_R EVF_R_4_R EVF_R_3_R EVF_R_2_R EVF_R_1_R A9 B9 A8 B8 A7 B7 A6 B6 A5 A1 B5 A4 B4 A3 B3 A2 B2 B1 E2 C2 VC-1016 BOARD (11/21) SERIALIZER XX MARK: NO MOUNT DEV-30/50/50V_L3 6-19...

  • Page 34: Hdmi Transmitter

    HDMI_C4_IC_3901 HDMI_C5_IC_3901 HDMI_C5_IC_3901 HDMI_C6_IC_3901 HDMI_C6_IC_3901 HDMI_C7_IC_3901 HDMI_C7_IC_3901 C7 C6 C5 D6 B1 C3 A3 F1 G7 F7 E5 E7 HDMI_DE_IC_3901 HDMI_DE_IC_3901 HDMI_HSYNC_IC_3901 HDMI_HSYNC_IC_3901 HDMI_VSYNC_IC_3901 HDMI_VSYNC_IC_3901 HDMI_VCK_IC_3901 HDMI_VCK_IC_3901 HDMI_AMRX HDMI_AMRX VC-1016 BOARD (12/21) HDMI TRANSMITTER XX MARK: NO MOUNT DEV-30/50/50V_L3 6-20...
  • Page 35 R3602 XX HDMI_C5_RX D_1.8V_HDMI_RX D_1.8V HDMI_C4_RX HDMI_C4_RX HDMI_C3_RX Q3602 HDMI_C3_RX SSM3K121TU,LSOYF HDMI_C2_RX HDMI_C2_RX B+ SWITCH R3603 XX HDMI_C1_RX A_1.8V_HDMI_RX HDMI_C1_RX A_1.8V HDMI_C0_RX HDMI_C0_RX R3605 LOAD_SW2 C3602 0.1u REG_GND VC-1016 BOARD (13/21) HDMI RECEIVER (MAIN) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-21...
  • Page 36 HDMI_C6_RX_S HDMI_C6_RX_S HDMI_C7_RX_S HDMI_C7_RX_S HDMI_C0_RX_S HDMI_C0_RX_S 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 HDMI_C1_RX_S HDMI_C1_RX_S HDMI_C2_RX_S HDMI_C2_RX_S HDMI_C3_RX_S HDMI_C3_RX_S VC-1016 BOARD (14/21) HDMI RECEIVER (SUB) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-22...
  • Page 37 GPO3 FSP_AD_6 FSP_AD_B_6 D_3.3V P10 TCK GPO2 FSP_AD_5 FSP_AD_B_5 GPO1 FSP_AD_B_4 FSP_AD_4 GPO0 FSP_AD_3 FSP_AD_B_3 P11 TMS FSP_AD_2 FSP_AD_B_2 P12 TRST FSP_AD_1 FSP_AD_B_1 FSP_AD_0 G14 FSP_AD_B_0 REG_GND P13 VPD VC-1016 BOARD (15/21) HDMI MIXING XX MARK: NO MOUNT DEV-30/50/50V_L3 6-23...
  • Page 38 C4361 C4360 R4358 REG_GND Q4310 IC4306 DSA300100L R4354 R1200N003A-TR-FE EVF_10V DC/DC CONVERTER DDEN_L DDEN_R Q4308 R4359 C4363 DRC3144E0L VOUT VC-1016 BOARD (16/21) C4358 C4359 0.1u R4360 Q4311 HN1C01FE DC/DC CONVERTER R4364 R4362 COM439 XX MARK: NO MOUNT REG_GND DEV-30/50/50V_L3 6-24...

