2.1CH Blu-ray™ Home Entertainment System Thank you for purchasing this Samsung product. HT-D7100_ELS_1227.indd 1 HT-D7100_ELS_1227.indd 1 user manual imagine the possibilities To receive more complete service, please register your product at www.samsung.com/register HT-D7100 2011-12-27 2011-12-27 1:17:58 1:17:58...
Safety Information TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE COVER(OR BACK). NO USER-SERVICEABLE PARTS ARE INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol indicates “dangerous voltage” inside the product that presents a risk of electric shock or personal injury. WARNING •...
• Ensure that the AC power supply in your house complies with the identifi cation sticker located on the back of your product. • Install your product horizontally, on a suitable base (furniture), with enough space around it for ventilation (7.5~10cm).
Connecting to the Network SETUP Initial Settings Accessing the Settings Menu Display 3D Settings TV Aspect Smart Hub Screen Size BD Wise (Samsung Products only) Resolution HDMI Colour Format Movie Frame (24 Fs) HDMI Deep Colour Still Mode Progressive Mode Audio...
Change Password General Front Display Network Remote Control Support Software Upgrade Contact Samsung Playing a Disc Using the Disc menu / Title menu / Popup menu Playing the Title List Using the Search and Skip Functions Slow Motion Play/Step Motion Play...
Getting Started Make sure to check the following terms before reading the user manual. Term Logo BD-ROM BD-RE/-R DVD-VIDEO DVD-RW(V) DVD-R DVD+RW DVD+R Audio CD JPEG DivX DivX USB storage device CAUTION NOTE Shortcut Key • This product is compatible with the PAL colour system only. •...
Getting Started Disc Types and Characteristics Blu-ray Disc Compatibility Blu-ray is a new and evolving format. Accordingly, disc compatibility issues are possible. Not all discs are compatible and not every disc will play back. For additional information, refer to the Disc Types and Characteristics section of this Manual.
Region Code Both the product and the discs are coded by region. These regional codes must match in order to play the disc. If the codes do not match, the disc will not play. Region Disc Type Code North America, Central America, South America, Korea, Japan, Taiwan, Hong Kong and South East Asia.
Getting Started Disc Format Using JPEG disc • CD-R/-RW, DVD-RW/-R recorded with UDF or JOLIET format can be played back. • Only JPEG fi les with the ".jpg", ".JPG", ".jpeg" or "JPEG" extension can be displayed. • Progressive JPEG is supported. DVD-RW/-R (V) •...
File Extension Container *.vro *.mpg *.mpeg *.ts *.tp *.trp Restrictions • Some of the Codecs above listed are not supported if having a problem with the contents. • Video source with incorrect container information or if corrupt will not be played properly. •...
Getting Started Notes on USB connection Supported devices: USB storage media, MP3 player, digital camera, USB card reader Does not support if a folder or fi le name is longer than 125 characters. A subtitle fi le bigger than 300 KB may not be properly displayed.
Front Panel POWER BUTTON ( FUNCTION BUTTON DISPLAY STOP BUTTON PLAY/PAUSE BUTTON ENTER BUTTON EJECT BUTTON REMOTE CONTROL SENSOR Detects signals from the remote control. VOLUME CONTROL DISC SLOT ✎ NOTE When the product displays the Blu-ray disc menu, you cannot start the movie by pressing the PLAY button on the product or the remote.
Getting Started Rear Panel FM ANT. VIDEO OUT FM ANTENNA JACK VIDEO OUT JACK LAN TERMINAL HDMI OUT JACK USB PORT EXTERNAL DIGITAL AUDIO IN JACK (OPTICAL) DC 12V JACK CAUTION Software upgrades using the USB Port must be performed with a USB memory fl ash stick only. ...
Tour of the Remote Control Turn the product on and off. If you want to change to TV mode, press the TV button. If you want to change to Home Cinema, press the BD button. Press numeric buttons to operate options. Press this to see the full screen on a TV.
The remote control may not work on some brands of TV's. Also, some operations may not be possible, depending on your brand of TV. The remote control will work with Samsung TVs by default. English HT-D7100_ELS_1227.indd 16 HT-D7100_ELS_1227.indd 16...
Connections This section involves various methods of connecting the product to other external components. Before moving or installing the product, be sure to turn off the power and disconnect the power cord. Front Speakers Subwoofer Speaker Components FRONT Using the Subwoofer with Product It is possible to use when you put the product on the subwoofer or lay it side.
