Summary of Contents for Asus ZenScreen MB16AH
- Page 1 ZenScreen MB16AH Portable USB Monitor User Guide...
-
Page 2: Table Of Contents
Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing. -
Page 3: Notices
Notices Federal Communications Commission Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: • This device may not cause harmful interference, and • This device must accept any interference received including interference that may cause undesired operation. -
Page 4: Safety Information
Safety information • Before setting up this Portable USB Monitor, carefully read all the documentation that came with the package. • To prevent fire or shock hazard, never expose this Portable USB Monitor to rain or moisture. • Never try to open this Portable USB Monitor cabinet. • Before using this Portable USB Monitor, make sure all cables are correctly connected and the power cables are not damaged. -
Page 5: Care & Cleaning
Refer to the following sources for additional information and for product and software updates. ASUS websites The ASUS websites worldwide provide updated information on ASUS hardware and software products. Refer to http://www.asus.com Optional documentation Your product package may include optional documentation that may have been added by your dealer. -
Page 6: Takeback Services
Takeback services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for our customers to be able to responsibly recycle our products, batteries and other components as well as the packaging materials. -
Page 7: Welcome
Welcome! ® Thank you for purchasing the ASUS Portable USB Monitor! The latest ASUS Portable USB Monitor provides great portability and simplicity to your daily life, enhancing both of your viewing experience and style. Package contents Check your package for the following items:... -
Page 8: Monitor Introduction
Monitor introduction 1.3.1 Front View and Charging Instructions Menu Close Volume Input Select Blue Light Filter Power button/Power LED • Press this button to turn the monitor on/off when connected to a valid source. • The color definition of the power indicator is as the below table. Status Description Blue... - Page 9 If your device become unusual hot, disconnect the USB cable from your device and send the device including the power adapter and USB cable to an ASUS qualified service personnel ASUS Portable Monitor MB16AH...
-
Page 10: Quickfit Function
1.3.2 QuickFit Function The QuickFit function contains two patterns: (1) Grid (2) Photo size. Grid pattern: Facilitates designers and users to organize content and layout on one page and achieve a consistent look and feel. Alignment grid 1 will be rotated automatically if auto rotation is enabled. -
Page 11: Monitor Standing Positions
Monitor standing positions You can prop the monitor up in either landscape or portrait mode with the protective sleeve. ASUS Portable Monitor MB16AH... - Page 12 Connect the portable monitor with system NOTE: When connecting with system by HDMI port, please connect inbox adapter to power up the monitor. Chapter 2: Setup...
-
Page 13: Osd (On-Screen Display) Menu
Move the key towards right or press the central button to enter the slide bar, and then use the Up or Down keys (depending on the indicators in the menu) to make changes. Move the key towards left to return to the previous menu. ASUS Portable Monitor MB16AH... -
Page 14: Osd Function Introduction
3.1.2 OSD Function Introduction Splendid This function contains eight sub-functions that you can select for your preference. ASUS MB16A Splendid Scenery Mode HDMI 1080p 60Hz Standard Mode sRGB Mode Scenery Mode Theater Mode Game Mode Night View Mode Reading Mode Darkroom Mode • Standard Mode: This is the best choice for document editing with... - Page 15 (2) Slowly roll your eyes (3) Move your eyes diagonal. • High energy blue light may lead to eye strain and AMD (Age-Related Macular Degeneration). Blue light Filter to reduce 70% (max.) harmful blue light to avoiding CVS (Computer Vision Syndrome). ASUS Portable Monitor MB16AH...
- Page 16 Color Select the image color you like from this function. ASUS MB16A Color Scenery Mode HDMI 1080p 60Hz Brightness Contrast Saturation Color Temp. Skin Tone • Brightness: The adjusting range is from 0 to 100. • Contrast: The adjusting range is from 0 to 100.
- Page 17 0 to faster 100. • Aspect Control: Adjusts the aspect ratio to “Full”, “4:3”. • VividPixel: ASUS Exclusive Technology that brings lifelike visuals for crystal-clear and detail-oriented enjoyment. The adjusting range is from 0 to 100.
- Page 18 System Setup Adjusts the system configuration. ASUS MB16A System Setup Scenery Mode HDMI 1080p 60Hz Splendid Demo Mode Auto Rotation ECO Mode Volume GamePlus QuickFit OSD Setup Language ASUS MB16A System Setup Scenery Mode HDMI 1080p 60Hz Key Lock Information...
- Page 19 • Key Lock: Pushing the 5-way button to the down for more than 5 seconds to disable key locking. • Information:Displays the monitor information. • Power Key Lock: To disable / enable power key. • All Reset: Selects “Yes” to revert all settings to the factory default mode. ASUS Portable Monitor MB16AH...
- Page 20 Shortcut Selecting this option allows you to set shortcut key. ASUS MB16A Shortcut Scenery Mode HDMI 1080p 60Hz Shortcut Shortcut Shortcut • Shortcut : User can select from “Blue Light Filter” “Splendid”, “Brightness”, “Contrast”, “Auto Rotation”, “Input Select”, “Volume” and set as shortcut key.
-
Page 21: Specifications
BIS ES8.0, ErP, MEPS, CEL, KCC, E-Standby 5 or 9V , 2.0A Voltage Rating QC3.0 charging spec is supported ASUS/AD2068M20 100-240V~50/60Hz 0.5A Adapter ,2A(Normal model） OR 9V , 2A(Quick charge model） *Specifications are subject to change without notice. ASUS Portable Monitor MB16AH... -
Page 22: Troubleshooting (Faq)
Troubleshooting (FAQ) Problem Possible Solution Power LED is not ON • Press the button to check if the monitor is in the ON mode. • Check if the Type-C and HDMI port connected to source of signal. • Check if the signal source is ON. The power LED lights blue • Check if the monitor and the computer are in and there is no screen image... - Page 23 USB Type-C cable. This operation will enable built-in safe mode. After displaying ASUS logo, please release the Blue Light Filter button. After ASUS Logo disappearing, there is “safe mode” message OSD showing up. Once “safe mode” message...
-
Page 24: Supported Timing List
Supported Timing List PC Supported Primary Timing Resolution Refresh Rate Horizontal Frequency 640x480 60Hz 31.469kHz 800x600 60Hz 37.879kHz 1024x768 60Hz 48.363kHz 1280x960 60Hz 60kHz 1280x1024 60Hz 63.981kHz 1440x900 60Hz 55.935kHz 1680x1050 60Hz 65.29kHz 1920x1080 60Hz 67.5kHz VESA Modes, User Available Timing Resolution Refresh Rate Horizontal Frequency...
