Contents
Safety Precautions...............................................................................................1
01
Installation Tools...................................................................................................2
02
Installation Environment.......................................................................................3
03
Unpacking and Check..........................................................................................3
04
Attaching Cable Labels........................................................................................6
05
Installation Overview............................................................................................7
06
Installing the Floor Stand.....................................................................................9
07
Installing the Display...........................................................................................11
08
Installing the Tray................................................................................................13
09
Installing the Camera Mount Bar........................................................................14
10
Adjusting the Display..........................................................................................16
11
Installing Components........................................................................................18
12
Connecting Cables.............................................................................................22
13
Installing Cable Covers......................................................................................25
14
Powering On......................................................................................................25
15
Installing Rear Covers.......................................................................................26
16
Advertisement
Table of Contents
Related Manuals for Huawei RoomPresence 65S
Summary of Contents for Huawei RoomPresence 65S
-
Page 1: Table Of Contents
Contents Safety Precautions....................1 Installation Tools....................2 Installation Environment..................3 Unpacking and Check..................3 Attaching Cable Labels..................6 Installation Overview....................7 Installing the Floor Stand..................9 Installing the Display...................11 Installing the Tray....................13 Installing the Camera Mount Bar................14 Adjusting the Display..................16 Installing Components..................18 Connecting Cables.....................22 Installing Cable Covers..................25 Powering On......................25 Installing Rear Covers..................26... -
Page 2: Safety Precautions
Safety Precautions Read this guide carefully and follow all instructions to safely install the RoomPresence system. General When installing the RoomPresence, obey local safety laws and regulations. The safety precautions of this guide are supplementary to local safety regulations. Adhere to the safety instructions in this guide during device installation. Only trained and qualified personnel should install or maintain the device. -
Page 3: Installation Tools
Installation Tools NOTE Actual tools may differ. Tools provided with the RoomPresence: M6 hex socket wrench Tools prepared by the installer: Diagonal pliers Electric screwdriver Spirit level ESD gloves Phillips screwdriver Measuring tape... -
Page 4: Installation Environment
Component Remarks Large box, including two small Floor stand box Floor stand boxes (RoomPresence 65S)/three small boxes (RoomPresence 75S) Front decorative strip box Front decorative strips Small box Display mount bracket box... - Page 5 Unpacking and Check Checking the Included Items What's in the floor stand box: Box No. RoomPresence 65S RoomPresence 75S Columns, bottom bar, cable covers, screws, Columns, bottom bar, cable covers, screws, and and socket wrench socket wrench Camera mount bar, tray, attachment plates, display mount...
- Page 6 Unpacking and Check Unpacking Remove the outer covering. Powering On Components 1. Lift the display by both sides of its edges to avoid applying direct force on the screen. 2. After powering on the display, set the display parameters by referring to the "Configuring the HD Display" section in the Configuration Guide.
-
Page 7: Attaching Cable Labels
1.5 m Differs depending on your country [P04] Box 600 power cable 1.5 m Differs depending on your country For RoomPresence 65S only [P05] Video display power cable 1.5 m Differs depending on your country For RoomPresence 75S only [P06] Video display power cable 1.5 m... -
Page 8: Installation Overview
Installation Overview Here, the RoomPresence 75S is used as an example. G-03 Start Point * Note: * Note: * Note: Labels Labels Labels Installation steps Assemble the bottom bar. Fasten the left and right columns to the bottom bar. Install the front decorative strips. Connect the display mount bar to the left and right columns. -
Page 9: Installing The Floor Stand
Installing the Floor Stand NOTE 1. Install the floor stand components in the sequence numbered on boxes. For example, install the bottom bar and columns in box 01, then display mount bar in box 02. 2. The screws must be pre-installed and then tightened. (Torque: 28 ±10% kgf.cm) Assemble the bottom bar with screws. - Page 10 Installing the Floor Stand Raise the display mount bar and mount it onto the attachment plates on the columns back-to-front. Then tighten the screws. 10 x M6 x 16 RoomPresence 65S Install the display mount bar Install the power adapter hanger...
