Wall-/Pipe-Mount Level Indicator
L160
Overall Dimensions
Dimensions in mm (in.)
160 (6.3)
250
(9.84)
69 (2.72)
Fixing
3 Fixing Holes
Centers
6.5 (0.25) Dia.
Electrical Connections
1
L
N
Mains Supply
85 to 265V a.c.
+
–
24V DC Supply
6
214
(8.43)
200 (7.9)
Allowance for
Cable Bends
Relay 1
N/O
C
N/C
3
4
5
6
7
14
15
16
17
18
2
N/O
C
N/C
Relay 2
68 (2.68)
232
(9.13)
Relay 3
N/O
C
N/C
RS485
TX–
TX+
C
RX– RX+
8
9
10
11
12
13
19
20
21
22
23
24
Isig +3v 0vs –3vs
–
+
Sensor Connections
Logic Input
42
(1.65)
68 (2.68)
214
(8.43)
61 (2.375) O.D.
Vertical or Horizontal Post
(Kit Part No. 4600/0138)
Isig +3v 0vs –3vs
4
14
21
22
23
24
–
+
2-wire Sensor
P851/P861 Sensor
DS/L160–EN Rev. F
232
(9.13)
