Order No VCB0704007CE Vacuum Cleaner MC-CG467-ZU21 Product color Z)Sherbet blue Destination : USA TABLE OF CONTENTS PAGE PAGE 1 Specifications ----------------------------------------------------- 2 6.3. EXPLODED VIEW (BODY UNIT)-------------------- 14 2 Location of Controls and Components ------------------- 3 6.4. PARTS LIST (BODY UNIT)---------------------------- 15 3 Troubleshooting Guide ----------------------------------------- 5 6.5.
1 Specifications Model No. MC-CG467-ZU21 Power source AC120V ~ 60Hz Current 11Amps Automatic cord rewind Dust bag Paper Dust capacity 3.0 L Extension wand Metal telescopic Floor nozzle 3-in-1 Turbo brush Dimensions (WxLxH)mm 280x425x260 Cord length 5.0m Net weight 4.5kg...
3 Troubleshooting Guide CONDITION CHECKPOINT METHOD OF INSPECTION CAUSE / REMEDY Motor fails to rotate Power supply cord Check power supply cord continu- If there is no continuity, replace the (no noise is heard at all) ity. cord reel patition unit. Fuse Check fuse continuity.
4 Disassembly and Assembly Instructions Important notice: Before replacing any components, make sure to turn OFF the vacuum cleaner. Remove the power plug from the outlet. 4.1. Dust cover assembly 4.2. Separate the upper and lower removal body units 1. Open the dust box cover assembly at an angle of approx. 1.
3. Lift the upper body U to separate it from the lower body U. 2. Figure 7 illustrates the main body with the control knob U and switch cover U removed. 4.3. Printed Circuit Board A Unit 3. Remove the P.C.B. AU from the P.C.B holder and discon- (P.C.B A Unit) removal nect the fast-on terminal on the lead wire connected to the P.C.B.
4.4. Motor removal 6. Remove all components fitted to the motor. a. Remove the motor support rubber (front). 1. Remove the dust box lid assembly. (Refer to paragraph b. Remove the motor support rubber (rear). 4.1 on P.6) c. Remove the motor support. 2.
4.5. Cord reel partition unit replace- 4.6. Rail base U replacement ment 1. Remove the screw fixing the rail base U onto the cord reel partition U. 1. Increase the gap width between the cord reel and the 2. Remove the rail base U from the cord reel partition U. lower body with a screwdriver.
4.8. How to disassemble the 4.8.3. Turbine Ass’y 1. Pull up the floor nozzle wand U and remove the turbine turbine nozzle ass’y. (Fig.18) 4.8.1. Agitator ass'y 1. Rotate the Lock on the brush cover to unlock and remove the brush cover U. 2.
6.2. PARTS LIST (ATTACHMENTS) Safety Ref.No Service Parts No. Part Name & Description Q'TY Remarks AMC94P-YZ0VP HOSE ASS'Y AMC99P-YZ00P EXTENSION WAND UNIT (Telescpic wand) AMC99R-ZF0VP TURBIN NOZZLE AMC60R-UA0VP CREVICE TOOL (Crevice Nozzle) AMC88R-UA0VP DUSTING BRUSH AMC98R-ZF00P FLOOR NOZZLE UPPER UNIT AMC18R-ZF02P NOZZLE LEVER AMC78Z-ZF0VP...
6.6. PACKING LIST Safety Ref.No Service Parts No. Part Name & Description Q'TY Remarks AMC61Z-YZ0ZU CARTON BOX AMC90Z-YP00P PARTITION BOARD U AMC69Z-YP00P CUSHION A AMC70Z-YP00P CUSHION B AMC62Z-YP00P CUSHION PLATE AMC10Z-YP00P BODY BAG AMC01Z-YP00U OPERATING INSTRUCTIONS...
