- Page 1 INVERTER Plug-in option FR-A7AY E kit-SC INSTRUCTION MANUAL PRE-OPERATION INSTRUCTIONS Analog output function INSTALLATION AND WIRING Digital output function PARAMETER LIST EXTENSION ANALOG OUTPUT DIGITAL OUTPUT...
- Page 2 Thank you for choosing this Mitsubishi Inverter plug-in option. SAFETY INSTRUCTIONS This Instruction Manual gives handling information and precautions for use of this equipment. Incorrect handling might cause an unexpected fault. Before using the equipment, please 1. Electric Shock Prevention read this manual carefully to use the equipment to its optimum.
- Page 3 2. Injury Prevention 3) Usage WARNING CAUTION • Do not modify the equipment. • The voltage applied to each terminal must be the ones • Do not perform parts removal which is not instructed in this specified in the Instruction Manual. Otherwise burst, damage, etc.
-
Page 4: Table Of Contents
— CONTENTS — 1 PRE-OPERATION INSTRUCTIONS Unpacking and Product Confirmation .....................1 1.1.1 Product confirmation............................1 Parts ..............................2 Specifications.............................3 2 INSTALLATION AND WIRING Pre-Installation Instructions ......................4 Installation Procedure ........................4 Wiring..............................9 3 PARAMETER LIST 4 EXTENSION ANALOG OUTPUT Wiring Example ..........................14 Internal Block Diagram........................15 Terminals ............................16 Extension Analog Output Function Parameter List..............17 Adjustment Procedure ........................18... - Page 5 5 DIGITAL OUTPUT Internal Block Diagram........................24 Terminals ............................25 Digital Output Function Parameter List ..................26 Output Signal List ..........................27...
-
Page 6: Pre-Operation Instructions
PRE-OPERATION INSTRUCTIONS Unpacking and Product Confirmation Take the plug-in option out of the package, check the product name, and confirm that the product is as you ordered and intact. This product is a plug-in option dedicated for the FR-E700-SC series (safety stop function model). 1.1.1 Product confirmation Check the enclosed items. -
Page 7: Parts
PRE-OPERATION INSTRUCTIONS Parts Mounting Terminal Front view Rear view hole block Mounting hole Connector Mounting hole Connect to the inverter option slot 5, 7 (Refer to page Terminal layout... -
Page 8: Specifications
PRE-OPERATION INSTRUCTIONS 1.3 Specifications (1) Output signals Voltage output (across terminals AM0-AMC) 0 to 10VDCMAX Current output (across terminals AM1-AMC) 0 to 20mADC (2) Output resolution Voltage output μ Current output (3) Output accuracy (reference value) ±10% of the full-scale output value Depends on the output signal type. -
Page 9: Installation And Wiring
INSTALLATION AND WIRING Pre-Installation Instructions Make sure that the input power of the inverter is off. CAUTION With input power on, do not install or remove the plug-in option. Otherwise, the inverter and plug-in option may be damaged. For prevention of damage due to static electricity, touch nearby metal before touching this product to eliminate static electricity from your body. - Page 10 INSTALLATION AND WIRING Inverter with one front cover (1) Remove the front cover from the inverter. (For removing the front cover, refer to the FR-E700 series instruction manual.) (2) Remove the PU cover from the front cover. Open the PU cover with a driver, etc. and remove it in the direction of arrow as shown below.
- Page 11 INSTALLATION AND WIRING (6) Remove the PU cover provided on the front cover for plug-in option and mount the other PU cover, which was removed in (2). (7) Loosen the terminal screws and insert the wires into the terminals. After that, fasten the terminal screws to the recommended tightening torque.
- Page 12 INSTALLATION AND WIRING Inverter with front covers 1 and 2 (1) Remove the front cover 1 and 2 from the inverter. (For removing the front cover, refer to the FR-E700 series instruction manual.) (2) Remove the PU cover from the front cover 2. For removing the PU cover, refer to page 5.
- Page 13 INSTALLATION AND WIRING (4) Junction (4) Hexagon connector spacer (4) Plug-in option connector of inverter Front cover for plug-in option Replace Installation completed (4) Spacer for (6) Mounting screws plug-in option (short) mounting (6) Mounting screw (long)
-
Page 14: Wiring
INSTALLATION AND WIRING Wiring (1) Untwist the twisted pair shielded cables after stripping its sheath. Shield Also, perform protective treatment of the shield to ensure that it will not (perform protective treatment) make contact with the conductive area. Sheath Twisted pair Strip off the sheath about the size as in the right figure. - Page 15 INSTALLATION AND WIRING REMARKS • Information on blade terminals Commercially available product examples (as of Jan. 2010) Wire Size Blade Terminal Model Terminal Maker Screw Size With insulation sleeve Without insulation sleeve Phoenix Contact 0.3, 0.5 AI 0,5-6WH A 0,5-6 Co.,Ltd.
- Page 16 INSTALLATION AND WIRING POINT If a hook of the front cover for plug-in option impedes wiring, cut the hooks off and perform wiring. Cut off hooks at the bottom of the Cut off with a option cover. nipper, etc. (Cut off so that no portion is left.) REMARKS The protective structure (JEM1030) is the open type (IP00).
-
Page 17: Parameter List
PARAMETER LIST When the FR-A7AY is mounted on the inverter, the following parameters are extended. Minimum Parameter Initial Refer to Name Setting Range Setting Number alue Page Increments 1 to 3, 5, 7 to 12, 14, 21, Analog output signal selection 24, 52, 53, 61, 62 Setting for zero analog output 0 to100%... - Page 18 PARAMETER LIST Minimum Parameter Initial Refer to Name Setting Range Setting Number alue Page Increments DO0 output selection 0, 1, 3, 4, 7, 8, 11 to 16, 20, 25, 26, 46, 47, 64, DO1 output selection 80, 81, 90, 91, 93, DO2 output selection 95, 96, 98, 99, 100, 101, 103, 104, 107, 108,...
