OWNER'S & INSTALLATION
MANUAL
AIR CONDITIONER
Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring standards by authorized personnel only.
Please retain this installation manual for future reference after reading it thoroughly.
WIRED REMOTE CONTROLLER
PREMTW101
MFL69312308
Rev.00_102119
