- Page 1 21LF-90H COLOUR TELEVISION OPERATION MANUAL Please read this operation manual carefully before using the colour television. Downloaded from: http://www.usersmanualguide.com/...
-
Page 2: Table Of Contents
No-Signal ..........19 Video ............29 Blue Background During No-Signal ..19 Troubleshooting ........30 Volume Bar ........... 19 AV Modes ..........19 Specifications ......... 31 Important Instructions ......32 - 1 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 3: Safety Precautions
Do not place this television equipment on an unstable cart, stand, or table. The televi- sion equipment may fall, causing serious injury to a child or an adult, and serious damage to the equipment. - 2 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... - Page 4 Do not put or insert anything Do not leave your TV set in Stand-by or between TV set and the stand, table or track. operating mode when you leave the house. - 3 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/...
- Page 5 The tube of your TV has a special coating. in this way no longer complies with Do not knock or rub on the tube face with sharp or hard surfaces, otherwise you will license and must not be operated. damage the coating.
-
Page 6: Supplied Accessories
To clean off sticky substances, the cloth can be moistened with acetone. Under no circumstances clean with this acetone cloth the TV-Cabinet. - 5 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 7: Remote Control Buttons
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. - 6 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 8: Control Panel Buttons
= Volume -/+ AUDIO R = Audio right = Program -/+ = Headphone 3,6 mm Ø MENU = Menu Antenna Connections Pˆ‡q‚‚…Ã6‡rhÃ8‚rp‡v‚† S‚ˆqÃ&$Âu€Ãp‚h‘vhyÃphiyr WCAÃh‡rh 9+)8+) Srh…ÂsÃUW Ayh‡Ã"‚u€Ã‡vÃyrhqÃphiyr 9+)8+) WCAVCAÃh‡rh Srh…ÂsÃUW S‚ˆqÃ&$‚u€Ãp‚h‘vhyÃphiyr - 7 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 9: Preparation
• WSS (wide screen signal decoding). • NTSC playback. 2. Insert two batteries 1.5 V (R03 AAA size). Be sure to match the battery +/- terminals with the +/- marks inside the compartment. $ÃWÃ666ÃS" - 8 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 10: Switching The Tv On/Off
GREEN LED will become displayed. After A.P.S. is finalized, the “PRO- RED, GRAM.” menu appears. Press the power button located on the front of the TV. - 9 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 11: Operating With The Onset Buttons
” button to select the next pro- button. Press the first digit and then second gramme or “ CH” button to select the pre- digit of the programme channel you want to vious programme. watch. - 10 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 12: Menu System
Menu button has two functions; first is open- ing or closing the "MAIN MENU", and the 92/80( %$/$1&( second is closing the sub-menu and then 02'( 0212 opening its parent menu. ())(&7 (48$/,=(5 6725( - 11 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... - Page 13 “ ” button on “STORE” option. During the store process all the items are stored, moreover, the USER mode informa- tion would not be lost. In other words, when - 12 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/...
-
Page 14: Picture Menu
Otherwise, HUE option is invisible in Picture menu.): • Using “ ” or “ ” button select Hue. • Press “ ” button to increase hue level. - 13 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 15: Feature Menu
3 seconds. Note: In the Picture menu if you press Flashback TG@@QÃUDH @S ) button the adjustments switch them- 8CDG9ÃGP8F G6IB V6B@ @IB GDTC selves to the factory settings. - 14 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 16: Installation Menu
“ ” button for back- ward search. SEARCH item blinks during search process, since the process is stopped or signal is found. During search process the semi-transparent menu back- - 15 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 17: Programme Menu
TV mode (except the AV mode). In menus, “ ” and “ ” buttons are working like "Direction Up" and "Direction Down". - 16 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... - Page 18 If you do not accept the locations and / or the "CANCEL" function cancels the activated "IN- programme names of programmes, you SERT" process. can change them in Programme menu. - 17 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/...