  • Page 39: Front Control

    LANC_IN LANC_OUT XLANC_PWR_ON XLANC_ON Note: IC4801 ans R4815 are not supplied, but they are included in VC-1016 COMPLETE BOARD (SERVICE). LOAD_SW2 GENERAL_AD GENERAL_AD VC-1016 BOARD (17/21) SYSTEM_AD SYSTEM_AD REG_GND FRONT CONTROL COM481 XX MARK: NO MOUNT COMMON-GND2 REG_GND DEV-30/50/50V_L3 6-25...
  • Page 40 C5221 I_DRIVE- OUT0B C5219 0.47u 0.47u OPIN2P OUT1A REG_GND DAC2OUT OUT1B OPIN2N TEST OPOUT2 D_1.8V D_2.8V MT_5.0V IC_5201_GND COM521 REG_GND IC_5201_SCK XCS_IC_5201 IC_5201_SO IC_5201_SI XIC_5201_RST IC_5501_IC_5201_CLK_M IC_5201_VD VC-1016 BOARD (18/21) IRIS MOTOR DRIVE (MAIN) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-26...
  • Page 41 PIO3 I_DRIVE+_S OPIN3N OUT0A I_DRIVE-_S OPOUT3 OUT0B OPIN2P OUT1A DAC2OUT OUT1B TEST OPIN2N OPOUT2 D_1.8V D_2.8V MT_5.0V IC_5301_S_GND COM531 REG_GND IC_5301_SCK_S XCS_IC_5301_S IC_5301_SO_S IC_5301_SI_S XIC_5301_RST_S IC_5501_IC_5301_CLK_S IC_5301_VD_S VC-1016 BOARD (19/21) IRIS MOTOR DRIVE (SUB) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-27...
  • Page 42 PITCH+_S IN3A OUT3A YAW-_S IN3B OUT3B YAW+_S IN4A OUT4A FOCUS_XA FC_ENB H10 IN4B OUT4B FOCUS_A FC_DIR_A FC_ENB IN5A OUT5A FOCUS_XB FC_DIR_B G10 IN5B OUT5B FOCUS_B IN6A OUT6A IN6B OUT6B VC-1016 BOARD (20/21) STEADYSHOT PROCESSOR XX MARK: NO MOUNT DEV-30/50/50V_L3 6-28...
  • Page 43 OUT6B PGND2 OUT7A PGND2 OUT7B COM571 MT_GND_7DRV REG_GND G2 F7 F6 G7 G3 G4 D1 D7 A4 G5 C1 E1 R5701 MT_5.0V C5702 C5704 C5705 COM572 0.1u MT_GND_7DRV VC-1016 BOARD (21/21) ZOOM/FOCUS MOTOR DRIVE XX MARK: NO MOUNT DEV-30/50/50V_L3 6-29...
  • Page 44 VREGA PITCH/YAW SENSOR C7501 GND3 0.1u VREGD VREF GYRO_VREF 11 12 13 14 15 C7515 0.047u R7512 C7514 C7513 C7502 0.33u 0.1u C7503 C7504 0.1u 0.1u GY_GND GY_GND GYRO_VREF MS-1012 BOARD (1/2) PITCH/YAW SENSOR XX MARK: NO MOUNT DEV-30/50/50V_L3 6-30...

  • Page 45: Memory Card Connector

    REG_GND SD_DAT_1 REG_GND CL8001 FR_XRESET BATT_LI_3V BT8001 (LITHIUM BATTERY) D_2.8V D8001 SML-D12V8WT86SN (ACCESS) XMS_ACC_LED BH8001 R8052 (BATTERY HOLDER) REG_GND Note: BT8001 is not included in MS-1012 BOARD (SERVICE). MS-1012 BOARD (2/2) MEMORY CARD CONNECTOR XX MARK: NO MOUNT DEV-30/50/50V_L3 6-31...

  • Page 46: Control Switches

    Note: All mounted parts and ZM-1001 COMPLETE BOARD are not supplied, D8202 but they are included in CABINET (TOP) BLOCK ASSY. CL-271SYG-C-TS D_2.8V (PHOTO) ZOOM_VR_AD XPHOTO_LED D8203 CL-271SYG-C-TS (CAM) REG_GND XCAM_LED ZM-1001 BOARD CONTROL SWITCHES XX MARK: NO MOUNT DEV-30/50/50V_L3 6-32...
  • Page 47 VF BLOCK ASSY (SERVICE). but this is included in VF BLOCK ASSY (SERVICE). FP-2136 FLEXIBLE BOARD (L) FP-2136 FLEXIBLE BOARD (R) VC-VF (L) CONNECTION VC-VF (R) CONNECTION (PRINTED WIRING BOARD is omitted.) (PRINTED WIRING BOARD is omitted.) DEV-30/50/50V_L3 6-33...
  • Page 48 VDD3 VDD2 C6026 2.2u DS_Hi VDD4 CN6003 Note: All mounted parts, VF-1006 COMPLETE BOARD and EVF UNIT are not supplied, but they are included in VF BLOCK ASSY (SERVICE). VF-1006 BOARD DESERIALIZER, EVF (L) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-34...
  • Page 49 VDD3 C6523 2.2u VDD2 DS_Hi VDD4 CN6502 Note: All mounted parts, VF-1007 COMPLETE BOARD and EVF UNIT are not supplied, but they are included in VF BLOCK ASSY (SERVICE). VF-1007 BOARD DESERIALIZER, EVF (R) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-35...

  • Page 50: Start/Stop Switch

    REG_GND REG_GND Note: All mounted parts and SS-1001 COMPLETE BOARD are not supplied, but they are included in VF BLOCK ASSY (SERVICE). RS-1003 BOARD ROTARY ENCODER SS-1001 BOARD XX MARK: NO MOUNT START/STOP SWITCH XX MARK: NO MOUNT DEV-30/50/50V_L3 6-36...
  • Page 51 JKR BLOCK ASSY. Note: FP-2146 FLEXIBLE BOARD is not supplied, but this is included in VF BLOCK ASSY (SERVICE). JK-1005 BOARD JACK XX MARK: NO MOUNT FP-2146 FLEXIBLE BOARD RS-SS CONNECTION (PRINTED WIRING BOARD is omitted.) DEV-30/50/50V_L3 6-37...

