Sony PSVITA PCH-ZHS1 G Instruction Manual

In-ear headset / 耳塞式耳機組 / 인이어 헤드셋
Instruction Manual / 使用説明書 / 사용설명서
PCH-ZHS1
G
A
B
MIC MUTE switch
MIC MUTE 開關
MIC MUTE 스위치
Microphone
麥克風
마이크
EN
Precautions
To help ensure the safe use of this product, carefully read this instruction manual and the
product information for the PlayStation
future reference. The parents or guardians of small children should read the manuals for them to
help ensure that they use the product safely.
Safety
Do not use this product while driving a car, riding a bicycle or engaging in any activity that

requires your complete attention. Doing so may result in accidents or injury.
Keep this product out of the reach of small children. Children may swallow small parts, which

can lead to injury.
Use and handling
If this product causes discomfort to your ears, immediately discontinue use.

Do not expose this product to high temperatures, high humidity or direct sunlight.

Do not allow the product to come into contact with any liquids.

Do not place any objects on top of the product.

Do not twist the cable or pull it forcibly.

Do not throw or drop this product, or otherwise expose it to strong physical impact.

Never disassemble or modify the product.

Follow the instructions below to help prevent the product exterior from deteriorating or

becoming discolored.
Wipe with a soft, dry cloth.

Do not place any rubber or vinyl materials on the product exterior for an extended period

of time.
Do not use solvents or other chemicals. Do not wipe the product with a chemically-treated

cleaning cloth.
To clean the earpieces, disconnect them from the headphones and wash them by hand, using a

mild soap. After cleaning, dry the earpieces thoroughly before using them.
Changing the earpieces
The headset is equipped with medium size earpieces. If the earpieces do not fit your
ears, replace them with the included small- or large-size earpieces. Twist and pull
the earpieces to remove them (Figure ).
4-414-580-11(1)
To the headset jack
連接至耳機／麥克風連接端
헤드폰/마이크 단자에
Vita system before using it and save the manuals for
®
Hint
When installing the earpieces, attach them firmly so that they do not come loose
during use.
How to use the in-ear headset
Connect the in-ear headset to the PS Vita system as shown in Figure . When you
are not using the microphone, put the MIC MUTE in the ON position.
Hint
For information about using the software for the microphone, refer to the
instructions supplied with the software.
Specifications
Cord 1.2 m
Plug 4-pole gold-plated mini plugs
Weight Approx. 15 g (including cord)
5 °C - 35 °C (41 °F - 95 °F)
Operating environmental
temperature
Microphone
Type Electret condenser type
Directional characteristics Omnidirectional
Input sensitivity –42 dB (0 dB = 1 V/Pa)
Headphones
Dynamic style
Type
10 mm diameter
Driver unit
60 mW*
Maximum power input
16 Ω
Impedance
105 dB/mW
Sensitivity
Frequency response 20 Hz-20 kHz
* This is the measured value based on the IEC (International Electrotechnical Commission)
standard.
Design and specifications are subject to change without notice.
LIMITATIONS OF LIABILITY
Other than as expressly set forth by Sony Computer Entertainment Hong Kong Limited
("SCEH") or any other Sony entity, or their suppliers or authorised service facilities, except to the
extent prohibited by applicable laws, SCEH or any other Sony entity, or their suppliers or
authorised service facilities, shall not be liable for any damages, including special, incidental or
consequential damages, or fees arising out of the use or inability to use this product.
CT
使用前須知事項
為確保本產品的使用安全，請先仔細閱讀本説明書及PlayStation
善保存，以備將來參考之用。未成年人請在監護人的陪同下閱讀，並安全使用。
警告
請勿於駕駛車子或騎腳踏車等時候使用，否則可能會導致交通事故。

請放在兒童拿不到的地方保管。兒童可能會誤吞小零件，導致人身受傷。

使用與保管
當您感覺耳機與您肌膚不合時，請立即中止使用。

請勿將本產品放置在高溫多濕、或易受陽光直接照射的場所。

請勿讓本產品被液體沾濕。

請勿在本產品上放置重物。

請勿用力扭動或拉扯連接線。

請勿投擲或掉落本產品，或使其受到強烈的外力撞擊。

切勿分解，改造本產品。

請遵循以下使用說明，以免產品外殼變形或變色。

使用乾淨軟布輕柔擦拭。

切勿在產品外殼上長時間放置任何橡膠或乙烯基材質。

切勿使用溶劑或其他化學藥劑。切勿使用經化學處理的擦布擦拭。

清潔耳塞前，請先從耳機組取出耳塞，使用中性清潔劑以雙手清先。清潔後，請將水

份完全拭去，然後使用。
更換耳塞
耳機組預先裝配的耳塞大小為M(中)。若耳塞與您耳朵的大小不合，請更換
S(小)或L(大)的耳塞。請扭動耳塞將耳塞取出(圖  )。
提示
裝上耳塞時，請確實裝妥而防在使用時鬆脫。
Vita的說明書，並妥
®
