Hicom 102 - Technical Specifications/ Installation and Start-up Instructions
1
Technical Specifications
.
1.1 Technical Specifications
- 2 exchange lines
- 1 master telephone
- 5 extensions
- 1 entrance telephone / door opener
1.2 General Data
Structural design:
height 191 mm / width 175
Weight
Line distributor:
Environmental conditions
room temperature
no forced ventilation
1.3 Electromagnetic Compatibility (EMC)
Protection as per FTZ 12 TR 1
Protection against
recommended that the exchange lines and the connecting
cables of the entrance telephone be additionally safeguarded
by protection devices (surge arresters; a-wire and b-wire
against ground). In areas with high electric storm activity this
is always necessary.
1.4 Subscriber Lines (subscriber Nos. 1-6)
Dialing method
Dial pulsing or DTMF, depending on the dialing method of
the exchange line
- Dial pulsing (DP)
- Pulse pause:
- Pulse length:
- Impulslange:
- Pulseratio:
- Dual-tone multi-frequency signaling as per CCITT
- Range
- Functional range:
- Loop current:
- Feed voltage:
- PBX recall button
- Flashing time:
- DTMF telephones always need a flash key
- DTMF telephones with grounding button are not allowed
- DP telephones need no grounding button
1.5 Line Connections
Trunk circuit for main station interface
- Dialing method
Dial pulsing or DTMF, depending on the dialing method of the
exchange line
- Exchange feed voltage:
- No satellite PABX traffic is possible
1.6 Power Failure Transfer (ALUM)
Trunk transfer occurs upon failure of the power network
voltage
First trunk to subscriber 1 (master station) Second trunk to
subscriber 2
A30950-M78-X-3-7628
wall-mounted case
mm / depth 57 mm
approx. 1,2 kg
integrated in the system
+4°Cto+40°C
atmospheric interference
22 ms-46 ms
52 ms - 71 ms
52 ms - 71 ms
1,4:1 - 1,8:1
2 x 60 ohms loop resistance
40 ms to 150 ms
at least 48 V
1.7 Entrance Telephone (call number 7)
- Range
* Maximum line resistance
* DC free (no feed)
- Activation contact for entrance telephone
* Neutral NO contact
* Contact load capacity:
1.8 Door Opener
* Neutral NO contact
* Contact load capacity:
1.9 Power Supply
- Class of protection 2
- AC network voltage:
- Power consumption:
- Overload protection
- Fuse in primary circuit:
1,25 A slow-blow (FS1), 80 mA slow-blow (FS2)
It is
1.1 0 Audible Tones
Frequency 425 Hz
- dial tone
- busy tone
- ringing tone
- call waiting tone
- special dial tone
- buzz tone
1.11 Ringing Signals
Frequenz 50 Hz
- internal ringing
- outside call
2. Installation of the System
The system does not need to be opened either for installation or for
25 mA
placing service. The distributor is accessible separately.
24 V
The installation site must be dry and of normal temperature (room
temperature, no exposure to direct sun or radiators.
2.1 Installation Work Sequence
- Affix the template to the wall, drill wall-plug holes, insert wall
plugs
- Screw in the top screw to protrude about 3mm and hang the unit
on this
- Remove distributor lid (one screw)
- Screw in and tighten the lower two screws
- Connect the line network
Note: 3 wall plugs with screws are provided with each system.
These can be found inside the distributor lid of the
system
2.2 Distributor Assignment / Connection
For the distributor assignments and connection examples, see the
rear side.
max. 0.3 A; 24 V
max. 0,3 A; 24 V
220 V, +/- 10%, 50 Hz
15 VA
pulse sequence in ms
pulses underlined
200/300/200/300/200/800
500/500
1000/4000
60/2500
100 / 100
960/120
1000 / 4000
400/200/400/4000
