  • Page 2 Preface S7-1500 / ET 200MP Documentation Guide SIMATIC Product overview Wiring S7-1500/ET 200MP Digital input module DI 64x24VDC SNK/SRC BA Address space (6ES7521-1BP00-0AA0) Diagnostic alarms Equipment Manual Technical specifications Dimensional drawing 07/2020 A5E48025116-AA...
  • Page 3 Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 4: Preface

    Siemens' products and solutions undergo continuous development to make them more secure. Siemens strongly recommends that product updates are applied as soon as they are available and that the latest product versions are used. Use of product versions that are no longer supported, and failure to apply the latest updates may increase customers' exposure to cyber threats.
  • Page 5 We are liable for the product described, including the open-source software contained in it, pursuant to the conditions applicable to the product. Siemens accepts no liability for the use of the open source software over and above the intended program sequence, or for any faults caused by modifications to the software.

  • Page 6: Table Of Contents

    Table of contents Preface ..............................3 S7-1500 / ET 200MP Documentation Guide ................... 6 Product overview ........................... 8 Properties ..........................8 Wiring ..............................10 Wiring and block diagrams ....................10 Terminal assignment X10 and X11..................11 Connecting a module with a connection module ..............14 Wiring of the module ......................

  • Page 7: S7-1500 / Et 200Mp Documentation Guide

    S7-1500 and ET 200MP systems, e.g. diagnostics, communication, motion control, Web server, OPC UA. You can download the documentation free of charge from the Internet (https://support.industry.siemens.com/cs/ww/en/view/109742691). Changes and supplements to the manuals are documented in a Product Information. You can download the product information free of charge from the Internet (https://support.industry.siemens.com/cs/us/en/view/68052815).
  • Page 8 You must register once to use the full functionality of "mySupport". You can find "mySupport" on the Internet (https://support.industry.siemens.com/My/ww/en). Application examples The application examples support you with various tools and examples for solving your automation tasks.

  • Page 9: Product Overview

    Product overview Properties Article number 6ES7521-1BP00-0AA0 View of the module Figure 2-1 View of the DI 64x24VDC SNK/SRC BA module Properties The module has the following technical properties: • 64 digital inputs; electrically isolated in 4 groups of 16 • Sourcing input or sinking input, depending on wiring •...
  • Page 10 The following accessories are supplied with the module and can be ordered as spare parts: • U connector • Universal front door with the article number: 6ES7 591-8AA00-0AA0 You can find additional information in the system manual S7-1500/ET 200MP (http://support.automation.siemens.com/WW/view/en/59191792). Other components The following must be ordered separately: • SIMATIC TOP connect connection module •...

  • Page 11: Wiring

    Wiring Wiring and block diagrams This section contains the block diagram of the module and the terminal assignment. Wiring and block diagram The following figure shows the terminal assignment and the assignment of the channels. • Inputs: Channel 0 to 31 to connector X10 •...

  • Page 12: Terminal Assignment X10 And X11

    Wiring 3.2 Terminal assignment X10 and X11. Terminal assignment X10 and X11. The following figure shows the assignment of the channels to the addresses. Figure 3-2 Front view of the module without front door Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...
  • Page 13 Wiring 3.2 Terminal assignment X10 and X11. Terminal and address assignment For connecting sensors or actuators, we recommend using the SIMATIC TOP connect pre- assembled connecting cables and the SIMATIC TOP connect connection modules. However, if you choose another wiring option, you will need the following tables. Table 3- 1 Assignment for connector X10 of the module Assignment for inputs to X10...
  • Page 14 Wiring 3.2 Terminal assignment X10 and X11. Table 3- 2 Assignment for the connector X11 of the module Assignment for inputs to X11 Terminal Channel Address Terminal Channel Address Channel 32 x+4.0 Channel 48 x+6.0 Channel 33 x+4.1 Channel 49 x+6.1 Channel 34 x+4.2...

  • Page 15: Connecting A Module With A Connection Module

    You can find additional information on the components of the SIMATIC TOP connect system cabling, e.g. for connecting connection modules, in the equipment manual SIMATIC TOP connect for S7-1500 and ET 200MP (https://support.industry.siemens.com/cs/ww/en/view/95924607). Note Common supply If you use the listed SIMATIC TOP connect connection modules, then all 32 channels of a connection module have a common supply.
  • Page 16 We recommend you use the TIA Selection Tool for planning your project. The TIA Selection Tool is available free of charge as a desktop version for download or as a cloud version, refer to the Internet (https://new.siemens.com/global/en/products/automation/topic-areas/tia/tia- selection-tool.html). Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0)

  • Page 17: Wiring Of The Module

    Wiring 3.4 Wiring of the module Wiring of the module Requirement • The I/O modules are installed on the mounting rail. • The supply voltage of the station is switched off. Procedure 1. Plug the two SIMATIC TOP connect connecting cables with the 40-pin IDC connector into X10 and X11.
  • Page 18 Additional information You can find out how to wire the SIMATIC TOP connect connection module in the equipment manual SIMATIC TOP connect for S7-1500 and ET 200MP (https://support.industry.siemens.com/cs/ww/en/view/95924607). Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...