-
Page 19: Extension Analog Output
EXTENSION ANALOG OUTPUT 4.1 Wiring Example By setting the Pr. 306 to Pr. 312 values, analog signals such as the output frequency and output current can be output from the voltage output terminal (AM0) and current output terminal (AM1). Connect the voltmeter or ammeter as shown below: Inverter Motor MCCB... -
Page 20: Internal Block Diagram
EXTENSION ANALOG OUTPUT 4.2 Internal Block Diagram The following is the internal block diagram about the FR-A7AY analog output function. Voltage amplifier Controller Connector Current amplifier Common to AM0/AM1... -
Page 21: Terminals
EXTENSION ANALOG OUTPUT 4.3 Terminals Terminal Symbol Terminal Name Description Voltage output Connect a DC voltmeter (10VDC). terminal Current output Connect a DC ammeter (20mADC). terminal Common Common to AM0 and AM1 terminal Y0 to Y6 Used for digital output function. (Refer to page 24 ) NC (empty) Do not use. -
Page 22: Extension Analog Output Function Parameter List
EXTENSION ANALOG OUTPUT 4.4 Extension Analog Output Function Parameter List Parameter Minimum Initial Name Setting Range Number Increments Value 1 to 3, 5, 7 to 12, Analog output signal selection 14, 21, 24, 52, 53, 61, 62 Setting for zero analog output 0 to 100% Setting for maximum analog output 0 to 100%... -
Page 23: Adjustment Procedure
EXTENSION ANALOG OUTPUT 4.5 Adjustment Procedure 4.5.1 Setting of analog output signal voltage/current switchover (Pr. 309) Use Pr. 309 Analog output signal voltage/current switchover to select whether to output the same signal or different signals from terminal AM0 (voltage output) and terminal AM1(current output). Parameters Pr. -
Page 24: Calibration Of Meter
EXTENSION ANALOG OUTPUT 4.5.2 Calibration of meter (1) Outputting the same select signals from terminals AM0 and AM1 (Pr. 309 = "0 or 10") START Connect a DC voltmeter (or DC ammeter) across At this time, check that the polarity is correct terminals AM0 (or terminal AM1) and AMC. - Page 25 EXTENSION ANALOG OUTPUT (2) Outputting different select signals from terminals AM0 and AM1 (Pr. 309 = "1 or 11") START Connect a DC voltmeter (or DC ammeter) across terminals AM0 (or terminal AM1) At this time, check that the polarity is correct and AMC.
-
Page 26: Output Signal Setting
EXTENSION ANALOG OUTPUT 4.5.3 Output signal setting Set the output signals to be monitored. Set Pr. 306 to output the same signal from terminals AM0 and AM1 and Pr. 306 and Pr. 310 to output different signals. For details of signal definitions, refer to Pr. 54 and Pr. 158 of the inverter instruction manual. -
Page 27: Analog Signal Adjustment [Pr. 307, Pr. 308, Pr. 311, Pr. 312]
EXTENSION ANALOG OUTPUT 4.5.4 Analog signal adjustment [Pr. 307, Pr. 308, Pr. 311, Pr. 312] Use Pr. 307 or Pr. 311 to set the value for zero analog output (meter points 0) and Pr. 308 or Pr. 312 for maximum analog output (full scale). When outputting the same signal from terminals AM0 and AM1, use Pr. -
Page 28: Instructions
EXTENSION ANALOG OUTPUT 4.6 Instructions (1) A voltmeter having smaller internal impedance (or an ammeter having larger internal impedance) than the value indicated in the Specifications (page 2) may not deflect to full-scale and may not be calibrated. (2) When calibrating a meter with a small full-scale value, set output of terminal AM0 and AM1 to minimum, then connect a meter. -
Page 29: Digital Output
DIGITAL OUTPUT 5.1 Internal Block Diagram The following is the internal block diagram about the FR-A7AY digital output function Connector Controller Common to Y0-Y6... -
Page 30: Terminals
DIGITAL OUTPUT 5.2 Terminals By setting the Pr. 313 to Pr. 319 values, output signals (RUN, SU etc.) available with an inverter as standard can be output from the open collector terminals. (1) Open collector output specifications: Permissible load 24V, 0.1ADC (2) The circuit logic is the same as that of the inverter. -
Page 31: Digital Output Function Parameter List
DIGITAL OUTPUT 5.3 Digital Output Function Parameter List Parameter Number Name Initial Value Setting Range DO0 output selection 9999 0, 1, 3, 4, 7, 8, 11 to 16, 20, 25, 26, 46, 47, 64, DO1 output selection 9999 80, 81, 90, 91, 93, DO2 output selection 9999 95, 96, 98, 99, 100, 101,... -
Page 32: Output Signal List
DIGITAL OUTPUT 5.4 Output Signal List For details of signal definitions, refer to Pr. 190 to Pr. 192 (Output terminal function selection) of the inverter instruction manual. Setting Setting Signal Signal Function Function Positive Negative Positive Negative Name Name Logic Logic Logic Logic... - Page 33 REVISIONS *The manual number is given on the bottom left of the back cover. Print Date *Manual Number Revision First edition Aug. 2011 IB(NA)-0600467ENG-A IB(NA)-0600467ENG-A...
