  • Page 1 SAMTRON 52V/72V...

  • Page 2: Safety Instructions

    Safety Instructions Notational Warning/Caution Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment. Notation Conventions Prohibited Do not disassemble Do not touch User’s Manual Important to read and understand at all times Disconnect the plug from the outlet Grounding to prevent an electric shock...
  • Page 3 Safety Instructions Power When not used for extended periods of time, set your PC to DPMS. If using a screen saver, set it to the active screen mode. • Do not use a damaged or loose plug. • This may cause an electric shock or fire. •...
  • Page 4 Safety Instructions Power • Disconnect the plug from the outlet during storms or lightening or if it is not used for a long period of time. • Failure to do so may cause an electric shock or fire. • Do not connect too many extension cords or plugs to an outlet.
  • Page 5 Safety Instructions Installation • Do not cover the vents on the monitor cabinet. • Bad ventilation may cause a breakdown or fire. • Put your monitor in a location with low humidity and a minimum of dust. • An electric shock or fire could result inside the monitor. •...

  • Page 6: Installation

    User’s Manual Safety Instructions Installation • Do not place the monitor face down. • The TFT-LCD surface may be damaged.
  • Page 7 Safety Instructions Clean When cleaning the monitor case or the surface of the TFT-LCD, wipe with a slightly moistened, soft fabric. • Do not spray detergent directly on the monitor. • Use the recommended detergent with a smooth cloth. • If the connector between the plug and the pin is dusty or dirty, clean it properly with a dry cloth.
  • Page 8 Safety Instructions Other • Do not remove cover(or back). No user serviceable parts inside. • This may cause an electric shock or a fire. • Refer servicing to qualified service personnel. • If your monitor does not operate normally - in particular, if there are any unusual sounds or smells coming from it - unplug it immediately and contact an authorized deal- er or service.
  • Page 9 Safety Instructions Other • Do not try to move the monitor by pulling on the wire or the signal cable. • This may cause a breakdown, electric shock or a fire due to damage to the cable. • Do not move the monitor right or left by pulling only the wire or the signal cable.
  • Page 10 Introduction Unparking Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Monitor and Stand User’s Manual Power Cord Signal Cable Quick Setup Guide Warranty Card (Not available in all locations) User's Guide and Driver Installation CD...
  • Page 11 Introduction Front 1. Auto button / Exit button 2. Menu button 3. Power button 4. Adjust buttons 5. Power indicator Note : See PowerSaver functions. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods.
  • Page 12 Introduction Rear (The configuration at the back of the monitor may vary from product to product.) 1. Power port : Connect the power cord for your monitor to the power port on the back of the monitor. 2. Signal cable : Connect the end of the signal cable to your computer's video port. (video board, video card or graphics card) Note : See Connecting Your Monitor for further information regarding cable connections.

  • Page 13: Connecting Your Monitor

    Setup Connecting Your Monitor 1. Connect the power cord for your monitor to the power port on the back of the monitor. Plug the power cord for the monitor into a nearby outlet.. 2. Connect the signal cable to the 15-pin, D-sub connector on the back of your monitor. 3.
  • Page 14 Setup When prompted by the operating system for the monitor driver, insert the CD-ROM included with this monitor. Driver installation is slightly different from one operating system to another. Follow the directions as appropriate for the operating system you have. Prepare a blank disk and download the driver program file at the Internet web site shown here.
  • Page 15 Setup Windows XP/2000 1. Insert CD into the CD-ROM drive. 2. Click "Windows XP/2000 Driver". 3. Choose your monitor model in the model list, then click the "OK" button. 4. Click the "Install" button in the "Warning" window. 5. If you can see following "Message" window, then click the "Continue Anyway" button. Then click "OK"...
  • Page 16 Setup When prompted by the operating system for the monitor driver, insert the CD-ROM included with this monitor. Driver installation is slightly different from one operating system to another. Follow the directions as appropriate for the operating system you have. Prepare a blank disk and download the driver program file at the Internet web site shown here.
  • Page 17 User’s Manual Setup 4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab. 5. Click "Update Driver.." and select "Install from a list or.." then click "Next" button. 6. Select "Don't search ,I will.." then click "Next" and then click "Have disk". 7.
  • Page 18 Setup 8. If you can see following "Message" window, then click the "Continue Anyway" button. Then click "OK" button. This monitor driver is under certifying MS logo,and this installation don't damage your system.The certified driver will be posted on SAMTRON Monitor Homepage http://www.samtron.com/ 9.
  • Page 19 Setup 10. Monitor driver installation is completed. ® ® Microsoft Windows When you can see "Digital Signature Not Found" on your monitor, follow these steps. 1. Choose "OK" button on the "Insert disk" window. 2. Click the "Browse" button on the "File Needed" window. 3.
  • Page 20 Setup ® ® Microsoft Windows 1. Click "Start" , "Setting" , "Control Panel". 2. Double click "Display" icon. 3. Select the "Settings" tab and click "Advanced Properties" button. 4. Select the "Monitor" tab. 5. Click the "Change" button in the "Monitor Type" area. 6.