-
Page 11: Installing The Display
3. When mounting the display, do not use its own handles. Use the screws that come with the display to secure the display mount brackets to the back of the display through the four VESA holes. RoomPresence 65S Loosen the adjustment screws and remove them. - Page 12 Installing the Display Two people working together are required to mount the display to its mount bar. Insert the locating block between the column and the display. Then, adjust the position of the display to align it closely with the locating block. After the display is installed, connect it to the power supply.
-
Page 13: Installing The Tray
Installing the Tray Lift the tray and place it on the attachment plates on the columns back-to-front. Tighten by screw type in the sequence A > B. M6 x 16... -
Page 14: Installing The Camera Mount Bar
Installing the Camera Mount Bar Insert the two arc attachment plates into the top of the left and right columns respectively, make sure all the joints are well fit, and secure them using screws. M6 x 16... - Page 15 Installing the Camera Mount Bar 1. Prepare a ladder or chair for tightening the screws. 2. Two people working together are required to lift the camera mount bar and place it into the floor stand. 3. Keep the support rods of the camera mount bar away from the screen to avoid damage. Lift the camera mount bar and install it on the floor stand.
-
Page 16: Adjusting The Display
Adjusting the Display Adjust the horizontal and vertical screws on the display support to ensure that the display is framed in the floor stand. Attach the left and right front decorative strips using the embedded magnet, Use the clamps to align the upper and lower strips. Push it above the clamp. - Page 17 Adjusting the Display Adjust the display support levers to secure the display. Then tighten the screws. M6 x 16...
-
Page 18: Installing Components
Installing Components Installing the Box 600 Screw in the mounting ears that come with the Box 600. Install the Box 600 in the middle of the tray. (You only need to install the two screws on the diagonal.) M6 x 16 Rubber feet facing forward... - Page 19 Installing Components Installing the Camera 200 Place the Camera 200 in the middle of the top bar and align it with the locating pins. Tighten the clamps. NOTE Place the Mic 500 microphone array and Touch on the conference table, and connect their cables by following the instructions in Connecting Cables.
- Page 20 Installing Components Installing the USB Connector Insert the USB connector on the tray. Then tighten the screw. M4 x 20 Installing the Loudspeakers Place the two loudspeakers (L, R) on both sides of the tray. M4 x 3...
- Page 21 Installing Components Installing the Power Box Place the power box on the tray, align the power button with its hole, and tighten the screws. M6 x 16 Installing the PDU Place the PDU on the PDU support. Ensure that the C13 power socket faces the right side of the display.
-
Page 22: Connecting Cables
Connecting Cables Routing Cables Here, the RoomPresence 75S is used as an example. CAUTION 1. Route the cables as shown and secure them using cable clips and ties. 2. Signal cables must be bundled separately from power cables. The minimum distance between bundles is 150 mm. 3. - Page 23 Connecting Cables Routing Cables Here, the RoomPresence 75S is used as an example. To avoid interfering with rear cover installation, route cables through the inner side of the display mount bar and then insert them to the camera ports. [P09] [N03] [ V01] [ V03]...
- Page 24 Connecting Cables Connection Diagram Here, the RoomPresence 75S is as an example. Network port Camera 200 Touch AirPresence Key HD display (video) Presentation video source Presentation display or projector Mic 500 Loudspeaker Power box Presentation audio source PB100 Power cable Video cable Audio cable Wall-mounted...
-
Page 25: Installing Cable Covers
Installing Cable Covers Attach the cable covers to both of the columns and the bottom bar using the embedded magnet. Powering On After the installation is complete, turn on the switches of all components, set the power switch in the lower right of the tray to ON, and check the device status. -
Page 26: Installing Rear Covers
Installing Rear Covers Here, the RoomPresence 75S is used as an example. Attach the three upper rear cover plates to the top bar using the embedded magnet. Install the lower left and right rear cover plates and then the lower middle rear cover plate. The three plates are mounted on top using hangers and attached at the bottom using the embedded magnet.