  • Page 52: Usb Connector

    Note: All mounted parts and JY-1001 COMPLETE BOARD are not supplied, BATT_UNREG BATT_UNREG but they are included in CABINET (TOP) BLOCK ASSY. BATT_UNREG BATT_UNREG BATT_UNREG BATT_UNREG Note: BT901 is not included in FP-2141 FLEXIBLE BOARD. JY-1001 BOARD CONTROL SWITCHES FP-2141 FLEXIBLE BOARD XX MARK: NO MOUNT BATTERY TERMINAL DEV-30/50/50V_L3 6-38...
  • Page 53 SIN0/RX0_1 XSCS0/CTS_1 XSCS0/CTS_1 SCK0/TX0_1 SCK0/TX0_1 SO0/RTS_1 SO0/RTS_1 C9305 C9306 C9307 C9310 Note: All mounted parts and GP-1009 COMPLETE BOARD are not supplied, but they are included in GP405 ASSY. GPS_GND GPIO14 GP-1009 BOARD (1/2) XX MARK: NO MOUNT DEV-30/50/50V_L3 6-39...
  • Page 54 CN0102 but they are included in CABINET (TOP) BLOCK ASSY. (PAGE 6-9) (PAGE 6-40) GPS_RTS GPS_CTS GPS_RX0 GPS_TX0 GPS_CTS GPS_RTS KY-1005 BOARD SWITCHES, LED XX MARK: NO MOUNT FP-2147 FLEXIBLE BOARD VC-GP CONNECTION (PRINTED WIRING BOARD is omitted.) DEV-30/50/50V_L3 6-40...

  • Page 55: Printed Wiring Boards

    C6729 1-884-413- 11 1-884-413- 11 Note: All mounted parts are not supplied, but they are included in CM-123 COMPLETE BOARD. Note: CM-123 BOARDs are used the same complete boards for MAIN and SUB imager. DEV-30/50/50V_L3 : Uses unleaded solder. 6-41...
  • Page 56 R1007 R1372 FB1301 CN1005 R1382 C1343 CN1008 RB1418 CN1007 CN1015 CN1018 CN1003 1-887-725- 11 12 Note: IC1301, IC1601, IC3106, IC3109 and R4361 are not supplied, but they are included in VC-1016 COMPLETE BOARD (SERVICE). DEV-30/50/50V_L3 : Uses unleaded solder. 6-42...
  • Page 57 C5306 R5503 R5301 C5301 R5531 R5310 C5307 IC5301 C5312 C5538 1-887-725- 11 12 Note: CN1016, IC3107, IC3108, IC3110, IC4304, IC4801 and R4815 are not supplied, but they are included in VC-1016 COMPLETE BOARD (SERVICE). DEV-30/50/50V_L3 : Uses unleaded solder. 6-43...
  • Page 58 Note: All mounted parts and KY-1005 COMPLETE BOARD are not supplied, Note: All mounted parts and ZM-1001 COMPLETE BOARD are not supplied, but they are included in CABINET (TOP) BLOCK ASSY. but they are included in CABINET (TOP) BLOCK ASSY. DEV-30/50/50V_L3 : Uses unleaded solder. 6-44...
  • Page 59 L9306 C9321 C9316 CN0102 (USB) IC9301 C9302 C9311 C9315 L9305 1-886-906- 11 1-886-906- 11 1-887-907- 11 Note: All mounted parts and GP-1009 COMPLETE BOARD are not supplied, but they are included in GP405 ASSY. DEV-30/50/50V_L3 : Uses unleaded solder. 6-45...
  • Page 60 (BT8001) on the MS-1012 board. テリホルダ （BH8001） も同時に新品に交換してください。 (The battery holder removed once cannot be used again.) （一度使用したバッテリホルダは再使用できません。 ） When mounting these parts, mount new battery holder first and 部品取り付けの際は，先にバッテリホルダを取り付けてからリ attach new lithium battery next. チウム電池を装着してください。 DEV-30/50/50V_L3 : Uses unleaded solder. 6-46...
  • Page 61 Note: All mounted parts and RS-1004 COMPLETE BOARD are not supplied, but they are included in VF BLOCK ASSY (SERVICE). Note: All mounted parts and RS-1003 COMPLETE BOARD are not supplied, 1-887-908- 11 but they are included in VF BLOCK ASSY (SERVICE). DEV-30/50/50V_L3 6-47E...