  • Page 19: Fuse

    Wiring 3.5 Fuse Fuse Miniature circuit breaker The supply lines of groups are to be protected with a 4 A miniature circuit breaker with tripping characteristic C or B. Below, you see the connection for "Sourcing" mode and for "Sinking" mode. Figure 3-5 "Sourcing"...
  • Page 20 Wiring 3.5 Fuse Figure 3-6 "Sinking" mode Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...

  • Page 21: Address Space

    Address space The module can be configured in various ways in STEP 7. Depending on the configuration, additional/different addresses are assigned in the process image output/input. Configuration options of DI 64x24VDC SNK/SRC BA You can configure the module with STEP 7 (TIA Portal) or with a GSD file. When you configure the module by means of the GSD file, the configurations are available under different short designations/module names.
  • Page 22 Address space Address space for configuration as 1 x 64-channel DI 64x24VDC SNK/SRC BA The figure below shows the address space assignment for configuration as a 1 x 64-channel module. You can freely assign the start address for the module. The addresses of the channels are derived from the start address.
  • Page 23 Address space Address space for configuration as 8 x 8-channel DI 64x24VDC SNK/SRC BA S For the configuration as an 8 x 8-channel module, the channels of the module are divided into multiple submodules. The submodules can be assigned to different IO controllers when the module is used in a shared device.
  • Page 24 Address space The figure below shows the assignment of the address space with submodules 1 and 2. Figure 4-3 Address space for configuration as 1 x 64-channel DI 64x24VDC SNK/SRC BA MSI with value status Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...
  • Page 25 Address space The figure below shows the assignment of the address space with submodules 3 and 4. Figure 4-4 Address space for configuration as 1 x 64-channel DI 64x24VDC SNK/SRC BA MSI with value status Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...
  • Page 26 Reference You can find information on the Shared Input/Output (MSI/MSO) function in the section Module-Internal Shared Input/Output (MSI/MSO) of the PROFINET with STEP 7 V16 (https://support.industry.siemens.com/cs/ww/en/view/49948856) function manual. Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...

  • Page 27: Diagnostic Alarms

    Diagnostic alarms Status and error displays LED displays The figure below shows the LED displays (status and error displays) of the DI 64x24VDC SNK/SRC BA. Figure 5-1 LED display of the module DI 64x24VDC SNK/SRC BA Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...
  • Page 28 Diagnostic alarms 5.1 Status and error displays Meaning of the LED displays The following table explains the meaning of the status and error displays. RUN and ERROR LED Table 5- 1 Status and error displays RUN and ERROR Meaning Remedy ERROR Voltage missing or too low at backplane bus •...

  • Page 29: Technical Specifications

    The following table shows the technical specifications as of 07/2020. You can find a data sheet including daily updated technical specifications on the Internet (https://support.industry.siemens.com/cs/ww/en/ps/td). Enter the article number or the short designation of the module on the website. Article number...
  • Page 30 Technical specifications Article number 6ES7521-1BP00-0AA0 Number of simultaneously controllable inputs 64; see additional description in the manual • Number of simultaneously controllable inputs Input voltage 24 V • Rated value (DC) 24 V DC – -30 to +5 V • for signal "0"...
  • Page 31 Technical specifications Article number 6ES7521-1BP00-0AA0 Diagnostics indication LED Yes; green LED • RUN LED Yes; red LED • ERROR LED • MAINT LED Monitoring of the supply voltage (PWR-LED) Yes; via SIMATIC TOP connect connection module • Yes; via SIMATIC TOP connect connection module •...
  • Page 32 Technical specifications Power reduction (derating) depending on the mounting position and ambient temperature (per module) The following graphs show the number of channels that can be used simultaneously depending on the mounting position of the S7-1500/ET 200MP automation system and the ambient temperature.

  • Page 33: Dimensional Drawing

    Dimensional drawing The dimensional drawing of the module on the mounting rail, as well as a dimensional drawing with open front cover, are provided in the appendix. Always observe the specified dimensions for installation in cabinets, control rooms, etc. Figure A-1 Dimensional drawing of the DI 64x24VDC SNK/SRC BA module Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...
  • Page 34 Dimensional drawing Figure A-2 Dimension drawing of the DI 64x24VDC SNK/SRC BA module, side view with open front cover Digital input module DI 64x24VDC SNK/SRC BA (6ES7521-1BP00-0AA0) Equipment Manual, 07/2020, A5E48025116-AA...