  • Page 21: Removing The Base

    User’s Manual Setup Installing VESA compliant mounting Removing the base 1 Turn off your monitor and unplug its power cord. 2 Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the screen. 3 Remove the four screws and then remove the Stand from the LCD monitor.

  • Page 22: Attaching A Base

    User’s Manual Setup Installing VESA compliant mounting Attaching a base NOTE : This monitor accepts a 75mm x 75mm VESA-compliant mounting interface pad. 1 Rear cover mounting pad 2 Mounting interface pad Align the Mounting Interface Pad with the holes in the Rear Cover Mounting Pad and secure it with the four screws that came with the arm-type base, wall mount hanger or other base.

  • Page 23: On-Screen Display

    On-Screen Display Use this button to open the OSD and activate a highlighted menu item. Use these buttons to highlight and adjust items using the On Screen Display. Use this button to Exit the active menu or the OSD User’s Manual...

  • Page 24: Troubleshooting

    Troubleshooting Check List Before calling for service, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the warranty card, the phone number on the Information section or contact your Symptom No images on the Is the power cord connected...
  • Page 25 Troubleshooting Check List The screen shows Is the screen displaying only one color as if looking at the screen strange colors or through a cellophane paper? just black and white. Have the screen colors become strange after running a program or due to a crash between applications? Has the video card been set...
  • Page 26 Troubleshooting Check List Check the following items if there is trouble with the monitor. 1. Check if the power cord and the cable are properly connected to the computer. 2. Check if the computer beeps more than 3 times when booting. (If it does, request an after-service for the main board of the computer.) 3.
  • Page 27 Troubleshooting Q&A Question How can I change the frequency? How can I adjust the resolution? How can I set the Power Saving function? How can I clean the outer case/LCD Panel? Answer Frequency can be changed by reconfiguring the video card. Note that video card support can vary, depending on the version of the driver used.

  • Page 28: Self-Test Feature Check

    Troubleshooting Self-Test Feature Check Your monitor provides a self test feature that allows you to check whether your monitor is functioning properly. Self-Test Feature Check 1. Turn off both your computer and the monitor. 2. Unplug the video cable from the back of the computer. 3.

  • Page 29: Werning Messages

    Troubleshooting Self-Test Feature Check Werning Messages If there is something wrong with the input signal, a message appears on the screen or the screen goes blank although the power indicator LED is still on. The message may indicate that the monitor is out of scan range or that you need to check the signal cable.

  • Page 30: Specifications

    Specifications General General Model Name SAMTRON 52V LCD Panel Size 15.0 inch diagonal Display area 304,1 (H) x 228,1 (V) Pixel Pitch 0,297 (H) x 0,297 (V) Type a-si TFT active matrix Viewing Angle 140/120(L,R/T,B) Synchronization Horizontal 31 ~ 61 kHz Vertical 56 ~ 75 Hz Display Color...
  • Page 31 User’s Manual Specifications General Plug and Play Capability This monitor can be installed on any Plug & Play compatible system. Interaction of the monitor and computer systems will provide the best operating conditions and monitor settings. In most cases, monitor installation will proceed automatically, unless the user wishes to select alternate settings. Dot Acceptable TFT LCD panel manufactured by using advanced semiconductor technology with precision of 99.999% above is used for this product.
  • Page 32 Specifications PowerSaver This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you move the computer's mouse or press a key on the keyboard.