Connections Connecting the Wireless Subwoofer Connect the power cord on the rear of the subwoofer to the power. • If the main unit is turned on The subwoofer will be automatically connected to the product and the Link LED on its front will blink blue for a few seconds.
CAUTION The wireless receiving antenna is built into the wireless subwoofer. Keep the unit away from water and moisture. For optimal listening performance, make sure that the area around the wireless subwoofer location is clear of any obstructions. ...
Connections Connecting the Video Out to your TV Choose one of the two methods for connecting to a TV. METHOD 1 Attach the ferrite core (Small) as shown. METHOD 1 : HDMI (BEST QUALITY) Connect an HDMI cable (not supplied) from the HDMI OUT jack on the rear of the product to the HDMI IN jack on your TV.
FM ANT. VIDEO OUT METHOD 2 : Composite Video (GOOD QUALITY) After connect the supplied Video Adapter to the VIDEO OUT on the rear of the product, connect the Video Adapter and the VIDEO IN of the TV with video cable. ✎...
Connections Connecting an External Digital Component OPTICAL : Connecting an External Digital Component Digital signal components such as a Cable Box/Satellite receiver (Set-Top Box). Connect the Digital Input (OPTICAL) on the product to the Digital Output of the external digital component.
✎ NOTE Internet access to Samsung’s software update server may not be allowed, depending on the router you use or the ISP’s policy. For more information, contact your ISP (Internet Service Provider). For DSL users, please use a router to make a network connection.
If you select the Pure High-throughput (Greenfi eld) 802.11n mode and set your AP's Security Encryption type to WEP, TKIP or TKIPAES (WPS2Mixed), your Samsung home cinema will not support the connection in compliance with new Wi-Fi certifi cation specifi cations.
If you use an HDMI cable to connect the product to an Anynet+ (HDMI-CEC)- compliant Samsung TV and 1.) You have set the Anynet+ (HDMI-CEC) feature to On in both the TV and the product and 2.) You have...
Page 26
EXIT NOTE When the product is connected to a network, select Internet from the Home menu. Download the desired content from Samsung Apps. (See pages 64~66) The access steps may differ depending on the menu you selected. ...
Display You can confi gure various display options such as the TV Aspect Ratio, Resolution, etc. 3D Settings Select whether to play a Blu-ray Disc with 3D contents in 3D Mode. Settings Display 3D Settings Audio 3D Settings Network 3D Blu-ray Playback Mode : Auto System Screen Size Language...
BD Wise is Samsung’s latest inter-connectivity feature. When you connect a Samsung product and a Samsung TV with BD Wise to each other via HDMI, and BD Wise is on in both the product and TV, the product outputs video at the video resolution and frame rate of the BD/DVD disc.
Page 29
Resolution according to the output mode • Blu-ray Disc/E-contents/Digital Contents playback Output Setup Blu-ray Disc BD Wise Optimal resolution Max. Resolution of Auto TV input 1080p@60F 1080p@60F Movie Frame : 1080p@24F Auto (24Fs) 1080i 1080i 720p 720p 576p/480p 576p/480p 576i/480i •...
Setup ✎ NOTE If the TV you connected to the product does not support Movie Frame or the resolution you selected, the message “If no pictures are shown after the selection, please wait for 15 seconds. And then, the resolution will be reverted to the previous value automatically.
Audio Speaker Settings Speaker Display Audio Level Network Distance System Language Security General Support > Move " Enter ' Return Level You can adjust the balance and level for each speaker. Adjusting Front/Subwoofer Speaker Level • The volume level can be adjusted in steps from -6dB to +6dB.
Setup HDMI Audio The audio signals transmitted over the HDMI Cable can be toggled On/Off. • Off : Video is transmitted over the HDMI connection cable only, and audio is output through your product speakers only. • On : Both video and audio signals are transmitted over the HDMI connection cable, and audio is output through your TV speakers only.
Page 33
Digital Output Selection Setup Connection Dolby Digital Dolby Digital Plus Audio Stream on Dolby TrueHD Blu-ray Disc DTS-HD HRA DTS-HD MA Audio Stream Dolby Digital on DVD Defi nition for Blu-ray Disc * If the Source Stream is 2ch, “Re-encoded Dolby D” Setting are not applied. Ouput will be LPCM 2ch. Blu-ray Discs may include three audio streams : - Main Feature Audio : The audio soundtrack of the main feature.
