Display Window - Sony DTC-1000ES Service Manual

DTC-I(noEs
liglcouNren indicatol
Lights up to show that the counter is displaying the
tape running time.
lisl aeuntNttlo indlcatol
-
Lights up to show that the counter is displaying the
remaining time.
The remaining time is not displayed during searcn
ooeration (the SEARCH indicator lighls)' fast
fonatarding or rewinding
hluemonv
indicator
Lights up when the MEMORY button is pressed to
show that the " 0M 00S" point is stored in memory
lâ-lpcu llME (program tlme) indicator
Lights up to show that the counter is displaying the
elapsed time of the current selection
Eleuexlsts
indicator
"Light.
up when recording a digital signal input.from
thé DIGITAL lN jack contains a pre€mphasized signal
In the playback mode, it also lights up while the
detected preemphasized signal is being de-
emphasized
@ eou (program number)
disPlaY
Shows the program number of the selection being
played.
Edlns
(automatic music sensor) display
"sno*i
the number of selections to be skipped ahead
or behind in AMS operation. When a numeric butlon
is oressed, the display shows the program numoer or
the target selection while the selection is being
searched for'
lâslcopv PRoHlBlr (digital copy prohlbit) indicator
-Blinks
when the digital signal to be recorded contains
a "digital copy prohibit" code In this case, digital-Îc
digital recording cannot be done.
EClclurtot't
indlcatol
Blinks when moislure condensalion occurs lf this
happens. the deck stops automalically
lâTselncn
indicaior
Lights up while a selection is being searched lor
IâClsrnnr tD indicator
Blinks when wriling or erasing a slart lD code, or
when the start lD is detected during playback.
lzglsxtp tD indicator
Lights up momentarily when writing or erasing a skip
lD code, or when the skip lD is detected during
playback
@ Sampling lrequency indicators
f ndicates the sampling frequencies (32 kqz, 44.1 k{z,
4B kHz) with which the digital program is encoded.
44,1 kHz: For playback of prerecorded DAT tap€
(Digital-todigital recording cannot be done.)
48 kHz: For recording/playback with DAT tape
lSil peak level metêrs
Indicate the level ot the audio signal being recorded
during recording, and the peak values of the audio
signal recorded on the tape during playback.
15â counter
Displays the tape running time, elapsed time of the
selection being played, and the total remaining time
of the taoe. Each time COUNTER MODE is pressed,
the display mode changes in turn,
-4-