-
Page 19: Other Features
If sleep timer is activated it is dis- number indicator. played with the TV status and erased with it after 3 seconds. - 18 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 20: Sound Mute
Blue Background is activated.During search process Blue Background is not ac- tive. But instead of it there is another feature given; the semi-transparent menu back- ground is made blue. - 19 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV1.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 21: Teletext
To Reveal “concealed”Information • Pressing “ “ button once will reveal an- swers on a quiz or games page. • Pressing “ “ button again will conceal the revealed answers. - 20 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 22: To Stop Automatic Page Change
Tele- For further information ask your dealer. See text will be displayed at the upper middle of also the booklet supplied with your decoder. the screen. - 21 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 23: Tv And Video Recoder (Vcr)
Search and Store TV channels. Store the test signal under programme number 0. • Replace the aerial cable in the aerial socket “ANT” of your video recorder once you have stored the test signal. - 22 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 24: Connecting External Equipment
• Video input and Audio L/R inputs are available. 21” REAR PANEL 6V9DPÃDIQVUÃ C@69QCPI@ 6&$57 WD9@PÃDIQVUÃ ÃÃU@SHDI6G ÃÃU@SHDI6G $17(11$ 6FDUW HEADPHONE AUDIO VIDEO 28 7 $17 ,1 '%1'36()6 FOR SATELLITE RECEIVER DECODER - 23 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 25: Typical Connections
I‚‡Ã†ˆƒƒyvrqà 6 & $57 6WU@SHDI6G ÃÃÃà ÃÃTph…‡ÃGrhq I‚‡Ã†ˆƒƒyvrqà à ÃÃ6r…vhyÃGrhqà I‚‡Ã†ˆƒƒyvrqà SAÃPVU 768FÃPAÃW8S ÃÃ6r…vhyÃGrhqà I‚‡Ã†ˆƒƒyvrqà 6r…vhyÃDIà 6ˆqv‚Wvqr‚à Note: For further details, please refer to operation manual of your VCR. - 24 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 26: Typical Connections (Continued)
6r…vhy ÃÃÃÃÃà I‚‡Ã†ˆƒƒyvrq Tph…‡ÃGrhq I‚‡Ã†ˆƒƒyvrq 6r…vhyÃGrhq I‚‡Ã†ˆƒƒyvrq SAÃPVU 768FÃPAÃW8S 6ˆqv‚Wvqr‚ 6r…vhyÃDIà 6r…vhyÃGrhq I‚‡Ã†ˆƒƒyvrq Note: For further details, please refer to operation manuals of your DVD Player, DECODER and VCR. - 25 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 27: Typical Connections (Continued)
I‚‡Ã†ˆƒƒyvrq 6r…vhyÃGrhq I‚‡Ã†ˆƒƒyvrq 9DBDU6GÃT@U Ã9v†uÃGrhq UPQÃ7PY I‚‡Ã†ˆƒƒyvrq SAÃPVU 6@SD6GÃDI 9DTCÃDI ÃUWÃT86SU Note: For further details, please refer to operation manuals of your DVD Player and Digital Set Top Box. - 26 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 28: Typical Connections (Continued)
