RADIUS Authentication and Accounting
Configuring a RADIUS Server To Specify Per-Port CoS and Rate-Limiting Services
Figure 6-8. Example of Displaying Inbound Rate-Limiting Imposed by a RADIUS Session
Figure 6-9. Example of Displaying Inbound CoS (802.1p) Priority Imposed by a RADIUS Session
Note
6-24
The DSCP in the Apply Rule column and the 001010 in the
a non-default CoS (802.1p) pr or ty conf gured n the switch for packets with a
Di ffserv codepoint of 001010 inbound on port B4. The in the
shows the CoS pr or ty most recently configured for application to packets with
that codepoint. The in the Radius Override column indicates that there is
currently at least one authenticated-client session on port B4, and that the most
recent RADIUS- mposed CoS prior ty for the port is 5, which overr des the
configured DSCP setting. Refer to the
Where multiple clients are currently authenticated on a given port where
inbound CoS and Rate-Limiting values have been imposed by a RADIUS
server, the port operates with the inbound CoS priority and rate-limit assigned
by RADIUS for the most recently authenticated client. Any earlier CoS or rate-
limit values on the same port for authenticated client sessions that are still
active are overwritten by the most recent RADIUS-imposed values. For exam­
The 50 i n the Limit field ind cates that the
most recent rate-limit configured in the
switch for this port is 50% of the port's
available bandwidth. The
Override fiel
active client session n which the RADIUS
server used to authenticate the most recent
client has imposed an nbound bandwidth
limi t of 80%. Refer to the Note on page 6-24.
Disabled indicates that there is no default
rate- l imit configured for the port. No-
override ndicates that there s currently no i
RADIUS-imposed rate-limit on the
associated ports.
i i i
i i
5
i i
Note , be ow.
i
80 in the Radius
d indicates that there is an
i
i
i
Priority in the Apply Rule column
indi cates a non-default CoS
(802.1p) priority configured in the
switch for port B1. The in the 3
Priority co umn shows the actua l
va ue configured. No-override l
indi cates that there is currently no
RADIUS-imposed CoS priority
affecting the port.
DSCP column ind cate i
i
2 Priority column
i
l
l
