- Page 1 User Manual Tumble Dryer ZDC 37100 W...
-
Page 2: Table Of Contents
Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document. -
Page 3: Important Safety Information
Important safety information In the interest of your safety and to ensure the correct use, before installing and first using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is important to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. - Page 4 Installation • This appliance is heavy. Care should be taken when moving it. • When unpackaging the appliance, check that it is not damaged. If in doubt, do not use it and contact the Service Centre. • All packing must be removed before use.
-
Page 5: Description Of The Appliance
Description of the appliance 1 Control panel 2 Fluff filters 3 Rating Plate 4 Condenser Unit 5 Water reservoir 6 Adjustable feet... -
Page 6: The Control Panel
The control panel 1. Time selector dial 2. Delicate button 3. Textile button 4. Indicator lights 5. Start/Pause button Allows you to select time controlled drying. Turn the dial to the required time. Pressing this button allows drying to be performed at a lower temperature, for delicate items. -
Page 7: Drying Programmes
Drying programmes Programme load Cotton Time Synthetics Type of Options laundry Textile Synthetics • Cotton • Delicate Description of programme If the TIME programme has been selected, programme duration time of 15 minutes up to 150 minutes can be set by intervals of 5 minutes or 10 minutes. -
Page 8: Before The First Use
Before the first use Ensure that the electrical connections comply with the installation instructions. • Remove the polystyrene block and any material from the drum. • Before using your tumble dryer for the first time, we recommend that you place a few damp cloths inside the appliance and dry for 30 minutes. There may be dust inside a brand new tumble dryer. - Page 9 has finished drying. • If individual items are still damp after drying, set a brief post-drying time, but at least 30 minutes. This will be necessary particularly for multilayered items (e.g. collars, pockets, etc.). Make sure that no metal objects are left in the laundry (e.g.
-
Page 10: Operating Sequence
Operating sequence 1. Load The Laundry Connect the appliance. Open the door (see picture). Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. Please check the laundry does not get caught between the door and filter. - Page 11 Start/Pause Button Press this button to start the dryer after having selected the programme and the options. The rele- vant light will stop flashing. If the pro- gramme selector dial is turned to another position, when the machine is running, the buzzer will sound and the programme phase indicator lights will flash.
- Page 12 carefully check that the drum is empty. If you do not intend to carry out anoth- er wash, close the water tap. Leave the door open to prevent the formation of mildew and unpleasant smells. After each use •Clean the filters (see page 13). •Empty the water reservoir (see page 15).
-
Page 13: Care And Cleaning
Care and cleaning Important! You must DISCONNECT the appliance from the electricity supply, before you can carry out any cleaning or maintenance work. External cleaning se only soap and water and then dry thoroughly. Important: do not use methylated spir- it, diluents or similar products.. - Page 14 Important! Do not use the appliance without fil- ters. Cleaning the condenser unit Clean the condenser when light “Condenser” comes on. The condenser is situated at the lower part of the cabinet behind a small door. To open the door, push the catch as per picture.
- Page 15 operation. Proceed as follows: • Open the small door at the lower part of the cabinet • Turn the yellow stop upwards • Pull out the reservoir • Open the small cover and let water flow down • Close the small cover and re-insert correctly the reservoir •...
-
Page 16: Something Not Working
Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. During machine operation it is possible that the red Start/Pause pilot light flashes to indicate that the machine is not working. - Page 17 Malfunction When pressing a button, the corresponding button flashes several times. Drying cycle ends shortly after programme starts. light illuminated. Programme inactive, Water reservoir full light illuminated. Drying cycle lasts an unusually long time. Note: After around 5 hours the drying cycle ends automatically (see „Drying cycle complete“)
-
Page 18: Technical Data
Technical data Technical data Dimensions Electrical connection Voltage - Overall power - Fuse Depth with loading door open Maximum Load This appliance conforms with the following EU Directives: – 73/23/EEC dated 19.02.1973 Low Voltage Directive – 89/336/EEC dated 03.05.1989 EMC Directive inclusive of Amending Directive 92/31/EEC –... -
Page 19: Consumption Values
Consumption values Programme Cottons Cupboard 1) Cottons Iron 1) Synthetics Cupboard 2) Max load: 1) Cottons load: 2) Synthetics load: Consumption values (*) Programme duration consumption (in minutes) The consumption values have been 7 kg established under standard conditions. 3 kg They may deviate when the machine is operated in domestic circumstances. -
Page 20: Disposal
Disposal Packaging materials The materials marked with the symbol are recyclable. This means that they can be recycled by disposing of them properly in appro- priate collection containers. Machine Use authorised disposal sites for your old appliance. Help to keep your coun- try tidy! Old appliance The symbol... -
Page 21: Installation
Installation Unpacking Slide out the polythene bag with the polystyrene stuffing before using the appliance Pull off adhesive strips from inside machine on top of drum. Should the appliance be moved, it must be transported vertically. The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side to that of the appliance. - Page 22 Door reversal To make it easier to load or unload the laundry the door can be reversed. Important: Reversing the door is not possible if after this operation the appliance result installed behind a door with a hinge on the opposite side to that of the appliance.
- Page 23 Permanent connection In the case of permanent connection it is necessary that you install a double pole switch between the appliance and the electricity supply (mains), with a minimum gap of 3mm between the switch contacts and of a type suitable for the required load in compliance with the current electrical regulations.
-
Page 24: Guarantee/Customer Service
Guarantee/Customer Service Standard guarantee conditions We, Zanussi undertake that if, within 12 months of the date of the purchase, this Zanussiappliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option, repair... - Page 25 Slavonska avenija 3, +385 1 63 23 338 10000 Zagreb +353 1 40 90 753 Long Mile Road Dublin 12 C.so Lino Zanussi, 26 - +39 (0) 434 558500 33080 Porcia (PN) Kr. Barona iela 130/2, +37 17 84 59 34...
- Page 26 Lietuva Luxembourg Magyarország Nederland Norge Österreich Polska Portugal Romania Schweiz - Suisse - Svizzera Slovenija Slovensko Ozo 10A, LT 08200 +370 5 2780609 Vilnius Rue de Bitbourg, 7, +352 42 431 301 L-1273 Hamm H-1142 Budapest XIV, +36 1 252 1773 Erzsébet királyné...
- Page 27 Suomi Sverige Türkiye Россия www.electrolux.fi Electrolux Service, S:t +46 (0)771 76 76 76 Göransgatan 143,S-105 45 Stockholm +90 21 22 93 10 25 129090 Москва, Олимпийский +7 495 937 7837 проспект, 16, БЦ "Олимпик"...
- Page 28 www.electrolux.com 136905601 -00-02092008...
