Important Safety Instructions These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings of these warnings contact the Customer Care Department. Prior to Installation •...
Servicing • This product should be serviced by an authorised engineer and only genuine spare parts should be used. • Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning.
Operation Before use Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Freezer controls ➀...
Warning light (red) If the temperature warning light (5) lights up, it indicates that the temperature within the freezer has reached a level where safe food storage is no longer ensured (warmer than -12°C). When the freezer is first switched on, the warning light will stay on until the temperature has dropped to a safe level for the storage of frozen food.
Freezing calendar The symbols on the drawers show different types of frozen goods. The numbers indicate storage times in months for the appropriate types of frozen goods. Whether the upper or lower value of the indicated storage time is valid depends on the quality of the foods and pre- treating before freezing.
Health and Safety Guidelines Because of consumer demand, preservatives have been removed from many pre-prepared foods. This together with the changes in shopping habits to a once-a-week shop, mean that safe handling and storage of food is even more important than ever. The following tips should help you to ensure that the food in your home is in as perfect condition as possible.
Defrosting The freezer compartment will become progressively covered with frost. This should be removed with the special plastic scraper provided, whenever the thickness of the frost exceeds 1/4". During this operation it is not necessary to switch off the power supply or to remove the foodstuffs. However, when the ice becomes very thick on the inner liner, complete defrosting should be carried out and it is advisable to carry out this operation when...
Maintenance and Cleaning Warning Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Important This appliance contains hydrocarbons in cooling unit maintenance recharging must therefore only be carried out by authorised technicians. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water).
Something not Working? Before contacting your local Service Force Centre check the following points. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. Symptom No power to appliance The temperature in the freezer is too high...
Customer Care Department For general enquiries concerning your Zanussi appliance or for further information on Zanussi products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.zanussi.co.uk...
Standard guarantee conditions We, Zanussi, undertake that if within 24 months of the date of purchase this Zanussi appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •...
Technical specifications POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY(*) GROSS CAPACITY NET CAPACITY STAR RATING (*)This figure is based on standard test results in accordance with European Standard EN153 (Actual consumption will depend on how the appliance is used and where it is located). Installation Warning IF YOU ARE DISCARDING AN OLD...
Door reversal The appliance’s door has been locked in position for transport by means of pins on both sides. According to the door opening direction, remove relevant pins at the top and at the bottom. Attention After completion of the door reversing operation, check that the door gasket adheres to the cabinet.
Electrical Connection WARNING THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. If the plug that is fitted to your appliance is not suitable for your socket outlet, it must be cut off and the appropriate plug fitted.
Building in Dimensions of the recess Height of housing (1) Depth of housing (2) Width of housing (3) It is necessary that the cabinet has a ventilation recess with the following dimensions: Depth 50 mm Width 540 mm For appropriate venting, follow indications in the figure.
Page 17
4. Snap vent grill (B) and hinge cover (E) into position. Apply blanking covers (C-D) as indicated. PR266 5. Separate parts Ha, Hb, Hc, Hd as shown in the figure. ca. 50 mm 90° 90° ca. 50 mm 6. Place guide (Ha) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes.
Page 18
PR168 10. Place the small square on the guide again and fix it with the screws supplied. Should the alignment of the furniture door be necessary, use the clearance of slots. At the end of this procedure, it is necessary to check if the door of the furniture closes properly.