  • Page 33: Horizontal Frequency

    Specifications Preset Timing Modes If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows.
  • Page 34 Specifications General General Model Name SAMTRON 72V LCD Panel Size 17.0 inch diagonal Display area 337.92 (H) x 270.336 (V) Pixel Pitch 0.264 (H) x 0.264 (V) Type a-si TFT active matrix Viewing Angle 140/120(L,R/T,B) Synchronization Horizontal 31 ~ 81 kHz Vertical 56 ~ 75 Hz Display Color...
  • Page 35 User’s Manual Specifications General Dot Acceptable TFT LCD panel manufactured by using advanced semiconductor technology with precision of 99.999% above is used for this product. But the pixels of RED, GREEN, BLUE and WHITE color seem to be bright sometimes or some of black pixels could be seen. This is not from bad quality and you can use it without uneasiness.
  • Page 36 Specifications PowerSaver This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor into a low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you move the computer's mouse or press a key on the keyboard.

  • Page 37: Preset Timing Modes

    Specifications Preset Timing Modes If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjust the screen as follows.
  • Page 38 BOX 713, S- 194 27 UPPLANDS VÄSBY TEL : 468- 590- 966- 00 FAX : 468- 590- 966- 50 SAMTRON MEXICO SAMSUNG ELECTRONICS MEXICO, S.A. DE C. V. Mina No. 200, ESQ. GAVILANCOL. GUADALUPE DEL MORAL IZTAPALAPA, MEXICO, D.F. C.P. 09300 TEL.
  • Page 39 Information Terms • Dot Pitch The image on a monitor is composed of red, green and blue dots. The closer the dots, the higher the resolution. The distance between two dots of the same color is called the 'Dot Pitch'. Unit: mm •...
  • Page 40 Communications Commission. It is available from the U.S. Government Printing Office, Washington, DC 20402, Stock Number 004-000-00345-4. The party responsible for product compliance: SAMSUNG ELECTRONICS CO., LTD America QA Lab of Samsung 3351 Michelson Drive, Suite #290, Irvine, CA92612 USA Tel) 949-975-7310...
  • Page 41 Information Regulatory • IC Compliance Notice This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations of ICES-003. Cet appareil Numérique de classe Brespecte toutes les exigences du Règlemont NMB-03 sur les équipements produisant des interférences au Canada. •...

  • Page 42: What Does Labelling Involve

    User’s Manual Information Regulatory • TCO'95-Ecological requirements for personal computers (TCO applied model only) AB general requirements AB2 Written Eco-document acompanying the products Congratulations! You have just purchased a TCO'95 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and to the further development of environmentally-adapted electronic products.
  • Page 43 Information Regulatory What does labelling involve?(continue) TCO Development Unit 1996-11-29 On the page this folder you will find a brief summary of the environmental requirements met by this product. The complere environmental criteria document may be ordered from: TCO Development Unit S-11494 Stockholm Sweden Fax: +46 8 782 92 07...

  • Page 44: Why Do We Have Environmentally Labelled Computers

    User’s Manual Information Regulatory • TCO'99-Ecological requirements for personal computers (TCO applied model only) Congratulations! You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with a product developed for professional use. Your purchase has also contributed to reducing the burden on the environment and also to the further development of environmentally adapted electronics products.
  • Page 45 User’s Manual Information Regulatory TCO Development SE-114 94 Stockholm, Sweden Fax: +46 8 782 92 07 Email (Internet): development@tco.se Current information regarding TCO'99 approved and labelled products may also be obtained via the Internet, using the address: http://www.tco-info.com/ Environmental requirements Flame retardants Flame retardants are present in printed circuit boards, cables, wires, casings and housings.
  • Page 46 Information Regulatory • Medical Requirement Classifications: In accordance with UL 2601-1/IEC 60601-1, the product is cssified as Continuous duty Class I equipment, which is not protected against ingress of liquids. The product is not suitable for use in the presence of a flammable anaesthetic mixture with air or with oxygen or nitrous oxide. This equipment has been tested and found to comply with the limits for medical devices to the IEC 601-1-2:1994.

  • Page 47: For Better Display

    Information For Better Display 1. Adjust computer resolution and screen injection rate (refresh rate) in control panel of computer as described below to enjoy the best quality of picture. You can have an uneven quality of picture in the screen if the best quality of picture is not provided in TFT-LCD. Resolution: 1024 x 768 Vertical frequency (refresh rate): 60 Hz 2.

  • Page 48: Information In This Document Is Subject To Change Without Notice

    Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co., Ltd. is strictly forbidden. Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