Setup Dynamic Range Control You can listen at low volumes, but still hear dialog clearly. This is only active if your product detects a Dolby Digital signal. • Auto : The Dynamic Range Control will be set automatically based on the information provided by the Dolby TrueHD Soundtrack.
Page 35
To enter the Network settings into your product, follow these steps: Press the ▲▼ buttons to select Wired, and then press the ENTER button. Press the ◄► buttons to select IP Settings, and then press the ENTER button. Settings IP Settings Display Audio IP Mode...
Page 36
Setup On the Security screen, enter your network’s Pass Phrase. Enter numbers directly using your remote control. To select a letter, press the ▲▼◄► buttons to move the cursor, then press the ENTER button. Settings Display Network Settings Audio Enter security key. Network System Language...
Security WPS(PBC) Wireless Router supports One Foot Connection. Select this connection type after placing the Wireless Router General One Foot within 10 inches(25cm) of Samsung Wireless LAN Adapter. Connection Support > Move " Enter ' Return HT-D7100_ELS_1227.indd 37 HT-D7100_ELS_1227.indd 37 Press the ENTER button.
This function is not available if the HDMI cable does not support CEC. If your Samsung TV has an Anynet+ logo, then it supports the Anynet+ function. Depending on your TV, certain HDMI output resolutions may not work.
To use the Network Remote Control function, follow these steps: Select On in the Network Remote Control menu. Install the Samsung network remote control application to control your product on your compatible portable device. Make sure your portable device and your product are connected to the same wireless router.
Never turn the product off or back on manually during the update process. Samsung Electronics shall take no legal responsibility for product malfunction caused by an unstable Internet connection or consumer negligence during a software upgrade.
By Disc To upgrade by Disc, follow these steps: Visit www.samsung.com/bluraysupport. Download the latest disc software upgrade zip archive to your computer. Unzip the zip archive to your computer. You should have a single folder with the same name as the zip fi le.
Basic Functions Playing a Disc Playback Insert a disc into the disc slot with the disc's label facing up. Press the PLAY (►) button. Playback related buttons ► Starts playback. PLAY ( Stops playback. • If you press the button once : The stop position is ...
Using the Title Menu During playback, press the TITLE MENU button on the remote control. Press the ◄ ► buttons to make the desired selection, then press the ENTER button. ✎ NOTE Depending on the disc, the menu items may differ and this menu may not be available.
Basic Functions Slow Motion Play/Step Motion Play Slow Motion Play hzZyx • pause ( mode, press the SEARCH () button. If you press the SEARCH () button, the playback speed is reduced to * 1/8 * 1/4 * 1/2 •...
Using the TOOLS button During playback, you can operate disc menu by pressing the TOOLS button. • TOOLS Menu Screen Title Search Chapter Search Time Search Picture Settings Audio User EQ Subtitle Angle < Change " Enter ' Return ✎ NOTE ▪...
Basic Functions Caption Function • You must have some experience with video extraction and editing in order to use this feature properly. • To use the caption function, save the caption fi le (*.smi) in the same fi le name as that of the DivX media fi...
Listening to Music Buttons on the Remote Control used for Music Playback RDS DISPLAY RDS DISPLAY PTY- PTY SEARCH FULL SCREEN FULL SCREEN MUTE MUTE TOOLS TOOLS RETURN RETURN TUNER TUNER MEMORY MEMORY SMART SMART SEARCH SEARCH S/W LEVEL S/W LEVEL REPEAT button : Selects the play mode in the Playlist.
Page 48
Basic Functions Playing an Audio CD (CD-DA)/MP3 Insert an Audio CD (CD-DA) or an MP3 Disc into the disc slot. • For an Audio CD (CD-DA), the fi rst track will be played automatically. • For an MP3 disc, press the ◄► buttons to select Music, then press the ENTER button.
Audio CD Music TRACK 001 00:43 TRACK 003 04:41 TRACK 005 03:43 TRACK 007 04:06 c Close Edit Mode ( ) Page Select a desired track and press the TOOLS button. To play the selected track(s), select Play Selected in the Tools menu and press ENTER.
Basic Functions 3D Sound You can enjoy much natural and vivid surround sound with enriched tones of sound. You can adjust the depth of sound using the level options. Off High Medium Low. ✎ NOTE It is not available in FM or W. IPOD mode. Playing back a Picture Viewing Photo Files Connect a USB memory that contains JPEG...
