Electric Bed Lift Kit
Electric-Powered Mid-Duty Workman
Model No. 07263—Serial No. 310000001 and Up
Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure
1
2
3
Note: Determine the left and right sides of the machine
from the normal operating position.
1
Preparing the Machine
No Parts Required
Procedure
1. Position the machine on a level surface. Set the
parking brake, turn the ignition off, and remove the
key.
© 2009—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Description
No parts required
Lift bracket, upper
Flange head screw (5/16 x 3/4 inch)
Lift cylinder support
Lift actuator
U-bolts
Flange nut (3/8 inch)
Carriage bolts (3/8 x 3/4 inch)
Clevis pin
Cotter pin
Solenoid
Bolt (#10 x 3/4 inch)
Nut (#10)
Accessory harness
Switch
Clevis pin, large
Cotter pin
Register at www.Toro.com.
®
Utility Vehicle
Qty.
–
Prepare the Machine
1
4
1
1
2
Install the bed lift
6
2
1
1
1
2
2
1
Install the switch
1
1
1
WARNING
If you leave the key in the ignition switch,
someone could accidently start the machine and
seriously injure you or other bystanders.
Remove the key from the ignition switch before
you do any maintenance.
2. Raise the bed. Rotate the latch rod upward and raise
the box with the other hand.
3. Raise the box to its full height; then lower it slightly
to engage the prop rod (Figure 1).
Form No. 3364-459 Rev A
Installation Instructions
Use
Original Instructions (EN)
Printed in the USA.
All Rights Reserved
Advertisement
Related Manuals for Toro 07263
Summary of Contents for Toro 07263
- Page 1 Form No. 3364-459 Rev A Electric Bed Lift Kit Electric-Powered Mid-Duty Workman ® Utility Vehicle Model No. 07263—Serial No. 310000001 and Up Installation Instructions Installation Loose Parts Use the chart below to verify that all parts have been shipped. Procedure Description Qty.
- Page 2 WARNING A raised box could fall and injure persons that are working beneath it. • Always use the prop rod to hold the box up before working under the box. • Remove any load material from the box before raising it. Figure 3 1.
-
Page 3: Installing The Switch
the axle. Tighten the two nuts securing the rear of the bracket to the rear frame (Figure 5). 5. Mount the bottom end of the lift actuator to the lift cylinder support with a clevis pin and cotter pin. Position the components as shown in Figure 6. Figure 4 1. - Page 4 3. Accessory harness 8. Cap 48v connector 180 inch-lb (13.5 to 21 N⋅m). extension, from accessory harness 12. Coat the battery terminals with Toro battery terminal 4. 48v connector, from main 9. Switch connector protector. harness 10. Plug in dash 5.
- Page 5 upper lift bracket. Secure the rod to the bracket with the large clevis pin and cotter pin. 14. Remove the screws and clip securing the prop rod to the frame rail (Figure 10). Figure 10 1. Prop rod 3. Prop rod bracket 2.
-
Page 6: Operation
Operation Important: When a ratcheting noise is heard, the box lift is completely extended or retracted. Do not continue pressing the switch. Raising the Bed WARNING Driving the vehicle with the cargo box raised may cause the vehicle to tip or roll easier. The box structure may become damaged if the box is raised for an extended period of time while operating the vehicle. - Page 7 Notes:...