6r…vhyÃGrhq Ã9v†uÃGrhq I‚‡Ã†ˆƒƒyvrq I‚‡Ã†ˆƒƒyvrq 9DBDU6GÃT@U UPQÃ7PY ÃUWÃT86SU 9DTCÃDI SAÃPVU 6@SD6GÃDI Note: For further details, please refer to operation manuals of your DVD Player, VCR and Digital Set Top Box. - 27 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 29: Typical Connections (Continued)
&RQQHFWLRQ79 SRZHU FDEOH WR D a 9 V\VWHP 768FÃPAÃUW à Hhv†ÃT‚pxr‡ÃPˆ‡yr‡ 68Ã!!—!#ÃWÃ$ÃC“ $17 6&$ 57 Note: For further details, please refer to operation manual of your Video Camera. - 28 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 30: 21-Pin Euro Connector And 21-Pin Audio/Video
5. Earth for blue 12. Not used 19. Video output 6. Audio left input 13. Earth for red 20. Video input (PAL/SECAM/NTSC) 7. Blue input 14. Not used 21. Plug shield - 29 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 31: Troubleshooting
Dsˆ‡†vqrÃhr…vhyÃv†Ãˆ†rqÃpurpxÃs‚…Ãi…‚xrÃv…r† 8urpxÃs‚…Ãy‚phyÃv‡r…sr…rpr 6qwˆ†‡Ã8PGPVSÃp‚‡…‚y U…’ÃsvrLjvtÇ‚Ãp‚……rp‡Ã &+ 0 (1 8 8urpxÃvsÇurÃ7…vtu‡r††Ã‚…Ã8‚‡…h†‡Ã†r‡‡vtÃvÇurÃvp‡ˆ…rÆr‡‡vtÀ‚qrÀvtu‡ÃirÃhyyÇurÃh’ T‚ˆqÃPF‚…Ãvp‡ˆ…r Ç‚ÇurÀvˆ†Ã†vqrà U…’ÃhÃrÃpuhryÇ‚ÃpurpxÃs‚…††viyrƇh‡v‚Ç…‚ˆiyr 8urpxÃs‚…Ãy‚phyÃv‡r…sr…rpr ÃDp…rh†rÇurÉ‚yˆ€rÃÃ8urpxÃ6ˆqv‚Ãyr‰ry† Qvp‡ˆ…rÃPF‚…Æ‚ˆq U…’ÃhÃrÃpuhryÇ‚ÃpurpxÃs‚…††viyrƇh‡v‚Ç…‚ˆiyr UW‡ÃyˆttrqÃvÃPˆ‡yr‡Ãƒ‚r…ÃPAA HhvÂr…Ãiˆ‡‡‚ÂsÃUW‡ÃPI 6r…vhy‡Ãp‚rp‡rqÇ‚Çr…€vhyÃh‡Ã‡urÃihpxÂsÇurÃUWÆr‡ Dsˆ‡†vqrÃhr…vhyÃv†Ãˆ†rqÃpurpxÃs‚…Ãi…‚xrÃv…r† Uˆ…ÃPAAȆvtÇurÃHhvÃQ‚r…Ãiˆ‡‡‚ÇurLj…ÃPIÃhthvÃhs‡r…ÃhÀvˆ‡r 0 (1 8 &+ 8urpxÃvsÇurÃ7…vtu‡r††Ã‚…Ã8‚‡…h†‡Ã†r‡‡vtÃvÇurÃvp‡ˆ…rÆr‡‡vtÀ‚qrÀvtu‡ÃirÃhyyÇurÃh’à ‡‚ÇurÀvˆ†Ã†vqrà I‚Ãvp‡ˆ…rÂ…Æ‚ˆq Dp…rh†rÇurÉ‚yˆ€rÃÃ8urpxÃ6ˆqv‚Ãyr‰ry† - 30 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 32: Specifications
220-240V AC, 50 Hz. AUDIO OUTPUT Stereo AUDIO OUTPUT POWER (W ) (%1 THD) RMS. 2 x 4 POWER CONSUMPTION (W) PICTURE TUBE 21“ (55 cm) DIMENSIONS (mm) 9DH@ITDPITÀ€ Xrvtu‡Ãxt - 31 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... -
Page 33: Important Instructions
COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. SAFETY PRECAUTION THIS EQUIPMENT MUST BE DISCONNECTED FROM THE MAINS WHEN NOT IN USE. DO NOT ALLOW THIS UNIT TO BE EXPOSED TO RAIN OR MOISTURE. - 32 - ENG-2163-1548 UK-PAL-TEK SCART-FAV-STEREO-SHARP-AK44-TV2.p65 06.01.2004, 15:37 Downloaded from: http://www.usersmanualguide.com/... - Page 34 SHARP CORPORATION SHARP ELECTRONICS (U.K.) LTD. Sharp House, Thorp Road, Newton Heath, Manchester M40 5BE 500***** 09/03 Downloaded from: http://www.usersmanualguide.com/...