Playing back a USB Storage Device You can use the USB connection to play multimedia fi les (MP3, JPEG, DivX, etc) downloaded from the USB storage device. Move to the home menu. My Contents Videos Photos Music Function My Devices In Stop mode, connect the USB storage device to the USB port on the front panel of the product.
Basic Functions Setting Mono/Stereo Press the MO/ST button. • Each time the button is pressed, the sound switches between STEREO and MONO. • In a poor reception area, select MONO for a clear, interference-free broadcast. Presetting Stations Example : Presetting FM 89.10 into memory Press the FUNCTION button to select FM.
Page 53
To show the RDS signals You can see the RDS signals the station sends on the display. Press the RDS DISPLAY button while listening to an FM station. • Each time you press the button, the display change to show you the following information : PS NAME Frequency While searching, <PS NAME>...
Page 54
Basic Functions Connecting iPod/iPhone Using the USB Cable If the system is connected to iPod/iPhone, you can play music in iPod/iPhone using the system. MI OUT OPTICAL 5V 500mA DIGITAL AUDIO IN 5V 500mA Connect iPod/iPhone using the USB cable to the front USB port.
Page 55
CAUTION It links to Wireless Dock Cradle when SWA-5000 is used. Only Samsung wireless transmitter that is compliant with the system can be recharged. iPod/iPhone Models You Can Use with This Product ...
Page 56
Basic Functions How to Link the Wireless Transmitter with the Main Unit Turn off your Home Cinema. Press the 4, 7, 6, 3 buttons on the remote control in order. • The Power LED blinks once. Connect the iPod/iPhone to the Wireless transmitter.
Network Services You can enjoy various network services such as Smart Hub or BD-LIVE by connecting the product to your network. Read the following instructions before using any network service. Connect the product to the network. (see pages 23~24) Confi gure the network settings. (see pages 34~37) Using Smart Hub Using Smart Hub, you can stream movies,...
Page 58
For easy access, use the SEARCH button on the remote control. • For instructions to use search function, please visit www.samsung.com. Samsung Apps : You can download various for pay or free-of-charge application services. Recommended : Displays recommended contents managed by Samsung. English HT-D7100_ELS_1227.indd 58...
Page 59
✎ NOTE Press the RED (A) button on your remote to show or hide the password as you enter it. Search Your Video Samsung Apps Contents 1 Contents 2 Contents 3 Contents 4 Login Recommended Press [Enter]...
Page 60
Network Services When done, press the ENTER button to select OK, and then press the ENTER button again. The Login screen re-appears. Select Confi rm password, and then press the ENTER button. Repeat Steps 7 and 8. When the Login screen re-appears, select Create Account, and then press the ENTER button.
Page 61
ENTER button. ✎ NOTE If you have a Samsung account and you want to use the Samsung Apps function in Smart Hub, you must register your Samsung Apps account here. See page 64 for more information. Using your remote and the on-screen Keypad, enter your site ID and password.
Page 62
Network Services After a few moments, Smart Hub automatically resets. The screen may go black, then Smart Hub re-appears. In a few moments, it starts the re-initialization procedure. To complete the re-initialization, go to Step 4 in Starting Smart Hub for the First Time. (See page 57) ✎...
Move to Folder The Move to Folder function lets you move a application to a folder. To use the Move to Folder function, follow these steps: Press the YELLOW (C) button on your remote. Select a application, and then press the ENTER button.
Additional applications and services are added regularly. For Pay Apps To download for pay apps, you need to create a Samsung Account and add a credit card to the account. To create a Samsung account, please visit www. samsung.com ✎...
Page 65
Using the Samsung Apps Screen To use the Samsung Apps screen, follow these steps: Press the ◄► buttons to move to the category list on the left. Press the ▲▼ to highlight a category. In a few seconds, the Samsung Apps screen displays the applications in that category.
If you have a DLNA compatible mobile phone or NAS, you can use AllShare without any additional software. You can download the PC software and get detailed instructions for using AllShare from the Samsung. com web site. 2011-12-27 2011-12-27 1:19:49...
Refer to the chart below when this product does not function properly. If the problem you are experiencing is not listed below or if the instruction below does not help, turn off the product, disconnect the power cord and contact the nearest authorized dealer or Samsung Electronics Service Centre. Symptom I cannot eject the disc.
Page 68
Other information Symptom Audio language and subtitles do not work. Menu screen does not appear even when the menu function is selected. Aspect ratio cannot be changed. • The product is not working. (Example: The power goes out or a strange noise is heard.) •...
Page 69
Hereby, Samsung Electronics, declares that this Home Cinema System is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. The offi cial Declaration of Conformity may be found at http://www.samsung.com, go to Support > Search Product Support and enter the model name.
Weight Dimensions Rated output power - Samsung Electronics Co., Ltd reserves the right to change the specifi cations without notice. - Weight and dimensions are approximate. - Design and specifi cations are subject to change without prior notice. - For the power supply and Power Consumption, refer to the label attached to the product.
Page 71
English Avis Cinavia : This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message will be displayed and playback or copying will be in interrupted.
Page 72
Français Avis de Cinavia : Ce produit utilise la technologie Cinavia pour limiter l'utilisation de copies non autorisées de certains films et vidéos commerciaux ainsi que leurs bandes son. Lorsqu'une copie non autorisée est détectée, un message est affiché et la lecture ou la copie est interrompue.
Page 73
Suomi Cinavia-ilmoitus: Tämä tuote käyttää Cinavia- tekniikkaa rajoittaakseen joidenkin kaupallisesti tuotettujen elokuvien ja videoiden sekä niiden ääniraitojen luvattomien kopioiden käyttöä. Kun luvattoman kopion kielletty käyttö tunnistetaan, viesti tulee näkyviin ja toisto tai kopiointi keskeytetään. Saat lisätietoja Cinavia-tekniikasta Cinavia Online Consumer Information Centre -kuluttajakeskuksesta osoitteessa http://www.cinavia.com.
Page 74
Polski Komentarz Cinavia : Urządzenie to korzysta z technologii Cinavia w celu ograniczenia wykorzystania nieupoważnionych kopii pewnych filmów i obrazów wideo wyprodukowanych w celach komercyjnych, oraz ich ścieżek dźwiękowych. W przypadku wykrycia zakazanego użycia nieautoryzowanej kopii, zostanie wyświetlony komunikat i proces odtwarzania i kopiowania zostanie zatrzymany. Więcej informacji o technologii Cinavia można uzyskać...
Page 75
Hrvatski Obavijest o tehnologiji Cinavia : ovaj proizvod rabi tehnologiju Cinavia kako bi se ograničila uporaba neovlaštenih kopija nekih komercijalno proizvedenih filmova i videozapisa i njihovih zvučnih zapisa. Kada se otkrije zabranjena uporaba neovlaštene kopije, prikazat će se poruka i prekinut će se reproduciranje i kopiranje. Ostale informacije o tehnologiji Cinavia dostupne su u mrežnom informacijskom centru za korisnike tvrtke Cinavia na http://www.cinavia.
Page 76
繁體中文 Cinavia 聲明:本產品使用 Cinavia 技術來限制 使用某些商業製造的電影和視訊及其聲道的未經授權副本。當偵測 到禁止使用的未經授權副本時,將會顯示一則訊息,並且播放或複 製動作將會中斷。 Cinavia 技術的詳細資訊在 Cinavia 線上消費者資訊中心中提供,網址為:http://www. cinavia.com。若要透過郵件請求關於 Cinavia 的其他資訊,請將含有您的郵寄地址的明信片寄往:Cinavia Consumer Information Centre, P.O. Box 86851, San Diego, CA, 92138, USA. 本产品融合了在获得 Verance Corporation 许可并且受美国专利 7,369,677 以及其他在盖和世界各地已公布和正在申请的专利保护 ,并且受此类技术特定方面的版权和商业秘密保护。 Cinavia 是 Verance Corporation 的商标。2004- 2010 Verance Corporation 版权所有。Verance 保留一切权利。严禁进行逆向工程和反汇编。...
Page 77
Tiếng Việt Thông bá o củ a Cinavia: Sả n phẩ m nà y sử dụ n g công nghệ Cinavia để hạ n chế việ c sử dụ n g cá c bả n sao trá i phé p mộ t số bộ phim và video đượ c sả n xuấ t thương mạ...
Page 78
Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Contact Centre Area ` North America Canada 1-800-SAMSUNG (726-7864) Mexico 01-800-SAMSUNG (726-7864) U.S.A 1-800-SAMSUNG (726-7864) ` Latin America...
Page 79
Correct disposal of batteries in this product (Applicable in the European Union and other European countries with separate battery return systems.) This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66.
